Has your puppy joined the dark side?

Has your puppy joined the dark side?

Machine learning is permeating mobile and web app development. To create modern, interactive apps that can evolve over time, it's a good idea to learn how to build and use machine learning models. What better way to super-charge an App than to integrate some AI? I'll step you through how to build a web app, embed an ML model that is trained using the Custom Vision AI service to tell if the furry animals living in your house are Shihtzu or Ewoks. In this talk I'll share my experience of building a progressive web app, integrating ML and adding in a bit of Continuous Integration/Continuous Delivery (CI/CD) to push updates to GitHub. By the end of the session you should be able to build your own app [Note: There will be gratuitous puppy and Ewok pictures throughout].
You can play with the App here: https://aka.ms/ewok
You can find the code here: https://aka.ms/GitHubEwok
You can find the deck with the side-by-side code comparison: https://aka.ms/PWAChange
Demo of the Custom Vision + ML here: https://youtu.be/_S5rYsLMd2s
Demo of the push from VSCode to GitHub and Azure: https://youtu.be/J9nyKkN6sWk
You can find a LiveCode video here: https://youtu.be/ZaV6tGFNL8g
Technorama BE was not recorded

Michelle Sandford

May 24, 2022
Tweet

More Decks by Michelle Sandford

Other Decks in Technology

Transcript

  1. Has your puppy joined the dark side? Michelle Sandford Microsoft

    Developer Engagement Lead Emerging Communities (Students/Career-Change/Data- Science+AI)
  2. Choices: Uh, what kind of App do I build? Low

    Code/No Code Native Web – Static/Dynamic Progressive Web App Mobile Can we just skip to the good part? #Technorama @codess_aus
  3. App.vue <template> <div id="app"> <img alt="Vue logo" src="./assets/logo.png"> <HelloWorld msg="Welcome

    to Your Vue.js App"/> </div> </template> <script> import HelloWorld from './components/HelloWorld.vue' export default { name: 'App', components: { HelloWorld } } </script> <template> <div id="app"> <DetectImage msg=“Has your puppy joined the dark side"/> </div> </template> <script> import DetectImage from './components/DetectImage.vue' export default { name: 'App', components: { DetectImage } } </script> Rename HelloWorld.vue and change all references to it #Technorama @codess_aus
  4. Create images Folder and replace links with image and button

    DetectImage.vue <template> <div class="hello"> <h1>{{ msg }}</h1> <p> For a guide and recipes on how to configure / customize this project,<br> check out the <a href="https://cli.vuejs.org" target="_blank" rel="noopener">vue-cli documentation</a>. </p> <h3>Installed CLI Plugins</h3> <ul> <li><a href="https://github.com/vuejs/vue- cli/tree/dev/packages/%40vue/cli-plugin-babel" target="_blank" rel="noopener">babel</a></li> <template> <div class="hello"> <h1>{{ msg }}</h1> <!-- Display an image --> <div> <img class="image" ref="img" :src="require('../assets/images/' + getImgIndex + '.jpg')"/> </div> <!-- Display a button --> <div> <button class="button" @click="next()" :disabled="disable">Next</button> </div> </div> </template> #Technorama @codess_aus
  5. Add a data method DetectImage.vue <script> export default { name:

    'HelloWorld', props: { msg: String } } </script> <script> export default { name: "DetectImage", props: { msg: String }, // create a placeholder for the data data() { return { image: 0, numImages: 21 }; }, }; </script> #Technorama @codess_aus
  6. Create a Computed Property to return the index of an

    image DetectImage.vue data() { return { image: 0, numImages: 21 }; }, data() { return { image: 0, numImages: 21 }; }, // return the index of the image computed: { getImgIndex() { return this.image.toString(); }, disable() { if (this.image == this.numImages) { return true; } else return false; }, }, } </script> #Technorama @codess_aus
  7. Create a Methods Object to capture user interaction DetectImage.vue //

    return the index of the image computed: { getImgIndex() { return this.image.toString(); }, disable() { if (this.image == this.numImages) { return true; } else return false; } }, computed: { getImgIndex() { return this.image.toString(); }, disable() { if (this.image == this.numImages) { return true; } else return false; } }, // capture user interaction methods: { next() { this.image++; this.predictions = []; setTimeout(this.predict, 500); } } }; </script> #Technorama @codess_aus
  8. Let’s update those styles DetectImage.vue <!-- Add "scoped" attribute to

    limit CSS to this component only --> <style scoped> h3 { margin: 40px 0 0; } ul { list-style-type: none; padding: 0; } li { display: inline-block; margin: 0 10px; } a { color: #42b983; } </style> <!-- bling bling baby --> <style scoped> h3 { margin: 40px 0 0; } .image { min-height: 500px; max-height: 500px; max-width: 100%; } .button { width: 200px; height: 50px; border-radius: 5px; background-color: blueviolet; color: white; font-size: 20pt; margin: 10px; } .button:disabled, .button[disabled] { border: 1px solid #999999; background-color: #cccccc; color: #666666; } </style> #Technorama @codess_aus
  9. Install the custom vision package Package.json "dependencies": { "core-js": "^3.6.5",

    "register-service-worker": "^1.7.1", "vue": "^2.6.11" }, "devDependencies": { "@vue/cli-plugin-babel": "~4.5.15", "@vue/cli-plugin-eslint": "~4.5.15", "@vue/cli-plugin-pwa": "~4.5.15", "@vue/cli-service": "~4.5.15", "babel-eslint": "^10.1.0", "eslint": "^6.7.2", "eslint-plugin-vue": "^6.2.2", "vue-template-compiler": "^2.6.11" }, "dependencies": { "core-js": "^3.6.5", "register-service-worker": "^1.7.1", "customvision-tfjs": "^1.0.1", "vue": "^2.6.11" }, "devDependencies": { "@vue/cli-plugin-babel": "~4.5.15", "@vue/cli-plugin-eslint": "~4.5.15", "@vue/cli-plugin-pwa": "~4.5.15", "@vue/cli-service": "~4.5.15", "babel-eslint": "^10.1.0", "eslint": "^6.7.2", "eslint-plugin-vue": "^6.2.2", "raw-loader": "^4.0.0", "webpack-cli": "^3.3.10", "vue-template-compiler": "^2.6.11" }, #Technorama @codess_aus
  10. Integrate the custom vision package DetectImage.vue <script> export default {

    name: "DetectImage", props: { msg: String }, <script> //integrate the customvision packages import * as cvstfjs from "customvision-tfjs"; import labels from "raw-loader!../../public/models/labels.txt"; export default { name: "DetectImage", props: { msg: String }, #Technorama @codess_aus
  11. Read the labels.txt file Webpack.config.js module.exports = { module: {

    rules: [ { test: /\.txt$/i, use: 'raw-loader', }, ], }, }; #Technorama @codess_aus
  12. Complete the Data elements section DetectImage.vue // create a placeholder

    for the data data() { return { image: 0, numImages: 21 }; }, // data elements data() { return { labels: labels, model: null, predictions: [], image: 0, numImages: 21 }; }, #Technorama @codess_aus
  13. Add a mounted lifecycle hook DetectImage.vue // return the index

    of the image computed: { getImgIndex() { return this.image.toString(); }, disable() { if (this.image == this.numImages) { return true; } else return false; } }, // return the index of the image computed: { getImgIndex() { return this.image.toString(); }, disable() { if (this.image == this.numImages) { return true; } else return false; } }, // load the model async mounted() { this.image++; //load up a new model this.model = new cvstfjs.ClassificationModel(); await this.model.loadModelAsync("models/model.json"); //parse labels this.labels = labels.split("\n").map(e => { return e.trim(); }); //run prediction this.predict(); }, #Technorama @codess_aus
  14. Add the asynchronous method DetectImage.vue // capture user interaction methods:

    { next() { this.image++; this.predictions = []; setTimeout(this.predict, 500); } } }; </script> methods: { async predict() { //execute inference let prediction = await this.model.executeAsync(this.$refs.img); let label = prediction[0]; //build up a predictions object by parsing details to labels and probability this.predictions = label.map((p, i) => { return { index: i, label: this.labels[i], probability: p * 100 }; }); }, // capture user interaction next() { this.image++; this.predictions = []; //this.predict(); setTimeout(this.predict, 500); } } }; </script> }, #Technorama @codess_aus
  15. Show the confidence level in the UI DetectImage.vue <template> <div

    class="hello"> <h1>{{ msg }}</h1> <!-- Display an image --> <div> <img class="image" ref="img" :src="require('../assets/images/' + getImgIndex + '.jpg')" /> </div> <!-- Display a button --> <div> <button class="button" @click="next()" :disabled="disable">Next</button> </div> </div> </template> <template> <div class="hello"> <h1>{{ msg }}</h1> <div> <img class="image" ref="img" :src="require('../assets/images/' + getImgIndex + '.jpg')" /> </div> <div> <button class="button" @click="next()" :disabled="disable">Next</button> </div> <!-- display the interactions in the UI --> <div v-for="pred in predictions" :key="pred.index">{{ pred.label }}: {{ pred.probability.toFixed(0) + '%' }}</div> <div v-if="!predictions.length">hmm.....</div> </div> </template> #Technorama @codess_aus
  16. Run on windows Web.config <?xml version="1.0" encoding="utf-8"?> <configuration> <system.webServer> <staticContent>

    <remove fileExtension=".json"/> <mimeMap fileExtension=".json" mimeType="application/json"/> </staticContent> </system.webServer> </configuration> #Technorama @codess_aus
  17. Create a Static Web App and Deploy to Azure with

    GitHub Actions #Technorama @codess_aus
  18. Resources Code https://aka.ms/GitHubEwok Ewok or Chouleke App https://aka.ms/ewok Side by

    Side Code Changes https://aka.ms/PWAChange MS Learn Path (long version) https://aka.ms/LearnPWA #Technorama @codess_aus
