Bringing SIMD to the web via Dart

John McCutchan wants the web to work faster. In this talk, he describes how Google's Dart, the Dart VM, and the Single Instruction Multiple Data processor can make this possible. By utilizing SIMD (already incorporated into every tablet, smartphone, and PC), John explains that you can improve the speed of your web software.

marakana

March 14, 2013
Tweet

More Decks by marakana

Other Decks in Technology

Transcript

  1. • inotify ◦ Linux kernel system for monitoring file systems

    for changes • Port Bullet Physics to the PS3 ◦ SPUs are fun • Optimizer for PS3 and PS Vita ◦ Make games run faster • PS4 CPU/GPU Expert ◦ Hardware architecture and algorithms Biography
  2. 1. Structure a. Tool visible type system b. Class based,

    object oriented c. Lexical this d. ; required 2. Performance a. Dart is designed to run fast by being less permissive b. New VM opens up new possibilities i. SIMD
  3. Static Object Shape Shape of MyClass function MyClass() { this.a

    = 1; this.b = "hey"; } a b foo = new MyClass(); ... foo.c = 3.14159; a b c Shape of foo Object Shape Change Previous optimizations invalid.
  4. Hole Free Arrays bigData = []; bigData[0] = 0.0; bigData[1]

    = 1.0; ... bigData[50] = 50.0; 0.0 1.0 ... 49.0 50.0 bigData[20000] = 22.0; 0.0 1.0 49.0 50.0 22.0 0 1 50 20000 49 ...
  5. Distinction between growable and fixed sized arrays var growable =

    new List<double>(); // length == 0 var fixed = new List<double>(200); for (int i = 0; i < fixed.length; i++) { // Safely query length only once // Bounds check hoisted out of loop } for (int i = 0; i < growable.length; i++) { // May have to query length many times // Bounds check inside the loop }
  6. No prototype chain foo = new SomeClass(); foo.someFunction(); SomeClass.prototype ParentClass.prototype

    GrandParentClass.prototype Respond to someFunction? Respond to someFunction? Respond to someFunction?
  7. Distinction between integer and double numbers • JavaScript only has

    double ◦ Double arithmetic slower than Integer arithmetic ▪ For mobile processors difference is greater • Dart has both double and integer ◦ Gives choice to developer Double Integer Double slowdown Multiply 6 2 3x Addition 4 1 4x Load 2 2 N/A Store 2 2 N/A http://infocenter.arm.com/help/index.jsp - Cortex A9 CPU
  8. What is SIMD? Single Instruction Multiple Data (SIMD) 1.0 3.0

    5.0 7.0 2.0 4.0 6.0 8.0 3.0 7.0 11.0 15.0 Vector Processor
  9. Why does SIMD matter? • SIMD can provide substantial speedup

    to: ◦ 3D Graphics ◦ 3D Physics ◦ Image Processing ◦ Signal Processing ◦ Numerical Processing
  10. Why does SIMD matter to the web? • SIMD can

    provide substantial speedup to: ◦ WebGL ◦ Canvas ◦ Animation ◦ Games ◦ Physics
  11. Why does SIMD matter? • SIMD requires fewer instructions to

    be executed ◦ Fewer instructions means longer battery life VS
  12. Why does SIMD matter? • Mozilla is attempting to automatically

    use SIMD in IonMonkey VM ◦ Gaussian Blur sped up ▪ https://bugzilla.mozilla.org/show_bug.cgi?id=832718 ◦ Based on pattern recognition ▪ Programs must be written to patterns detectable by VM ◦ "Automatic Vectorization" ▪ Open research topic
  13. SIMD in Dart • New types ◦ Float32x4 ◦ Float32x4List

    ◦ Uint32x4 • Composable operations ◦ Arithmetic ◦ Logical ◦ Comparisons ◦ Reordering (shuffling) 4 Unsigned 32-bit Integer Numbers List of Float32x4 4 IEEE-754 32-bit Floating Point Numbers
  14. SIMD in Dart Float32x4 • + • - • /

    • * • sqrt (square root) • reciprocal • rsqrt (reciprocal square root) • min • max • clamp • abs (absolute value) x w y z Lanes
  15. Constructing var a = new Float32x4(1.0, 2.0, 3.0, 4.0); var

    b = new Float32x4.zero(); 1.0 4.0 2.0 3.0 0.0 0.0 0.0 0.0
  16. var a = new Float32x4(1.0, 2.0, 3.0, 4.0); var b

    = a.x; // 1.0 var c = a.withX(5.0); Accessing and Modifying Individual Elements 1.0 4.0 2.0 3.0 5.0 4.0 2.0 3.0
  17. var a = new Float32x4(1.0, 2.0, 3.0, 4.0); var b

    = new Float32x4(5.0, 10.0, 15.0, 20.0); var c = a + b; Arithmetic 1.0 4.0 2.0 3.0 5.0 20.0 10.0 15.0 6.0 24.0 12.0 18.0
  18. Example double average(Float32List list) { var n = list.length; var

    sum = 0.0; for (int i = 0; i < n; i++) { sum += list[i]; } return sum / n; }
  19. Example double average(Float32x4List list) { var n = list.length; var

    sum = new Float32x4.zero(); for (int i = 0; i < n; i++) { sum += list[i]; } var total = sum.x + sum.y + sum.z + sum.w; return total / (n * 4); }
  20. Example 1.0 3.0 7.0 7.0 2.0 5.0 6.0 8.0 3.0

    7.0 11.0 15.0 17.0 24.0 16.0 18.0 75.0
  21. The inner loop sum += list[i]; ;; Load list[i] 0x4ccddcc

    d1ff sar edi, 1 0x4ccddce 0f104c3807 movups xmm1,[eax+edi*0x1+0x7] 0x4ccddd3 03ff add edi,edi ;; sum += 0x4ccddde 0f59ca addps xmm2,xmm1 Load 4 floats Add 4 floats
  22. Shuffling var a = new Float32x4(1.0, 2.0, 3.0, 4.0); var

    b = a.xxyy; var c = a.wwww; var d = a.wzyx; 1.0 4.0 2.0 3.0 1.0 2.0 1.0 2.0 4.0 4.0 4.0 4.0 4.0 1.0 3.0 2.0
  23. Branching double max(double a, double b) { if (a >

    b) { return a; } else { return b; } } max(4.0, 5.0) -> 5.0
  24. Branching Float32x4 max(Float32x4 a, Float32x4 b) { if (a >

    b) { return a; } else { return b; } } 1.0 4.0 2.0 3.0 0.0 2.0 3.0 5.0
  25. Branching Float32x4 max(Float32x4 a, Float32x4 b) { Uint3x4 greaterThan =

    a.greaterThan(b); return greaterThan.select(b, a); } = 0xF 0xF 0x0 0x0 2.0 3.0 5.0 0.0 > 1.0 4.0 2.0 3.0
  26. Branching Float32x4 max(Float32x4 a, Float32x4 b) { Uint3x4 greaterThan =

    a.greaterThan(b); return greaterThan.select(a, b); } 0xF 0xF 0x0 0x0 0.0 2.0 3.0 5.0 1.0 4.0 2.0 3.0 0xF SELECT 0x0 1.0 3.0 5.0 4.0 =
  27. How does the VM optimize for SIMD? 1. Unboxing a.

    Boxed -> allocated in memory b. Unboxed -> in CPU memory (in registers) 2. Replacing method calls with inlined machine instructions a. Allows values to remain unboxed (in registers) b. Avoids method call overhead
  28. • Dart SIMD has landed* ◦ Try it out! ◦

    Use your entire CPU Dart VM stretches the performance envelop. Dart VM makes new, magical experiences possible. Wrap Up Fewer Instructions Faster Performance Longer Battery A better Web
  29. • SIMD References ◦ Wikipedia ▪ http://en.wikipedia.org/wiki/SIMD ◦ Intel's site

    ▪ http://software.intel.com/en-us/articles/using-intel-streaming-simd-extensions-and-intel-integrated-performance-primitives-to-accelerate-algorithms ▪ http://software.intel.com/en-us/articles/optimizing-the-rendering-pipeline-of-animated-models-using-the-intel-streaming-simd-extensions ◦ ARM's site ▪ http://blogs.arm.com/software-enablement/161-coding-for-neon-part-1-load-and-stores/ ◦ www.gamasutra.com ◦ www.gamedev.net Wrap Up
