2015 OSCON - Java-based microservices, containers, Kubernetes - How To

This is the deck for the 2015 OSCON session:
http://www.oscon.com/open-source-2015/public/schedule/detail/41359

Docker Image:
https://registry.hub.docker.com/u/saturnism/spring-boot/

GitHub Source:
https://github.com/saturnism/spring-boot-docker

Transcript

1. Kubernetes with Java-based Microservices How To w/ @saturnism
2. @saturnism @kubernetesio #oscon Ray Tsang Developer Advocate @saturnism | +RayTsang
3. @saturnism @kubernetesio #oscon Ray Tsang Developer Architect Traveler Photographer flickr.com/saturnism
4. @saturnism @kubernetesio #oscon Microservices? You probably heard a lot already! No theories here - just a how to
5. @saturnism @kubernetesio #oscon
6. @saturnism @kubernetesio #oscon Hello World Service - Greet Guestbook Service - Create Guestbook Service - Retrieve
7. @saturnism @kubernetesio #oscon Guestbook UI Hello World Service Redis session replication greeting MySQL Guestbook Service CRUD
8. @saturnism @kubernetesio #oscon Package & Deployment application.ear app.war helloworld-service.jar guestbook-service.jar apache-xyz.jar application.war /... helloworld-service.jar guestbook-service.jar apache-xyz.jar
9. @saturnism @kubernetesio #oscon Microservices Way?
10. @saturnism @kubernetesio #oscon Package & Deployment helloworld-service.jar guestbook-service.jar app.jar
11. @saturnism @kubernetesio #oscon Deployment? Just run it! java -jar helloworld-service.jar java -jar guestbook-service.jar java -jar app.jar
12. @saturnism @kubernetesio #oscon Let’s see some code
13. @saturnism @kubernetesio #oscon So many services Deploy, Manage, Ports, Discovery, Isolation… How?
14. @saturnism @kubernetesio #oscon Containers & Orchestration To the Rescue!
15. @saturnism @kubernetesio #oscon Local Docker Repository Container Image Repository myservice:1.0 1. Build an image myservice:1.0 2. Push image to repository Cluster Node 1..n 3. Deploy the service myservice:1.0 5. Pull image from repository Container Orchestrator 4. Which Node? 6. Run!
16. @saturnism @kubernetesio #oscon Containerize Option #1 Dockerfile
17. @saturnism @kubernetesio #oscon Containerize Option #2 spotify/docker-maven-plugin mvn docker:build
18. @saturnism @kubernetesio #oscon Containerize Option #3 Docker Hub / GitHub saturnism/spring-boot
19. @saturnism @kubernetesio #oscon Let’s run the container! docker run -ti -p 8080:8080 helloworld-service
20. @saturnism @kubernetesio #oscon MySQL docker run -d --name mysql -p 3306:3306 -e MYSQL_ROOT_PASSWORD=yourpassword -e MYSQL_DATABASE=app mysql
21. @saturnism @kubernetesio #oscon Redis docker run -d --name redis redis
22. @saturnism @kubernetesio #oscon Guestbook Service docker run -ti --name guestbookservice --link mysql:mysql saturnism/guestbook-service
23. @saturnism @kubernetesio #oscon Hello World Service docker run -ti --name helloworldservice \ saturnism/spring-boot-helloworld-service:1.0
24. @saturnism @kubernetesio #oscon Guestbook UI docker run -ti --rm --link redis:redis \ --link helloworldservice:helloworldservice \ --link guestbookservice:guestbookservice \ -p 8080:8080 saturnism/spring-boot-helloworld-ui
25. @saturnism @kubernetesio #oscon Docker Compose docker-compose up
26. @saturnism @kubernetesio #oscon Everything at Google runs in containers
27. @saturnism @kubernetesio #oscon Everything at Google runs in containers Launch over 2 billion containers per week.
28. @saturnism @kubernetesio #oscon Enter Kubernetes Greek for “Helmsman”; also the root of the word “Governor” • Container orchestrator • Runs containers • Supports multiple cloud and bare- metal environments • Inspired and informed by Google’s experiences and internal systems • Open source, written in Go Manage applications, not machines
29. @saturnism @kubernetesio #oscon Try out Google Container Engine https://cloud.google.com/container-engine/
30. @saturnism @kubernetesio #oscon libs app kernel libs app libs app libs app Kubernetes Cluster libs app kernel libs app libs app libs app libs app kernel libs app libs app libs app Kubernetes Master
31. @saturnism @kubernetesio #oscon Distributed process scheduler cluster of machines as one!
32. @saturnism @kubernetesio #oscon Version 1.0 Hosted on GitHub 410+ contributors 14,800+ commits 9,200+ GitHub stars CoreOS HP IBM Mesosphere Microsoft Project Partners Open Source Community Pivotal Red Hat SaltStack VMWare
33. @saturnism @kubernetesio #oscon Group of containers Live and die together Shared network interface Shared volumes Unique Routable IP Pod App Log Collector Pods ...
34. @saturnism @kubernetesio #oscon Label anything Name-value pair Make your own Pod App Log Collector Labels ... type = Frontend version = 1.0
35. @saturnism @kubernetesio #oscon Replication Controller Replicas → 2 Pod frontend Pod App Log Collector ... type = Frontend version = 1.0 Pod App Log Collector ... type = Frontend version = 1.0 Replication Controllers
36. @saturnism @kubernetesio #oscon Replication Controller Replicas → 1 Pod App Log Collector ... type = Frontend version = 1.0 Replication Controllers
37. @saturnism @kubernetesio #oscon Replication Controllers node 1 f0118 node 3 node 4 node 2 d9376 b0111 a1209 Replication Controller - Desired = 4 - Current = 4
38. @saturnism @kubernetesio #oscon Replication Controllers node 1 f0118 node 3 node 4 node 2 Replication Controller - Desired = 4 - Current = 4 d9376 b0111 a1209
39. @saturnism @kubernetesio #oscon Replication Controllers node 1 f0118 node 3 node 4 Replication Controller - Desired = 4 - Current = 3 b0111 a1209
40. @saturnism @kubernetesio #oscon Replication Controllers node 1 f0118 node 3 node 4 Replication Controller - Desired = 4 - Current = 4 b0111 a1209 c9bad
41. @saturnism @kubernetesio #oscon Replication Controller Replicas → 2 Pod frontend Pod type = Frontend version = 1.0 Pod type = Frontend version = 1.0 Services Service Label selectors: version = 1.0 type = Frontend
42. @saturnism @kubernetesio #oscon Pod frontend Pod type = Frontend version = 1.0 Pod type = Frontend version = 1.0 Services Service Label selectors: type = Frontend Pod type = Frontend version = 2.0
43. @saturnism @kubernetesio #oscon Service discovery Read service IP addresses via environmental variables
44. @saturnism @kubernetesio #oscon Service discovery Kubernetes API or… DNS Lookups! ping redis
45. @saturnism @kubernetesio #oscon Let’s Deploy
46. @saturnism @kubernetesio #oscon Local Docker Repository Container Image Repository myservice:1.0 1. docker build myservice:1.0 2. docker push Cluster Node 1..n 3. kubectl create myservice:1.0 5. docker push Container Orchestrator 4. Which Node? 6. docker run
47. @saturnism @kubernetesio #oscon Docker Repository DockerHub or … Private Repository (gcr.io)
48. @saturnism @kubernetesio #oscon Tag image docker tag spring-boot-demo gcr.io/wise-coyote-827/spring- boot-demo
49. @saturnism @kubernetesio #oscon Push image gcloud docker push gcr.io/wise-coyote-827/spring-boot-demo
50. @saturnism @kubernetesio #oscon Deploy Redis Pod kubectl create -f redis-master-pod.json
51. @saturnism @kubernetesio #oscon Deploy Redis Service kubectl create -f redis-master-service.json
52. @saturnism @kubernetesio #oscon Deploy a fleet of microservice kubectl create -f spring-boot-demo-controller.json
53. @saturnism @kubernetesio #oscon DevOps with Kubernetes
54. @saturnism @kubernetesio #oscon Versioning container image docker tag spring-boot-demo spring-boot-demo:1.0
55. @saturnism @kubernetesio #oscon Staging vs. production Use labels - deploy in the same infrastructure
56. @saturnism @kubernetesio #oscon Canary Use service, and replication controllers to canary new versions
57. @saturnism @kubernetesio #oscon Rollback Super simple with versioned containers
58. @saturnism @kubernetesio #oscon Rolling upgrade Similar to canary, but slowly let the new version take over
59. @saturnism @kubernetesio #oscon Vagrant export KUBERNETES_PROVIDER=vagrant curl -sS https://get.k8s.io | bash Google Container Engine - Beta http://cloud.google.com/container-engine http://kubernetes.io/gettingstarted/
60. @saturnism @kubernetesio #oscon Tips and Tricks
61. @saturnism @kubernetesio #oscon Test locally! Set environmental variables
62. @saturnism @kubernetesio #oscon Use Docker Machine In the cloud - faster network to download images
63. @saturnism @kubernetesio #oscon SecureRandom - slow =( For development and testing -Djava.security.egd=file:/dev/urandom
64. @saturnism @kubernetesio #oscon Don’t Log to Container Filesystem! Log to a volume… docker -v /tmp/log:/log Or Send it elsewhere!
65. @saturnism @kubernetesio #oscon Clean up disk spaces Every image, layer, and, even containers litters docker rm $(docker ps -a -q) docker rmi $(docker images -q --filter dangling=true)
66. @saturnism @kubernetesio #oscon Combine RUN commands apt-get update && apt-get install xyz && apt-get clean Saves you space.
67. @saturnism @kubernetesio #oscon Session affinity Scalable systems don’t need it... But if absolutely needed, base on ClientIP
68. @saturnism @kubernetesio #oscon Use Spring Profile One container - run on Docker Machine, Kubernetes, and App Engine!
69. @saturnism @kubernetesio #oscon Thanks! Images by Connie Zhou http://kubernetes.io http://bit.ly/1QLg5E1
