Monsters, mailboxes and other non-sense. A talk about about combining sensors, switches and displays with different technologies to solve problems that don't really exist and more importantly just to have fun with IoT and make geeky stuff. This talk contains monsters, and lots of them.

Transcript

1. monsters, brievenbussen en andere onzin
4. een nieuw huis
7. 10 meter
8. het huis
 van de toekomst
10. IoT is zo ongelofelijk saai
11. 433MHz
16. mesh networking
17. afstand mesh rechtstreeks 2-weg standaard ̣ ✔ ✔ ✔ ̣̣ ✱ ✔ ✔ ✔ 433 MHz ̣̣̣ ✱ ̣̣̣̣ ✔ ✔ ✱ ̣̣̣̣ ✔ ✔ ✔
18. raspberry pi met domoticz
21. kippenverwarming
22. brrrr!
23. kippenwaterdrinkbak
24. kippenwaterdrinkbakverwarmingselement
25. kippenwaterdrinkbakverwarmingselementschakelaar
26. kippenwaterdrinkbakverwarmingselementschakelaarthermometer
28. rfxcom
29. elke 30 seconden een “ping” met de temperatuur
30. temperatuur onder nul, zet de verwarming aan
31. zet klikaanklikuit schakelaar aan
33. The “S” in IoT stands for security
35. de vurige
 heksenpot
36. Doe-het-zelf IoT
37. brains (oftewel microcontrollers)
38. Arduino Uno
 ATmega238
 16 Mhz
 2 KB RAM
 32 KB Flash
39. ESP-01
 ESP 8266
 80 Mhz
 128 KB RAM
 512 KB Flash

40. NodeMCU
 ESP 8266
 80 Mhz
 128 KB RAM
 4 MB Flash

41. NodeMCU
42. Neopixel
 24 serieel
 geschakelde
 WS2812 RGB
 LEDs
43. #include <Adafruit_NeoPixel.h> #define PIN D1 #define PIXELS 24 Adafruit_NeoPixel strip = Adafruit_NeoPixel(PIXELS, PIN, NEO_GRB + NEO_KHZ800); void setup(void) { strip.begin(); strip.setBrightness(255); strip.setPixelColor(0, strip.Color(0, 0, 255)); strip.show(); } void loop(void) { }
44. int i = 0; void setup(void) { strip.begin(); strip.setBrightness(255); } void loop(void) { i = (i + 1) % PIXELS; strip.setPixelColor(i % PIXELS, strip.Color(0, 0, 0)); strip.setPixelColor((i + 1) % PIXELS, strip.Color(0, 0, 63)); strip.setPixelColor((i + 2) % PIXELS, strip.Color(0, 0, 127)); strip.setPixelColor((i + 3) % PIXELS, strip.Color(0, 0, 195)); strip.setPixelColor((i + 4) % PIXELS, strip.Color(0, 0, 255)); strip.show(); delay(8); }
45. ?! JavaScript? En C?
 Zo'n beetje hetzelfde. Ongeveer.
 Niet helemaal. Nee.
46. IKEA SOMMAR 2017 theelichthouder
51. WiFi is vast heel moeilijk…
52. const char* ssid = "........"; const char* password = "........"; ESP8266WebServer server(80); void setup(void) { WiFi.begin(ssid, password); while (WiFi.status() != WL_CONNECTED) delay(500); server.on("/on", [](){ server.send(200, "text/plain", "on"); }); server.on("/off", [](){ server.send(200, "text/plain", "off"); }); server.begin(); } void loop(void) { server.handleClient(); }
53. http:/ /sparkle.local/api?command=power&status
 command=power&on
 command=power&off command=brightness&status
 command=brightness&set=50 command=color&status
 command=color&set=f34d0d
54. homebridge homebridge-better-http-rgb
55. siri
56. pixel monsters
57. Prolight 12W plafondlamp
59. Neopixel
 64 serieel
 geschakelde
 WS2812 RGB
 LEDs
61. SD card Opslag van monsters Buzzer Piepjes voor een notificatie Lichtgevoelige weerstand Nachtstand
66. progressive
 web app
67. http:/ /pixel.local
68. http:/ /pixel.local
70. editor.addEventListener('touchstart', handleTouch); editor.addEventListener('touchmove', handleTouch); function handleTouch(e) { for (var i = 0; i < e.changedTouches.length; i++) { let elem = document.elementFromPoint( e.changedTouches[i].pageX, e.changedTouches[i].pageY ); if (elem.tagName && elem.tagName == 'TD' &&
 editor.contains(elem))
 { drawPixel(elem); } } e.preventDefault(); }
71. editor.addEventListener('touchstart', handleTouch); editor.addEventListener('touchmove', handleTouch); function handleTouch(e) { for (var i = 0; i < e.changedTouches.length; i++) { let elem = document.elementFromPoint( e.changedTouches[i].pageX, e.changedTouches[i].pageY ); if (elem.tagName && elem.tagName == 'TD' &&
 editor.contains(elem))
 { drawPixel(elem); } } e.preventDefault(); }
72. let socket = new WebSocket( "ws://" + window.location.host + "/ws" ); function drawPixel(elem) { if (elem.dataset.color != currentColor) { elem.dataset.color = currentColor; elem.style.backgroundColor = '#' + currentColor; socket.send(JSON.stringify({ command: "draw", x: elem.dataset.x, y: elem.dataset.y, color: currentColor })); } }
73. let socket = new WebSocket( "ws://" + window.location.host + "/ws" ); function drawPixel(elem) { if (elem.dataset.color != currentColor) { elem.dataset.color = currentColor; elem.style.backgroundColor = '#' + currentColor; socket.send(JSON.stringify({ command: "draw", x: elem.dataset.x, y: elem.dataset.y, color: currentColor })); } }
74. {
 "command": "draw",
 "x": 5,
 "y": 5,
 "color": "ffffff"
 }
75. {
 "command": "draw",
 "x": 5,
 "y": 5,
 "color": "ffffff"
 }
78. socket.onmessage = function(msg) { let data = JSON.parse(msg.data); if (data.command == "draw") { let elem = document.querySelector( 'td[data-x=' + data.x + ']' +
 '[data-y=' + data.y + ']' ); elem.dataset.color = data.color; elem.style.backgroundColor = '#' + data.color }; } }
79. socket.onmessage = function(msg) { let data = JSON.parse(msg.data); if (data.command == "draw") { let elem = document.querySelector( 'td[data-x=' + data.x + ']' +
 '[data-y=' + data.y + ']' ); elem.dataset.color = data.color; elem.style.backgroundColor = '#' + data.color }; } }
80. demo
81. het mysterie
 van de
 spookbrievenbus
82. brieven bus
83. magneetcontact
84. bij openen van de deksel een signaal
85. http:/ /pixel.local/api?command=notify&icon=mailbox
89. oplossing #1 magneetcontact
 combineren met een
 bewegingsdetector?
90. oplossing #2 magneetcontact
 uitzetten bij
 harde westenwind?
91. oplossing #3
92. de wispelturige
 wasmachine
95. Standby verbruik
 4,6 watt Wasmachine uit
 0,3 watt Begin programma
 24,9 watt
97. De was is klaar!
98. De was is klaar! De was is klaar! De was is klaar! De was is klaar!
100. 2000 watt
101. 20 - 200 watt
102. 2 - 5 watt
103. De was is klaar! De was is klaar! De was is klaar! De was is klaar!
105. commandArray = {} if (uservariables['WasmachineBezig'] == 2) then s = uservariables_lastupdate['WasmachineBezig'] lastUpdate = os.time{ year=string.sub(s, 1, 4), month=string.sub(s, 6, 7), day=string.sub(s, 9, 10), hour=string.sub(s, 12, 13), min=string.sub(s, 15, 16), sec=string.sub(s, 18, 19) } difference = os.difftime (os.time(), lastUpdate) if (difference > 300) then commandArray['Variable:WasmachineBezig'] = '0' commandArray['OpenURL'] = 'pixel.local/api?command=notify&icon=shirt' end end return commandArray
106. De was is klaar!
109. vragen?
