  1. Next Generation Indexes For Big Data Engineering Daniel Lemire and

    collaborators blog: https://lemire.me twitter: @lemire Université du Québec (TÉLUQ) Montreal Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018.
  2. Knuth on performance Premature optimization is the root of all

    evil Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018.
  3. Knuth on performance Premature optimization is the root of all

    evil (...) After a programmer knows which parts of his routines are really important, a transformation like doubling up of loops will be worthwhile. Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018.
  4. Constants matter fasta benchmark: elapsed time total time (all processors)

    single‑threaded 1.36 s 1.36 s https://benchmarksgame‑ team.pages.debian.net/benchmarksgame/performance/fasta.html Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018.
  5. Constants matter fasta benchmark: elapsed time total time (all processors)

    single‑threaded 1.36 s 1.36 s multicore (4 cores) 1.00 s 2.00 s Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018.
  6. Constants matter fasta benchmark: elapsed time total time (all processors)

    single‑threaded 1.36 s 1.36 s multicore (4 cores) 1.00 s 2.00 s vectorized (1 core) 0.31 s 0.31 s https://lemire.me/blog/2018/01/02/multicore‑versus‑simd‑ instructions‑the‑fasta‑case‑study/ Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018.
  7. “One Size Fits All”: An Idea Whose Time Has Come

    and Gone (Stonebraker, 2005) Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 7
  8. Rediscover Unix In 2018, Big Data Engineering is made of

    several specialized and re‑ usable components: Calcite : SQL + optimization Hadoop etc. Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 8
  9. "Make your own database engine from parts" We are in

    a Cambrian explosion, with thousands of organizations and companies building their custom high‑speed systems. Specialized used cases Heterogeneous data (not everything is in your Oracle DB) Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 9
  10. For high‑speed in data engineering you need... Front‑end (data frame,

    SQL, visualisation) High‑level optimizations Indexes (e.g., Pilosa, Elasticsearch) Great compression routines Specialized data structures .... Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 10
  11. Sets A fundamental concept (sets of documents, identifiers, tuples...) →

    For performance, we often work with sets of integers (identifiers). Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 11
  12. tests : x ∈ S? intersections : S ∩ S

    , unions : S ∪ S , differences : S ∖ S Similarity (Jaccard/Tanimoto): ∣S ∩ S ∣/∣S ∪ S ∣ Iteration f o r x i n S d o p r i n t ( x ) 2 1 2 1 2 1 1 1 1 2 Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 12
  13. How to implement sets? sorted arrays ( s t d

    : : v e c t o r < u i n t 3 2 _ t > ) hash tables ( j a v a . u t i l . H a s h S e t < I n t e g e r > , s t d : : u n o r d e r e d _ s e t < u i n t 3 2 _ t > ) … bitmap ( j a v a . u t i l . B i t S e t ) compressed bitmaps Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 13
  14. Arrays are your friends w h i l e (

    l o w < = h i g h ) { i n t m I = ( l o w + h i g h ) > > > 1 ; i n t m = a r r a y . g e t ( m I ) ; i f ( m < k e y ) { l o w = m I + 1 ; } e l s e i f ( m > k e y ) { h i g h = m I - 1 ; } e l s e { r e t u r n m I ; } } r e t u r n - ( l o w + 1 ) ; Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 14
  15. Hash tables value x at index h(x) random access to

    a value in expected constant‑time much faster than arrays Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 15
  16. in‑order access is kind of terrible [15, 3, 0, 6,

    11, 4, 5, 9, 12, 13, 8, 2, 1, 14, 10, 7] [15, 3, 0, 6, 11, 4, 5, 9, 12, 13, 8, 2, 1, 14, 10, 7] [15, 3, 0, 6, 11, 4, 5, 9, 12, 13, 8, 2, 1, 14, 10, 7] [15, 3, 0, 6, 11, 4, 5, 9, 12, 13, 8, 2, 1, 14, 10, 7] [15, 3, 0, 6, 11, 4, 5, 9, 12, 13, 8, 2, 1, 14, 10, 7] [15, 3, 0, 6, 11, 4, 5, 9, 12, 13, 8, 2, 1, 14, 10, 7] (Robin Hood, linear probing, MurmurHash3 hash function) Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 16
  17. Set operations on hash tables h 1 < - h

    a s h s e t h 2 < - h a s h s e t . . . f o r ( x i n h 1 ) { i n s e r t x i n h 2 / / c a c h e m i s s ? } Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 17
  18. "Crash" Swift v a r S 1 = S e

    t < I n t > ( 1 . . . s i z e ) v a r S 2 = S e t < I n t > ( ) f o r i i n d { S 2 . i n s e r t ( i ) } Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 18
  19. Some numbers: half an hour for 64M keys size time

    (s) 1M 0.8 8M 22 64M 1400 Maps and sets can have quadratic‑time performance https://lemire.me/blog/2017/01/30/maps‑and‑sets‑can‑have‑ quadratic‑time‑performance/ Rust hash iteration+reinsertion https://accidentallyquadratic.tumblr.com/post/153545455987/ru st‑hash‑iteration‑reinsertion Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 19
  20. Bitmaps Efficient way to represent sets of integers. For example,

    0, 1, 3, 4 becomes 0 b 1 1 0 1 1 or "27". {0} → 0 b 0 0 0 0 1 {0, 3} → 0 b 0 1 0 0 1 {0, 3, 4} → 0 b 1 1 0 0 1 {0, 1, 3, 4} → 0 b 1 1 0 1 1 Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 21
  21. Manipulate a bitmap 64‑bit processor. Given x , word index

    is x / 6 4 and bit index x % 6 4 . a d d ( x ) { a r r a y [ x / 6 4 ] | = ( 1 < < ( x % 6 4 ) ) } Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 22
  22. How fast is it? i n d e x =

    x / 6 4 - > a s h i f t m a s k = 1 < < ( x % 6 4 ) - > a s h i f t a r r a y [ i n d e x ] | - m a s k - > a O R w i t h m e m o r y One bit every ≈ 1.65 cycles because of superscalarity Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 23
  23. Bit parallelism Intersection between {0, 1, 3} and {1, 3}

    a single AND operation between 0 b 1 0 1 1 and 0 b 1 0 1 0 . Result is 0 b 1 0 1 0 or {1, 3}. No branching! Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 24
  24. Bitmaps love wide registers SIMD: Single Intruction Multiple Data SSE

    (Pentium 4), ARM NEON 128 bits AVX/AVX2 (256 bits) AVX‑512 (512 bits) AVX‑512 is now available (e.g., from Dell!) with Skylake‑X processors. Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 25
  25. Bitsets can take too much memory {1, 32000, 64000} :

    1000 bytes for three values We use compression! Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 26
  26. Git (GitHub) utilise EWAH Run‑length encoding Example: 000000001111111100 est 00000000

    − 11111111 − 00 Code long runs of 0s or 1s efficiently. https://github.com/git/git/blob/master/ewah/bitmap.c Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 27
  27. Complexity Intersection : O(∣S ∣ + ∣S ∣) or O(min(∣S

    ∣, ∣S ∣)) In‑place union (S ← S ∪ S ): O(∣S ∣ + ∣S ∣) or O(∣S ∣) 1 2 1 2 2 1 2 1 2 2 Daniel Lemire, Séminaires du doctorat en informatique cognitive, septembre 2018. 28
  28. Roaring Bitmaps http://roaringbitmap.org/ Apache Lucene, Solr et Elasticsearch, Metamarkets’ Druid,

    Apache Spark, Apache Hive, Apache Tez, Netflix Atlas, LinkedIn Pinot, InfluxDB, Pilosa, Microsoft Visual Studio Team Services (VSTS), Couchbase's Bleve, Intel’s Optimized Analytics Package (OAP), Apache Hivemall, eBay’s Apache Kylin. Java, C, Go (interoperable) Roaring bitmaps 29
  29. Hybrid model Set of containers sorted arrays ({1,20,144}) bitset (0b10000101011)

    runs ([0,10],[15,20]) Related to: O'Neil's RIDBit + BitMagic Roaring bitmaps 30
  30. Roaring All containers are small (8 kB), fit in CPU

    cache We predict the output container type during computations E.g., when array gets too large, we switch to a bitset Union of two large arrays is materialized as a bitset... Dozens of heuristics... sorting networks and so on Roaring bitmaps 32
  31. Use Roaring for bitmap compression whenever possible. Do not use

    other bitmap compression methods (Wang et al., SIGMOD 2017) Roaring bitmaps 33
  32. Unions of 200 bitmaps bits per stored value bitset array

    hash table Roaring census1881 524 32 195 15.1 weather 15.3 32 195 5.38 cycles per input value: bitset array hash table Roaring census1881 9.85 542 1010 2.6 weather 0.35 94 237 0.16 Roaring bitmaps 34
  33. Sometimes you do want arrays!!! But you'd like to compress

    them up. N ot always: compression can be counterproductive. Still, if you must compress, you want to do it fast Integer compression 35
  34. Integer compression "Standard" technique: VByte, VarInt, VInt Use 1, 2,

    3, 4, ... byte per integer Use one bit per byte to indicate the length of the integers in bytes Lucene, Protocol Buffers, etc. Integer compression 36
  35. varint‑GB from Google VByte: one branch per integer varint‑GB: one

    branch per 4 integers each 4‑integer block is preceded byte a control byte Integer compression 37
  36. Vectorisation Stepanov (STL in C++) working for Amazon proposed varint‑G8IU

    Use vectorization (SIMD) P atented Fastest byte‑oriented compression technique (until recently) SIMD‑Based Decoding of Posting Lists, CIKM 2011 https://stepanovpapers.com/SIMD_Decoding_TR.pdf Integer compression 38
  37. Observations from Stepanov et al. We can vectorize Google's varint‑GB,

    but it is not as fast as varint‑ G8IU Integer compression 39
  38. Stream VByte Reuse varint‑GB from Google But instead of mixing

    control bytes and data bytes, ... We store control bytes separately and consecutively... Daniel Lemire, Nathan Kurz, Christoph Rupp Stream VByte: Faster Byte‑Oriented Integer Compression Information Processing Letters 130, 2018 Integer compression 40
  39. Stream VByte is used by... Redis (within RediSearch) https://redislabs.com upscaledb

    https://upscaledb.com Trinity https://github.com/phaistos‑networks/Trinity Integer compression 42
  40. Dictionary coding Use, e.g., by Apache Arrow Given a list

    of values: "Montreal", "Toronto", "Boston", "Montreal", "Boston"... Map to integers 0, 1, 2, 0, 2 Compress integers: Given 2 distinct values... Can use n‑bit per values (binary packing, patched coding, frame‑ of‑reference) n Integer compression 43
  41. Dictionary coding + SIMD dict. size bits per value scalar

    AVX2 (256‑ bit) AVX‑512 (512‑ bit) 32 5 8 3 1.5 1024 10 8 3.5 2 65536 16 12 5.5 4.5 (cycles per value decoded) https://github.com/lemire/dictionary Integer compression 44
  42. To learn more... Blog (twice a week) : https://lemire.me/blog/ GitHub:

    https://github.com/lemire Home page : https://lemire.me/en/ CRSNG : F aster C ompressed I ndexes O n N ext‑G eneration H ardware (2017‑2022) Twitter @lemire @lemire 45
