Building customer-visible data science dashboards with Altair / Vega / Vue

There are several tools to build ML dashboards and visulisations. Their focus is often on making it as simple as possible for a (Python) data scientist. Shipp ing them as part of our product means that other roles like frontend developers get involved. Aspects that ease development for one role, create pains for others. We want to show how balance this using Altair, Vega and Vue.

Uwe L. Korn

May 27, 2018
Tweet

More Decks by Uwe L. Korn

Other Decks in Programming

Transcript

  1. 1 PyData Amsterdam 2018 Uwe L. Korn Building customer-visible data

    science dashboards with Altair / Vega / Vue
  2. 2 • Senior Data Scientist at Blue Yonder (@BlueYonderTech) •

    Apache {Arrow, Parquet} PMC • Work in Python, C++11 and SQL • Data Engineer and Architect with heavy focus around Pandas About me xhochy [email protected]
  3. 3 1. Use Case 2. Conflict of interests 3. The

    nice compromise 4. Technical dive-in Agenda
  4. 5 Why do we need dashboards? • Present output of

    your machine learning models • Make insights available to non-technical users • Repetitive tasks can also be done much faster, even for tech-savy folks • „You cannot give your customer just an API“
  5. 6 So, have you seen Bokeh? from bokeh.io import curdoc

    from bokeh.layouts import column from bokeh.models.widgets import TextInput, Button, Paragraph # create some widgets button = Button(label="Say HI") input = TextInput(value="Bokeh") output = Paragraph() # add a callback to a widget def update(): output.text = "Hello, " + input.value button.on_click(update) # create a layout for everything layout = column(button, input, output) # add the layout to curdoc curdoc().add_root(layout)
  6. 7 Why didn’t we use it? • It’s really great

    but… • It provides an environment to write dashboards in purely Python • Our frontend devs work in JavaScript et al. • Bokeh(js) introduces its own dependencies on the frontend • Building dashboards just for you or your data science team? Use it!
  7. 8 What do these UI developers want? • Work with

    their native toolchain, i.e. JavaScript, CSS, … not Python • Choose dependencies freely • Don’t be constrained by the backend • Custom widgets should be a concern of the frontend
  8. 9 Vega and Vega-lite Vega is a declarative format for

    creating, saving, and sharing visualization designs. With Vega, visualizations are described in JSON, … Vega-Lite is a more high-level version of this grammar approach. https://vega.github.io/
  9. 10 VueJS for the frontend • Vega is for visualizations,

    we also need widgets • Could be substituted by ReactJS / Angular / … • provides reactive and composable view components • Basics can be learned without deep frontend knowlegde
  10. 12 Vega(-lite) specs in Python from flask import Flask, jsonify

    app = Flask(__name__) @app.route("/barchart.json") def barchart(): return jsonify({ "$schema": "https://vega.github.io/schema/vega-lite/v2.json", "description": "A simple bar chart with embedded data.", "data": { "values": [ {"a": "A","b": 28}, {"a": "B","b": 55}, {"a": "C","b": 43}, {"a": "D","b": 91}, {"a": "E","b": 81}, {"a": "F","b": 53}, {"a": "G","b": 19}, {"a": "H","b": 87}, {"a": "I","b": 52} ] }, "mark": "bar", "encoding": { "x": {"field": "a", "type": "ordinal"}, "y": {"field": "b", "type": "quantitative"} } }
  11. 13 Altair import altair as alt import pandas as pd

    df = pd.DataFrame({ 'a': ["A", "B", "C", "D", "E", "F", "G", "H", "I"], 'b': [28, 55, 43, 91, 81, 53, 19, 87, 52] }) alt.Chart(df).mark_bar().encode( x='a', y='b', )
  12. 15 app = Flask(__name__) cars = vega_datasets.data.cars() @app.route("/vega-example") def hello():

    columns = [ … ] chart = alt.Chart(cars).mark_point().encode( x=random.choice(columns), y=random.choice(columns) ) return jsonify(chart.to_dict()) app.py
  13. 16 HelloWorld.vue (I/II) <script> import {default as vegaEmbed} from 'vega-embed'

    export default { methods: { reloadImage () { fetch('/vega-example').then(response => { response.json().then(spec => { vegaEmbed('#vega-box', spec, {actions: false}) }) }) } } } </script>
  14. 17 HelloWorld.vue (II/II) <template> <v-container fluid> <v-slide-y-transition mode="out-in"> <v-layout column

    align-center> <v-btn @click.native="reloadImage()">Reload</v-btn> <div id="vega-box"></div> </v-layout> </v-slide-y-transition> </v-container> </template>
  15. 19 Altair Basics Some really simple basics, for more see

    https://github.com/altair-viz/ altair-tutorial from vega_datasets import data import altair as alt cars = data.cars()
  16. 26 Summary • Chose technologies that make all involved happy

    • Talk to each other • Tools that work good for you, might not work for your team • Altair is a great visualization library • Use it in UIs • Use it in Jupyter Notebooks
  17. 27 By JOEXX (Own work) [CC BY-SA 3.0 (http://creativecommons.org/licenses/by-sa/3.0)], via

    Wikimedia Commons By JOEXX (Own work) [CC BY-SA 3.0 (http://creativecommons.org/licenses/by-sa/3.0)], via Wikimedia Commons 24. - 26. October + 2 days of sprints (27/28.10.) ZKM Karlsruhe, DE Karlsruhe Call for Participation opens next week.
  18. 28 Karlsruhe 24. - 26. October ZKM Karlsruhe + 2

    days of sprints (27/28.10.) Conference all in English language. More info: http://pycon.de Wed Fri Call for Proposals OPEN! Tickets soon.
