Engineering fast indexes (Deep dive)

Daniel Lemire
February 07, 2017

Engineering fast indexes (Deep dive)

Contemporary computing hardware offers massive new performance opportunities. Yet high-performance programming remains a daunting challenge.

Daniel Lemire

February 07, 2017
Tweet

More Decks by Daniel Lemire

Other Decks in Technology

Transcript

  1. Roaring : Hybrid Model A collection of containers... array: sorted

    arrays ({1,20,144}) of packed 16‑bit integers bitset: bitsets spanning 65536 bits or 1024 64‑bit words run: sequences of runs ([0,10],[15,20]) 2
  2. Keeping track E.g., a bitset with few 1s need to

    be converted back to array. → we need to keep track of the cardinality! In Roaring, we do it automagically 3
  3. Setting/Flipping/Clearing bits while keeping track Important : avoid mispredicted branches

    Pure C/Java: q = p / 6 4 o w = w [ q ] ; n w = o w | ( 1 < < ( p % 6 4 ) ) ; c a r d i n a l i t y + = ( o w ^ n w ) > > ( p % 6 4 ) ; / / E X T R A w [ q ] = n w ; 4
  4. In x64 assembly with BMI instructions: s h r x

    % [ 6 ] , % [ p ] , % [ q ] / / q = p / 6 4 m o v ( % [ w ] , % [ q ] , 8 ) , % [ o w ] / / o w = w [ q ] b t s % [ p ] , % [ o w ] / / o w | = ( 1 < < ( p % 6 4 ) ) + f l a g s b b $ - 1 , % [ c a r d i n a l i t y ] / / u p d a t e c a r d b a s e d o n f l a g m o v % [ l o a d ] , ( % [ w ] , % [ q ] , 8 ) / / w [ q ] = o w s b b is the extra work 5
  5. For each operation union intersection difference ... Must specialize by

    container type: array bitset run array ? ? ? bitset ? ? ? run ? ? ? 6
  6. Bitset vs. Bitset... Intersection: First compute the cardinality of the

    result. If low, use an array for the result (slow), otherwise generate a bitset (fast). Union: Always generate a bitset (fast). (Unless cardinality is high then maybe create a run!) We generally keep track of the cardinality of the result. 8
  7. Cardinality of the result How fast does this code run?

    i n t c = 0 ; f o r ( i n t k = 0 ; k < 1 0 2 4 ; + + k ) { c + = L o n g . b i t C o u n t ( A [ k ] & B [ k ] ) ; } We have 1024 calls to L o n g . b i t C o u n t . This counts the number of 1s in a 64‑bit word. 9
  8. Population count in Java / / H a c k

    e r ` s D e l i g h t i n t b i t C o u n t ( l o n g i ) { / / H D , F i g u r e 5 - 1 4 i = i - ( ( i > > > 1 ) & 0 x 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 L ) ; i = ( i & 0 x 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 L ) + ( ( i > > > 2 ) & 0 x 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 L ) ; i = ( i + ( i > > > 4 ) ) & 0 x 0 f 0 f 0 f 0 f 0 f 0 f 0 f 0 f L ; i = i + ( i > > > 8 ) ; i = i + ( i > > > 1 6 ) ; i = i + ( i > > > 3 2 ) ; r e t u r n ( i n t ) i & 0 x 7 f ; } Sounds expensive? 10
  9. Population count in C How do you think that the

    C compiler c l a n g compiles this code? # i n c l u d e < s t d i n t . h > i n t c o u n t ( u i n t 6 4 _ t x ) { i n t v = 0 ; w h i l e ( x ! = 0 ) { x & = x - 1 ; v + + ; } r e t u r n v ; } 11
  10. Compile with - O 1 - m a r c

    h = n a t i v e on a recent x64 machine: p o p c n t r a x , r d i 12
  11. Why care for p o p c n t ?

    p o p c n t : throughput of 1 instruction per cycle (recent Intel CPUs) Really fast. 13
  12. Population count in Java? / / H a c k

    e r ` s D e l i g h t i n t b i t C o u n t ( l o n g i ) { / / H D , F i g u r e 5 - 1 4 i = i - ( ( i > > > 1 ) & 0 x 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 L ) ; i = ( i & 0 x 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 L ) + ( ( i > > > 2 ) & 0 x 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 L ) ; i = ( i + ( i > > > 4 ) ) & 0 x 0 f 0 f 0 f 0 f 0 f 0 f 0 f 0 f L ; i = i + ( i > > > 8 ) ; i = i + ( i > > > 1 6 ) ; i = i + ( i > > > 3 2 ) ; r e t u r n ( i n t ) i & 0 x 7 f ; } 14
  13. Population count in Java! Also compiles to p o p

    c n t if hardware supports it $ j a v a - X X : + P r i n t F l a g s F i n a l | g r e p U s e P o p C o u n t I n s t r u c t i o n b o o l U s e P o p C o u n t I n s t r u c t i o n = t r u e But only if you call it from L o n g . b i t C o u n t 15
  14. Java intrinsics L o n g . b i t

    C o u n t , I n t e g e r . b i t C o u n t I n t e g e r . r e v e r s e B y t e s , L o n g . r e v e r s e B y t e s I n t e g e r . n u m b e r O f L e a d i n g Z e r o s , L o n g . n u m b e r O f L e a d i n g Z e r o s I n t e g e r . n u m b e r O f T r a i l i n g Z e r o s , L o n g . n u m b e r O f T r a i l i n g Z e r o s S y s t e m . a r r a y c o p y ... 16
  15. Cardinality of the intersection How fast does this code run?

    i n t c = 0 ; f o r ( i n t k = 0 ; k < 1 0 2 4 ; + + k ) { c + = L o n g . b i t C o u n t ( A [ k ] & B [ k ] ) ; } A bit over ≈ 2 cycles per pair of 64‑bit words. load A, load B bitwise AND p o p c n t 17
  16. Take away Bitset vs. Bitset operations are fast even if

    you need to track the cardinality. even in Java e.g., p o p c n t overhead might be negligible compared to other costs like cache misses. 18
  17. Array vs. Array intersection Always output an array. Use galloping

    O(m log n) if the sizes differs a lot. i n t i n t e r s e c t ( A , B ) { i f ( A . l e n g t h * 2 5 < B . l e n g t h ) { r e t u r n g a l l o p i n g ( A , B ) ; } e l s e i f ( B . l e n g t h * 2 5 < A . l e n g t h ) { r e t u r n g a l l o p i n g ( B , A ) ; } e l s e { r e t u r n b o r i n g _ i n t e r s e c t i o n ( A , B ) ; } } 19
  18. Galloping intersection You have two arrays a small and a

    large one... w h i l e ( t r u e ) { i f ( l a r g e S e t [ k 1 ] < s m a l l S e t [ k 2 ] ) { f i n d k 1 b y b i n a r y s e a r c h s u c h t h a t l a r g e S e t [ k 1 ] > = s m a l l S e t [ k 2 ] } i f ( s m a l l S e t [ k 2 ] < l a r g e S e t [ k 1 ] ) { + + k 2 ; } e l s e { / / g o t a m a t c h ! ( s m a l l S e t [ k 2 ] = = l a r g e S e t [ k 1 ] ) } } If the small set is tiny, runs in O(log(size of big set)) 20
  19. Array vs. Array union Union: If sum of cardinalities is

    large, go for a bitset. Revert to an array if we got it wrong. u n i o n ( A , B ) { t o t a l = A . l e n g t h + B . l e n g t h ; i f ( t o t a l > D E F A U L T _ M A X _ S I Z E ) { / / b i t m a p ? c r e a t e e m p t y b i t m a p C a n d a d d b o t h A a n d B t o i t i f ( C . c a r d i n a l i t y < = D E F A U L T _ M A X _ S I Z E ) { c o n v e r t C t o a r r a y } e l s e i f ( C i s f u l l ) { c o n v e r t C t o r u n } e l s e { C i s f i n e a s a b i t m a p } } o t h e r w i s e m e r g e t w o a r r a y s a n d o u t p u t a r r a y } 21
  20. Array vs. Bitmap (Intersection)... Intersection: Always an array. Branchy (3

    to 16 cycles per array value): a n s w e r = n e w a r r a y f o r v a l u e i n a r r a y { i f v a l u e i n b i t s e t { a p p e n d v a l u e t o a n s w e r } } 22
  21. Branchless (3 cycles per array value): a n s w

    e r = n e w a r r a y p o s = 0 f o r v a l u e i n a r r a y { a n s w e r [ p o s ] = v a l u e p o s + = b i t _ v a l u e ( b i t s e t , v a l u e ) } 23
  22. Array vs. Bitmap (Union)... Always a bitset. Very fast. Few

    cycles per value in array. a n s w e r = c l o n e t h e b i t s e t f o r v a l u e i n a r r a y { / / b r a n c h l e s s s e t b i t i n a n s w e r a t i n d e x v a l u e } Without tracking the cardinality ≈ 1.65 cycles per value Tracking the cardinality ≈ 2.2 cycles per value 24
  23. Parallelization is not just multicore + distributed In practice, all

    commodity processors support Single instruction, multiple data (SIMD) instructions. Raspberry Pi Your phone Your PC Working with words x × larger has the potential of multiplying the performance by x. No lock needed. Purely deterministic/testable. 25
  24. SIMD is not too hard conceptually Instead of working with

    x + y you do (x , x , x , x ) + (y , y , y , y ). Alas: it is messy in actual code. 1 2 3 4 1 2 3 4 26
  25. With SIMD small words help! With scalar code, working on

    16‑bit integers is not 2 × faster than 32‑bit integers. But with SIMD instructions, going from 64‑bit integers to 16‑bit integers can mean 4 × gain. Roaring uses arrays of 16‑bit integers. 27
  26. Bitsets are vectorizable Logical ORs, ANDs, ANDNOTs, XORs can be

    computed fast with Single instruction, multiple data (SIMD) instructions. Intel Cannonlake (late 2017), AVX‑512 Operate on 64 bytes with ONE instruction → Several 512‑bit ops/cycle Java 9's Hotspot can use AVX 512 ARM v8‑A to get Scalable Vector Extension... up to 2048 bits!!! 28
  27. Java supports advanced SIMD instructions $ j a v a

    - X X : + P r i n t F l a g s F i n a l - v e r s i o n | g r e p " A V X " i n t x U s e A V X = 2 29
  28. Vectorization matters! f o r ( s i z e

    _ t i = 0 ; i < l e n ; i + + ) { a [ i ] | = b [ i ] ; } using scalar : 1.5 cycles per byte with AVX2 : 0.43 cycles per byte (3.5 × better) With AVX‑512, the performance gap exceeds 5 × Can also vectorize OR, AND, ANDNOT, XOR + population count (AVX2‑Harley‑Seal) 30
  29. Vectorization beats p o p c n t i n

    t c o u n t = 0 ; f o r ( s i z e _ t i = 0 ; i < l e n ; i + + ) { c o u n t + = p o p c o u n t ( a [ i ] ) ; } using fast scalar (popcnt): 1 cycle per input byte using AVX2 Harley‑Seal: 0.5 cycles per input byte even greater gain with AVX‑512 31
  30. Sorted arrays sorted arrays are vectorizable: array union array difference

    array symmetric difference array intersection sorted arrays can be compressed with SIMD 32
  31. Bitsets are vectorizable... sadly... Java's hotspot is limited in what

    it can autovectorize: 1. Copying arrays 2. String.indexOf 3. ... And it seems that U n s a f e effectively disables autovectorization! 33
  32. There is hope yet for Java One big reason, today,

    for binding closely to hardware is to process wider data flows in SIMD modes. (And IMO this is a long‑term trend towards right‑sizing data channel widths, as hardware grows wider in various ways.) AVX bindings are where we are experimenting, today (John Rose, Oracle) 34
  33. Fun things you can do with SIMD: Masked VByte Consider

    the ubiquitous VByte format: Use 1 byte to store all integers in [0, 2 ) Use 2 bytes to store all integers in [2 , 2 ) ... Decoding can become a bottleneck. Google developed Varint‑GB. What if you are stuck with the conventional format? (E.g., Lucene, LEB128, Protocol Buffers...) 7 7 14 35
