United Summit 2015: Internet of Threats

HD Moore
June 17, 2015

United Summit 2015: Internet of Threats

This presentation highlights real-world exposure stats from Project Sonar.

HD Moore

June 17, 2015
Tweet

More Decks by HD Moore

Other Decks in Research

Transcript

  1. What this talk is NOT about • Making fun of

    technology users due to product flaws • Image galleries of open industrial systems • Snapshots of baby monitor cameras • Shaming product vendors • ShellHeartPoodleBleed • Pew Pew Attack Maps
  2. Why Scan the Internet? • Improve security decision making with

    real-world data • Fix endemic security flaws before they get exploited • Prioritize vulnerability research according to impact • Improve open source security tools • Hold vendors accountable • Make the Internet safer • The kids are doing it
  3. Why You Shouldn’t Scan the Internet • Network administrators see

    scans as attacks • Scanning the internet is resource-intensive • Lots of complaints (legal & physical) • IP addresses constantly shuffle • Processing can be difficult • Skip all of this and use publicly available data!
  4. Internet Scanning with Project Sonar • Focused entirely on IPv4

    and public DNS records • 1.0.0.0 to 223.255.255.255 • Exclude reserved & private ranges • Exclude our opt-out list • Scan about 3.7 billion IPv4 addresses • Scans run sequentially, from a single server • Typically span Monday - Friday * Unless you opted out, see https://sonar.labs.rapid7.com/
  5. TCP & UDP Scanning • Use Zmap to scan all

    of IPv4, except for opt-out ranges • UDP scans are throttled to 180,000 pps on average • TCP scans only send the SYN packet • AWS nodes used to grab banners • Data is deduplicated & decoded • Uploaded to https://scans.io/
  6. Project Sonar TCP & UDP Services UDP UDP SSL TCP

    53 1900 25 22* 111 5060 143 80* 123 5351 443 445* 137 5353 993 623 17185 995 1434 47808
  7. Reverse DNS Enumeration • Reverse DNS lookup of 0.0.0.0/0 every

    two weeks • Use dozens of cloud nodes to balance the load • Accidentally melted a few Tier-1 ISPs* • 1.2 billion PTR records on average
  8. Forward DNS Enumeration • Forward DNS is driven by a

    giant list of hostnames • Pulled from TLD/gTLD zone files • Extracted form SSL certificates (SAN/CN) • Extracted from HTTP scan HTML references • Extracted from PTR records • 1.4 billion records on average
  9. Data, Tools, and Documentation • Public Datasets • https://scans.io/ •

    Open Source Tools • https://zmap.io/ • https://nmap.org/ • https://github.com/rapid7/dap/ && https://github.com/rapid7/recog/ • Documentation • https://github.com/rapid7/sonar/wiki
  10. Other Projects & Data Sources • Active scanning projects with

    public data • University of Michigan: https://scans.io/ • Shodan: https://shodan.io/ • Older scanning projects with public data • http://internetcensus2012.bitbucket.org/ (2012) • Previous scanning projects • Critical.IO (2012-2013) • PTCoreSec (2012+) • Metlstorm: “Low Hanging Kiwi Fruit” (2009+) • Nmap: Scanning the Internet (2008) • BASS (1998)
  11. What is the internet? • In terms of unique systems?

    Nobody really knows • Cisco claimed 8.7 billion in 2012, predicted 15 billion in 2015 • Carrier NAT hides a millions of connected nodes • Firewalls and traditional NAT hide the rest • Over 7 billion active mobile phones • IPv6 gateways also do IPv4 NAT
  12. What is directly exposed on the IPv4 internet? • Approximately

    1 billion IPv4 systems are directly connected • ~500 million broadband clients and gateways • ~200 million servers (web, email, database, VPN) • ~200 million mobile devices (phones, tablets) • ~100 million devices (routers, printers, cameras)
  13. What about IPv6? • Somewhere between 10-20 million IPv6 global

    unicast nodes • 97.6% of top-level domains have an IPv6 DNS record* • 6.7 million domain names with a top-level AAAA record* • RIPE has issued over 8000 network blocks • HE.net TunnelBroker alone serves 562,000 users * 2015-04-19 Hurricane Electric IPv6 Progress Report http://bgp.he.net/ipv6-progress-report.cgi
  14. Service Trends • Project Sonar scans 12 unique UDP services

    each week • Most should never be exposed to the internet • Many can lead to a direct compromise • How have exposure levels changed?
  15. UDP Service Exposure (Non-)Trends 0 2,000,000 4,000,000 6,000,000 8,000,000 10,000,000

    12,000,000 14,000,000 16,000,000 18,000,000 IPMI MDNS MSSQL NATPMP Netbios NTP-Monlist Portmap SIP WDBRPC
  16. Vulnerability Trends • Instead of service trends, how about vulnerability

    trends? • Are known vulnerabilities getting patched? • How quickly are patches being applied?
  17. UPnP SSDP Vulnerabilities (1900/udp) • Monitored two UPnP SSDP vulnerabilities

    that have public exploits • We tracked the % of vulnerable services for libupnp & miniupnp • June 2014 to November 2014 is basically flat… 0% 5% 10% 15% 20% 25% 30% 20140609 20140616 20140630 20140707 20140714 20140729 20140804 20140811 20140818 20140825 20140901 20140908 20140915 20140922 20140929 20141103 20141110 Devices Vulnerable to Exploitable SSDP Stack Overflows (% of total) libupnp/CVE-2012-5959 MiniUPnP/CVE-2013-0230
  18. UPnP SSDP Vulnerabilities (1900/udp) • In late 2014, both of

    these issues spiked dramatically • Likely the result of a new broadband ISP deployment • Vulnerability ratio is higher in 2015 than 2014! 0% 10% 20% 30% 40% 50% 60% Devices Vulnerable to Exploitable SSDP Stack Overflows (% of total) libupnp/CVE-2012-5959 MiniUPnP/CVE-2013-0230
  19. SSDP Distributed Reflective Denial of Service • SSDP should never

    be internet-facing in the first place • DrDoS capabilities in addition to exploits • 15+ million SSDP services • Massive amplification • Live stats at SS • https://ssdpscan.shadowserver.org/
  20. IPMI: The Server Backdoor (623/udp) • IPMI is used for

    OOB server management (iDRAC, iLO, SMC IPMI) • Almost the equivalent of physical access • Keyboard, video, mouse, ISO boot, I2C bus access • Typically Linux running on ARM or MIPS SoCs • Enabled by default on major server brands • Dan Farmer broke the IPMI protocol • http://fish2.org/ipmi/
  21. IPMI Exposure (623/udp) • We identified ~300,000 exposed instances in

    2013 • This dropped down to ~250,000 as of June 2014 • Leveled off at ~210,000 in January 2015 0 50,000 100,000 150,000 200,000 250,000 300,000 IPMI Exposure
  22. IPMI Capabilities • The IPMI probe response includes a list

    of capabilities • 50% support anonymous authentication! 0 20,000 40,000 60,000 80,000 100,000 120,000 140,000 160,000 180,000 200,000 IPMI-MD2 IPMI-NOAUTH IPMI-PERMSG IPMI-STRAIGHT-PASS IPMI-USRLVL
  23. Vxworks 5.x Debugger Exposure (17185/udp) • WDBRPC has dropped from

    300k to about 65k since 2010 • Provides remote memory access and OS control • Relatively flat exposure level for the last year 0 10,000 20,000 30,000 40,000 50,000 60,000 70,000 80,000
  24. NAT-PMP Exposure (5351/udp) • This service should never be on

    the internet by definition (RFC) • Increasing exposure, even after CERT/CC advisory 1,000,000 1,050,000 1,100,000 1,150,000 1,200,000 1,250,000 1,300,000 1,350,000 1,400,000 20140609 20140616 20140624 20140630 20140707 20140714 20140721 20140728 20140804 20140811 20140818 20140825 20140901 20140908 20140915 20140922 20140929 20141006 20141013 20141020 20141027 20141103 20141110 20141117 20141124 20141201 20141208 20141215 20141222 20141229 20150105 20150112 20150119 20150126 20150223 20150302 20150309 20150316 20150323 20150330 R7-2014-17 Advisory
  25. Vulnerability Trend Summary • Vulnerability trends don’t follow the expected

    decreasing pattern • Some flaws issues got worse after the advisory (NATPMP) • Most things that Sonar measures are not improving • We need vendors to take more responsibility
  26. Portmap Exposure (111/udp) • Portmap (SunRPC) is a discovery mechanism

    for other services • Not commonly used in new application development • Commonly open on Linux servers, not much of a risk 0 500,000 1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 3,500,000 20140609 20140616 20140624 20140630 20140707 20140714 20140721 20140728 20140804 20140811 20140818 20140825 20140901 20140908 20140915 20140922 20140929 20141006 20141013 20141020 20141027 20141103 20141110 20141117 20141124 20141201 20141208 20141215 20141222 20141229 20150105 20150112 20150119 20150126 20150223 20150302 20150309 20150316 20150323 20150330 Portmap Services
  27. SunRPC Program Trends • Analyzing SunRPC program IDs from portmap

    “dump” scans • These provide a list of all registered programs • Vendors often create proprietary program IDs • These can be used for precise fingerprints
  28. SunRPC Program ID: 302520656 • Zero to substantial in just

    a few months • Seems to be a Samsung TV Set-Top Box DVR • 80% of these show up on Comcast ranges... • This is their 4K TV rollout! • With no firewall?
  29. SunRPC Program ID: 302520656 0 10,000 20,000 30,000 40,000 50,000

    60,000 70,000 80,000 90,000 We start to notice the trend... Exposure peaks at 82k DVRs...
  30. VoIP Session Initiation Protocol (5060/udp) Internet-exposed SIP telephones • 15

    million exposed SIP endpoints • 44% of these are in Germany • 24% of these are in Japan • Digging deeper… Germany 44% Japan 24% Spain 6% USA 4% Other 22%
  31. SIP: Hallo from Germany • 5.5 million devices over three

    primary ISPs • All based on the FRITZ!BOX sold by AVM.de • All running variants of the same firmware • Not the best security record • At the least, DDoS potential • At the worst, shells! • 2014 RCE flaw abused for fraud • Likely more bugs...
  32. Conclusions • Internet-wide scanning highlights global security challenges • ISPs

    have far too much control over internet security • Vulnerabilities have an incredibly long half-life • Public data is driving security improvements
