Type Profiler: An Analysis to guess type signatures

RubyKaigi 2018 (2018-06-01)

http://rubykaigi.org/2018/presentations/mametter.html

Transcript

1. Type Profiler: An analysis to guess type signatures Yusuke Endoh (@mametter) Cookpad Inc. RubyKaigi 2018 (2018/06/01)
2. Yusuke Endoh (@mametter) • A full-time MRI committer @ Cookpad – w/ Koichi Sasada
3. Recent achievement for Ruby 2.6 • Endless range [Feature #12912] (1..) Endless!
4. Endless range • Take an array without the first element ary=["a","b","c"] ary[1..-1] #=> ["b","c"] ary.drop(1) #=> ["b","c"] ary[1..] #=> ["b","c"]
5. Endless range • Loop from 1 to infinity i=1; loop { ……; i+=1 } (1..Float::INFINITY).each {……} 1.step {|i|……} (1..).each {|i|……}
6. Endless range • each_with_index from index 1 i=1; ary.each { ……; i+=1 } ary.each.with_index(1){|x,i|……} ary.zip(1..) {|x,i|……}
7. Endless range ✓Has been already committed in trunk ✓Will be included in Ruby 2.6 • Stay tuned! ary[1..] (1..).each {……} ary.zip(1..) {|x,i|……}
8. Beginless range...? • Just have implemented yesterday [Feature #14799] (..1) Beginless!
9. Today’s theme • Ruby3's type. • Some people held some meetings to discuss Ruby3's type – Matz, soutaro, akr, ko1, mame – Main objective: clarify matz's hidden requirements (and compromises) for Ruby3's type • (Not to decide everything behind closed door) • We'll explain the (current) requirements
10. Agenda • A whirlwind tour of already-proposed "type systems" for Ruby • Type DB: A key concept of Ruby3's type system • A missing part: Type profiler
11. A whirlwind tour of already-proposed "type systems" for Ruby
12. Type-related systems for Ruby • Steep – Static type check • RDL – (Semi) static type check • contracts.ruby – Only dynamic check of arguments/return values • dry-types – Only dynamic checks of typed structs • RubyTypeInference (by JetBrains) – Type information extractor by dynamic analysis • Sorbet (by Stripe)
13. RDL: Types for Ruby • Most famous in academic world – Jeff Foster at Univ. of Maryland – Accepted in OOPSLA, PLDI, and POPL! • The gem is available – https://github.com/plum-umd/rdl • We evaluated RDL – thought writing type annotations for OptCarrot
14. Basis for RDL # load RDL library require "rdl" class NES # activate type annotations for RDL extend RDL::Annotate # type annotation before method definition type "(?Array<String>) -> self", typecheck: :call def initialize(conf = ARGV) ...
15. RDL type annotation • Accepts one optional parameter typed Array of String • Returns self – Always "self" for initialize method type "(?Array<String>) -> self", typecheck: :call def initialize(conf = ARGV) ...
16. RDL type annotation • "typecheck" controls type check timing – :call: when this method is called – :now: when this method is defined – :XXX: when "RDL.do_typecheck :XXX" is done – nil: no "static check" is done • Used to type-check code that uses the method • Still "run-time check" is done type "(?Array<String>) -> self", typecheck: :call def initialize(conf = ARGV) ...
17. Annotation for instance variables • Needs type annotations for all instance variables class NES # activate type annotations for RDL extend RDL::Annotate var_type :@cpu, "%any" type "() -> %any", typecheck: :call def reset @cpu.reset #=> receiver type %any not supported yet ...
18. Annotation for instance variables • Needs type annotations for all instance variables class NES # activate type annotations for RDL extend RDL::Annotate var_type :@cpu, "[reset: () -> %any]" type "() -> %any", typecheck: :call def reset @cpu.reset #=> receiver type [reset: () -> %any] not sup ...
19. Annotation for instance variables • Needs type annotations for all instance variables class NES # activate type annotations for RDL extend RDL::Annotate var_type :@cpu, "Optcarrot::CPU" type "() -> %any", typecheck: :call def reset @cpu.reset # error: no type information for # instance method `Optcarrot::CPU#reset'
20. Annotation for instance variables • Succeeded to type check class NES # activate type annotations for RDL extend RDL::Annotate type "Optcarrot::CPU","reset","()->%any" var_type :@cpu, "Optcarrot::CPU" type "() -> %any", typecheck: :call def reset @cpu.reset ...
21. Requires many annotations... type "() -> %bot", typecheck: :call def reset @cpu.reset @apu.reset @ppu.reset @rom.reset @pads.reset @cpu.boot @rom.load_battery end
22. Requires many annotations... type "() -> %bot", typecheck: nil def reset @cpu.reset @apu.reset @ppu.reset @rom.reset @pads.reset @cpu.boot @rom.load_battery end No static check
23. … still does not work type "() -> %bot", typecheck: nil def reset ... @rom.load_battery #=> [65533] end # Optcarrot::CPU#reset: Return type error.… # Method type: # *() -> %bot # Actual return type: # Array # Actual return value: # [65533]
24. Why? • typecheck:nil doesn't mean no check – Still dynamic check is done • %bot means "no-return" – Always raises exception, process exit, etc. – But this method returns [65533] – In short, this is my bug in the annotation type "() -> %bot", typecheck: nil def reset ... @rom.load_battery #=> [65533] end
25. Lessons: void type • In Ruby, a lot of methods return meaningless value – No intention to allow users to use the value • What type should we use in this case? – %any, or return nil explicitly? • We need a "void" type – %any for the method; it can return anything – "don't use" for users of the method def reset LIBRARY_INTERNAL_ARRAY. each { … } end
26. RDL's programmable annotation • RDL supports meta-programming symbols.each do |id| attr_reader_type, id, "String" attr_reader id end
27. RDL's programmable annotation • RDL supports pre-condition check – This can be also used to make type annotation automatically • I like this feature, but matz doesn't – He wants to avoid type annotations embedded in the code – He likes separated, non-Ruby type definition language (as Steep) pre(:belongs_to) do |name| …… type name, "() -> #{klass}" end
28. Summary: RDL • Semi-static type check – The timing is configurable • It checks the method body – Not only dynamic check of arguments/return values • The implementation is mature – Many features actually works, great! • Need type annotations • Supports meta-programming
29. Steep • Snip: You did listen to soutaro's talk • Completely static type check • Separated type definition language – .rbi – But also requires (minimal?) type annotation embedded in .rb files
30. Digest: contracts.ruby require 'contracts' class Example include Contracts::Core include Contracts::Builtin Contract Num => Num def double(x) x * 2 end end • RDL-like type annotation – Run-time type check
31. Digest: dry-types require 'dry-types' require 'dry-struct' module Types include Dry::Types.module end class User < Dry::Struct attribute :name, Types::String attribute :age, Types::Integer end • Can define structs with typed fields – Run-time type check – "type_struct" gem is similar
32. Digest: RubyTypeInference • Type information extractor by dynamic analysis – Run test suites under monitoring of TracePoint API – Hooks method call/return events, logs the passed values, and aggregate them to type information – Used by RubyMine IDE
33. Digest: RubyTypeInference https://speakerdeck.com/valich/automated-type-contracts-generation-1
34. Summary of Type Systems Objective Targets Annotations Steep Static type check Method body Separated (mainly) RDL Semi-static type check Method body Embedded in code contracts. ruby Dynamic type check Arguments and return values Embedded in code dry-types Typed structs Only Dry::Struct classes Embedded in code RubyType Inference Extract type information Arguments and return values N/A
35. Type DB: A key concept of Ruby3's Type System
36. Idea • Separated type definition file is good • But meta-programming like attr_* is difficult to support – Users will try to generate it programmatically • We may want to keep code position – To show lineno of code in type error report – Hard to manually keep the correspondence between type definition and code position in .rbi file – We may also want to keep other information
37. Type DB Type DB Steep type definition typecheck Steep RDL/Sorbet type annotation RDL typecheck better error report Ruby interpreter IDE
38. How to create Type DB Type DB Steep type definition Ruby code write manually compile stdlib Already included RubyTypeInference automatically extract by dynamic analysis Type Profiler
39. A missing part: Type Profiler
40. Type Profiler • Another way to extract type information from Ruby code – Alternative "RubyTypeInference" • Is not a type inference – Type inference of Ruby is hopeless – Conservative static type inference can extracts little information • Type profiler "guesses" type information – It may extract wrong type information – Assumes that user checks the result
41. Type Profilers • There is no "one-for-all" type profiler – Static type profiling cannot handle ActiveRecord – Dynamic type profiling cannot extract syntactic features (like void type) • We need a variety of type profilers – For ActiveRecord by reading DB schema – Extracting from RDoc/YARD
42. In this talk • We prototyped three more generic type profilers – Static analysis 1 (SA1) • Mainly for used-defined classes – Static analysis 2 (SA2) • Mainly for builtin classes – Dynamic analysis (DA) • Enhancement of "RubyTypeInference"
43. SA1: Idea • Guess a type of formal parameters based on called method names class FooBar def foo(...); ...; end def bar(...); ...; end end def func(x) #=> x:FooBar x.foo(1) x.bar(2) end
44. SA1: Prototyped algorithm • Gather method definitions in each class/modules – FooBar={foo,bar} • Gather method calls for each parameters – x={foo,bar} – Remove general methods (like #[] and #+) to reduce false positive – Arity, parameter and return types aren't used • Assign a class that all methods match class FooBar def foo(...);...;end def bar(...);...;end end def func(x) x.foo(1) x.bar(2) end
45. SA1: Evaluation • Experimented SA1 with WEBrick – As a sample code that has many user- defined classes • Manually checked the guessed result – Found some common guessing failures • Wrong result / no-match result – No quantitative evaluation yet
46. SA1: Problem 1 • A parameter is not used • Many methods are affected def do_GET(req, res) raise HTTPStatus::NotFound, "not found." end DefaultFileHandler#do_GET(req:#{}, res:HTTPResponse) FileHandler#do_GET(req:#{}, res:#{}) AbstractServlet#do_GET(req:#{}, res:#{}) ProcHandler#do_GET(request:#{}, response:#{}) ERBHandler#do_GET(req:#{}, res:HTTPResponse)
47. SA1: Problem 2 • Incomplete guessing • Cause – the method calls req.request_uri – Both HTTPResponse and HTTPRequest provides request_uri HTTPProxyServer#perform_proxy_request( req: HTTPResponse | HTTPRequest, res: WEBrick::HTTPResponse, req_class:#{new}, :nil)
48. (Argurable) solution? • Exploit the name of parameter – Create a mapping from parameter name to type after profiling • "req"  HTTPRequest – Revise guessed types using the mapping • Fixed! DefaultFileHandler#do_GET(req:HTTPRequest, res:HTTPResponse) FileHandler#do_GET(req:HTTPRequest, res:HTTPResponse) AbstractServlet#do_GET(req:HTTPRequest, res:HTTPResponse) ProcHandler#do_GET(request:#{}, response:#{}) ERBHandler#do_GET(req:HTTPRequest, res:HTTPResponse) CGIHandler#do_GET(req:HTTPRequest, res:HTTPResponse)
49. SA1: Problem 3 • Cannot guess return type • Can guess in only limited cases – Returns formal parameter – Returns a literal or "Foo.new" – Returns an expression which is already included Type DB • See actual usage of the method? – Requires inter-procedural or whole-program analysis!
50. SA1: Pros/Cons • Pros – No need to run tests – Can guess void type • Cons – Hard when parameters are not used • This is not a rare case – Heuristic may work, but cause wrong guessing
51. SA2: Idea • I believe this method expects Numeric! def add_42(x) #=> (x:Num)=>Num x + 42 end
52. SA2: Prototyped algorithm • Limited type DB of stdlib – Num#+(Num)  Num – Str#+(Str)  Str, etc. • "Unification-based type-inference" inspired algorithm – searches "α#+(Num)  β" – Matches "Num#+(Num)  Num" • Type substitution: α=Num, β=Num x + 42
53. SA2: Prototyped algorithm (2) • When multiple candidates found – matches: • Num#<<(Num)  Num • Str#<<(Num)  Str • Array[α]#<<(α)  Array[α] – Just take union types of them • (Overloaded types might be better) def push_42(x) x << 42 end #=> (x:(Num|Str|Array))=>(Num|Str|Array) x << 42
54. SA2: Evaluation • Experimented SA1 with OptCarrot – As a sample code that uses many builtin types • Manually checked the guessed result – Found some common guessing failures • Wrong result / no-match result – No quantitative evaluation yet
55. SA2: Problem 1 • Surprising result – Counterintuitive, but actually it works with @fetch:Array[Num|Str] def peek16(addr) @fetch[addr] + (@fetch[addr + 1] << 8) end # Optcarrot::CPU#peek16(Num) => (Num|Str)
56. SA2: Problem 2 • Difficult to handle type parameters – Requires constraint-based type-inference @ary = [] # Array[α] @ary[0] = 1 # unified to Array[Num] @ary[1] = "str" # cannot unify Num and Str
57. SA2: Pros/Cons • Pros – No need to run tests – Can guess void type – Can guess parameters that is not used as a receiver • Cons – Cause wrong guessing – Hard to handle type parameters (Array[α]) – Hard to scale • The bigger type DB is, more wrong results will happen
58. DA: Idea • Recording actual inputs/output of methods by using TracePoint API – The same as RubyTypeInference • Additional features – Support block types • Required enhancement of TracePoint API – Support container types: Array[Int] • By sampling elements
59. DA: Evaluation • Evaluated with OptCarrot and WEBrick • It works easily and robust
60. DA: Problem 1 • Very slow (in some cases) – Recording OptCarrot may take hours – Element-sampling for Array made it faster, but still take a few minutes • Without tracing, it runs in a few seconds – It may depend on application • Profiling WEBrick is not so slow
61. DA: Problem 2 • Cannot guess void type – Many methods returns garbage – DA cannot distinguish garbage and intended return value • SA can guess void type by heuristic – Integer#times, Array#each, etc. – if statement that has no "else" – while and until statements – Multiple assignment • (Steep scaffold now supports some of them)
62. DA: Problem 3 • Some tests confuse the result – Need to ignore error-handling tests by cooperating test framework assert_raise(TypeError) { … }
63. DA: Pros/Cons • Pros – Easy to implement, and robust – It can profile any programs • Including meta-programming like ActiveRecord • Cons – Need to run tests; it might be very slow – Hard to handle void type – TracePoint API is not enough yet – Need to cooperate with test frameworks
64. Conclusion • Reviewed already-proposed type systems for Ruby – Whose implementations are available • Type DB: Ruby3's key concept • Some prototypes and experiments of type profilers – Need more improvements / experiments!
