  1. Spark and Shark: High-speed In-memory Analytics over Hadoop Data May

    14, 2013 @ Oracle Reynold Xin, AMPLab, UC Berkeley
  2. The Big Data Problem Data is growing faster than computation

    speeds Accelerating data sources » Web, mobile, scientific, … Cheap storage Stalling clock rates
  3. Result Processing has to scale out over large clusters Users

    are adopting a new class of systems » Hadoop MapReduce now used at banks, retailers, … » $1B market by 2016
  4. Berkeley Data Analytics Stack Spark Shark SQL HDFS / Hadoop

    Storage Mesos Resource Manager Spark Streaming GraphX MLBase
  5. Today’s Talk Spark Shark SQL HDFS / Hadoop Storage Mesos

    Resource Manager Spark Streaming GraphX MLBase
  6. Spark Separate, fast, MapReduce-like engine » In-memory storage for fast iterative

    computations » General execution graphs » Up to 100X faster than Hadoop MapReduce Compatible with Hadoop storage APIs » Read/write to any Hadoop-supported systems, including HDFS, Hbase, SequenceFiles, etc
  7. Shark An analytics engine built on top of Spark » Support

    both SQL and complex analytics » Up to 100X faster than Apache Hive Compatible with Hive data, metastore, queries » HiveQL » UDF / UDAF » SerDes » Scripts
  8. Community 3000 people attended online training 800 meetup members 14

    companies contributing spark-­‐project.org
  9. Today’s Talk Spark Shark SQL HDFS / Hadoop Storage Mesos

    Resource Manager Spark Streaming GraphX MLBase
  10. Background Two things make programming clusters hard: » Failures: amplified at

    scale (1000 nodes è 1 fault/day) » Stragglers: slow nodes (e.g. failing hardware) MapReduce brought the ability to handle these automatically map map map reduce reduce Replicated
  11. One Reaction Specialized models for some of these apps » Google

    Pregel for graph processing » Iterative MapReduce » Storm for streaming Problem: » Don’t cover all use cases » How to compose in a single application?
  12. Observation Complex, streaming and interactive apps all need one thing

    that MapReduce lacks: Efficient primitives for data sharing
  13. Goal: Sharing at Memory Speed iter. 1 iter. 2 …

    Input Iterative: Interactive: Input query 1 query 2 select … 10-100x faster than network/disk, but
  14. Existing Storage Systems Based on a general “shared memory” model

    » Fine-grained updates to mutable state » E.g. databases, key-value stores, RAMCloud Requires replicating data across the network for fault tolerance » 10-100× slower than memory write!
  15. Restricted form of shared memory » Immutable, partitioned sets of records

    » Can only be built through coarse-grained, deterministic operations (map, filter, join, …) Enables fault recovery using lineage » Log one operation to apply to many elements » Recompute any lost partitions on failure Solution: Resilient Distributed Datasets (RDDs) [NSDI 2012]
  16. Example: Log Mining Exposes RDDs through a functional API in

    Scala Usable interactively from Scala shell lines = spark.textFile(“hdfs://...”) errors = lines.filter(_.startsWith(“ERROR”)) errors.persist() Block 1 Block 2 Block 3 Worker errors.filter(_.contains(“foo”)).count() errors.filter(_.contains(“bar”)).count() tasks results Errors 2 Base RDD Transformed RDD Action Result: full-text search of Wikipedia in <1 sec (vs 20 sec for on-disk data) Result: 1 TB data in 5 sec
  17. public static class WordCountMapClass extends MapReduceBase implements Mapper<LongWritable, Text, Text,

    IntWritable> { private final static IntWritable one = new IntWritable(1); private Text word = new Text(); public void map(LongWritable key, Text value, OutputCollector<Text, IntWritable> output, Reporter reporter) throws IOException { String line = value.toString(); StringTokenizer itr = new StringTokenizer(line); while (itr.hasMoreTokens()) { word.set(itr.nextToken()); output.collect(word, one); } } } public static class WorkdCountReduce extends MapReduceBase implements Reducer<Text, IntWritable, Text, IntWritable> { public void reduce(Text key, Iterator<IntWritable> values, OutputCollector<Text, IntWritable> output, Reporter reporter) throws IOException { int sum = 0; while (values.hasNext()) { sum += values.next().get(); } output.collect(key, new IntWritable(sum)); } }
  18. Word Count val docs = sc.textFiles(“hdfs://…”) docs.flatMap { doc =>

    doc.split(“\s”) } .map { word => (word, 1) } .reduceByKey { case(v1, v2) => v1 + v2 } docs.flatMap(_.split(“\s”)) .map((_, 1)) .reduceByKey(_ + _)
  19. Generality of RDDs Despite their restrictions, RDDs can express surprisingly

    many parallel algorithms » These naturally apply the same operation to many items Unify many current programming models » Data flow models: MapReduce, Dryad, SQL, … » Specialized models for iterative apps: Pregel, iterative MapReduce, GraphLab, … Support new apps that these models don’t
  20. Memory bandwidth Network bandwidth Tradeoff Space Granularity of Updates Write

    Throughput Fine Coarse Low High K-V stores, databases, RAMCloud GFS RDDs
  21. Example: Logistic Regression val data = spark.textFile(...).map(readPoint).cache() var w =

    Vector.random(D) for (i <- 1 to ITERATIONS) { val gradient = data.map(p => (1 / (1 + exp(-p.y*(w dot p.x))) - 1) * p.y * p.x ).reduce(_ + _) w -= gradient } println("Final w: " + w) Initial  parameter  vector   Repeated  MapReduce  steps   to  do  gradient  descent   Load  data  in  memory  once
  22. Iterative Algorithms 0.96 110 0 25 50 75 100 125

    Logistic Regression 4.1 155 0 30 60 90 120 150 180 K-Means Clustering Hadoop Spark Time per Iteration (s) Similar speedups to other in-memory engines
  23. Spark Spark Shark SQL HDFS / Hadoop Storage Mesos Resource

    Manager Spark Streaming GraphX MLBase
  24. Shark Spark Shark SQL HDFS / Hadoop Storage Mesos Resource

    Manager Spark Streaming GraphX MLBase
  25. MPP Databases Oracle, Vertica, HANA, Teradata, Dremel… Pros » Very mature

    and highly optimized engine. » Fast! Cons » Generally not fault-tolerant; challenging for long running queries as clusters scale up » Lack rich analytics (machine learning)
  26. MapReduce Hadoop, Hive, Google Tenzing, Turn Cheetah… Pros » Deterministic, idempotent

    tasks enable fine-grained fault-tolerance » Beyond SQL (machine learning) Cons » High-latency, dismissed for interactive workloads
  27. Shark A data analytics system that » builds on Spark, » scales

    out and tolerate worker failures, » supports low-latency, interactive queries through in- memory computation, » supports both SQL and complex analytics, » is compatible with Hive (storage, serdes, UDFs, types, metadata).
  28. Hive Architecture Meta store HDFS Client Driver SQL Parser Query

    Optimizer Physical Plan Execution CLI JDBC MapReduce
  29. Shark Architecture Meta store HDFS Client Driver SQL Parser Physical

    Plan Execution CLI JDBC Spark Cache Mgr. Query Optimizer
  30. Engine Features Dynamic Query Optimization Columnar Memory Store Machine Learning

    Integration Data Co-partitioning & Co-location Partition Pruning based on Range Statistics …
  31. Partial DAG Execution (PDE) Lack of statistics for fresh data

    and the prevalent use of UDFs necessitate dynamic approaches to query optimization. PDE allows dynamic alternation of query plans based on statistics collected at run-time.
  32. Shuffle Join Stage 3 Stage 2 Stage 1 Join Result

    Stage 1 Stage 2 Join Result Map Join (Broadcast Join) minimizes network traffic
  33. PDE Statistics 1.  Gather customizable statistics at per-partition granularities while

    materializing map output. » partition sizes, record counts (skew detection) » “heavy hitters” » approximate histograms 2.  Alter query plan based on such statistics » map join vs shuffle join » symmetric vs non-symmetric hash join » skew handling
  34. Columnar Memory Store Simply caching Hive records as JVM objects

    is inefficient. Shark employs column-oriented storage. 1   Column  Storage   2   3   john   mike   sally   4.1   3.5   6.4   Row  Storage   1   john   4.1   2   mike   3.5   3   sally   6.4
  35. Columnar Memory Store Simply caching Hive records as JVM objects

    is inefficient. Shark employs column-oriented storage. 1   Column  Storage   2   3   john   mike   sally   4.1   3.5   6.4   Row  Storage   1   john   4.1   2   mike   3.5   3   sally   6.4   Benefit: compact representation, CPU efficient compression, cache locality.
  36. Machine Learning Integration Unified system for query processing and machine

    learning Query processing and ML share the same set of workers and caches def logRegress(points: RDD[Point]): Vector { var w = Vector(D, _ => 2 * rand.nextDouble - 1) for (i <- 1 to ITERATIONS) { val gradient = points.map { p => val denom = 1 + exp(-p.y * (w dot p.x)) (1 / denom - 1) * p.y * p.x }.reduce(_ + _) w -= gradient } w } val users = sql2rdd("SELECT * FROM user u JOIN comment c ON c.uid=u.uid") val features = users.mapRows { row => new Vector(extractFeature1(row.getInt("age")), extractFeature2(row.getStr("country")), ...)} val trainedVector = logRegress(features.cache())
  37. Performance 0 25 50 75 100 Q1 Q2 Q3 Q4

    Runtime0(seconds) Shark Shark0(disk) Hive 1.1 0.8 0.7 1.0 1.7 TB Real Warehouse Data on 100 EC2 nodes
  38. Why are previous MR-based systems slow? 1.  Disk-based intermediate outputs.

    2.  Inferior data format and layout (no control of data co-partitioning). 3.  Execution strategies (lack of optimization based on data statistics). 4.  Task scheduling and launch overhead!
  39. Scheduling Overhead! Hadoop uses heartbeat to communicate scheduling decisions. » Task

    launch delay 5 - 10 seconds. Spark uses an event-driven architecture and can launch tasks in 5ms. » better parallelism » easier straggler mitigation » elasticity » multi-tenancy resource sharing
  40. 0 1000 2000 3000 4000 5000 0 2000 4000 6000

    Number of Hadoop Tasks Time (seconds) 0 1000 2000 3000 4000 5000 50 100 150 200 Number of Spark Tasks Time (seconds)
  41. Behavior with Insufficient RAM 68.8   58.1 40.7 29.7 11.5

    0   20   40   60   80   100   0%   25%   50%   75%   100%   Iteration time (s) Percent of working set in memory
  42. Breaking Down the Speedup 15.4   13.1   2.9

    8.4   6.9   2.9   0   5   10   15   20   In-­‐mem  HDFS   In-­‐mem  local  file   Spark  RDD   Iteration time (s) Text  Input   Binary  Input
  43. Conviva GeoReport Group aggregations on many keys w/ same filter

    40× gain over Hive from avoiding repeated I/O, deserialization and filtering 0.5   20   0   5   10   15   20   Spark   Hive   Time (hours)
  44. Example: PageRank 1. Start each page with a rank of

    1 2. On each iteration, update each page’s rank to Σi∈neighbors ranki / |neighborsi | links = // RDD of (url, neighbors) pairs ranks = // RDD of (url, rank) pairs for (i <- 1 to ITERATIONS) { ranks = links.join(ranks).flatMap { (url, (links, rank)) => links.map(dest => (dest, rank/links.size)) }.reduceByKey(_ + _) }
