Compacting GC for MRI

Implementation of manual heap compaction for MRI

Transcript

2. Compacting GC for MRI In Ruby 2.7
3. HELLO!!!
4. Aaron Patterson @tenderlove
10. Rails Core Team
12. Ruby Core Team
13. 10 Years On Ruby Core! W ow !!!
14. Expectations
15. Ruby Cores [aaron@TC ~]$ ls /cores core.22948 core.32321 core.44049 core.73547 core.76951 core.31231 core.36549 core.73064 core.73848 core.77093 core.31784 core.36550 core.73479 core.76655 core.82911 core.31802 core.36605 core.73493 core.76710 core.86743
16. Compacting GC for MRI
17. Controversial Features in Ruby 2.7
18. Pipeline Operator
19. Pipeline Operator 1..100 |> map { |x| x.to_s } |> sort |> reverse |> take 5 |> display
20. "Ruby is designed for developer happiness" —matz
21. Smile Operator 1..100 map { |x| x.to_s } sort reverse take 5 display
22. https://github.com/ruby/ruby/pull/2273
23. Pipeline Operator ANCELLED
24. Typed Ruby?
25. Compacting GC for MRI
26. Manual Heap Compaction For MRI
27. ~3 years to complete
29. "Novel Solution"
30. I am a genius
32. THANK YOU!
33. THANKS!!!!!
34. Today’s Topics!
35. Ruby’s Heap Compaction Algorithm Implementation Details Debugging Results
36. What is Compaction?
37. Compaction Allocated Memory Computer Memory Allocated Memory Allocated Memory Free Memory Free Memory
38. Compaction Allocated Memory Computer Memory Allocated Memory Allocated Memory Free Memory Free Memory
39. Compaction Allocated Memory Computer Memory Free Memory
41. Why Compact?
42. Efficient Memory Usage
43. Efficient Memory Usage Allocated Memory Computer Memory Allocated Memory Allocated Memory Free Memory Free Memory Want To Allocate
44. Efficient Memory Usage Allocated Memory Computer Memory Allocated Memory Allocated Memory Free Memory Free Memory Want To Allocate
45. Efficient Memory Usage Allocated Memory Computer Memory Allocated Memory Allocated Memory Wanted To Allocate
46. CPU Caches
47. CPU Cache Hits Allocated Memory Computer Memory Allocated Memory Allocated Memory Free Memory Free Memory In CPU Cache
48. CPU Cache Hits Allocated Memory Computer Memory Allocated Memory Allocated Memory Free Memory Free Memory In CPU Cache
49. "Good Locality"
50. CoW Friendliness CoW is "Copy on Write"
51. CoW Friendliness Computer Memory Allocated Memory Allocated Memory Allocated Memory Free Memory Free Memory Allocated Memory Allocated Memory Allocated Memory Free Memory Free Memory Parent Process Child Process
52. CoW Friendliness Computer Memory Allocated Memory Allocated Memory Allocated Memory Free Memory Free Memory Allocated Memory Allocated Memory Allocated Memory Free Memory Free Memory Parent Process Child Process
53. CoW Friendliness Computer Memory Allocated Memory Allocated Memory Allocated Memory Free Memory Free Memory Allocated Memory Allocated Memory Allocated Memory Free Memory Free Memory Parent Process Child Process
54. CoW Friendliness Computer Memory Allocated Memory Allocated Memory Allocated Memory Free Memory Free Memory Allocated Memory Allocated Memory Allocated Memory Free Memory Free Memory Parent Process Child Process
55. Eliminating Fragmentation
56. Fragmented Memory Allocated Memory Computer Memory Allocated Memory Allocated Memory Free Memory Free Memory
57. No Fragmentation Allocated Memory Computer Memory Allocated Memory Allocated Memory Free Memory Free Memory
58. Two Heaps
59. Ruby Heaps System Memory Malloc Heap Ruby’s Object Heap
60. Ruby Heaps System Memory Malloc Heap Ruby’s Object Heap Object.new
61. Ruby Heaps System Memory Malloc Heap Ruby’s Object Heap String.new "The Quick Brown Fox Jumps Over The Lazy Dog"
62. Fragmentation Can Occur in Both Heaps
63. For Malloc Heap: jemalloc
64. For Ruby Heap: GC.compact
65. Ruby’s Heap
66. Ruby Heaps System Memory Malloc Heap Ruby’s Object Heap
67. Ruby’s Heap Layout 40 bytes Each chunk is a "slot" Em pty Filled Empty Filled Moved
68. Ruby’s Heap Layout ~16 kb Contiguous slots make a "page"
69. Ruby’s Heap Layout
70. Ruby’s Heap Layout malloc( malloc( malloc( ) ) )
71. Ruby’s Heap Layout Each slot has a unique address 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
72. Compaction Algorithm
73. Two Finger Compaction The Programming Language LISP: Its Operation and Applications (1964)
74. Move Objects Update References
75. Moving Objects A B C D E F Free Scan 1 2 3 4 5 6 7 8 9 10 Empty Filled Moved 4 5
76. Updating References A B C D E F 1 2 3 4 5 6 7 8 9 10 Empty Filled Moved Before Moving Objects
77. Updating References A B C D 5 4 1 2 3 4 5 6 7 8 9 10 Empty Filled F Moved E After Moving Objects
78. Updating References A B C D 5 4 1 2 3 4 5 6 7 8 9 10 Empty Filled F Moved E After Moving Objects
79. Object Movement def compact heap = [ ... ] # many slots left = 0 right = heap.length - 1 while left < right left_slot = heap[left] right_slot = heap[right] if is_empty?(left_slot) && !is_empty?(right_slot) && can_move?(right_slot) swap(left, right) heap[right] = T_MOVED.new(left) # leave forwarding address end while !is_empty?(heap[left]) left += 1 end while is_empty?(heap[right]) || !can_move?(heap[right]) right -= 1 end end end Pointers Met? Copy / Forward Advance "free" Retreat "scan"
80. Reference Updating def update_references heap.each do |slot| next if is_empty?(slot) || is_moved?(slot) slot.references.each_with_index do |child, i| if is_moved?(child) slot.set_reference(i, child.new_location) end end end end How are references stored?
81. Finding References • How do Hashes hold references? • How do Arrays hold references? • How do Objects hold references? • … • … • …
82. Reference Updating static void gc_ref_update_array(rb_objspace_t * objspace, VALUE v) { long i, len; if (FL_TEST(v, ELTS_SHARED)) return; len = RARRAY_LEN(v); if (len > 0) { VALUE *ptr = (VALUE *)RARRAY_CONST_PTR_TRANSIENT(v); for(i = 0; i < len; i++) { UPDATE_IF_MOVED(objspace, ptr[i]); } } } static void gc_ref_update_object(rb_objspace_t * objspace, VALUE v) { uint32_t i, len = ROBJECT_NUMIV(v); VALUE *ptr = ROBJECT_IVPTR(v); for (i = 0; i < len; i++) { UPDATE_IF_MOVED(objspace, ptr[i]); } } static int hash_replace_ref(st_data_t *key, st_data_t *value, st_data_t argp, int existing)
83. Reference Updating
84. Supporting C Extensions
85. Where Are References Stored?
86. Array Array VALUE* Some Object Some Object Some Object
87. Hashes Hash VALUE* Some Object Some Object VALUE* Some Object Some Object Keys Values
88. Strings, Classes, Modules, Symbols, etc
89. GC Can Update All "Known Types"
90. "Known Types" Are Types Implemented by Ruby
91. What About "Unknown Types"?
92. Unknown Types are Types Implemented in C
93. Yajl typedef struct { VALUE builderStack; VALUE parse_complete_callback; int nestedArrayLevel; int nestedHashLevel; int objectsFound; int symbolizeKeys; yajl_handle parser; } yajl_parser_wrapper; C Code (yajl_ext.h) malloc(yajl_parser_wrapper) Ruby Object T_DATA Ruby Object Ruby Object builderStack parse_complete_callback Ruby Heap Malloc Heap
94. Yajl typedef struct { VALUE builderStack; VALUE parse_complete_callback; int nestedArrayLevel; int nestedHashLevel; int objectsFound; int symbolizeKeys; yajl_handle parser; } yajl_parser_wrapper; C Code (yajl_ext.h) malloc(yajl_parser_wrapper) Ruby Object T_DATA Ruby Object Ruby Object builderStack parse_complete_callback GC: "idk, " MOVED! Ruby Heap Malloc Heap
95. Yajl Mark Function void yajl_parser_wrapper_mark(void * wrapper) { yajl_parser_wrapper * w = wrapper; if (w) { rb_gc_mark(w->builderStack); rb_gc_mark(w->parse_complete_callback); } } malloc(yajl_parser_wrapper) Ruby Object T_DATA Ruby Object Ruby Object rb_gc_mark(builderStack) rb_gc_mark(parse_complete_callback) Ruby Heap Malloc Heap
96. Anything Marked With `rb_gc_mark` Cannot Move
97. Pinning Bits 1 2 3 4 5 6 7 8 9 10 Yajl [ ] ? "foo" "bar" ? Address Content Pinned x = [ "foo", "bar" ] y = Yajl.new Ruby Code rb_gc_m ark rb_gc_m ark gc_m ark_no_pin gc_m ark_no_pin
98. Pinning Bits 1 2 3 4 5 6 7 8 9 10 Yajl [ ] ? ? Address Content Pinned x = [ "foo", "bar" ] y = Yajl.new Ruby Code Free Scan "bar" "foo" 4 5 Move Step
99. Pinning Bits 1 2 3 4 5 6 7 8 9 10 Yajl [ ] ? ? Address Content Pinned x = [ "foo", "bar" ] y = Yajl.new Ruby Code 4 5 Reference Update Step "bar" "foo" Update
100. Known Types Use `gc_mark_no_pin`
101. Unknown Types Use `rb_gc_mark`
102. Allowing Movement in C Extensions
103. Compaction Callback Movable "No Pin" Marking New Location Function
104. GC Cannot Update a C Extension
105. C Extension Can Update Itself
106. Compaction Callback static const rb_data_type_t yajl_parser_type = { "Yajl/parser", {yajl_parser_wrapper_mark, yajl_parser_wrapper_free, NULL,}, 0, 0, RUBY_TYPED_FREE_IMMEDIATELY, }; Mark No Compaction Callback static const rb_data_type_t yajl_parser_type = { "Yajl/parser", {yajl_parser_wrapper_mark, yajl_parser_wrapper_free, NULL, yajl_parser_compact}, 0, 0, RUBY_TYPED_FREE_IMMEDIATELY, }; Compact With Compaction Callback Sweep
107. "No Pin" Marking void yajl_parser_wrapper_mark(void * wrapper) { yajl_parser_wrapper * w = wrapper; if (w) { rb_gc_mark(w->builderStack); rb_gc_mark(w->parse_complete_callback); } } No Compaction Support void yajl_parser_wrapper_mark(void * wrapper) { yajl_parser_wrapper * w = wrapper; if (w) { rb_gc_mark_movable(w->builderStack); rb_gc_mark_movable(w->parse_complete_callback); } } With Compaction Support
108. Compaction Callback void yajl_parser_compact(void *wrapper) { yajl_parser_wrapper * w = wrapper; if (w) { w->builderStack = rb_gc_new_location(w->builderStack); w->parse_complete_callback = rb_gc_location(w->parse_complete_callback); } } New Location
109. Known Issue
110. Problem Object Graph Object Implemented in Ruby Object Implemented in C Some Object Automatically Marked!! (gc_mark_no_pin) Not Marked
111. Compaction 1 2 3 4 5 6 7 8 9 10 Ruby Obj C Obj ? 4 5 3
112. Maybe Not Common
113. Compilation Process Text Abstract Syntax Tree Intermediate Representation Instruction Sequences
114. RubyVM Instruction Sequence ISeq Object (in C) def foo "bar" end Code Mark Array (Ruby) "bar" Marked Marked NOT Marked
115. "Direct Marking" in Ruby 2.6 ISeq Object (in C) def foo "bar" end Code "bar" Marked https://bugs.ruby-lang.org/issues/14370
116. Ruby AST AST Object (in C) def foo "bar" end Code Mark Array (Ruby) "bar" Marked Marked NOT Marked
117. Direct AST Marking AST Object (in C) def foo "bar" end Code "bar" Marked https://github.com/ruby/ruby/pull/2414
118. Ruby IR IR Object (in C) def foo "bar" end Code Mark Array (Ruby) "bar" Marked Marked NOT Marked
119. Compilation Process Text Abstract Syntax Tree Intermediate Representation Instruction Sequences
120. JSON Object Implemented in Ruby Object Implemented in C Some Object Automatically Marked!! (gc_mark) Not Marked
121. Problem Code static VALUE CNaN, CInfinity, CMinusInfinity; void Init_parser(void) { #undef rb_intern CNaN = rb_const_get(mJSON, rb_intern("NaN")); CInfinity = rb_const_get(mJSON, rb_intern("Infinity")); CMinusInfinity = rb_const_get(mJSON, rb_intern("MinusInfinity")); }
122. Potential Crasher require 'json' JSON.send :remove_const, :NaN GC.start json = '{ "foo": NaN }' JSON.load(json, nil, :allow_nan => true)['foo'].nan? Cut the reference
123. Fix diff --git a/ext/json/parser/parser.c b/ext/json/parser/parser.c index 0bd328ca42..6f0d31c2eb 100644 --- a/ext/json/parser/parser.c +++ b/ext/json/parser/parser.c @@ -2099,8 +2099,13 @@ void Init_parser(void) rb_define_method(cParser, "source", cParser_source, 0); CNaN = rb_const_get(mJSON, rb_intern("NaN")); + rb_gc_register_mark_object(CNaN); + CInfinity = rb_const_get(mJSON, rb_intern("Infinity")); + rb_gc_register_mark_object(CInfinity); + CMinusInfinity = rb_const_get(mJSON, rb_intern("MinusInfinity")); + rb_gc_register_mark_object(CMinusInfinity); i_json_creatable_p = rb_intern("json_creatable?"); i_json_create = rb_intern("json_create");
124. MsgPack Object Implemented in Ruby Object Implemented in C Some Object Automatically Marked!! (gc_mark) Not Marked
125. Pure Ruby Shouldn’t Crash https://github.com/msgpack/msgpack-ruby/issues/133
126. If you hold a reference, you must mark the reference
127. More Challenges Object#object_id
128. Direct Memory Access Prevents Movement
129. object_id is based on location 1 2 3 4 5 6 7 8 9 10 Ruby Obj Ruby Obj Ruby Obj 5 object#object_id => 1 object#object_id => 2 object#object_id => 9 object#object_id => ?
130. Object ID After Move x = Object.new GC.compact x.object_id 1 2 3 4 X x.object_id => 1 Heap
131. Object ID After Move x = Object.new x.object_id GC.compact x.object_id 1 2 3 4 X x.object_id => 4 Heap
132. "Seen" Object IDs $seen_object_id = {} class Object def object_id $seen_object_id[memory_location] ||= memory_location end end
133. Object ID After Move x = Object.new x.object_id GC.compact x.object_id 1 2 3 4 X Heap Object ID Table Memory Location Object ID 4 4 Updated Object ID Table Memory Location Object ID 1 4
134. Object ID Collisions x = Object.new x.object_id GC.compact x.object_id y = Object.new y.object_id 1 2 3 4 X Heap Object ID Table Memory Location Object ID 4 4 Updated Object ID Table Memory Location Object ID 1 4 y.object_id => ??? x.object_id => 4 Y
135. Collision Resolution $seen_object_id = {} $location_to_object_id = {} class Object def object_id id = memory_location while $seen_object_id[id] id += 1 end $seen_object_id[id] = id $location_to_object_id[memory_location] = id end end
136. Object ID Collisions x = Object.new x.object_id GC.compact x.object_id y = Object.new y.object_id 1 2 3 4 X Heap Object ID Table Memory Location Object ID 4 4 Updated Object ID Table Memory Location Object ID 1 4 y.object_id => 5 x.object_id => 4 Y Updated Object ID Table- Memory Location Object ID 1 4 4 5
137. GC Cleanup $seen_object_id = {} $location_to_object_id = {} def free_obj(obj) if $location_to_object_id[obj.memory_location] id = $location_to_object_id.delete(obj.memory_location) $seen_object_id.delete(id) end end
138. "Mostly Location Based" ANCELLED 20% CANCELLED Refactored o be better
139. Monotonic Object ID Thanks @jhawthorn!!!
140. Monotonic IDs irb(main):001:0> Object.new.object_id => 480 irb(main):002:0> Object.new.object_id => 500 irb(main):003:0> Object.new.object_id => 520 irb(main):004:0> Object.new => #<Object:0x00007fdab60dcf30> irb(main):005:0> Object.new.object_id => 540
141. Object IDs are Truly Unique
142. Count object_id Calls
143. Inspect vs Object ID $ ruby -v -e'x = Object.new; p x; p x.object_id' ruby 2.6.4p104 (2019-08-28 revision 67798) [x86_64-darwin18] #<Object:0x00007f9f7a13c948> 70161462322340 $ ruby -v -e'x = Object.new; p x; p x.object_id' ruby 2.7.0dev (2019-11-15T09:07:34Z master 11ae47c266) [x86_64-darwin19] #<Object:0x00007fd708886878> 40 Related! No Relationship! Ruby 2.6 Ruby 2.7
144. Don’t Use Object ID! (Unless you need to, it’s really fine)
145. Compaction Impact Patch Results
146. Basic Rails Application Before Compaction
147. Basic Rails Application After Compaction
148. GitHub Before Compaction After Compaction
149. ~3% Pinned
150. GitHub Before Compaction After Compaction
151. ~1% pinned
152. GitHub Before Compaction After Compaction
153. 0.3% pinned
154. ~10% smaller heap
155. Future Plans
156. Performance Improvements
157. Full GC Move Objects Update References Full GC
158. Automatic Compaction Ruby 3.0
159. Sliding Compaction
160. Sliding Compaction 1 2 3 4 5 6 7 8 9 10 Yajl [ ] ? "foo" "bar" ? Address Content
161. Better Locality
162. Supports Variable Widths
163. Variable Width Allocation
164. Fixed Width Layout
165. Variable Width Layout
166. We’re constantly improving
167. Ruby’s Future is Exciting!
168. THANK YOU! http://bugs.ruby-lang.org/issues/15626
169. Debugging GC
170. Problem Code /* static value pointing at Foo constant */ static VALUE foo = rb_const_get("Foo");
171. Compaction Bug 1 2 3 4 5 6 7 8 9 10 Foo 4 5 3 static VALUE foo = rb_const_get("Foo");
172. Compaction Bug 1 2 3 4 5 6 7 8 9 10 Foo 4 5 3 static VALUE foo = rb_const_get("Foo"); Bar
173. 3 Major Techniques
174. 1. Maximum Chaos
175. Heap Doubling 1 2 3 4 5 6 7 8 9 10 4 5 11 12 13 14 15 16 17 18 19 20 18 19 20
176. 2 Space Collector
177. 2. Zombie Objects
178. Compaction Bug 1 2 3 4 5 6 7 8 9 10 Foo 4 5 3 static VALUE foo = rb_const_get("Foo");
179. Compaction Bug 1 2 3 4 5 6 7 8 9 10 Foo 4 5 3 static VALUE foo = rb_const_get("Foo"); Bar
180. Compaction Bug 1 2 3 4 5 6 7 8 9 10 Foo 4 5 3 static VALUE foo = rb_const_get("Foo"); Bar
181. 3. Address Sanitizer
182. 2 Features Custom Allocator Compiler Extension
183. Read / Write Checks if (isPoisoned(foo)) abort(); *foo = 1;
184. Read / Write Checks if (isPoisoned(foo)) abort(); *foo = 1;
185. Compaction Bug 1 2 3 4 5 6 7 8 9 10 Foo 4 5 3 static VALUE foo = rb_const_get("Foo"); Bar
186. Using Address Sanitizer $ clang -fsanitize=address … __asan_poison_memory_region(ptr, size); Compiler Flags Runtime Function
187. Stuff to Google 2 Space Collector Zombie Objects Address Sanitizer
