  1. Open Crypto Audit Project •  Originally formed to manage community-funded

    TrueCrypt audit •  Independent technical research public interest organization •  Technical Advisory Board: academic, industry, and legal experts in security and privacy
  2. Open Crypto Audit Project •  Originally formed to manage community-funded

    TrueCrypt audit •  Independent technical research public interest organization •  Technical Advisory Board: academic, industry, and legal experts in security and privacy •  Mission: Research, analysis & education around technical security in open source software •  Focus: software security, cryptography engineering, public awareness
  3. Open Crypto Audit Project •  Originally formed to manage community-funded

    TrueCrypt audit •  Independent technical research public interest organization •  Technical Advisory Board: academic, industry, and legal experts in security and privacy •  Mission: Research, analysis & education around technical security in open source software •  Focus: software security, cryptography engineering, public awareness •  Current project: CII OpenSSL audit
  4. The OpenSSL Audit •  Commissioned by Linux Foundation’s Core Infrastructure

    Initiative (CII) •  Ambitious Scope o Independent review o Coordinating closely with OpenSSL core team o Delayed for v. 1.1 maturity (significant refactor) o Diverse, complex codebase o Linux, BSDs, Windows, OSX, SRV5 (AIX, HP-UX, Solaris) o Intel x86 (incl. AES-NI), ARMv7, MIPS, PowerPC, Alpha… o FIPS module
  5. OpenSSL Audit •  Goals •  Thorough public security analysis of

    the core code in the next major release of OpenSSL •  Demonstrate viability of a reusable open source test harness framework •  Foster web-scale peer-reviewed public tools & data sets for protocol & negotiation analysis
  6. OpenSSL Audit •  Phase 1 Goals •  BigNum: multiprecision ints,

    constant time, blinding •  BIO (focus on composition & file functions) •  ASN.1 & x509 (cert & key parsing, DER/PEM decoding, structs, subordinate chains) •  93M cert corpus, “Frankencert” fuzzing •  Phase 2 Goals •  TLS state machine •  EVP (PKI constructions, H/MACs, envelopes) •  Protocol flows, core engine implementation •  Memory management •  Crypto core (RSA, SHA-2, DH/ECDH, CBC, GGM…)
  7. OpenSSL Audit Caveats •  Schedule, funding, or quality: Pick 2

    •  High Priority •  Major architectures •  Modern (TLS 1.1+) protocols & primitives •  DH, ECC, signatures, ASN.1 & x509 •  Non-crypto constructions (data structures, memory management, core API/ABI hooks) •  Lower Priority •  AES implementation (finite field tables, matrix transformations, etc. TBD, possibly in Phase 3 formal academic cryptanalysis) •  DTLS •  S/MIME •  OpenSSL s_server (smtp-aware web server!)
  8. OpenSSL Audit Major Software Components • BIGNUM (code review &

    minor tooling) • BIOs (code review & minor tooling) • PEM/x509 Parsing (code review & tooling) • ASN.1 (primarily tooling) • Side channels in cryptographic primitives • TLS Stack
  9. OpenSSL Audit Key Phase I Findings o  Complexity: led to

    some potential bugs invalidated due to pre- or post- target parsing o  PEM parsing contained unexpected formats including access to ASN.1 decoding facilities HMAC and CMAC algorithms o  Tooling used to provide most coverage for ASN.1 complex parsing o  Memory leak and integer overflow identified but very unlikely invalid or low severity issues o  RSA uses blinding and constant time operations by default o  RSA_padding_check_SSLv23 does not appear to be constant time, but is deprecated o  ECDSA also constant time, although implemented at the encryption layer rather than the BIGNUM layer o  Some overreads identified in the TLS stack handshake, but unlikely to result in security issues
  10. OpenSSL Audit Key Phase I Findings o  x509 & ASN.1fuzzing

    done on ~20M certs using afl-cmin •  Corpus of 277 certificates that result in diverse paths being taken through the certificate parsing code. •  Fuzzed the PEM_read_X509 function for 228 hours covering 28,552,385 executions, and 803 paths •  Fuzzed the d2i_X509_fp function for 228 hours also, covering 28,647,659 executions and 959 paths. •  x509 fuzzing resulted in no crashes or interesting results •  DER fuzzing resulted in four instances of particularly slow execution •  Tool developed to exercise several types of ASN.1 structures
  11. OpenSSL Audit Key Phase I Findings TLS Handshake o  Some

    data structures in init_buf used wen parsing network input masked buffer overreads o  selftls did generate some crashes, but unlikely to lead to directly exploitable conditions (due to the oversized backing buffer) Crashes identified by small stub developed for fuzzing the BIO_print function when the attacker can control a format string No crashes identified by a small fuzzer developed for BIGNUM operations
  12. OpenSSL Audit Key Phase II Findings •  Potential code execution

    via a stack buffer overflow when processing SSLv3 records using certain digest functions during PSK authentication (deprecated) •  Potential code execution via heap buffer overflow during server key exchange messages •  Possible Denial of Service caused by an uncontrolled out of bound read while processing client key exchange messages •  Denial of Service caused by replay protections in DTLS •  A few cases of potentially unwiped secrets in memory, likely difficult to exploit
  13. OpenSSL Audit Future work ChaCha20 and Poly1305 implementation https://www.openssl.org/blog/blog/2016/02/15/poly1305-revised/ Documentation

    of EVP_* opaque structures (function calls to initialize and process, rather than direct access) FIPS v 2.0 module •  Implemented on over 100 platforms •  Not in the initial release of v 1.1 •  CMVP validation: $350K+ (est.) Post-Logjam
  14. Real-world Apache/Nginx TLS PROTOCOL SSL v1 SSL v2 SSL v3

    TLS 1.0 TLS 1.1 TLS 1.2 TLS 1.3 CIPHER NULL DES 3DES RC4 Twofish Blowfish AES ChaCha20 KEYEX RSA DH DHE ECDH HMAC MD5 SHA-1 SHA-256 SHA-384 SHA-512 Poly1305 MODE ECB CBC GCM AUTH ECDSA RSA
  15. Real-world Apache/Nginx TLS PROTOCOL SSL v1 SSL v2 SSL v3

    TLS 1.0 TLS 1.1 TLS 1.2 TLS 1.3 CIPHER NULL DES 3DES RC4 Twofish Blowfish AES ChaCha20 KEYEX RSA DH DHE ECDH HMAC MD5 SHA-1 SHA-256 SHA-384 SHA-512 Poly1305 MODE ECB CBC GCM AUTH ECDSA RSA Also: HSTS (strict secure transport), HPKP (pinning), CT (cert transparency), SNI (virtual hosts)
