Serverless landscape in Google Cloud

An overview of Cloud Functions, Knative, Cloud Run, Eventarc and Workflows on Google Cloud

1. Mete Atamel Developer Advocate at Google @meteatamel atamel.dev speakerdeck.com/meteatamel Serverless landscape in Google Cloud Cloud Functions, Knative/Cloud Run, Eventarc, Workflows
2. Operational Model Programming Model No Infra Management Managed Security Pay only for usage Service-based Event-driven Stateless Serverless
3. Proprietary + Confidential Virtual Machine OS Application Runtime Application Virtual Hardware Dedicated Server OS Application Runtime Application Virtual Hardware Containers OS Application Runtime Application Virtual Hardware Functions Functions Functions Application Platform OS Application Runtime Application Virtual Hardware Functions Serverless OS Application Runtime Application Virtual Hardware Functions Infrastructure Container Platform Function Compute Engine Kubernetes Engine App Engine Cloud Functions On-Premises Serverless Zone Physical Hardware Cloud Run
4. Serverless functions Serverless web applications Serverless HTTP workloads Source code-based event driven functions Source code-based web apps and API backends HTTP containers fully managed HTTP containers on GKE cluster Cloud Functions App Engine Cloud Run Serverless compute options
5. Proprietary + Confidential Functions that trigger in response to events Microservices Cloud "glue" Certain versions of Node.js, Python, Go, Java, .NET, PHP, Ruby Cloud Functions
6. Cloud Functions as cloud glue Access 20+ Google services from GCF Cloud Storage Cloud Pub/Sub HTTPS Firebase Cloud Scheduler Cloud Tasks
7. Certain versions of Node.js, Python, Go, Java, .NET, PHP, Ruby • Node.js 10, 12, 14 • Python 3.7, 3.8, 3.9 • Go 1.11, 1.13 • Java 11 • .NET Core 3.1 • PHP 7.4 • Ruby 2.6, 2.7
8. What to do when Cloud Functions runtime is not enough? Create your own runtime!
9. Containers Any language Any library Ecosystem around containers .js .rb .go .py .sh … 0 1 0 1 0 0 1 1 1
10. Containers Flexibility Serverless Velocity
11. Cloud Run Fully managed, deploy your workloads and don’t see the cluster. Cloud Run on Anthos Deploy into Anthos, run serverless side-by-side with your existing workloads. Knative Everywhere Use the same APIs and tooling anywhere you run Kubernetes with Knative. Serverless containers with Knative and Cloud Run
12. Knative Stack Serving Eventing Kubernetes Platform Products Components Cloud Run Cloud Run on Anthos Gateway Kourier Istio
13. Confidential & Proprietary Knative Serving What is it? Rapid deployment of serverless containers Automatic (0-n) scaling Configuration and revision management Traffic splitting between revisions
14. Confidential & Proprietary Knative Serving Knative Service High level abstraction for the application Configuration Current/desired state of an application Code & configuration separated (a la 12-factor) Revision Point in time snapshots for your code and configuration Route Maps traffic to revisions
15. Container to production in seconds Natively Serverless One experience, where you want it Cloud Run (Managed Knative Serving on Google Cloud)
16. Confidential & Proprietary Knative Eventing What is it? For loosely coupled, event-driven services A number of different delivery methods Scales from just few events to live streams Uses standard CloudEvents Delivery Methods Event source(s) Event type(s) Event consumer(s)
17. Confidential & Proprietary Knative Eventing Namespace subscribe Trigger Service (Callable) Broker Trigger Service (Callable) subscribe filter= filter= ✓ ✓ ✓ Source Events Source Events ingress ingress publish
18. Confidential & Proprietary CloudEvents - cloudevents.io { "specversion": "1.0", "type": "com.github.pull.create", "source": "https://github.com/cloudevents/spec/pull/123", "id": "A234-1234-1234", "time": "2019-04-08T17:31:00Z", "datacontenttype": "application/json", "data": "{ GitHub Payload... }" } FTP GitHub GCS Broker FTP Receive Adapter GitHub Receive Adapter GCS Receive Adapter CloudEvent
19. Confidential & Proprietary Event Sources Name Description Apache Camel Allows to use Apache Camel components for pushing events into Knative Apache Kafka Brings Apache Kafka messages into Knative AWS SQS Brings AWS Simple Queue Service messages into Knative Cron Job Uses an in-memory timer to produce events on the specified Cron schedule. GCP PubSub Brings GCP PubSub messages into Knative GitHub Brings GitHub organization/repository events into Knative GitLab Brings GitLab repository events into Knative. Google Cloud Scheduler Google Cloud Scheduler events in Knative when jobs are triggered Google Cloud Storage Brings Google Cloud Storage bucket/object events into Knative Kubernetes Brings Kubernetes cluster/infrastructure events into Knative https://github.com/knative/docs/tree/master/docs/eventing/sources
20. Confidential & Proprietary Knative GCP Project - github.com/google/knative-gcp Easy configuration and consumption of Google Cloud Platform events in Knative Ready to use event sources: 1. CloudPubSubSource 2. CloudStorageSource 3. CloudSchedulerSource 4. CloudAuditLogsSource 5. CloudBuildSource
21. BigQuery Processing Pipeline - Knative github.com/meteatamel/knative-tutorial/blob/master/docs/image-processing-pipeline.md
22. What about Knative Eventing on Google Cloud?
23. A new way of getting events to managed Cloud Run services Private alpha since early 2020 as Events for Cloud Run Public GA as Eventarc in J Public GA as Eventarc in Jan 2021 Inspired by Knative Eventing an 202 Eventarc
24. Eventarc - Vision
25. Eventarc - Current State
26. Create a trigger for new object creation in Cloud Storage → Cloud Run gcloud eventarc triggers create trigger-auditlog \ --destination-run-service=${SERVICE_NAME} \ --destination-run-region=${REGION} --event-filters="type=google.cloud.audit.log.v1.written" \ --event-filters="serviceName=storage.googleapis.com" \ --event-filters="methodName=storage.objects.create" \ --service-account=${PROJECT_NO}-compute@developer.gserviceaccount.com gcloud - AuditLog
27. Create a trigger for Pub/Sub messages → Cloud Run gcloud eventarc triggers create trigger-pubsub \ --destination-run-service=${SERVICE_NAME} \ --destination-run-region=${REGION} --event-filters="type=google.cloud.pubsub.topic.v1.messagePublished" --transport-topic=projects/${PROJECT_ID}/topics/${TOPIC_ID} gcloud - Pub/Sub
28. Cloud Console - Trigger section of Cloud Run
29. POST / HTTP/1.1 Content-Type: application/json; charset=utf-8 Content-Length: 33 ce-specversion: 1.0 ce-type: google.cloud.pubsub.topic.publish ce-time: 2020-09-05T03:56:24Z ce-id: 1234-1234-1234 ce-source: mycontext/subcontext custom-attr: 42 { "message": "Hello Cloud Next!" } CloudEvents cloudevents.io "Data" "Context"
30. Cloud Run Service CloudEvent SDK HTTP request → CloudEvent in your language cloudevents.io Google Events Library Type library for CloudEvent#data Event parsing libraries HTTP POST to Cloud Run URL HTTP body is a CloudEvent with event data ("binary" CloudEvent V1) (optional) (optional) github.com/googleapis/google-cloudevents
31. const { HTTP } = require("cloudevents"); const {toLogEntryData} = require('@google/events/cloud/audit/v1/LogEntryData') app.post('/', async (req, res) => { // Read CloudEvent using CloudEvents SDK const cloudEvent = HTTP.toEvent({ headers: req.headers, body: req.body }); // Read AuditLog using Google.Events library for Node.js const logEntryData = toLogEntryData(cloudEvent.data); // Extract bucket and objectName const tokens = logEntryData.protoPayload.resourceName.split('/'); const bucket = tokens[3]; const objectName = tokens[5];
32. using CloudNative.CloudEvents; using Google.Events; using Google.Events.Protobuf.Cloud.PubSub.V1; public async Task<CloudEvent> Read(HttpContext context) { // Read CloudEvent using CloudEvents SDK var cloudEvent = await context.Request.ReadCloudEventAsync(); // Read Pub/Sub message using Google.Events library for .NET var messagePublishedData = CloudEventConverters.ConvertCloudEventData<MessagePublishedData>(cloudEvent); // Extract the Pub/Sub message var pubSubMessage = messagePublishedData.Message;
33. BigQuery Processing Pipeline - Cloud Run + Eventarc github.com/GoogleCloudPlatform/eventarc-samples/tree/main/processing-pipelines/bigquery
34. Choreography vs Orchestration in microservices
35. Choreography (event-driven) Event-driven services Frontend App Engine Order request Payment Processor Cloud Run Authorize & charge CC Shipper Cloud Functions Prepare & ship items Notifier Cloud Run Notify user Message Broker
36. Choreography: Pros and Cons Pros ➕ Services are loosely coupled ➕ Services can be changed / scaled independently ➕ No single point of failure ➕ Events are useful to extend the system Cons ➖ Difficult to monitor the whole system ➖ Errors / retries / timeouts are hard ➖ The business flow is not captured explicitly ➖ Who ensures the whole transaction is successful?
37. Orchestration Orchestrated services Frontend App Engine Order request Payment Processor Cloud Run Authorize & charge CC Shipper Cloud Functions Prepare & ship items Notifier Cloud Run Notify user Orchestrator
38. Orchestration: Pros and Cons Pros ➕ Business flow captured centrally and source controlled ➕ Each step can be monitored ➕ Errors / retries / timeouts are centralized ➕ Use simple REST, no need for events ➕ Services are still independent Cons ➖ A new orchestrator service to worry about ➖ Orchestrator could be a single point of failure ➖ Reliance on REST means more tight-coupling
39. Which one is better?
40. It depends... Choreography Services are not closely related Services can exist in different bounded contexts Orchestration Can you describe the business logic in a flow chart? Are services closely related? Do you want to stay in REST?
41. Serverless Compute External API’s Google API’s etc... Workflows - orchestrate & integrate SaaS API’s Private API’s Other Clouds
42. - processPayment: call: http.post args: url: https://payment-processor.run.app/... body: input: ${paymentDetails} result: processResult - shipItems: call: http.post args: url: https://.../cloudfunctions.net/ship body: input: ${processResult.body} result: shipResult - notifyUser: call: http.post ... Payment Processor Cloud Run Authorize & charge CC Notifier Cloud Run Notify user Shipper Cloud Functions Prepare & ship items YAML or JSON syntax
43. Payment Processor Cloud Run Authorize & charge CC Notifier Cloud Run Notify user Shipper Cloud Functions Prepare & ship items Payment Processor Cloud Run Authorize & charge CC Notifier Cloud Run Notify user Shipper Cloud Functions Prepare & ship items WAIT Payment Processor Cloud Run Authorize & charge CC Notifier Cloud Run Notify user Shipper Cloud Functions Prepare & ship items shipmentDetails userDetails Step Sequencing Serverless Pause Variable passing JSON Parsing Steps
44. Errors and retries Payment Processor Cloud Run Authorize & charge CC Notifier Cloud Run Notify user Shipper Cloud Functions Prepare & ship items MAX: 5 times BACKOFF Payment Processor Cloud Run Authorize & charge CC Notifier Cloud Run Notify user Shipper Cloud Functions Prepare & ship items Pager Cloud Run Escalate to support SUCCESS ERROR Configurable retries Configurable exception handling
45. Conditionals and 3rd party calls Notifier Cloud Run Notify user Shipper Cloud Functions Prepare & ship items Pager Cloud Run Escalate to support SUCCESS ERROR Out of Stock? No Request from the supplier Yes Read inventory Inventory DB Update inventory Inventory DB Supplier API
46. Other useful features Subworkflows to encapsulate common reusable flows Connectors ßeta to connect to other Google Cloud services & APIs
47. Deploy, execute, manage workflows # Deploy a workflow gcloud workflows deploy my-workflow --source=workflow.yaml # Execute a workflow gcloud workflows execute my-workflow # See the result gcloud workflows executions describe <your-execution-id> --workflow my-workflow
49. @meteatamel speakerdeck.com/meteatamel github.com/meteatamel/knative-tutorial github.com/meteatamel/cloudrun-tutorial github.com/GoogleCloudPlatform/eventarc-samples github.com/GoogleCloudPlatform/workflows-demos Thank you!
