Network (in)security Thierry Sans

How many of you … • have programmed with sockets
? • have taken a networking course ? • have used tools like ?  ping, traceroute, ipconfig/ifconfig, nslookup  netstat, netcat, nmap, wireshark • know what is :   IP address, port, a canonical hostname   client, server, router  switch (or hub), gateway • can explain with a fair amount of details :  Ethernet, WiFi  IP, TCP  ARP, BGP, DNS

The Internet 1980’s - few hosts connected : government institutions
and universities ➡ Trustworthy environment 2016 - ~ 6 billion hosts connected : network of networks ➡ Untrustworthy environment ➡ Internet (and its protocols) was   not designed for untrustworthy environment

A network of networks ISP - Internet   Service Provider
Backbone LAN - Local   Network LAN LAN ISP

What is a protocol Communication protocol is an agreement on
how communication should take place • defines the data encoding and/or format • defines the message sequence ➡ (most) protocols are standards defined by   the IETF - The Internet Engineering Task Force HTTP GET /document.html HTTP 200 <!DOCTYPE html = …

Internet Applications Mail  smtp imap  pop3 exchange Web  http File
Exchange  BiTorrent Remote Shell  ssh … Internet example.com

The Internet Protocol Suite   (a.k.a the network stack) Protocols
are built on top of each as layers (modularity and encapsulation) • How two programs can send messages to each other ? • How to make sure that messages have been well transmitted ? • How to route messages through the network ? • How to encode messages to go through copper, ﬁber or air ? Link   Layer Network   Layer Transport Layer Application Layer

The attacker is capable of … Scanning - survey the
network and its hosts Sniffing - eavesdrop communications Spoofing - forge illegitimate messages DOS (Denial of Service) - disrupt the communications ➡ The attacker can target any layer in the network stack confidentiality integrity availability

Link Layer  connecting machines together

Link Layer Collection of protocols to connect hosts through a
medium ➡ Deﬁnes how information is encoded to go through copper, ﬁber, air, etc … (message [,recipient]) Ethernet WiFi OTN Bluetooth USB IRDA DSL …

Multiple Interfaces A host can be connected to several hosts
or networks through multiple interfaces • Some are connected to a single host only (Point-to-Point) • Others are connected to a entire network (BUS) WiFi Ethernet USB

Point-to-Point Link Only two hosts are connected at each end
of the medium e.g. OTN, IRDA, DSL … ➡ Harder for an attacker to intercept messages

Bus Link (a.k.a LAN - Local Area Network) Several hosts
are connected to the same medium  with a unique physical address called e.g. Ethernet and WiFi uses MAC  Media Access Control addresses ➡ Easier for the attacker to intercept messages since they are all broadcasted to the same medium

Packet Sniffing over Ethernet or WiFi • All messages are
transmitted on the medium with the MAC address of the recipient • Each network interface only picks messages that correspond to its MAC address ➡ An attacker can set its network interface in   promiscuous mode to capture (sniff) all traffic e.g. Wireshark confidentiality

Network Layer connecting networks together

The Network Layer Collection of protocols to connect networks together
➡ Deﬁnes how messages are routed through the different networks based on IP addresses Link IPv6 ICMP (message,IP_address) IPv4

IP - Internet Protocol • Each message has the IP
address of the issuer and recipient • Routers route packet based on their routing table and a default route ➡ Best effort protocol

ICMP - Internet Control Message Protocol Exchange information about the
network e.g. error reporting, congestion control, network reachability ➡ ping, traceroute

Host Discovery By default, hosts answer to ICMP echo request
messages ➡ An attacker scan an entire network to ﬁnd IP addresses of active hosts e.g. nmap (does that among other things) ~ conﬁdentiality

IP Spooﬁng • Routers do not validate the source •
Receiver cannot tell that the source has been spoofed ➡ An attacker can generate raw IP packets with custom IP source ﬁelds e.g. DOS (blackhole) and MITM attacks integrity availability

ICMP ping of death   (before 1997) Any host receiving
a 64K ICMP payload would crash or reboot ➡ 64K bytes payload were assumed to be invalid by programmers ➡ An attacker could split a 64K payload, transmit it and would be reassembled by the receiver overﬂowing a buffer availability

ICMP Ping Flood ➡ An attacker can overwhelm a host
by sending multiples ICMP echo requests availability

ICMP Smurf Attack - an elaborated ping ﬂood attack

Transport Layer end-to-end connection

The Transport Layer Collection of protocols to ensure end-to- end
connections ➡ Allows hosts to have multiple connections through ports ➡ Allows messages to be fragmented into small IP packets ➡ Make sure that all packets are received Link Network TCP UDP

TCP - Transmission Control Protocol • The sender divides data-stream
into packets sequence number is attached to every packet • The receiver checks for packets errors, reassembles packets in correct order to recreate stream • ACK (acknowledgements) are sent when packets are well received and lost/corrupt packets are re-sent ➡ Connection state maintained on both ends

TCP “3-way” handshake

Port scanning ➡ Using the “3-way” handshake, an attacker can
scan for all open ports for a given host e.g. nmap ~ conﬁdentiality

TCP-syn ﬂooding availability

TCP Connection Reset (DOS) Each TCP connection (i.e each port)
has an associated state sequence number ➡ An attacker can guess (sniff) the current sequence number for an existing connection and send packet with reset ﬂag set, which will close the connection availability

UDP - User Datagram Protocol UDP is a connectionless transport-layer
protocol ➡ No acknowledgement, no ﬂow control, no message continuation, no reliability guarantees e.g. media streaming (VoIP, video broadcasting)

UDP Flood When a UDP packet is received on a
non-opened port, the host replies with an ICMP Destination Unreachable ➡ An attacker can send a large number of UDP packets to all ports of a target host e.g Low Orbit Ion Canon availability

The TCP/IP Stack

Layering

TCP/IP

Data encapsulation

Special Protocols

ARP - Address Resolution Protocol Each host has an ARP
table that contains mapping between MAC and IP addresses ➡ Host broadcasts their own IP address and MAC address to others to build their ARP table Link ARP Network

ARP Cache Poisoning ➡ An attacker can broadcast fake IP-MAC
mappings to the other hosts on the network e.g. DOS and MITM attacks integrity availability

BGP - Border Gateway Protocol (a.k.a routing) Each router has
a routing table to IP messages BGP is the protocol for establishing routes ➡ Routers advertise the best route to other nearby routers depending on the state of the network

Route hijacking ➡ An attacker can advertise fake routes e.g.
DOS (blackhole) and MITM attacks conﬁdentiality availability
