Having Our Cake and Eating It at CukeUp 2017

Having Our Cake and Eating It at CukeUp 2017

Presented at CukeUp 2017

Video: https://www.youtube.com/watch?v=Fk4rCn4YLLU

Nat Pryce

June 23, 2017
Tweet

More Decks by Nat Pryce

Other Decks in Programming

Transcript

  1. We needed a new approach Developers responsible for all test

    automation QA responsible for manual, exploratory & qualitative testing Automated functional tests written in terms of the domain model, not the user interface
  2. The Hexagonal architecture AKA Ports & Adaptors HTTP service f

    Adaptor layer maps from technical domain to application domain, but does no business logic.
  3. Service cluster Service cluster Front-end cluster Front-end cluster Service cluster

    ...and wider Test driver (g∘f) -1 Test Front-end cluster Web browser f g
  4. Scenario Turn the Screenplay metaphor up to eleven! Actor Role

    Tasks Domain Model Behind the scenes Visible in test code System under test Production System Interface Plays Acts upon Acts upon Creates Involves Performs Defined in terms of Defines
  5. Example @Test fun `An editor can request an amendment`() {

    val scenario = theProduction.newScenario() val alice = scenario.newAuthor() val ed = scenario.newEditorialStaffMember() val submissionDetails = exampleSubmission.withSingleAuthor(alice) val initialSubmission = alice.hasSubmitted(submissionDetails) val amendment = ed.canRequestAmendmentOf(initialSubmission) alice.canReview(amendment, expectedContents = submissionDetails.withStatus(IN_PROGRESS)) alice.canUpdate(amendment, SetTitle("a new title"), SubmitToPeerReview) ed.canSeeInThePeerReviewSystem(amendment, status = RECEIVED) }
  6. Benefits Same test code can run quickly against the domain

    model, or more slowly against different deployments of the system Tests are quick to write • Concise • Type safe • IDE support: navigation, auto-complete, refactoring, etc. Tests are easy to read • Concise • No user-interface and technical details No duplication in test code or between test & production code
  7. 2. Combinatorial explosion of mappings Add Author Remove Author Set

    Affiliation Set Title & Abstract Submit to Review Domain Model Service API Browser (with JS) Browser (no JS)
  8. 2. Apply the Lingua Franca Pattern! Add Author Remove Author

    Set Affiliation Set Title & Abstract Submit to Review Domain Model Service API Browser (with JS) Browser (no JS) User Actions
  9. 3. Multiple possible mappings Can map from action to user

    action in multiple ways • Different ways to navigate through the user interface • Different ways to upload files • Keyboard vs mouse input • JavaScript vs no JavaScript Approaches: • Choose randomly on each run ◦ A form of property test • Ensure equivalence with unit tests and exercise only one in the functional tests
  10. To test the system we need to... know what the

    system is doing know when it has stopped doing it know when the system has failed explain what has gone wrong restore the system to a good state
  11. To test the system we need to... support know what

    the system is doing know when it has stopped doing it know when the system has failed explain what has gone wrong restore the system to a good state
