Parsing JSON Really Quickly: Lessons Learned

Parsing JSON Really Quickly: Lessons Learned

Our disks and networks can load gigabytes of data per second; we feel strongly that our software should follow suit. Thus we wrote what might be the fastest JSON parser in the world, simdjson. It can parse typical JSON files at speeds of over 2 GB/s on single commodity Intel core with full validation; it is several times faster than conventional parsers.

How did we go so fast? We started with the insight that we should make full use of the SIMD instructions available on commodity processors. These instructions are everywhere, from the ARM chip in your smartphone all to way to server processors. SIMD instructions work on wide registers (e.g., spanning 32 bytes): they are faster because they process more data using fewer instructions. To our knowledge, nobody had ever attempted to produce a full parser for something as complex as JSON by relying primarily on SIMD instructions. And many people were skeptical that a full parser could be done fruitfully with SIMD instructions. We had to develop interesting new strategies that are generally applicable. In the end, we learned several lessons. Maybe one of the most important lesson is the importance of a nearly obsessive focus on performance metrics. We constantly measure the impact of the choices we make.

Daniel Lemire

November 09, 2019
Tweet

More Decks by Daniel Lemire

Other Decks in Technology

Transcript

  1. Parsing JSON Really Quickly : Lessons Learned Daniel Lemire blog:

    https://lemire.me twitter: @lemire GitHub: https://github.com/lemire/ professor (Computer Science) at Université du Québec (TÉLUQ) Montreal 2
  2. How fast can you read a large file? Are you

    limited by your disk or Are you limited by your CPU? 3
  3. Reading text lines (CPU only) ~0.6 GB/s on 3.4 GHz

    Skylake in Java void parseLine(String s) { volume += s.length(); } void readString(StringReader data) { BufferedReader bf = new BufferedReader(data); bf.lines().forEach(s -> parseLine(s)); } Source available. Improved by JDK-8229022 5
  4. Reading text lines (CPU only) ~1.5 GB/s on 3.4 GHz

    Skylake in C++ (GNU GCC 8.3) size_t sum_line_lengths(char * data, size_t length) { std::stringstream is; is.rdbuf()->pubsetbuf(data, length); std::string line; size_t sumofalllinelengths{0}; while(getline(is, line)) { sumofalllinelengths += line.size(); } return sumofalllinelengths; } Source available. 6
  5. JSON Specified by Douglas Crockford RFC 7159 by Tim Bray

    in 2013 Ubiquitous format to exchange data {"Image": {"Width": 800,"Height": 600, "Title": "View from 15th Floor", "Thumbnail": { "Url": "http://www.example.com/81989943", "Height": 125,"Width": 100} } 8
  6. JSON parsing Read all of the content Check that it

    is valid JSON Check Unicode encoding Parse numbers Build DOM (document-object-model) Harder than parsing lines? 10
  7. Jackson JSON speed (Java) twitter.json: 0.35 GB/s on 3.4 GHz

    Skylake Source code available. speed Jackson (Java) 0.35 GB/s readLines C++ 1.5 GB/s disk 2.2 GB/s 11
  8. RapidJSON speed (C++) twitter.json: 0.650 GB/s on 3.4 GHz Skylake

    speed RapidJSON (C++) 0.65 GB/s Jackson (Java) 0.35 GB/s readLines C++ 1.5 GB/s disk 2.2 GB/s 12
  9. simdjson speed (C++) twitter.json: 2.4 GB/s on 3.4 GHz Skylake

    speed simdjson (C++) 2.4 GB/s RapidJSON (C++) 0.65 GB/s Jackson (Java) 0.35 GB/s readLines C++ 1.5 GB/s disk 2.2 GB/s 13
  10. Write random numbers on an array. while (howmany != 0)

    { out[index] = random(); index += 1; howmany--; } e.g., ~ 3 cycles per iteration 16
  11. Write only odd random numbers: while (howmany != 0) {

    val = random(); if( val is odd) { // <=== new out[index] = val; index += 1; } howmany--; } 17
  12. Go branchless! while (howmany != 0) { val = random();

    out[index] = val; index += (val bitand 1); howmany--; } back to under 4 cycles! Details and code available 19
  13. When possible, use SIMD Available on most commodity processors (ARM,

    x64) Originally added (Pentium) for multimedia (sound) Add wider (128-bit, 256-bit, 512-bit) registers Adds new fun instructions: do 32 table lookups at once. 22
  14. ISA where max. register width ARM NEON (AArch64) mobile phones,

    tablets 128-bit SSE2... SSE4.2 legacy x64 (Intel, AMD) 128-bit AVX, AVX2 mainstream x64 (Intel, AMD) 256-bit AVX-512 latest x64 (Intel) 512-bit 23
  15. "Intrinsic" functions (C, C++, Rust, ...) mapping to specific instructions

    on specific instructions sets Higher level functions (Swift, C++, ...): Java Vector API Autovectorization ("compiler magic") (Java, C, C++, ...) Optimized functions (some in Java) Assembly (e.g., in crypto) 24
  16. Processor frequencies are not constant Especially on laptops CPU cycles

    different from time Time can be noisier than CPU cycles 29
  17. Example 1. UTF-8 Strings are ASCII (1 byte per code

    point) Otherwise multiple bytes (2, 3 or 4) Only 1.1 M valid UTF-8 code points 31
  18. Validating UTF-8 with if/else/while if (byte1 < 0x80) { return

    true; // ASCII } if (byte1 < 0xE0) { if (byte1 < 0xC2 || byte2 > 0xBF) { return false; } } else if (byte1 < 0xF0) { // Three-byte form. if (byte2 > 0xBF || (byte1 == 0xE0 && byte2 < 0xA0) || (byte1 == 0xED && 0xA0 <= byte2) blablabla ) blablabla } else { // Four-byte form. .... blabla } 32
  19. Example: Verify that all byte values are no larger than

    244 Saturated subtraction: x - 244 is non-zero if an only if x > 244 . _mm256_subs_epu8(current_bytes, 244 ); One instruction, checks 32 bytes at once! 34
  20. Example 2. Classifying characters comma (0x2c) , colon (0x3a) :

    brackets (0x5b,0x5d, 0x7b, 0x7d): [, ], {, } white-space (0x09, 0x0a, 0x0d, 0x20) others Classify 16, 32 or 64 characters at once! 36
  21. Divide values into two 'nibbles' 0x2c is 2 (high nibble)

    and c (low nibble) There are 16 possible low nibbles. There are 16 possible high nibbles. 37
  22. ARM NEON and x64 processors have instructions to lookup 16-byte

    tables in a vectorized manner (16 values at a time): pshufb, tbl 38
  23. Start with an array of 4-bit values [1, 1, 0,

    2, 0, 5, 10, 15, 7, 8, 13, 9, 0, 13, 5, 1] Create a lookup table [200, 201, 202, 203, 204, 205, 206, 207, 208, 209, 210, 211, 212, 213, 214, 215] 0 200, 1 201, 2 202 Result: [201, 201, 200, 202, 200, 205, 210, 215, 207, 208, 213, 209, 200, 213, 205, 201] 39
  24. Find two tables H1 and H2 such as the bitwise

    AND of the look classify the characters. H1(low(c)) & H2(high(c)) comma (0x2c): 1 colon (0x3a): 2 brackets (0x5b,0x5d, 0x7b, 0x7d): 4 most white-space (0x09, 0x0a, 0x0d): 8 white space (0x20): 16 others: 0 40
  25. const uint8x16_t low_nibble_mask = (uint8x16_t){16, 0, 0, 0, 0, 0,

    0, 0, 0, 8, 12, 1, 2, 9, 0, 0}; const uint8x16_t high_nibble_mask = (uint8x16_t){8, 0, 18, 4, 0, 1, 0, 1, 0, 0, 0, 3, 2, 1, 0, 0}; const uint8x16_t low_nib_and_mask = vmovq_n_u8(0xf); Five instructions: uint8x16_t nib_lo = vandq_u8(chunk, low_nib_and_mask); uint8x16_t nib_hi = vshrq_n_u8(chunk, 4); uint8x16_t shuf_lo = vqtbl1q_u8(low_nibble_mask, nib_lo); uint8x16_t shuf_hi = vqtbl1q_u8(high_nibble_mask, nib_hi); return vandq_u8(shuf_lo, shuf_hi); 41
  26. Can you tell where the strings start and end? {

    "\\\"Nam[{": [ 116,"\\\\" ... Without branching? 43
  27. Identify backslashes: { "\\\"Nam[{": [ 116,"\\\\" ___111________________1111_ : B Odd

    and even positions 1_1_1_1_1_1_1_1_1_1_1_1_1_1 : E (constant) _1_1_1_1_1_1_1_1_1_1_1_1_1_ : O (constant) 45
  28. Do a bunch of arithmetic and logical operations... (((B +

    (B &~(B << 1)& E))& ~B)& ~E) | (((B + ((B &~(B << 1))& O))& ~B)& E) Result: { "\\\"Nam[{": [ 116,"\\\\" ... ______1____________________ No branch! 46
  29. { "\\\"Nam[{": [ 116,"\\\\" __1___1_____1________1____1 : all quotes ______1____________________ :

    escaped quotes __1_________1________1____1 : string-delimiter quotes 48
  30. Find the span of the string mask = quote xor

    (quote << 1); mask = mask xor (mask << 2); mask = mask xor (mask << 4); mask = mask xor (mask << 8); mask = mask xor (mask << 16); ... __1_________1________1____1 (quotes) becomes __1111111111_________11111_ (string region) 49
  31. Example 4. Decode bit indexes Given the bitset 1000100010001 ,

    we want the location of the 1s (e.g., 0, 4, 8 12) 51
  32. while (word != 0) { result[i] = trailingzeroes(word); word =

    word & (word - 1); i++; } If number of 1s per 64-bit is hard to predict: lots of mispredictions!!! 52
  33. Instead of predicting the number of 1s per 64-bit, predict

    whether it is in {1, 2, 3, 4} {5, 6, 7, 8} {9, 10, 11, 12} Easier! 53
  34. Reduce the number of misprediction by doing more work per

    iteration: while (word != 0) { result[i] = trailingzeroes(word); word = word & (word - 1); result[i+1] = trailingzeroes(word); word = word & (word - 1); result[i+2] = trailingzeroes(word); word = word & (word - 1); result[i+3] = trailingzeroes(word); word = word & (word - 1); i+=4; } Discard bogus indexes by counting the number of 1s in the word directly (e.g., bitCount ) 54
  35. Example 5. Number parsing is expensive strtod : 90 MB/s

    38 cycles per byte 10 branch misses per floating-point number 55
  36. Check whether we have 8 consecutive digits bool is_made_of_eight_digits_fast(const char

    *chars) { uint64_t val; memcpy(&val, chars, 8); return (((val & 0xF0F0F0F0F0F0F0F0) | (((val + 0x0606060606060606) & 0xF0F0F0F0F0F0F0F0) >> 4)) == 0x3333333333333333); } 56
  37. Then construct the corresponding integer Using only three multiplications (instead

    of 7): uint32_t parse_eight_digits_unrolled(const char *chars) { uint64_t val; memcpy(&val, chars, sizeof(uint64_t)); val = (val & 0x0F0F0F0F0F0F0F0F) * 2561 >> 8; val = (val & 0x00FF00FF00FF00FF) * 6553601 >> 16; return (val & 0x0000FFFF0000FFFF) * 42949672960001 >> 32; } Can do even better with SIMD 57
  38. int json_parse_dispatch(...) { Architecture best_implementation = find_best_supported_implementation(); // Selecting the

    best implementation switch (best_implementation) { case Architecture::HASWELL: json_parse_ptr = &json_parse_implementation<Architecture::HASWELL>; break; case Architecture::WESTMERE: json_parse_ptr= &json_parse_implementation<Architecture::WESTMERE>; break; default: return UNEXPECTED_ERROR; } return json_parse_ptr(....); } 59
  39. Where to get it? GitHub: https://github.com/lemire/simdjson/ Modern C++, single-header (easy

    integration) ARM (e.g., iPhone), x64 (going back 10 years) Apache 2.0 (no hidden patents) Used by Microsoft FishStore and Yandex ClickHouse wrappers in Python, PHP, C#, Rust, JavaScript (node), Ruby ports to Rust, Go and C# 60
  40. Reference Geoff Langdale, Daniel Lemire, Parsing Gigabytes of JSON per

    Second, VLDB Journal, https://arxiv.org/abs/1902.08318 61
  41. Credit Geoff Langdale (algorithmic architect and wizard) Contributors: Thomas Navennec,

    Kai Wolf, Tyler Kennedy, Frank Wessels, George Fotopoulos, Heinz N. Gies, Emil Gedda, Wojciech Muła, Georgios Floros, Dong Xie, Nan Xiao, Egor Bogatov, Jinxi Wang, Luiz Fernando Peres, Wouter Bolsterlee, Anish Karandikar, Reini Urban. Tom Dyson, Ihor Dotsenko, Alexey Milovidov, Chang Liu, Sunny Gleason, John Keiser, Zach Bjornson, Vitaly Baranov, Juho Lauri, Michael Eisel, Io Daza Dillon, Paul Dreik, Jérémie Piotte and others 62
  42. 63
