Slides for my keynote at PyData Madrid 2016

FrancescAlted

April 10, 2016
Tweet

More Decks by FrancescAlted

Other Decks in Technology

Transcript

  1. New Computer Trends And How This Affect Us Francesc Alted

    Freelance Consultant http://www.blosc.org/professional-services.html April 10rd, 2016
  2. “No sensible decision can be made any longer without taking

    into account not only the computer as it is, but the computer as it will be.” — My own rephrasing “No sensible decision can be made any longer without taking into account not only the world as it is, but the world as it will be.” — Isaac Asimov
  3. About Me • Physicist by training • Computer scientist by

    passion • Open Source enthusiast by philosophy • PyTables (2002 - 2011) • Blosc (2009 - now) • bcolz (2010 - now)
  4. –Manuel Oltra, music composer “The art is in the execution

    of an idea. Not in the idea. There is not much left just from an idea.” “Real artists ship” –Seth Godin, writer Why Open Source Projects? • Nice way to realize yourself while helping others
  5. Overview • Recent trends in computer architecture • The need

    for speed: storing and processing as much data as possible with your existing resources • Blosc & bcolz as examples of compressor and data containers for large datasets that follow the principles of the newer computer architectures
  6. The growing gap between DRAM and HDD is facilitating the

    introduction of
 new SDD devices Forthcoming Trends BGA SSD M.2 SSD PCIe SSD
  7. Latency Numbers Every Programmer Should Know Latency Comparison Numbers --------------------------

    L1 cache reference 0.5 ns Branch mispredict 5 ns L2 cache reference 7 ns 14x L1 cache Mutex lock/unlock 25 ns Main memory reference 100 ns 20x L2 cache, 200x L1 cache Read 4K randomly from memory 1,000 ns 0.001 ms Compress 1K bytes with Zippy 3,000 ns Send 1K bytes over 1 Gbps network 10,000 ns 0.01 ms Read 4K randomly from SSD* 150,000 ns 0.15 ms Read 1 MB sequentially from memory 250,000 ns 0.25 ms Round trip within same datacenter 500,000 ns 0.5 ms Read 1 MB sequentially from SSD* 1,000,000 ns 1 ms 4X memory Disk seek 10,000,000 ns 10 ms 20x datacenter roundtrip Read 1 MB sequentially from disk 20,000,000 ns 20 ms 80x memory, 20X SSD Send packet CA->Netherlands->CA 150,000,000 ns 150 ms Source: Jeff Dean and Peter Norvig (Google), with some additions http://www.eecs.berkeley.edu/~rcs/research/interactive_latency.html
  8. tref ttrans CPU cache CPU cache Block in storage to

    transmit to CPU Reference Time vs Transmission Time tref ~= ttrans => optimizes storage access
  9. Not All Storage Layers Are Created Equal Memory: tref: 100

    ns / ttrans (1 KB): ~100 ns Solid State Disk: tref: 10 us / ttrans (4 KB): ~10 us Mechanical Disk: tref: 10 ms / ttrans (1 MB): ~10 ms But essentially, a blocked data access is mandatory for speed! The slower the media, the larger the block
 that is worth to transmit
  10. We Need More Data Blocking In Our Infrastructure! • Not

    many data containers focused on blocking access • No silver bullet: we won’t be able to find a single container that makes everybody happy; it’s all about tradeoffs • With blocked access we can use persistent media (disk) as it is ephemeral (memory) and the other way around -> independency of media!
  11. Compression for Random & Sequential Access in SSDs • Compression

    does help performance! (65MB/s) (240MB/s) (180MB/s) (200MB/s)
  12. Compression for Random & Sequential Access in SSDs • Compression

    does help performance! • However, limited by SATA bandwidth (65MB/s) (240MB/s) (180MB/s) (200MB/s)
  13. Leveraging Compression Straight To CPU Less data needs to be

    transmitted to the CPU Disk bus Decompression Disk CPU Cache Original
 Dataset Compressed
 Dataset Transmission + decompression faster than direct transfer?
  14. When we have a fast enough compressor we can get

    rid of the limitations of the bus bandwidth. How to get maximum compression performance?
  15. Computer Architecture Evolution Up to end 80’s 90’s and 2000’s

    2010’s Figure 1. Evolution of the hierarchical memory model. (a) The primordial (and simplest) model; (b) the most common current Mechanical disk Mechanical disk Mechanical disk Speed Capacity Solid state disk Main memory Level 3 cache Level 2 cache Level 1 cache Level 2 cache Level 1 cache Main memory Main memory CPU CPU (a) (b) (c) Central processing unit (CPU)
  16. Hierarchy of Memory
 By 2018 (Educated Guess) SSD SATA (persistent)

    L4 RAM (addressable) XPoint (persistent) HDD (persistent) L3 L2 L1 9 levels will be common! SSD PCIe (persistent)
  17. Improving RAM Speed? Less data needs to be transmitted to

    the CPU Memory Bus Decompression Memory (RAM) CPU Cache Original
 Dataset Compressed
 Dataset Transmission + decompression faster than direct transfer?
  18. Query Times 2012 old laptop (Intel Ivy-Bridge, 2 cores) Compression

    speeds things up Source: https://github.com/Blosc/movielens-bench
  19. Query Times 2010 laptop (Intel Core2, 2 cores) Compression still

    slow things down Source: https://github.com/Blosc/movielens-bench
  20. bcolz vs pandas (size) bcolz can store 20x more data

    than pandas by using
 compression
  21. Accelerating I/O With Blosc Blosc Main Memory Solid State Disk

    Capacity Speed CPU Level 2 Cache Level 1 Cache Mechanical Disk Level 3 Cache } } Other compressors
  22. Compression matters! “Blosc compressors are the fastest ones out there

    at this point; there is no better publicly available option that I'm aware of. That's not just ‘yet another compressor library’ case.” — Ivan Smirnov (advocating for Blosc inclusion in h5py)
  23. What is bcolz? • bcolz provides data containers that can

    be used in a similar way than the ones in NumPy, Pandas • The main difference is that data storage is chunked, not contiguous • Two flavors: • carray: homogenous, n-dim data types • ctable: heterogeneous types, columnar
  24. String … String Int32 Float64 Int16 String … String Int32

    Float64 Int16 String … String Int32 Float64 Int16 String … String Int32 Float64 Int16 Interesting column Interesting Data: N * 4 bytes (Int32) Actual Data Read: N * 64 bytes (cache line) }N rows In-Memory Row-Wise Table (Structured NumPy array)
  25. String … String Int32 Float64 Int16 String … String Int32

    Float64 Int16 String … String Int32 Float64 Int16 String … String Int32 Float64 Int16 Interesting column Interesting Data: N * 4 bytes (Int32) Actual Data Read: N * 4 bytes (Int32) In-Memory Column-Wise Table (bcolz ctable) }N rows Less memory travels to CPU! Less entropy so much more compressible!
  26. Some Projects Using bcolz • Visualfabriq’s bquery (out-of-core groupby’s):
 https://github.com/visualfabriq/bquery

    • Scikit-allel:
 http://scikit-allel.readthedocs.org/ • Quantopian:
 http://quantopian.github.io/talks/NeedForSpeed/ slides#/

  27. bquery - On-Disk GroupBy In-memory (pandas) vs on-disk (bquery+bcolz) groupby

    “Switching to bcolz enabled us to have a much better scalable
 architecture yet with near in-memory performance”
 — Carst Vaartjes, co-founder visualfabriq
  28. –Alistair Miles Head of Epidemiological Informatics for the Kwiatkowski group.

    Author of scikit-allel. “The future for me clearly involves lots of block- wise processing of multidimensional bcolz carrays"”
  29. Introducing Blosc2 Next generation of Blosc Blosc2 Header Chunk 1

    (Blosc1) Chunk 2 (Blosc1) Chunk 3 (Blosc1) Chunk N (Blosc1)
  30. Planned features for Blosc2 • Looking into inter- chunk redundancies

    (delta filter) • Support for more codecs (Zstd is there already!) • Serialized version of the super-chunk (disk, network) …
  31. • At 3 GB/s, Blosc2 on ARM achieves one of

    the best bandwidth/Watt ratios in the market • Profound implications for the density of data storage devices (e.g. arrays of disks driven by ARM) Not using NEON Using NEON
  32. Blosc2 has its own repo https://github.com/Blosc/c-blosc2 Meant to be usable

    only when heavily tested! (bcolz2 will follow after Blosc2)
  33. Closing Notes • Due to the evolution in computer architecture,

    the compression can be effective for two reasons: • We can work with more data using the same resources. • We can reduce the overhead of compression to near zero, and even beyond than that!
