  1. What’s Composable ɾA new set of Jetpack UI widgets ɾA

    kotlin compiler plugin ɾFully compatible with your existing app/code
  2. What’s Composable ɾA new set of Jetpack UI widgets ɾA

    kotlin compiler plugin ɾFully compatible with your existing app/code ɾExperimental
  3. @Composable fun Greeting(name: String) { Text("Hello $name!") } class ComposeSampleActivity

    : Activity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) } }
  4. @Composable fun Greeting(name: String) { Text("Hello $name!") } class ComposeSampleActivity

    : Activity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { CraneWrapper { Greeting("takusemba") } } } }
  5. @Composable fun Greeting(name: String) { Text("Hello $name!") } class ComposeSampleActivity

    : Activity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { CraneWrapper { Greeting("takusemba") } } } }
  6. @Composable fun Greeting(name: String) { Text("Hello $name!") } class ComposeSampleActivity

    : Activity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { CraneWrapper { Greeting("takusemba") } } } }
  7. @Composable fun Greeting(name: String) { Text("Hello $name!") } class ComposeSampleActivity

    : Activity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { CraneWrapper { Greeting("takusemba") } } } }
  8. class ComposeSampleActivity : Activity() { override fun onCreate(savedInstanceState: Bundle?) {

    super.onCreate(savedInstanceState) setContent { CraneWrapper { MaterialTheme { Greeting("takusemba") } } } } } @Composable fun Greeting(name: String) { Text("Hello $name!") }
  9. @Composable fun Greeting(name: String) { Text(text = "Hello $name!", style

    = +themeTextStyle { h5 }) } class ComposeSampleActivity : Activity() { override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) setContent { CraneWrapper { MaterialTheme { Greeting("takusemba") } } } } }
  10. @Composable fun <T> ScrollingList( data: List<T>, body: @Composable()(T) -> Unit

    ) { // ... body(item) // ... } @Composable fun NewsFeed(stories: List<Story>) { ScrollingList(stories) { story -> StoryWidget(story) } }
  11. @Composable fun <T> ScrollingList( data: List<T>, body: @Composable()(T) -> Unit

    ) { // ... body(item) // ... } @Composable fun MenuList(items: List<Item>) { ScrollingList(items) { item -> when (item) { is FoodItem -> FoodWidget(item) is DrinkItem -> DrinkWidget(item) } } }
  12. @Composable fun Greeting(name: String) { val count = +state {

    0 } Column { Button(text = "greet", onClick = { count.value++ }) Text(text = "$name greeted ${count.value} times") } }
  13. @Composable fun Greeting(name: String) { val count = +state {

    0 } Column { Button(text = "greet", onClick = { count.value++ }) Text(text = "$name greeted ${count.value} times") } }
  14. @Composable fun Greeting(name: String) { val count = +state {

    0 } Column { Button(text = "greet", onClick = { count.value++ }) Text(text = "$name greeted ${count.value} times") } }
  15. @Model class GreetCounter(var count: Int) { fun add() { count++

    } fun substract() { count-- } } @Composable fun Greeting(name: String) { val count = +state { 0 } Column { Button(text = "greet", onClick = { count.value++ }) Text(text = "$name greeted ${count.value} times") } }
  16. @Model class GreetCounter(var count: Int) { fun add() { count++

    } fun substract() { count-- } } @Composable fun Greeting(name: String) { val counter = +memo { GreetCounter(0) } Column { Button(text = "greet", onClick = { count.add() }) Text(text = "$name greeted ${count.count} times") } }
  17. @Composable fun Greeting(name: String) { val counter = +memo {

    GreetCounter(0) } Column { Button(text = "greet", onClick = { count.add() }) Text(text = "$name greeted ${count.count} times") } } @Model class GreetCounter(var count: Int) { fun add() { count++ } fun substract() { count-- } }
  18. @Model class LoginState(var username: String, var password: String) { val

    valid: Boolean get() = username.isNotEmpty() && password.isNotEmpty() }
  19. @Model class LoginState(var username: String, var password: String) { val

    valid: Boolean get() = username.isNotEmpty() && password.isNotEmpty() } @Composable fun LoginScreen(onClick: () -> Unit) { val model = +memo { LoginState() } EditText( text=model.username, onTextChange={ text -> model.username = text } ) EditText( text=model.password, onTextChange={ text -> model.password = text } ) Button(text="Login", enabled=model.valid, onClick={ onClick() }) }
  20. @Model class LoginState(var username: String, var password: String) { val

    valid: Boolean get() = username.isNotEmpty() && password.isNotEmpty() } @Composable fun LoginScreen(onClick: () -> Unit) { val model = +memo { LoginState() } EditText( text=model.username, onTextChange={ text -> model.username = text } ) EditText( text=model.password, onTextChange={ text -> model.password = text } ) Button(text="Login", enabled=model.valid, onClick={ onClick() }) }
  21. @Composable
 @GenerateView fun Greeting(name: String) { Text ("Hello $name!") }

    // In your existing xml <GreetingView app:name="takusemba" />
  22. @Composable
 @GenerateView fun Greeting(name: String) { Text ("Hello $name!") }

    // In your existing xml <GreetingView app:name="takusemba" /> // find view by Id val greeting = findViewById(R.id.greeting)
