rtcamp11 @kugi_masa 蛍光分子のエネルギー状態 不安定な高エネルギー状態へ E S 2 S 0 S
1 蛍光分子くん う わ ぁ ぁ ぁ ぁ ぁ ぁ ぁ -
rtcamp11 @kugi_masa 蛍光分子のエネルギー状態 E S 2 S 0 S 1
蛍光分子くん ふ...ふぅ... エネルギー損失を伴い 半安定的な状態へ -
rtcamp11 @kugi_masa 蛍光分子のエネルギー状態 E S 2 S 0 S 1
蛍光分子くん 半安定状態から光を放出し 安定な状態へと戻る パァァァ -
rtcamp11 @kugi_masa Re-radiation Matrix Spectral Rendering in a Non-Spectral Renderer:
How Can we Author and Render Fluorescence in RGB? [Laurent Belcour, SIGGRAPH2025 Course: Physically Based Shading in Theory and Practice] 入射波長λ i で吸収される光に対して 出射波長λ o で放出される光の分布 蛍光材質の蛍光特性を表す行列 Spectrophotometry of fluorescent pigments [Donalson 1954] Re-radiation Matrix : R(𝜆 i ,𝜆 o ) またの名を Donalson Matrix -
rtcamp11 @kugi_masa Re-radiation Matrixの構成要素 非蛍光の反射 (𝜆 i = 𝜆 o
) 蛍光 (𝜆 i < 𝜆 o ) 対角成分 Acquisition and Analysis of Bispectral Bidirectional Reflectance and Reradiation Distribution Functions [Hullin et al., SIGGRAPH2010] 下三角行列 -
rtcamp11 @kugi_masa 上三角部分は? ΔE > S 2 - S 0
𝜆 i ≤ 𝜆 o 上三角行列 ? ストークスの法則 Acquisition and Analysis of Bispectral Bidirectional Reflectance and Reradiation Distribution Functions [Hullin et al., SIGGRAPH2010] -
rtcamp11 @kugi_masa エネルギー保存則 放出される光のエネルギーは 入射光のエネルギーを超えてはならない Spectral Rendering in a Non-Spectral
Renderer: How Can we Author and Render Fluorescence in RGB? [Laurent Belcour, SIGGRAPH2025 Course: Physically Based Shading in Theory and Practice] -
rtcamp11 @kugi_masa BBRRDF [Hullin et al. SIGGRAPH2010] 蛍光現象は波長依存性のある光学現象 また、入射光と出射光の波長が変化する Bispectral
Bidirectional Reflectance and Reradiation Distribution Function BBRRDF -
rtcamp11 @kugi_masa 蛍光現象のレンダリング Handling Fluorescence in a Uni-directional Spectral Path
Tracer [Mojik et al. EGSR2018] スペクトラルレンダラーによる実装 蛍光時の波長の変化を考慮するため 別途波長をサンプルする必要がある -
rtcamp11 @kugi_masa RGBでも蛍光を!? [Fichet et al. EGSR2024] 非スペクトラルレンダラーで蛍光を描画する手法 [Fichet et
al. SIGGRAPH2025] 蛍光材質パラメータの編集を可能にした手法 -
rtcamp11 @kugi_masa RGBでも蛍光を!? [Fichet et al. EGSR2024] 非スペクトラルレンダラーで蛍光を描画する手法 [Fichet et
al. SIGGRAPH2025] 蛍光材質パラメータの編集を可能にした手法 力尽きてしまったので 本日はこちらのみ スミマセン... -
rtcamp11 @kugi_masa 蛍光のスペクトラルレンダリング 光源のスペクトル分布 Re-radiation Matrix 等色関数 XYZ値 Spectral Rendering
in a Non-Spectral Renderer: How Can we Author and Render Fluorescence in RGB? [Laurent Belcour, SIGGRAPH2025 Course: Physically Based Shading in Theory and Practice] -
rtcamp11 @kugi_masa 蛍光のRGB(or XYZ)レンダリング 光源のスペクトル分布 Re-radiation Matrix 等色関数 XYZ値 同様の流れでRGB(XYZ)レンダリングを考える
Spectral Rendering in a Non-Spectral Renderer: How Can we Author and Render Fluorescence in RGB? [Laurent Belcour, SIGGRAPH2025 Course: Physically Based Shading in Theory and Practice] -
rtcamp11 @kugi_masa 蛍光のRGB(or XYZ)レンダリング Spectral Rendering in a Non-Spectral Renderer:
How Can we Author and Render Fluorescence in RGB? [Laurent Belcour, SIGGRAPH2025 Course: Physically Based Shading in Theory and Practice] XYZ等色関数とRGB等色関数で挟むことで upsampling、downsamplingの部分を省略できる 様々な蛍光分子ちゃんず ヤッター!! -
rtcamp11 @kugi_masa 可視光領域外への対応 Non-Orthogonal Reduction for Rendering Fluorescent Materials in
Non-Spectral Engines [Fichet et al., EGSR2024] 等色関数では可視光領域外は扱っていないため 別途応答関数を追加することで対応している -
rtcamp11 @kugi_masa • Spectral Rendering in a Non-Spectral Renderer: How
Can we Author and Render Fluorescence in RGB? ◦ [Laurent Belcour, SIGGRAPH2025 Course: Physically Based Shading in Theory and Practice] ◦ https://blog.selfshadow.com/publications/s2025-shading-course/belcour/slides/index.html • Acquisition and Analysis of Bispectral Bidirectional Reflectance and Reradiation Distribution Functions ◦ [Hullin et al., SIGGRAPH 2010] ◦ https://jankautz.com/publications/BispectralBRRDF_SIG10.pdf • Handling Fluorescence in a Uni-directional Spectral Path Tracer ◦ [Mojizik et al., EGSR 2018] ◦ https://cgg.mff.cuni.cz/~wilkie/Website/EGSR_18_files/MFW18HFUSPT_lowres.pdf • Efficient Storage and Importance Sampling for Fluorescent Reflectance ◦ [Hua et al. CGF 2023] ◦ https://graphics.cg.uni-saarland.de/papers/hua-2022-cgf-fluo.pdf • Non-Orthogonal Reduction for Rendering Fluorescent Materials in Non-Spectral Engines ◦ [Fichet et al., EGSR2024] ◦ https://arxiv.org/abs/2406.17360 • A Fluorescent Material Model for Non-Spectral Editing & Rendering ◦ [Fichet et al., SIGGRAPH 2025] ◦ https://arxiv.org/abs/2505.19672 • Molecular Probes 蛍光教室 ◦ Thermo Fisher Scientific - Molecular Probes® ◦ https://www.thermofisher.com/jp/ja/home/life-science/cell-analysis/cell-analysis-learning-center/molecular-probes-scho ol-of-fluorescence.html 蛍光文献
