Elementary Analytics with Kafka Streams (Anna McDonald, Confluent) | RTA Summit '23

In life, there are certainly situations where only ANOVA will do. However, many times valuable insights can be found with a much simpler approach. Whether it’s direct analysis or data format transformations, Kafka Streams has got you covered.

In this talk we will cover the core features of Kafka Streams that enable elementary analytics and data transformation.

Including:
– Windowing and window types
– Aggregate functions
– Continuous to discrete mappings

Armed with this information, your understanding of conducting elementary analytics in Kafka Streams will improve exponentially with no chance of regression.

Transcript

1. @jbfletch_ Anna McDonald: Twitter: @jbfletch_ <- fully committed to the underscore GitHub: jbfletch
2. @jbfletch_ Agenda 1. Elementary analytics 2. Kafka Streams for Analytics 3. Real example
3. @jbfletch_ Elementary, my dear attendees… • Mean • Median • Mode • Skewness • Kurtosis
4. @jbfletch_ Why should I not do advanced Math Stat?
5. @jbfletch_ Why should I not do advanced Math Stat? Java
6. @jbfletch_ Why should I not do advanced Math Stat? Java • No elegant support for 2d dynamic arrays • Lack of support for more advanced DoE test etc.
7. @jbfletch_ Why should I not do advanced Math Stat? Java • No elegant support for 2d dynamic arrays • Lack of support for more advanced DoE test etc. Pandas, R!
8. A Case for Kafka Streams @jbfletch_ I want to run my analysis as soon as all my assumptions are met. I don’t want to wait until a window closes if I have everything I need…
9. A Case for Kafka Streams @jbfletch_ INTRODUCING…….
10. A Case for Kafka Streams @jbfletch_ INTRODUCING……. Statistical assumption templates! aka SATs
11. Example Assumption Templates @jbfletch_ • Number of Observations == 30
12. Example Assumption Templates @jbfletch_ • Number of Observations == 30 • Number of Unique States (as in NY) represented == 50
13. Example Assumption Templates @jbfletch_ • Number of Observations == 30 • Number of Unique States (as in NY) represented == 50 • Specific combinations for Design of Experiments
14. Example Assumption Templates @jbfletch_ • Number of Observations == 30 • Number of Unique States (as in NY) represented == 50 • Specific combinations for Design of Experiments • Study Group completeness
15. Example Assumption Templates @jbfletch_ • Number of Observations == 30 • Number of Unique States (as in NY) represented == 50 • Specific combinations for Design of Experiments • Study Group completeness • Number of observations == Given model prediction confidence
16. Kafka Streams Overview for Analytics @jbfletch_
17. Kafka Streams Dedicated Cluster VS Java Library @jbfletch_
18. Kafka Streams @jbfletch_ Kafka Streams DSL (Domain Specific Language) Processor API (PAPI) ?
19. Time @MatthiasJSax Stream Time Wall-Clock Time Vs. @jbfletch_
20. Time Wall-Clock Time @jbfletch_ • The actual time based on system time or your watch • Not fully available in all DSL Methods • Used when there is no way to drive time by incoming messages
21. Time @MatthiasJSax Stream Time @jbfletch_
22. Time @MatthiasJSax Stream Time @jbfletch_ • Per Partition aka Stream Task • Advances Based on Incoming Messages at a Partition Level
23. @jbfletch_ Stream Time 101 this.testTopology.input() .at(1000).add("1",obs1) Stream Time: 1000 Key Value
24. @jbfletch_ Stream Time 101 this.testTopology.input() .at(1000).add("1",obs1) .at(1100).add("1",obs2) Stream Time: 1100
25. @jbfletch_ Stream Time 101 this.testTopology.input() .at(1000).add("1",obs1) .at(1100).add("1",obs2) .at(1200).add("3",obs3) Stream Time: 1200
26. @jbfletch_ Stream Time 101 this.testTopology.input() .at(1000).add("1",obs1) .at(1100).add("1",obs2) .at(1200).add("3",obs3) .at(1300).add("4",obs4) Stream Time: 1300
27. @jbfletch_ Stream Time 101 this.testTopology.input() .at(1000).add("1",obs1) .at(1100).add("1",obs2) .at(1200).add("3",obs3) .at(1300).add("4",obs4) .at(1400).add("1",obs5) .at(1500).add("6",obs6) .at(1510).add("10",obs10) .at(1520).add("11",obs11) .at(1530).add("1",obs13) .at(1540).add("4",obs14) .at(1550).add("1",obs15) .at(1560).add("4",obs16) .at(12000).add("7",obs7) .at(12100).add("1",obs8) .at(12200).add("4",obs9); Stream Time: 12200
28. @jbfletch_ Windowing!
29. @jbfletch_ Windowing Steps 1. Group data
30. Group Data • What do I need to reason about? Ex. Store Location, Shoe Type, Feature ID groupBy @jbfletch_
31. @jbfletch_ Windowing Steps 1. Group data 2. Specify the window type
32. @jbfletch_ Tumbling Windows
33. @jbfletch_ Tumbling Windows • Non-Overlapping
34. @jbfletch_ Tumbling Windows • Non-Overlapping • Controlled by a Fixed-Size Window
35. @jbfletch_ Tumbling Windows • Non-Overlapping • Controlled by a Fixed-Size Window • Uniquely Identifiable as: Memory Changelog <key>@[start epoch]/[end epoch] <key>@[start epoch] <pass in window size>
36. @jbfletch_ Hopping Windows
37. @jbfletch_ Hopping Windows • Overlapping
38. @jbfletch_ Hopping Windows • Overlapping • Fixed Sized
39. @jbfletch_ Hopping Windows • Overlapping • Fixed Sized • Controlled by Window Size and Advance
40. @jbfletch_ Hopping Windows • Overlapping • Fixed Sized • Controlled by Window Size and Advance • Uniquely Identifiable as: Memory Changelog <key>@[start epoch]/[end epoch] <key>@[start epoch] <pass in window size>
41. @jbfletch_ Sliding Windows aka Look Back/Forward
42. @jbfletch_ Sliding Windows aka Look Back • Slides continuously along a timeline
43. @jbfletch_ Sliding Windows aka Look Back • Slides continuously along a timeline • Fixed Size
44. @jbfletch_ Sliding Windows aka Look Back • Slides continuously along a timeline • Fixed Size • Controlled by max time difference between two records of the same key
45. @jbfletch_ Sliding Windows aka Look Back • Slides continuously along a timeline • Fixed Size • Controlled by max time difference between two records of the same key • Uniquely Identifiable as: Memory Changelog <key>@[start epoch]/[end epoch] <key>@[start epoch] <pass in window size>
46. @jbfletch_ Sliding Windows aka Look Back Key Value Record Time Stream Time A 1 8000 8000 A 2 9200 9200 A 3 12400 12400 Phil 496 13200 13200 Angela Lansbury 96 14500 14500 We'd have the following 5 windows: • window [3000;8000] contains [1] (created when first record enters the window) • window [4200;9200] contains [1,2] (created when second record enters the window) • window [7400;12400] contains [1,2,3] (created when third record enters the window) • window [8001;13001] contains [2,3] (created when the first record drops out of the window) • window [9201;14201] contains [3] (created when the second record drops out of the window) Time Difference = 5000
47. @jbfletch_ Session Windows
48. @jbfletch_ Session Windows • Non-Overlapping with Gaps
49. @jbfletch_ Session Windows • Non-Overlapping with Gaps • Unfixed Size!
50. @jbfletch_ Session Windows • Non-Overlapping with Gaps • Unfixed Size! • Controlled by defining an inactivity gap for seeing records with a given key
51. @jbfletch_ Session Windows • Non-Overlapping with Gaps • Unfixed Size! • Controlled by defining an inactivity gap for seeing records with a given key • Uniquely Identifiable as: Memory Changelog <key>@[start epoch]/[end epoch] <key>@[start epoch]/[end epoch]
52. @jbfletch_ Windowing Steps 1. Group data 2. Specify the window type 3. Aggregate
53. @jbfletch_ Aggregate • Simple Aggregates - Count, Summation, etc.
54. @jbfletch_ Aggregate • Simple Aggregates - Count, Summation, etc. • Create an array containing all values for further analysis
55. @jbfletch_ Aggregate • Simple Aggregates - Count, Summation, etc. • Create an array containing all values for further analysis • Continuous to Discrete Mappings
56. @jbfletch_ Putting it all Together! Task: Calculate the following descriptive statistics when and only when you have at least 30 observations for each class of sneaker: • Count • Min • Max • Mean • Skewness • Kurtosis
57. @jbfletch_ Putting it all Together! We want fixed size non-overlapping windows so we choose tumbling and define our window size TimeWindows tumblingWindow = TimeWindows.ofSizeWithNoGrace(Duration.ofSeconds(10));
58. @jbfletch_ Putting it all Together! We define our input KTable from our baseStream and create our groupBy, windowBy and aggregate TimeWindows tumblingWindow = TimeWindows.ofSizeWithNoGrace(Duration.ofSeconds(10)); KTable<Windowed<String>, List<Integer>> observationsByClass = baseStream .groupBy((k,v) -> v.path("sneakerID").asText()) .windowedBy(tumblingWindow) .aggregate(() -> new ArrayList<Integer>(), (key, value, aggregate) -> { aggregate.add(value.path("peeps").asInt()); return aggregate; } , Materialized.<String, List<Integer>, WindowStore<Bytes, byte[]>>as("classes").withValueSerde(listSerde));
59. @jbfletch_ Putting it all Together! We define our input KTable from our baseStream and create our groupBy, windowBy and aggregate TimeWindows tumblingWindow = TimeWindows.ofSizeWithNoGrace(Duration.ofSeconds(10)); KTable<Windowed<String>, List<Integer>> observationsByClass = baseStream .groupBy((k,v) -> v.path("sneakerID").asText()) .windowedBy(tumblingWindow) .aggregate(() -> new ArrayList<Integer>(), (key, value, aggregate) -> { aggregate.add(value.path("peeps").asInt()); return aggregate; } , Materialized.<String, List<Integer>, WindowStore<Bytes, byte[]>>as("classes").withValueSerde(listSerde));
60. @jbfletch_ Putting it all Together! We define our input KTable from our baseStream and create our groupBy, windowBy and aggregate TimeWindows tumblingWindow = TimeWindows.ofSizeWithNoGrace(Duration.ofSeconds(10)); KTable<Windowed<String>, List<Integer>> observationsByClass = baseStream .groupBy((k,v) -> v.path("sneakerID").asText()) .windowedBy(tumblingWindow) .aggregate(() -> new ArrayList<Integer>(), (key, value, aggregate) -> { aggregate.add(value.path("peeps").asInt()); return aggregate; } , Materialized.<String, List<Integer>, WindowStore<Bytes, byte[]>>as("classes").withValueSerde(listSerde));
61. @jbfletch_ Putting it all Together! observationsByClass .toStream() .filter((k,v) -> v.size() == 30) .map( ((stringWindowed, integers) -> { DescriptiveStatistics stats= new DescriptiveStatistics(); double[] array = integers.stream().mapToDouble(Integer::doubleValue).toArray(); Arrays.stream(array) .forEach(obs -> { stats.addValue(obs); }); System.out.println("Number of Values: " + String.valueOf(stats.getN())); System.out.println("Min Value: " + String.valueOf(stats.getMin())); System.out.println("Max Value: " + String.valueOf(stats.getMax())); System.out.println("Mean: " + String.valueOf(stats.getMean())); System.out.println("Skewness: " + String.valueOf(stats.getSkewness())); System.out.println("Kurtosis: " + String.valueOf(stats.getKurtosis())); return KeyValue.pair(stringWindowed, integers); }) ) .print(Printed.<Windowed<String>, List<Integer>>toSysOut().withLabel("Full Key and Values")); Time to apply our statistical assumption template (SAT)
62. @jbfletch_ Putting it all Together! observationsByClass .toStream() .filter((k,v) -> v.size() == 30) .map( ((stringWindowed, integers) -> { DescriptiveStatistics stats= new DescriptiveStatistics(); double[] array = integers.stream().mapToDouble(Integer::doubleValue).toArray(); Arrays.stream(array) .forEach(obs -> { stats.addValue(obs); }); System.out.println("Number of Values: " + String.valueOf(stats.getN())); System.out.println("Min Value: " + String.valueOf(stats.getMin())); System.out.println("Max Value: " + String.valueOf(stats.getMax())); System.out.println("Mean: " + String.valueOf(stats.getMean())); System.out.println("Skewness: " + String.valueOf(stats.getSkewness())); System.out.println("Kurtosis: " + String.valueOf(stats.getKurtosis())); return KeyValue.pair(stringWindowed, integers); }) ) .print(Printed.<Windowed<String>, List<Integer>>toSysOut().withLabel("Full Key and Values")); Create and add the observations in our window to a new stats object
63. @jbfletch_ Putting it all Together! observationsByClass .toStream() .filter((k,v) -> v.size() == 30) .map( ((stringWindowed, integers) -> { DescriptiveStatistics stats= new DescriptiveStatistics(); double[] array = integers.stream().mapToDouble(Integer::doubleValue).toArray(); Arrays.stream(array) .forEach(obs -> { stats.addValue(obs); }); System.out.println("Number of Values: " + String.valueOf(stats.getN())); System.out.println("Min Value: " + String.valueOf(stats.getMin())); System.out.println("Max Value: " + String.valueOf(stats.getMax())); System.out.println("Mean: " + String.valueOf(stats.getMean())); System.out.println("Skewness: " + String.valueOf(stats.getSkewness())); System.out.println("Kurtosis: " + String.valueOf(stats.getKurtosis())); return KeyValue.pair(stringWindowed, integers); }) ) .print(Printed.<Windowed<String>, List<Integer>>toSysOut().withLabel("Full Key and Values")); And finally…calculate our required descriptive statistics!
64. @jbfletch_ GitHub: https://github.com/jbfletch/kafkastreamsmathstat
