Load and Performance Testing Microservices (Dig...

Load and Performance Testing Microservices (Digital Transformation Meetup)

At the first Digital Transformation Meetup in Düsseldorf, Germany (http://www.meetup.com/Digital-Transformation-Meetup/events/225841693/) I gave a talk on the challenges of testing for non-functional requirements.

Sebastian Cohnen

October 18, 2015
Tweet

More Decks by Sebastian Cohnen

Other Decks in Technology

Transcript

  1. Sebastian Cohnen, M. Sc.
 CEO & CTO • Focus on

    web performance and architectures • 5+ years consulting and development • Performance engineering & regular execution of dynamic performance analysis for customers Lars Wolff
 CEO & CPO • Focus on large, technical ambitious web projects and products • 10+ years consulting and development • Agile Coach / Certified ScrumMaster®; strategy, conception, product/project management plus development Hello!
  2. With load tests the system you want to test
 will

    be loaded with a defined amount of requests. The behavior of the system will thereby be monitored and rated.
  3. Performance, Load, Configuration, […]-Testing • There are many variations on

    what and how you can assess performance related aspects. • What you need to do depends on what you want to learn about your system.
  4. Why (Performance) Testing? • I'd argue, that every system has

    issues. • Almost every project we worked on so far, has had (serious) issues. • YOU want to find issues before your customers do!
  5. What you might want to know / learn about your

    system? • Speed, Latency, Performance • Stability • Resource Requirements, Capacity Planning • Resiliency, Failure Scenarios, Edge Cases
  6. Top Performance Issues 1. Configuration 2. Configuration 3. Configuration 4.

    Bugs 5. New Features 6. Resource Contention (hello RDMS!) 7. Architectural Design
  7. Performance vs Scalability • Performance:

 "1x instance can handle

    250 API requests per second with p99 at 50ms…" • Scalability:

 "10x instances can handle 2500 API requests per second with p99 at 50ms…"
  8. You want to know both! • Performance is important, because

    it defines a baseline for latency and capacity. • Scalability is important, because it will tell you if and how far you can grow.
  9. (Micro-)Services • promising approach to build better isolated systems •

    supposedly helps to scale to many independent teams • supposedly helps to scale your operation • CAUTION! Complexity is not abundant, it is moved "between" the services
  10. What about Performance? • A (micro-)service architecture can have a

    beneficial impact on performance… • but it can also be very dangerous!
  11. Huh? • Your SLA: "We need 500ms 95% of the

    time" • Your endpoint requires a service, which requires a service, which in turn re……… • What happens to your SLAs? For three services in a chain? You are left with 500ms for 86% of the time!
  12. Challenges • Distributed teams build a distributed system • Communication

    is the primary challenge • For non-functional requirements, you have to end up coordinating with other teams
  13. Lots of Open Questions • Test Environments? Test Data? •

    Test Coordination? Supervision? Monitoring? • What about CI and CD?
  14. Empower Individuals as much as possible! • Everyone should be

    able to run a test – anytime • You don't want have independent teams and then block them by orthogonal tasks like perf testing
  15. Work "Bottom-Up" • Start with very simple and basic tests

    as building blocks • Continue with coarser grained tests, combining basic blocks • Only start with complex business flows in the end
  16. Why "Bottom-Up"? • Systems and stacks are complex • To

    understand a system under load, you need to be able to identify what happens and you have to be able to reproduce a test. • Low-Level Tests can be performed by each team in isolation.
  17. Have Dedicated Test Environments • Ideally you have a 1:1

    Environment for Performance Testing ($$$) • But you should have at least a scaled version of it and be able to size it up • Very, very important: Have a representative data set available!
  18. StormForger • SaaS Product and Consulting on Performance and Load

    Testing • We take care of the heavy lifting and pave the way for regular performance assessments
  19. https://stormforger.com Thank you! How can we help you? Sebastian Cohnen
