1. Network Security Thierry Sans
2. The Protocol Stack Ethernet WiFi … ICMP IPv4 UDP … SMTP DNS BGP HTTP Application Transport Network Link ARP IPv6 TCP
3. The attacker is capable of … Scanning - survey the network and its hosts Eavesdropping - read messages Spoofing - forge illegitimate messages DOS (Denial of Service) - disrupt the communications ➡ The attacker can target any layer in the network stack confidentiality integrity availability
4. Ethernet WiFi … ICMP IPv4 UDP … SMTP DNS BGP HTTP ARP IPv6 TCP Packet Sniffing (eavesdropping)
5. Ethernet WiFi … ICMP IPv4 UDP … SMTP DNS BGP HTTP ARP IPv6 TCP ARP-cache poisoning (spoofing)
6. Ethernet WiFi … ICMP IPv4 UDP … SMTP DNS BGP HTTP ARP IPv6 TCP • Host discovery (scanning) • IP forgery (spoofing) • ICMP Ping flooding (DOS)
7. Ethernet WiFi … ICMP IPv4 UDP … SMTP DNS BGP HTTP ARP IPv6 TCP • Port scanning (scanning) • TCP forgery (spoofing, DOS) • TCP-syn flooding (DOS) • UDP flooding (DOS)
8. Ethernet WiFi … ICMP IPv4 UDP … SMTP DNS BGP HTTP ARP IPv6 TCP • Route Hijacking
 (spoofing, DOS) • DNS-cache poisoning (spoofing, DOS)
9. TLS - Transport Layer Security
10. TLS - Tranport Layer Protection ➡ Transport Layer Security (a.k.a SSL v3) provides • integrity: authentication handshake • confidentiality: end-to-end secure channel ✓ Prevents all kinds of eavesdropping and spoofing
 for application protocols e.g HTTP + TLS = HTTPS ๏ 2-10 times slower than an insecure TCP connection ๏ Not used in practice to secure DNS and BGP
11. Authentication Handshake
12. Specific attacks of HTTPS Webpages can be delivered either with HTTPS or HTTP ➡ The browser can automatically switch between HTTP and HTTPS Sometime within the same webpage (mixed-content)
 e.g the main page loads over HTTPS
 but images, scripts or css load with HTTP An attacker can do a MitM attack and remove the SSL protection ➡ SSLStripping attack (lab 05)
13. Preventing eavesdropping attacks
14. Preventing packet sniffing over Ethernet Hub : broadcast all messages on all ports Switch : (smart HUB) forward messages on specific port based on their MAC addresses ➡ isolate Ethernet traffics (no straightforward packet sniffing) ≈
15. Packet sniffing over a wireless network ➡ Encrypt message before sending them over the air Wireless Security WEP WPA WPA2 Personal Enterprise Authentication Shared Key Shared Key Shared Key RADIUS
 Server Cryptography RC4 TKIP and RC4 CCMP and AES Security Broken Broken External attackers only Good
16. Preventing spoofing attacks
17. Preventing ARP-cache poisoning • Authenticating ARP messages has been proposed (research) but never implemented • Static ARP tables (not practical in dynamic environment) • Detection and correction tools
18. Preventing IP forgery IPsec - Internet Protocol Security provides authentication (and optionally encryption) of IP traffic ➡ Uses SHA2 and AES (previously SHA1 and 3DES) ✓ Used usually between routers (link and network layers only) ๏ However IPsec is rarely deployed in practice m IP header m IP header m IP header IPsec header IPsec encapsulation IPsec secure channel router 1 router 2
19. Preventing DNS spoofing DNSSEC - Domain Name System Security Extensions
 provides authentication (but not encryption) between DNS servers ๏ Not widely deployed yet
20. Preventing route hijacking (BGP) No standard solution yet, still work in progress
21. Preventing DOS attacks
22. Preventing TCP-syn flooding TCP-syn cookie prevents from maintaining a queue
 of half-opened TCP connections
23. Preventing DOS and DDOS attacks in general Network Ingress Filtering (a.k.a BCP 38) Best Current Practice to limit the impact of DOS and DDOS 1. Deny access to network traffic with spoofed addresses 2. Ensure that traffic is traceable to its correct source network ➡ Implemented by ISPs (Internet Service Providers)
24. Preventing scanning attacks
 (and beyond)
25. Preventing host discovery and port-scanning Host discovery uses ICMP ping echo message ➡ ICMP can be disabled or reserved to hosts
 on the same network Port Scanning uses TCP-syn messages ➡ TCP connections can be rejected if a source attempts to initiate multiple connections on multiple ports simultaneously ➡ Packet filtering can prevent these two scanning techniques
26. Limitation of a host-by-host packet filtering solution How to enable packet filtering on every host on the network? 1. Each host needs to have packet filtering capability
 across different hardware, OS and versions 2. The admin needs to have administrative privilege on every host to push the packet filtering policy ➡ Impossible in practice
27. Firewall
28. Network Firewall Protected Network Internet Firewall
29. Network Firewall A firewall defines a logical defense parameter
 and acts an access control between two networks ➡ Packet filtering based on IP addresses (TCP filtering) • inbound traffic from the Internet trying to get into the protected network • outbound traffic going the other way ✓ For the most part, we trust the outbound
 but not the inbound
30. Widely used in practice Assuming the attacks comes from outside, a firewall can prevent • Most scanning attacks • Some spoofing attacks • Some flooding attacks (as long as it can handle the load) • Anomalous messages e.g smurf attack • and others ➡ But more generally, it can restrict access to protected hosts
31. Two type of firewalls Stateless packet filtering is purely based on the IP address and the port Stateful packet filtering tracks the status of every connection (TCP 3 way handshake)
32. Example of a stateful firewall policy ACL - Access Control Lists action protocol IP src port dst IP dst port dst state allow TCP 222.22/16 >1023 ! 222.22/16 80 any allow TCP ! 222.22/16 80 222.22/16 >1023 ack allow UDP 222.22/16 >1023 ! 222.22/16 53 - allow UDP ! 222.22/16 53 222.22/16 >1023 - deny all all all all all all
33. Concept of DMZ DMZ - DeMilitarized Zone isolates exposed public servers
 e.g web, mail, database and so on Internal Network Internet DMZ Protected Network
34. Intrusion Detection
35. Two approaches to build an IDS Signature-based IDS Have pre-defined malicious message pattern ➡ Relies on a signature database Heuristic-based Builds a model of acceptable message exchange patterns ➡ Relies on machine learning
36. (Network) Intrusion Detection Systems IDS - Intrusion detection systems performs deep packet inspection • Looks at the headers • Look at packet contents (payload) • Looks at the packet fragmentation
37. IDS in the protected network ➡ IDSs often operate in stealth mode Protected Network Internet IDS
38. IPS - Intrusion Prevention system IPS = IDS + Firewall ➡ IP addresses sending malicious packets can be filtered
39. Problem with nomad hosts Protected Network Internet
40. VPN - Virtual Private Network
41. VPN - Virtual Private Network VPN protected nomad hosts outside the protected network Protected Network Internet VPN server
42. Tunneling protocol 1. Alice’s message is encapsulated and sent to the VPN server 2. The VPN extract this traffic and send it to the destination 3. Same thing on the way back ➡ Provides anonymity (from the IP perspective at least) m TCP header m TCP header TCP header TCP secure channel VPN server
43. Different type of VPNs VPN can be built using different technology e.g. • IPsec • TLS (e.g openVPN) • SSH
44. VPN to enforce security … or evade it :) ➡ Evade censorship and geo-restrictions
 by masking the real IP address
45. The TOR network a.k.a Onion Routing
