AISA May 2013: Serial Offenders

HD Moore
April 21, 2013

AISA May 2013: Serial Offenders

This presentation dives into the crazy world of serial port converters, remote access devices, and terminal servers, demonstrating simple methods for accessing thousands of servers, routers, and point of sales systems using Metasploit.

HD Moore

April 21, 2013
Tweet

More Decks by HD Moore

Other Decks in Research

Transcript

  1. Devices that provides remote IP access to serial ports •

    Known as serial-to-ethernet converters or terminal servers • Used for remote management, logging, out-of-band access • Widely used for industrial, point of sale, and transportation Serial Port Servers
  2. Embedded processor • ARM, MIPS, x86 Embedded OS • NET+OS,

    Evolution, eCOS, VxWorks, or Linux Management UI • Telnet, SSH, HTTP Serial ports • RJ45, DB25, DB9, DIN Network ports • Ethernet, GSM, 3G, LTE, WiFi Serial Port Servers: Components
  3. Remote serial port access • Interact with target ports through

    telnet, SSH, and HTTP • TCP socket proxy ports provide direct pass-through • Proprietary protocols for virtual COM port drivers Serial port monitoring and automation • Some products offer basic automated interaction • Use expect-style logic, can alert, send commands • Stream to remote hosts when criteria are met Serial Port Servers: Features
  4. Sold as kits for proprietary implementations • Integrators buy devices,

    create custom code, and resell • Custom automation for industrial, medical, and telco • Development is typically in C, Python, or scripts Expanded use beyond serial ports • GPIO pins used for custom hardware integration • Wireless support for Zigbee and other RF serial • Support for MODBUS and other IA protocols Serial Port Servers: Development
  5. Transportation • Remote traffic signal monitoring and management • Remote

    tracking of vehicle location via 3G + GPS • Remote management of fleet fueling stations IT Systems • Remote access to UPS and PDU for remote reboot • Remote access to servers, routers, and switches • Out-of-band equipment access via GSM & 3G/LTE Use Cases: Even More
  6. Internet-facing devices identified using 3 data sets • http://www.shodanhq.com/ •

    http://internetcensus2012.bitbucket.org/ • Critical.IO ( private) Try to detect to servers using multiple protocols • Digi Advanced Device Discovery Protocol • SNMP “public” System Description • Telnet, FTP, and SSH banners • Web interface HTML • SSL certificates SHODAN, Internet Census 2012, Critical.IO
  7. SNMP “public” System Description • Over 114,000 Digi and Lantronix

    devices expose SNMP • Over 95,000 Digi devices connected via GPRS, EDGE, & 3G Serial Port Device Exposure: SNMP Digi Lantronix Digi Connect WAN 3G Digi Connect WAN Edge/GSM Digi ConnectPort WAN VPN Digi ConnectPort X4 Lantronix SLS Lantronix UDS1100 Lantronix XPort AR Lantronix CoBox Lantronix UDS Digi Connect ME
  8. Telnet, FTP, SSH, HTTP, and SSL detection • Less reliable

    than SNMP and smaller sample sizes • 8,000 Digi devices found with FTP exposed • 500 Lantronix systems detected via Telnet • Telnet & FTP ambiguous for some devices • HTTP and SSL also ambiguous Serial Port Device Exposure: TCP Certificate chain: s:/CN=192.168.0.60 i:/CN=192.168.0.60 HTTP/1.1 302 Found Location: https://127.0.0.1:8080/home.htm Content-Length: 0 Server: Allegro-Software-RomPager/4.01 Trying 192.168.0.60... Connected to 192.168.0.60. Escape character is '^]'. login:
  9. Digi devices support a custom discovery protocol • ADDP: Advanced

    Device Discovery Protocol • Obtain the IP settings of a remote Digi device • Metasploit scanner module implemented Serial Port Device Exposure: ADDP $ msfconsole msf > use auxiliary/scanner/scada/digi_addp_version msf auxiliary(digi_addp_version) > set RHOSTS 192.168.0.60 msf auxiliary(digi_addp_version) > run [*] Finding ADDP nodes within 192.168.0.60->192.168.0.60 (1 hosts) [*] 192.168.0.60:2362 ADDP hwname:Digi Connect WAN Edge10 hwrev:0 fwrev:Version 82001160_J1 01/04/2007 mac:00:40:9D:2E:AD:B2 ip:192.168.0.60 mask:255.255.255.0 gw:192.168.0.1 dns:0.0.0.0 dhcp:false ports:1 realport:771 realport_enc:false magic:DIGI http://qbeukes.blogspot.com/2009/11/advanced-digi-discovery-protocol_21.html
  10. 14,000+ devices respond to Digi ADDP probes • Enabled by

    default only on some equipment • Three “magic” strings: DIGI, DVKT, and DGDP • DIGI magic is used for “normal” Digi products (87%) • DVKT magic is used for third-party builds (13%) Serial Port Device Exposure: ADDP
  11. Digi ADDP allows for configuration changes • Requires the root

    password, which defaults to “dbps” • Change the running network configuration (DNS, IP, etc) • Change the DHCP and WiFi configuration • Reboot the device Serial Port Device Exposure: ADDP
  12. Third-party products using Digi development kits • Found on the

    internet and responded to ADDP Serial Port Device Exposure: ADDP TrippLite SNMP Card NS7520 Development Board BP880 TNA-IP1-1 TechNode-MMP500 ES1A Lonbox PID4000 EtherLink/3 Konwerter PD8 AnywhereUSB/2 xEPI 2 Vitylan /2.0.0 Vaisala WLAN Interface SP1490-9232 Dual PSU Ethernet PROFline STR (CC75) Netcom V3.0 RSLAN PicoGate PD8 Converter Informer-IP OpenNET Max LPD401A ME-NS9210 ECOLOG-NET LAN ADA-13110 Pinnacle(tm) / LANLink™ Profi42 EDI Ethernet Port 2010ECLip Signal Monitor SQ20XX Stulz WIB 8000 A900-LAN 9210 DOMIQ D-BL-1B Endress+Hauser NEMA X4 Sabre SNMP Module Rotronic HygroWeb 3M Detection System Model 9100 WEB Remote Control GridStream IP Radio Nightshift SeCo Grathic XBox2 Q.gate IP
  13. Third-party products are often hardcoded for ADDP • No configuration

    interface to disable the ADDP protocol • Often no way to change the “dbps” password • Metasploit includes an ADDP reboot module Serial Port Device Exposure: ADDP $ msfconsole msf > use auxiliary/scanner/scada/digi_addp_reboot msf auxiliary(digi_addp_reboot) > set RHOSTS 192.168.0.60 msf auxiliary(digi_addp_reboot) > run
  14. Remote Management • Username and password is required to manage

    the device • Typically done via the web interface or telnet • Some support HTTPS and SSH management Default Passwords • Digi equipment defaults to root:dbps for authentication • Digi-based products often have their own defaults (“faster”) • Lantronix varies based on hardware model and access  root:root, root:PASS, root:lantronix, access:systemn Serial Port Server Authentication
  15. Serial port access methods • Authenticated encrypted TCP multiplex ports

    • Authenticated, encrypted ssh or web consoles • Authenticated, clear-text telnet or web consoles • Authenticated clear-text TCP multiplex ports • Unauthenticated clear-text TCP multiplex ports • Unauthenticated TCP pass-through ports • Unauthenticated encrypted TCP multiplexed ports • Unauthenticated UDP mapped ports Serial Port Access Authentication
  16. Guess which are most common? • Authenticated encrypted TCP multiplex

    ports • Authenticated, encrypted ssh or web consoles • Authenticated, clear-text telnet or web consoles • Authenticated clear-text TCP multiplex ports • Unauthenticated clear-text TCP multiplex ports • Unauthenticated TCP pass-through ports • Unauthenticated encrypted TCP multiplexed ports • Unauthenticated UDP mapped ports Serial Port Access Authentication
  17. Port range depends on the vendor • Lantronix uses 2001-2032

    and 3001-3032 • Digi uses 2001-2099 Connect and immediately access the port • Linux root shells sitting on ports 2001/3001 [root@localhost root]# Serial Port Passthrough Services
  18. Digi uses the RealPort protocol on port 771 • The

    encrypted (SSL) version is on port 1027 • 9,043 unique IPs expose RealPort (IC2012) Digi can expose up to 64 ports this way • Client must know (or guess) the line speed Serial Port TCP Multiplexed Services
  19. Scanning for RealPort services via Metasploit Serial Port TCP Multiplexed

    Services $ msfconsole msf > use auxiliary/scanner/scada/digi_realport_version msf auxiliary(digi_realport_version) > set RHOSTS 192.168.0.60 msf auxiliary(digi_realport_version) > run [*] 192.168.0.60:771 Digi Connect WAN ( ports: 1 )
  20. Scanning for RealPort shells via Metasploit Serial Port TCP Multiplexed

    Services $ msfconsole msf > use auxiliary/scanner/scada/digi_realport_serialport_scan msf auxiliary(digi_realport_serialport_scan) > set RHOSTS 192.168.0.60 msf auxiliary(digi_realport_serialport_scan) > run [*] 192.168.0.60:771 [port 1 @ 9600bps] "[root@localhost root] # \r\n"
  21. Approximately 13,000 shells were found online • Direct-mapped via 2001/3001

    or via RealPort multiplexer • One 16-port Digi exposed 16 shells across FreeBSD & IOS • The target devices DO support authentication… Serial Target Shells
  22. Administrators will connect and authenticate • No such thing as

    “disconnecting” from a serial port • Some network devices enforce inactivity timeouts • Others stay authenticated until an explicit logoff Serial Target Authentication
  23. Getting access to the web interface is step one •

    Default, missing, or weak passwords make this easy • Used Metasploit to bruteforce purchased gear • Passwords were “dbps”, “digi”, & “faster” Lantronix exposes a full Linux environment • All of the standard tricks apply (sniffers, scripting) Digi provides remote data logging • Send all serial data to an external IP (UDP/TCP) • Trigger based on content, data, timing Exploitation & Beyond
  24. Upload static exploits to the web interface • Use the

    device as a drive-by host or target the admin • Automatically shows index.htm to the admin Digi File Manager
  25. Newer Digi systems support on-device python • Used for things

    like meter monitoring and MODBUS • Can just as easily create a persistent backdoor Digi File Manager: Python
  26. Only use encrypted management services (SSL/SSH) Set a strong password

    and non-default username Scan for and disable ADDP wherever you find it Require authentication to access serial ports • Enable RealPort authentication and encryption for Digi • Use SSH instead of telnet & direct-mapped ports Enable inactivity timeouts for serial consoles Enable remote event logging Audit uploaded scripts Remediation
  27. Audit of embedded web server & ssh services Audit of

    the RealPort protocol stack Audit of Lantronix devices Metasploit session support Metasploit payloads Next Steps
  28. Based on Digi development kits, exposes ADDP • Default password

    is “dbps” as a result • ~40 or so identified in the Internet Census 2012 data EDI Traffic Signal Monitors
  29. Often connected through Digi serial port servers • Appears to

    be a x86 board managed via serial K800 Fuel Control Systems
  30. Over 114,000 serial port servers on the internet 95,000 are

    on mobile connections, no firewall Concentrated within a few mobile ISP subnets Discoverable via SNMP, ADDP, RealPort scans Network configuration exposed through ADDP Indexed by Internet Census 2012 & SHODAN Summary: Exposure
  31. Weak, default, and missing management credentials Third-party Digi kits may

    hardcode ADDP password Most servers do not authenticate the serial port Most serial devices do not automatically logout 13,000 serial ports lead to authenticated shells Summary: Authentication
  32. Industrial automation equipment is most exposed Serial servers a gateway

    to Zigbee and MODBUS Exposes important hardware • Traffic signal equipment • Electrical monitors • Medical systems Summary: Systems
