Unicode at gigabytes per second

Unicode at gigabytes per second

We often represent text using Unicode formats (UTF-8 and UTF-16). UTF-8 is increasingly popular (XML, HTML, JSON, Rust, Go, Swift, Ruby). UTF-16 is most common in Java, .NET, and inside operating systems such as Windows. Software systems frequently have to validate text or convert text from one encoding to the other. While recent disks have bandwidths of 5 GB/s or more, conventional approaches transcode non-ASCII text at a fraction of a gigabyte per second. We show that we can transcode (UTF-8, UTF-16) at gigabytes per second on current systems (x64 and ARM) without sacrificing safety. Our open-source library can be ten times faster than the popular ICU library on non-ASCII strings and even faster on ASCII strings.

Invited talk at SPIRE 2021, 28th International Symposium on String Processing and Information Retrieval (October 4-6th, 2021 - Lille, France)

Daniel Lemire

October 01, 2021
Tweet

More Decks by Daniel Lemire

Other Decks in Technology

Transcript

  1. Unicode at gigabytes per second Daniel Lemire with Wojciech Muła

    and John Keiser professor, Université du Québec (TÉLUQ) Montreal blog: https://lemire.me twitter: @lemire GitHub: https://github.com/lemire/ credit for figures: Wojciech Muła many other contributors!
  2. From characters to bits Morse code A : 0 1

    B : 1 0 0 0 C : 1 0 1 0 26 letters. 2
  3. Fixed-length codes Baudot code (~1860). 5 bits. Hollerith code (~1896).

    6 bits. American Standard-Code for Information Interchange or ASCII (~1961). 7 bits. 128 characters. 3
  4. 4

  5. Too many fixed-length codes! IBM: Binary Coded Decimal Interchange Code.

    6 bits. IBM: Extended Binary Coded Decimal Interchange Code or EBCDIC. 8 bits. ISO 8859 (~1987). 8 bits. European. Thai (TIS 620), Indian languages (ISCII), Vietnamese (VISCII) and Japanese (JIS X 0201). Windows character sets, Mac character sets. 5
  6. Unicode: how many bits? 16 bits ought to be enough?

    Numerical range from 0x000000 to 0x10FFFF. Would need 20 to 21 bits. 7
  7. UTF-16 and UTF-8 Two main formats. UTF-16: Java, C#, Windows

    UTF-8: XML, JSON, HTML, Go, Rust, Swift 8
  8. UTF-16 and UTF-8 character range UTF-8 bytes UTF-16 bytes ASCII

    (0000-007F) 1 2 latin (0080-07FF) 2 2 asiatic (0800-D7FF, E000-FFFF) 3 2 supplemental (010000-10FFFF) 4 4 9
  9. UTF-16 16-bit words. characters in 0000-D7FF and E000-FFFF, stored as

    16-bit values---using two bytes. characters in 010000-10FFFF are stored using a 'surrogate pair'. Comes in two flavours (little and big endian at the 16-bit level). 10
  10. UTF-16 (surrogate pair) first word in D800-DBFF. second word in

    DC00-DFFF. character value is 10 least significant bits of each---second element is least significant. add 0x10000 to the result. 11
  11. UTF-8 format Most significant bit of leading is zero, ASCII:

    [01000001]. 3 most significant bits 110, two-byte sequence: [11000100] [10000101]. 4 most significant bits 1100, three-byte sequence. 5 most significant bits 11000, four-byte sequence. Non-leading bytes have 10 as the two most significant bits. 13
  12. UTF-8 validation rules The five most significant bits of any

    byte cannot be all ones. The leading byte must be followed by the right number of continuation bytes. A continuation byte must be preceded by a leading byte. The decoded character must be larger than 7F for two-byte sequences, larger than 7FF for three-byte sequences, and larger than FFFF for four-byte sequences. The decoded code-point value must be less than 110000 The code-point value must not be in the range D800-DFFF. 14
  13. Some numbers bandwidth between node instances: over 3 GB/s PCIe

    4.0 disks (and PlayStation 5): over 5 GB/s Popular C++ trancoding library (ICU): ~1 GB/s 20
  14. UTF-8 to UTF- 16 UTF-16 to UTF- 8 validation table

    size Cameron's u8u16 (2008) yes no yes N/A Inoue et al. (2008) partial no no 105 kB simdutf yes yes yes 20 kB Software implementations (no formal paper): Goffart (2012) and Gatilov (2019) 22
  15. Vectorized permutation Can permute blocks of 16 bytes (or 32

    bytes) using a single cheap instruction. Need a precomputed shuffle mask. data : [a b c d e f g] shuffle mask : [3 1 0 3 3 2 -1] (indexes) result : [d b a d d c 0] Conversely may be used as a form of vectorized table lookup. 23
  16. UTF-8 to UTF-16 transcoding (core) Take a block of bytes.

    Continuation bytes (leading bits 10, less than -64) Non-continuation bytes are leading bytes Bytes before a leading byte end a character Build a bitmap Use the bitmap in a lookup table 24
  17. UTF-8 to UTF-16 transcoding (example) Start with... [01000001] ([11000100] [10000101])

    [01100011] ([11000011] [10000011]) [01101100] ([11000101] [10111010]) We have 9 bytes. Build a 9-bit bitmap where '1' means the end of a character 101101101 Use this as index in a table. 25
  18. UTF-8 to UTF-16 transcoding (table) If using 12-byte blocks, need

    4096-long table. Each entry points to a shuffle mask and number of consumed bytes. 26
  19. UTF-8 to UTF-16 transcoding (cases) Shuffle masks are sorted into

    'cases'. 1. First 64 cases correspond to 1-byte or 2-byte characters only. 2. Next 81 cases correspond to 1, 2 or 3 bytes per character. 3. Next 64 cases correspond to general case (1 to 4 bytes). Each case corresponds to a code path. 27
  20. 28

  21. UTF-8 to UTF-16 transcoding (more tricks) 1. Load blocks of

    64 bytes. 2. Check for fast paths (e.g. all ASCII). 3. Eat 12 bytes at a time within 64 bytes. 4. Add a few fast path (e.g., all ASCII, all 2-byte, all 3-byte). 29
  22. UTF-8 to UTF-16 transcoding (validation) Given a 64-byte block, we

    can use a fast vectorized validation routine. Validating UTF-8 In Less Than One Instruction Per Byte, Software: Practice and Experience 51 (5), 2021 30
  23. UTF-8 to UTF-16 transcoding (core algo) You can identify most

    UTF-8 errors by looking at sequences of 3 nibbles (4-bit). E.g., ASCII followed by continuation, leading not followed by continuation byte. Do three lookups (using shuffe mask) and compute a bitwise AND. We call this vectorized classification. 31
  24. Simplified vectorized classification Suppose you want to find all instances

    where value 3 is followed by value 1 or 2. Create two lookup tables. One for first nibble [0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0] second nibble [0,1,1,0,0,0,0,0,0,0,0,0,0,0,0,0] Lookup first nibble in table, lookup second, compute bitwise AND. If result is 1, you have a match. Can do this in parallel over many values. 32
  25. Fancier vectorized classification Suppose you want to find all instances

    where value 3 is followed by value 1 or 2. Value 5 followed by 0. Value 6 followed by 10. Create two lookup table2. One for first nibble [0,0,0,1,0,2,4,0,0,0,0,0,0,0,0,0] second nibble [2,1,1,0,0,0,0,0,0,0,4,0,0,0,0,0] Lookup first nibble in table, lookup second, compute bitwise AND. 33
  26. Array of nibbles: original: [a0 a1 a2 a3 a4 ...]

    shift: [a1 a2 a3 a4 ...] shift: [a2 a3 a4 ...] f([a0 a1 a2 a3 a4 ...]) AND g([a1 a2 a3 a4 ...]) AND g([a2 a3 a4 ...]) 34
  27. UTF-16 to UTF-8 (ASCII) If all 16-bit words are ASCII

    (0000-007F), use a fast routine: 16 bytes into 8 'packed' bytes. 36
  28. UTF-16 to UTF-8 (0000-07FF) If all 16-bit words are in

    (0000-07FF)... build an 8-bit bitset indicating which 16-byte words are ASCII (0000-007F), load a shuffle mask, permute and patch. 37
  29. UTF-16 to UTF-8 (0000-07FF, E000-FFFF) If all 16-bit words are

    in the ranges 0000-D7FF, E000-FFFF, we use another similar specialized routine to produce sequences of one-byte, two-byte and three-byte UTF-8 characters. Otherwise, when we detect that the input register contains at least one part of a surrogate pair, we fall back to a conventional/scalar code path. 38
  30. Experiments AMD processor (AMD EPYC 7262, Zen 2 microarchitecture, 3.39

    GHz) and GCC10. International Components for Unicode (UCI) u8u16 library lipsum text in various languages 39
  31. 41

  32. Software https://github.com/simdutf/simdutf Open source, no patent. ARM NEON, SSE, AVX...

    Support runtime dispatch: adapts to your CPU. Easy to use: drop simdutf.cpp and simdutf.h in your project. Compiles to tens of kilobytes. 42
  33. Further reading Lemire, Daniel and Wojciech Muła , Transcoding Billions

    of Unicode Characters per Second with SIMD Instructions, Software: Practice and Experience (to appear) https://r-libre.teluq.ca/2400/ Blog: https://lemire.me/blog/ 43
