AWS re:Invent 2024 ふりかえり勉強会
yhana
December 23, 2024
Transcript
48 slides
-
もくじ 2 • アップデート紹介(re:Invent 開催前のアップデート含む) ◦ コンピューティング ▪ Amazon Elastic
VMware Service のプレビュー ▪ Amazon EC2 Allowed AMI ▪ AWS Step Functions が Variables と JSONata の変換 ◦ ネットワーク ▪ Amazon VPC ブロックパブリックアクセス ▪ Amazon CloudFront が VPC origins ▪ Resource Configuration & Resource gateways ◦ ストレージ ▪ AWS Transfer Family web apps ◦ データベース ▪ Amazon Aurora DSQL のプレビュー ▪ Oracle Database@AWS のプレビュー • その他のアップデートの参考情報 -
コンピューティングのアップデートから紹介する内容 4 • Amazon Elastic VMware Service のプレビュー • Amazon
EC2 Allowed AMI 機能 • AWS Step Functions が Variables と JSONata の変換 -
Amazon Elastic VMware Service(プレビュー) 5 • VMware Cloud Foundation (VCF)
◦ ユーザー作成の VPC にデプロイして利用 ◦ ユーザー側で仮想化基盤の管理者権限を利用可能 ◦ セルフマネージド型またはパートナーによるマネージド型 • リリース時点でベアメタルインスタンス i4i.netal × 4hosts 構成から • 限定プレビュー中のため利用には申請が必要 関連ブログ:「ついに来た!Amazon Elastic VMware Serviceの爆速キャッチアップ」というタイトルでCM re:Growth 2024 OSAKAに登壇しました -
Amazon EC2 Allowed AMI 8 • AWS アカウント内における AMI の使用を制限する機能
• 使用制限する設定の他、基準に沿っているか確認できる Audit モードあり • ルールは JSON 形式で作成 関連ブログ:[アップデート] Amazon EC2 で AMI ガバナンスを強化するために 許可された AMI が導入されました { "imageCriteria": [ { "imageProviders": [ "amazon", "aws-marketplace", "123456789012", "112233445566", ] } ] } -
Amazon EC2 Allowed AMI 11 「 Allowed AMI 」導入のベストプラクティス 1.
監査モードを有効にする 2. AMI の基準を決定・設定する 3. 予想されるビジネス(システム)への影響を確認する ◦ 影響を受ける Amazon EC2 の「起動テンプレート」の修正なども必要 4. 許可された AMI を有効にする 5. 継続的に問題がないかの確認・見直し AWSユーザーガイド:Control the discovery and use of AMIs in Amazon EC2 with Allowed AMIs - Amazon Elastic Compute Cloud -
Amazon EC2 Allowed AMI 12 • 現在サポートされているのは「imageProviders」のみ ◦ 個別の AMI
指定はできないと思われる AWSユーザーガイド:Control the discovery and use of AMIs in Amazon EC2 with Allowed AMIs - Amazon Elastic Compute Cloud imageProvidersの有効な値 説明 amazon AWSによって作成されたAMI aws-marketplace AWS Marketplaceで検証済みのプロバイダーによって作成されたAMI aws-backup-vault AWS Backup Vaultに存在するバックアップ AMI AWS account IDs 任意のAWSアカウント none 自アカウントで作成された AMI -
AWS Step Functions が Variables と JSONata の変換に対応 13 •
Variables (変数) の利用によりステート内で値の引き渡しが不要に • JSONata は、JSON をクエリ・変換するための言語 ◦ 読み方は「じぇいそなーた」 関連ブログ: ・[アップデート] AWS Step Functions で変数が使えるようになりました ・ 「これでLambdaが不要に?!Step FunctionsのJSONata対応について」というタイトルでCM re:Growth 2024 OSAKAに登壇しました https://jsonata.org/ -
AWS Step Functions の JSONata 利用例 14 • JSONata で変換する例
• Web上の「JSONata Exerciser」で 動作確認が簡易にできる -
AWS Step Functions の JSONata 利用例 15 • 従来はLambdaが必要だった整形処理がJSONataだけで実現できるケースあり •
従来のStep Functionsの乗算のステート(左図)とJSONataを利用したステート(右図) 引用元:AWS Step Functionsで組み込み関数だけを使って整 数の乗算を実装してみた(AWS CDK) -
JSONata の利用例 16 • JSONataでできること ◦ 正規表現 ◦ 文字列操作 ◦
日付操作 ◦ 四則演算 ◦ 簡単なプログラミング ▪ 変数の利用 ▪ 条件分岐の利用 ▪ 関数の定義 ▪ コメントの利用 -
ネットワークのアップデートから紹介する内容 18 • Amazon VPC ブロックパブリックアクセス • Amazon CloudFront が
VPC origins • Resource Configuration & Resource gateways ◦ AWS PrivateLink を介した VPC リソースへのアクセスが可能に -
Amazon VPC ブロックパブリックアクセス 19 • VPC とインターネット間の通信をブロックをする機能 • 双方向とインバウンドのみ(インターネット →
VPC)のブロックが可能 関連ブログ:ブロックパブリックアクセス(BPA)でインターネットアクセスを遮断してみた Bidirectional (双方向) のブロック Ingress-only (インバウンドのみ) のブロック -
Amazon VPC ブロックパブリックアクセス 20 • VPC パブリックブロックアクセスはリージョン毎の設定 ◦ AWS Organizations
の宣言型ポリシーを用いて組織 / OU 単位でまとめて設定も可能 • ブロック除外とする VPC の指定も可能 -
Amazon CloudFront VPC origins 21 • VPC のプライベートサブネットに存在するリソースからのコンテンツ配信を 可能にする新機能 ◦
プライベートサブネットの Application Load Balancer (ALB)、 Network Load Balancer (NLB)、また は EC2 インスタンスにアクセス 関連ブログ:CloudFront 新機能!VPCオリジンでプライベートなALBをセキュアに公開してみた -
Amazon CloudFront VPC origins 22 • これまでの構成と新しく構築できる構成案のイメージ図 これまでの構成 新しく構築できる ようになった構成
・CloudFront経由以外のアクセス をブロックする考慮が必要 ・グローバルIPアドレスが必要 -
Resource configuration & Resource gateways 23 • AWS PrivateLink で
NLB を利用せずに他 VPC に TCP でアクセス可能に • 新しい機能である Resource configuration & Resource gateways を利用 これまでの構成 新しく構築できる ようになった構成 関連ブログ:「ネットワークの新要素!Resource Gateway&Configuration関連アップデートまとめ」というタイトルでre:Growth 2024 東京に登壇しました -
Resource configuration & Resource gateways 24 • Resource configuration &
Resource gateways の利用イメージ -
Resource configuration & Resource gateways 25 • Resource configuration &
Resource gateways の利用イメージ ◦ ①:Resource gateway を作成 Resource gateway ①:Resource gateway 作成 -
Resource configuration & Resource gateways 26 • Resource configuration &
Resource gateways の利用イメージ ◦ ①:Resource gateway を作成 ◦ ②:Resource configuration を Resource gateway と関連付けて作成 Resource gateway Resource configuration ①:Resource gateway 作成 ②: Resource configuration 作成 関連付け -
Resource configuration & Resource gateways 27 • Resource configuration &
Resource gateways の利用イメージ ◦ ①:Resource gateway を作成 ◦ ②:Resource configuration を Resource gateway と関連付けて作成 ◦ ③:VPC エンドポイント(「Resource」タイプ)を Resource configuration と関連付けて作成 Resource gateway Resource configuration ①:Resource gateway 作成 ②: Resource configuration 作成 Resource Configuration を指定 ③: VPCエンドポイント作 成 「Resource」タイ プVPCエンドポイ ント -
Resource configuration & Resource gateways 28 • Resource configuration &
Resource gateways の利用イメージ ◦ ①:Resource gateway を作成 ◦ ②:Resource configuration を Resource gateway と関連付けて作成 ◦ ③:VPC エンドポイント(「Resource」タイプ)を Resource configuration と関連付けて作成 Resource gateway Resource gateway ①:Resource gateway 作成 ②: Resource Configuration 作成 ③: VPCエンドポイント作 成 TCP 「Resource」タイ プVPCエンドポイ ント -
Resource configuration & Resource gateways 29 • Resource configuration &
Resource gateways のクロスアカウント利用イメージ -
Resource configuration & Resource gateways 30 • Resource configuration &
Resource gateways のクロスアカウント利用イメージ ◦ ①:Resource gateway を作成 ◦ ②:Resource configuration を Resource gateway と関連付けて作成 Resource gateway Resource configuration ①:Resource gateway 作成 ②: Resource Configuration 作成 -
Resource configuration & Resource gateways 31 • Resource configuration &
Resource gateways のクロスアカウント利用イメージ ◦ ①:Resource gateway を作成 ◦ ②:Resource configuration を Resource gateway と関連付けて作成 ◦ ③:Resource configuration を RAM で共有 Resource gateway Resource configuration ①:Resource gateway 作成 ②: Resource Configuration 作成 共有 承認 ③:RAMで共 有 -
Resource configuration & Resource gateways 32 • Resource configuration &
Resource gateways のクロスアカウント利用イメージ ◦ ①:Resource gateway を作成 ◦ ②:Resource configuration を Resource gateway と関連付けて作成 ◦ ③:Resource configuration を RAM で共有 ◦ ④:VPCエンドポイント(「Resource」タイプ)を Resource configuration と関連付けて作成 Resource gateway Resource configuration 「Resource」タ イプVPCエンド ポイント ①:Resource gateway 作成 ②: Resource Configuration 作成 ④: VPCエンドポイント作 成 共有 承認 Resource Configuration を指定 ③:RAMで共 有 -
Resource configuration & Resource gateways 33 • Resource configuration &
Resource gateways のクロスアカウント利用イメージ ◦ ①:Resource gateway を作成 ◦ ②:Resource configuration を Resource gateway と関連付けて作成 ◦ ③:Resource configuration を RAM で共有 ◦ ④:VPCエンドポイント(「Resource」タイプ)を Resource configuration と関連付けて作成 Resource gateway Resource configuration ①:Resource gateway 作成 ②: Resource Configuration 作成 ④: VPCエンドポイント作 成 共有 承認 TCP ③:RAMで共 有 「Resource」タ イプVPCエンド ポイント -
37 • S3 へのファイルアップロード/ダウンロードを GUI で提供する新機能 ◦ 例えば、特定 S3 に対してファイルをアップロードするだけのユーザーへの手段提供に便利
◦ マネジメントコンソールにアクセスすることなくファイル操作ができる • ユーザー管理にアカウントインスタンスの AWS IAM Identity Center を利用可 AWS Transfer Family web apps アカウントインスタンスの AWS IAM Identity Center (AWS Organizations 環境以外でも利用可能) AWS Transfer Family web apps -
38 • 利用イメージ ◦ ユーザーはマネジメントコンソールにアクセスすることなく権限のある S3 バケットを操作可能 ◦ AWS IAM
Identity Center のユーザーを作成する必要はあるが、IAMユーザーは不要 AWS Transfer Family web apps -
39 AWS Transfer Family web apps 構築の流れ 1. AWS Transfer
Family Web App を作成 2. S3 Access Grants で利用する IAM ロールを作成 ◦ Configure IAM roles for Transfer Family web apps - AWS Transfer Family 3. S3 Access Grants を作成 ◦ インスタンスを作成 ◦ ロケーションを作成(IAM ロールを指定) ◦ AWS IAM Identity Center を関連付け ◦ ユーザーに対する権限を設定 4. 対象の S3 バケットの Cross-Origin Resource Sharing (CORS) ポリシーを設定 ◦ Set up Cross-origin resource sharing (CORS) for your bucket - AWS Transfer Family AWS Transfer Family web apps 関連ブログ:Announcing AWS Transfer Family web apps for fully managed Amazon S3 file transfers | AWS News Blog -
Amazon Aurora DSQL(プレビュー) 42 • Active-Active で⾼い可⽤性を備えた分散 SQL データベースのサービス ◦
事実上無制限のスケーラビリティ • PostgreSQL 互換 • マルチリージョンで強い整合性を提供 • 現在、東京・大阪リージョン未提供 引用元:Amazon Aurora DSQL の紹介 | Amazon Web Services ブログ 関連ブログ:Aurora DSQLの楽観同時実行制御を手を動かして学ぶ -
Oracle Database@AWS(プレビュー) 43 • AWSとOracle の協⼒による新しいサービス ◦ 2024年9月12日に オラクルと Amazon
Web Services、戦略的パートナーシップを発表 • AWS のデータセンター内に設置された Oracle Cloud Infrastructure (OCI) が 管理する Exadata インフラで動作する Oracle Database Service を利⽤可能 • 限定プレビューのため利用には申請が必要 ◦ 現在、東京・大阪リージョン未提供 関連ブログ:公開情報のみでプライベートプレビューの Oracle Database@AWS を掘り下げてみた -
Oracle Database@AWS(プレビュー) 44 • 右図が仕組み • AWS のデータセンター 上に構築 •
コントロールプレーン は OCI 側にある • ODB ピアリングはVPC ピアリングとは異なる 仕組み 引用元:How Oracle Database@AWS works - Oracle Database@AWS -
AWS 公式の re:Cap 46 資料(PDF):AWS-Black-Belt_2024_AWS-reInvent_1206_v1.pdf 動画(YouTube):AWS Black Belt Online Seminar
2024 年 AWS re:Invent 速報 #AWSDevLiveShow #AWSBlackBelt - YouTube -
クラスメソッド re:Growth 2024 47 • 東京・大阪・福岡・札幌で AWS re:Invent ふりかえり勉強会を開催 •
YouTube 動画 ◦ [東京] AWSパートナー国内最多の全認定資格保有者!クラスメソッドが選ぶ #reinvent 2024 注目アップデート ◦ [大阪] AWS re:Invent 2024 ふりかえり勉強会「クラスメソッド re:Growth 2024 大阪」 • 登壇フログ ◦ クラスメソッド re:Growth 2024 の記事一覧
