Andrew Knight - Behavior-Driven Python

Behavior-Driven Development (BDD) is gaining popularity as an improved way to collaborate over product features and tests. In Python, **behave** is one of the leading BDD test frameworks. Using **behave**, teams write Gherkin behavior scenarios (e.g., tests) in plain language, and then programmers write Python code to automate the steps. BDD testing is great because tests are self-documenting and steps abide by the DRY principle. An example test could be:

> Given the DuckDuckGo home page is displayed
> When the user searches the phrase "Python"
> Then search results for "Python" are shown

This talk will teach how to use **behave** to develop well-designed test scenarios and a robust automation framework. It will focus on the layers of the behave framework: feature files, step definitions, support classes, and config files. A full example project will be hosted on GitHub for audience members to reference after the talk.

https://us.pycon.org/2018/schedule/presentation/87/

Transcript

1. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Behavior-Driven Python Andrew Knight Friday, May 11th @ PyCon 2018
2. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Who is Andy Knight? • Software engineer • Expert in testing, automation, and BDD • Lives in Raleigh, NC • Works at PrecisionLender • Co-founded Reformed Menswear • RIT Class of 2010 • Avid Pythoneer! Twitter: @AutomationPanda Blog: AutomationPanda.com GitHub: AndyLPK247
3. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Agenda 1. Behavior-Driven Development 2. The behave Framework 3. Gherkin Features 4. Python Mechanics 5. Running Tests 6. Final Remarks
4. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Behavior-Driven Development
5. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com What is a “Behavior”? In software, a behavior is how a feature operates. A behavior is defined as a scenario of inputs, actions, and outcomes. A product or feature exhibits countless behaviors. • Submitting forms on a website • Searching for desired results • Saving a document • Making REST API calls • Running CLI commands be·hav·ior the way in which one acts or conducts oneself
6. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Separating Behaviors Separating individual behaviors makes it easy to define a system without unnecessary repetition. Search from the DuckDuckGo home page text field Search using a DuckDuckGo URL with query params Select the first link on the search results page
7. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Behavior-Driven Development BDD is a quality-centric software development process that puts product behaviors first. It complements existing process like Agile. Behaviors are identified early in development using specification by example: plain-language descriptions that tell what more than how. Behavior specs become requirements, acceptance criteria, and acceptance tests all in one. Test frameworks can directly automate specs as well: every step in a behavior scenario can be “glued” to code to run it. ⚠ Python has many BDD test frameworks. This talk will focus on behave.
8. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Gherkin Behavior Spec Example Scenario: Basic DuckDuckGo Search Given the DuckDuckGo home page is displayed When the user searches for "panda" Then results are shown for "panda" ✓ Concise ✓ Focused ✓ Sensible ✓ Meaningful ✓ Declarative
9. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Benefits of BDD The main benefits of BDD are better collaboration and automation. • Everyone can contribute to development, not just programmers. • Expected behavior is well defined and understood from the beginning. • Tests can be automated together with the features they cover. • Steps can be reused by behavior specs, creating a snowball effect. Expedite Automation!
10. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com The behave Framework
11. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com How behave Works The behave framework essentially automates behavior specs using Python for the purpose of testing. There are two main layers: 1. Behavior specs written in Gherkin “.feature” files for test focus. 2. Step definitions and hooks written in Python for automation focus. Gherkin scenarios use plain language steps: 1. Given some initial state 2. When an action is taken 3. Then verify the outcome Each step is “glued” by decorator to a Python function when behave runs tests.
12. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Installing behave Only one package is needed: pip install behave Other packages may also be useful, such as: pip install requests # for REST API calls pip install selenium # for Web browser interactions ✓ Try using pipenv! It combines pip, Pipfile, and virtualenv.
13. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Gherkin Features
14. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Example Feature Feature: Cucumber Basket As a gardener, I want to carry many cucumbers in a basket, So that I don’t drop them all. Scenario: Add and remove cucumbers Given the basket is empty When "4" cucumbers are added to the basket And "6" more cucumbers are added to the basket But "3" cucumbers are removed from the basket Then the basket contains "7" cucumbers
15. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com A Scenario with a Step Table Feature: DuckDuckGo Instant Answer API As an application developer, I want to get instant answers to search terms via a REST API, So that my app can get answers anywhere. Scenario: Basic DuckDuckGo API Query When the DuckDuckGo API is queried with | phrase | format | | panda | json | Then the response status code is "200" And the response contains results for "panda"
16. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com A Scenario with Long Text Feature: DuckDuckGo Web Browsing Scenario: Lengthy DuckDuckGo Search Given the DuckDuckGo home page is displayed When the user searches for the phrase """ When in the Course of human events, it becomes necessary for one people to dissolve the political bands which have connected them with another """ Then one of the results contains "Declaration of Independence"
17. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com A Scenario Outline Feature: DuckDuckGo Web Browsing Scenario Outline: Basic DuckDuckGo Search Given the DuckDuckGo home page is displayed When the user searches for "<phrase>" Then results are shown for "<phrase>" Examples: Animals | phrase | | panda | | python | | platypus |
18. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Tags and Comments @web @duckduckgo Feature: DuckDuckGo Web Browsing # These scenarios should be able to run in any browser @search @panda Scenario: Basic DuckDuckGo Search Given the DuckDuckGo home page is displayed When the user searches for "panda" Then results are shown for "panda"
19. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Python Mechanics
20. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Step Definitions Step definitions are Python functions that provide implementations for Gherkin steps. Each function is annotated by the step type and a matching string. It also received a shared context and any step parameters. Three step matchers are available: (1) parse, (2) cfparse, and (3) re. The default and simplest is parse (shown to the right). from behave import * from cucumbers.basket import CucumberBasket @given('the basket has "{initial:d}" cucumbers') def step_impl(context, initial): context.basket = CucumberBasket(initial_count=initial) @when('"{some:d}" cucumbers are added to the basket') def step_impl(context, some): context.basket.add(some) @then('the basket contains "{total:d}" cucumbers') def step_impl(context, total): assert context.basket.count == total ✓ Pro tip: Surround parameters with “ ”!
21. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Gluing Steps to Definitions Feature: Cucumber Basket Scenario: Add and remove cucumbers Given the basket has "4" cucumbers When "3" cucumbers are added to the basket Then the basket contains "7" cucumbers from behave import * from cucumbers.basket import CucumberBasket @given('the basket has "{initial:d}" cucumbers') def step_impl(context, initial): context.basket = CucumberBasket(initial_count=initial) @when('"{some:d}" cucumbers are added to the basket') def step_impl(context, some): context.basket.add(some) @then('the basket contains "{total:d}" cucumbers') def step_impl(context, total): assert context.basket.count == total
22. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Scenario Context Notice the context variable passed into each step def. It holds data specific to the currently-running scenario. This is the proper way to pass data between steps! Standard fields include feature, scenario, and tags. The text and table fields get step data. Custom fields may be added, too. from behave import * from cucumbers.basket import CucumberBasket @given('the basket has "{initial:d}" cucumbers') def step_impl(context, initial): context.basket = CucumberBasket(initial_count=initial) @when('"{some:d}" cucumbers are added to the basket') def step_impl(context, some): context.basket.add(some) @then('the basket contains "{total:d}" cucumbers') def step_impl(context, total): assert context.basket.count == total Ⓧ Warning: Do not use globals to share data!
23. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Hooks Steps focus on behavior, but automation often has extra needs. For example, Web tests must set up and tear down a WebDriver instance. Hooks in the environment.py file can add instructions before and after steps, scenarios, features, tags, and the whole test run. This is similar to Aspect-Oriented Programming. from selenium import webdriver def before_scenario(context, scenario): if 'web' in context.tags: context.browser = webdriver.Firefox() context.browser.implicitly_wait(10) def after_scenario(context, scenario): if 'web' in context.tags: context.browser.quit() ✓ Use tags to selectively apply hooks! Ⓧ Don’t put cleanup in steps!
24. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Fixtures While hooks can insert any sort of logic, fixtures specifically handle setup and cleanup with more advanced options. For example, any scenario tagged with the fixture to the right will have a Firefox WebDriver instance automatically created before the scenario and cleaned up after the scenario. Check behave’s doc for examples of composite fixtures and registries. from behave import fixture from selenium import webdriver # The tag to use for the following fixture is: # @fixture.browser.firefox @fixture def browser_firefox(context): # -- SETUP-FIXTURE PART: context.browser = webdriver.Firefox() context.browser.implicitly_wait(10) yield context.browser # -- CLEANUP-FIXTURE PART: context.browser.quit()
25. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Directory Layout behave is picky about the directory layout. By default, all feature files and the environment module must be under a directory named “features/”, and all step definition modules must be under “features/steps/”. Feature file paths may be overridden by the paths config option. It’s popular to put everything under “tests/”. ✓ Feature files can use step definitions from any module under “steps”. Files don’t need to have the same name.
26. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Support Classes Any Python packages or custom modules can be used with behave. Use them to build a better framework! Major packages include logging, requests, and selenium. Be sure to employ good design patterns as well. For example, use the Page Object Model or the Screenplay Pattern instead of raw WebDriver calls for Web tests. Step def code should be concise!
27. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Running Tests
28. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Running Tests Use the behave command from the project root directory to run features as tests: # run all tests behave # run the scenarios in a feature file behave features/web.feature # filter tests by tag behave --tags-help behave --tags @duckduckgo behave --tags ~@unit behave --tags @basket --tags @add,@remove ⚠ Use “pipenv run behave” if using pipenv.
29. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Config Files Options may be provided in config files, too. Config files may be named “.behaverc”, “behave.ini”, “setup.cfg”, or “tox.ini”. They follow Windows INI format and use the “[behave]” label. The best place to put the file is under the project root. Run “behave --help” to see all available options. Popular ones include: • Custom feature file paths • JUnit reporting • Logging options ⚠ Command line options override config file options.
30. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Testing Considerations 1. Using virtual environments for package isolation is a Python best practice, especially for test automation. Using a tool like pipenv is even better. Packages used only for testing (like behave) can be dev dependencies. 2. The behave framework does not support parallel execution out of the box. Offshoot projects make it happen, but it is still an open issue for the main project. Alternatively, scripts could be written to partition tests across separate processes and then aggregate results into one report. 3. Build server integration is easy: just recreate the virtual environment and run the commands. JUnit reports are widely compatible (for example, Jenkins).
31. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Final Remarks
32. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Other Python BDD Frameworks pytest-bdd • Gherkin-style BDD plugin for pytest • Benefits from all pytest features and plugins • Joint execution and filtering with non-Gherkin tests • More flexible fixtures and directory layout radish • BDD framework compatible with Cucumber Gherkin • Adds Scenario Loops and Preconditions to Gherkin • Rich command line options lettuce • Another Gherkin-style BDD framework • Small differences in framework mechanics • Little recent GitHub activity
33. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Links and Resources behave • GitHub project: https://github.com/behave/behave • Official docs: http://behave.readthedocs.io/en/latest/index.html • Andy’s examples: https://github.com/AndyLPK247/behavior-driven-python Automation Panda • Twitter: @AutomationPanda • More on BDD: https://automationpanda.com/bdd/ • More on Testing: https://automationpanda.com/testing/ • More on Python: https://automationpanda.com/python/
34. PyCon 2018 | Behavior-Driven Python | Andrew Knight | AutomationPanda.com Thank you!
