The future vision of Ruby Parser

RubyKaigi 2023
https://rubykaigi.org/2023/presentations/spikeolaf.html

ruby/lrama
https://github.com/ruby/lrama

Transcript

1. The future vision of Ruby Parser May 11, 2023 in RubyKaigi 2023 @yui-knk Yuichiro Kaneko
2. About me • Yuichiro Kaneko • yui-knk (GitHub) / spikeolaf (Twitter) • Treasure Data • Engineering Manager of Applications Backend
3. PR: We are Gold sponsor!
4. TD and Ruby committers twitter: @nalsh GitHub: @nurse twitter: @k_tsj GitHub: @k-tsj twitter: @ spikeolaf GitHub: @yui-knk twitter: @mineroaoki GitHub: @aamine twitter: @nahi GitHub: @nahi Applications Backend
5. Attendees from TD @spikeolaf @nalsh @k_tsj @frsyuki @takkanm @makimoto @ citystar (GH) @chezou @ybiquitous @hkdnet @a_ksi19 @exoego
6. About me • Yuichiro Kaneko • yui-knk (GitHub) / spikeolaf (Twitter) • CRuby committer, mainly develop parser related features • Code positions to RNode (2018, Ruby 2.6) • Coverage • Error reporting • RubyVM::AbstractSyntaxTree (2018, Ruby 2.6) • keep_tokens option (2022, Ruby 3.2) • error_tolerant option (2022, Ruby 3.2)
7. Introduction LR ߏจղੳͷجૅΛͳ͢ΞΠσΞ ͸ɼʮਖ਼نݴ ޠͷղੳख๏Λ܁Γฦ͠࢖͍ɼจ຺ࣗ༝จ๏ͷ෯ ޿͍ΫϥεΛղੳ͢Δʯͱ͍͏ (ଟ͘ͷ༏ΕͨΞ ΠσΞ ͕ͦ͏Ͱ͋ΔΑ͏ʹ) ୯७ͳ΋ͷͰ͋Δɽ େງ ३ “LRߏจղੳͷݪཧ”
8. Parser in Ruby • Converting input script into Abstract Syntax Tree • CRuby’s parser is LALR parser • CRuby uses GNU Bison to generate parser codes
9. History of parser generator • 1965: Donald E. Knuth invents LR parsing. “On the translation of languages from left to right” • 1975: Yacc is published • 1985: GNU Bison initial release • 1989: Berkeley Yacc initial release • 2006: GCC migrates it’s parser from Bison to hand- written recursive-descent parsers (C++ was 2004) • 2015: Go migrates it’s parser from Bison to hand-written recursive- descent parsers
10. What’s the problem? • Usability • Error-tolerant parser • Maintainability • “parse.y” seems dif fi cult • Universal Parser • It’s tough task to write your own parser for Ruby From “Ruby Committers vs The World” 2022 and 2021
11. Today’s talk • Usability • Maintainability • Universal Parser • Me
12. Usability For example, the Java error recovery approach in the Eclipse IDE is 5KLoC long, making it only slightly smaller than a modern version of Berkeley Yacc
13. Parser’s responsibility • Check if the input is valid Ruby code • If valid • Build internal representation (AST) for subsequent process, “compile.c” • If invalid • Report Syntax Error
14. Why Error-tolerant parser is need? • LSP requires parser to parse invalid code as far as possible • Just raising syntax error is not enough in this case
15. Parser’s responsibility • Check if the input is valid Ruby code • If valid • Build internal representation (AST) for subsequent process (“compile.c”) • If invalid • Report Syntax Error • Build AST as far as possible (New!)
16. Python’s approach • CPython uses PEG parser • Try “A” • Try “B” if “A” fails • Try “C” if “B” fails https://devguide.python.org/internals/parser
17. Python’s approach • CPython de fi nes valid cases and invalid cases • A rule failure doesn’t imply a parsing failure like in context free grammars https://github.com/python/cpython/blob/889b0b9bf95651fc05ad532cc4a66c0f8ff29fc2/Grammar/python.gram
18. Rust/Go’s approach • Both of them use hand-written parser • Go skips one or more tokens until one of “followlist” appears https://github.com/golang/go/blob/157aae6eed1c092fd9e8ead3527185378eb828e1/src/cmd/compile/internal/syntax/parser.go#L1032
 https://github.com/golang/go/blob/157aae6eed1c092fd9e8ead3527185378eb828e1/src/cmd/compile/internal/syntax/parser.go#L321
19. Rust/Go’s approach • rust-analyzer also skips speci fi ed token https://github.com/rust-lang/rust-analyzer/blob/21e61bee8b74e93f14205f4a6c316db08f811e38/crates/parser/src/grammar.rs#L302
 https://github.com/rust-lang/rust-analyzer/blob/21e61bee8b74e93f14205f4a6c316db08f811e38/crates/parser/src/parser.rs#L227
20. Bison’s approach • Bison panic-mode error recovery discards part of input so that it can parse the rest of input. =>
21. In short • PEG requires developers to implement all error cases • hand-written parser requires developers to cover all error cases • panic-mode error recovery loses part of input, sometimes which is most important for complementation
22. Our approach • Insert/Delete/Shift operations based error recovery • Fischer, Corchuelo, CPCT+ • Lukas Diekmann and Laurence Tratt. “Don’t Panic! Better, Fewer, Syntax Errors for LR Parsers”, July 2020 • https://arxiv.org/pdf/1804.07133.pdf
23. How it works? Diekmann and Tratt. “Don’t Panic! Better, Fewer, Syntax Errors for LR Parsers”
24. Insert/Delete token • Inserting tokens until input script to be valid • Deleting tokens until input script to be valid • Mixed operations is also acceptable
25. How LR parse works? • (LA)LR converts production rules into DFA (Deterministic Finite Automaton) • (LA)LR parser is implemented as PDA (Pushdown Automaton) • The stack manages states of DFA
26. How approach works? (2) k_if • expr_value … true • k_def • def_name … … “true” “def” …
27. How approach works? (3) k_if expr_value • then … “then” “;” “\n” (4) k_if expr_value then • … (4) k_if expr_value then • … (4) k_if expr_value then • …
28. How approach works? (4) k_if expr_value then • compstmt if_tail k_end (7) k_if expr_value then compstmt if_tail k_end • compstmt and if_tail are optional
29. How approach works? Diekmann and Tratt. “Don’t Panic! Better, Fewer, Syntax Errors for LR Parsers”
30. Summary • There are some paths to recover an error • Find the cheapest path to repair it • Need to implement only path fi nding logic • No need to take care about detail of a grammar
31. Problems of expanding Bison • Bison = Bison command + template fi le (“yacc.c”) • Template fi le is a detail of implementation • Installed version of Bison depends on environments • Expanding Bison template is not easy https://github.com/akimd/bison/blob/25b3d0e1a3f97a33615099e4b211f3953990c203/data/skeletons/yacc.c#L1640
32. Lrama LALR (1) parser generator • https://github.com/yui-knk/lrama • 100% Ruby implementation • Will be installed ruby/ruby tool directory • Input fi le is Bison format fi le (“parse.y”) • Output is LALR parser written by C • Generate 100% compatible C fi le for Ruby 3.0.5, 3.1.0, 3.2.0 • https://bugs.ruby-lang.org/issues/19637
33. Error Recovery by Bison • Does not work well for this case • This example is provided by @tompng
34. Error Recovery by Lrama • https://github.com/yui-knk/lrama/tree/error_recovery
35. Summary • Parser’s responsibility is increasing • PEG and hand-written parser need to be aware of detail of grammar • Bison’s panic mode loses part of input • Token based error recovery is fl exible, no need to know the detail of grammar • We can ride on DFA’s theory if we use LR parser • Defeated the fi rst boss !
36. Maintainability In this work we demonstrate that, contrary to the prevailing consensus, we can have the best of both worlds: for a very general, practical class of grammars—a strict superset of Knuth’s canonical LR—we can generate parsers automatically, and such that the resulting parser code, as well as the generation procedure itself, is highly ef fi cient. “Practical LR Parser Generation”
37. Why “parse.y” is dif fi cult? 1. “parse.y” is large (about 15,000 lines) 2. LALR is dif fi cult, e.g. S/R con fl ict, R/R con fl ict 3. Bison doesn’t provide syntax sugar like option, list 4. It’s a mixture of parser and ripper 5. Parser and Lexer are tightly-coupled
38. Monstrous lexer state • enum lex_state_e state: Has 13 different types of state. • int paren_nest: Nest level of (, [, {. Used for parsing -> {}. • int lpar_beg: Stores paren_next when parsing lambda starts. • int brace_nest: Next level of {. Used for parsing “#{var}". • stack_type cond_stack: Used for parsing condition like “while ... do” • stack_type cmdarg_stack: Used for parsing command call like “foo 1, 2 do”
39. 1. Resolve con fl icts • Ruby uses 4 different “do” • lambda • condition (while) • command call • method call
40. • It’s not a joke nor metaphor, CRuby literally has 4 different “do” 1. Resolve con fl icts
41. 1. Resolve con fl icts • “do” is a cause of shift/reduce con fl icts • “do” never appears in the condition of while, until and so on
42. 1. Resolve con fl icts • Matz daily 2004/04/26 • https://matz.rubyist.net/20040426.html#p02 1. Write two full set of rules, one is with do, another is without do.
43. 1. Resolve con fl icts • Matz daily 2004/04/26 • https://matz.rubyist.net/20040426.html#p02 1. Write two full set of rules, one is with do, another is without do. 2. Hack a lexer so that a lexer returns different tokens for same “do” string based on the context (= state) • CRuby selected the later
44. Matz dialy • > yaccͷએݴతͳจ๏͸৚͕݅ॻ͚ͳ͍ɻ ʮ͜ͷ৚݅ͷͱ͖͸͜ͷϧʔ ϧΛద༻͠ͳ͍ʯͱ͍͏Α͏ͳจ๏͸͋Γ͑ͳ͍ɻ·͋ɺLALR(1)ͷੑ࣭ Λߟ͑Ε͹͋Δҙຯ౰વͳͷͰɺ͜ΕΛऑ఺ͱ͍͏ͷ͸ద੾Ͱ͸ͳ͍ɻ Α Γਖ਼֬ʹ͸ʮऑ఺ʯͰ͸ͳͯ͘ɺ͍͍ͤͥʮཁ๬ʯͱ͔ʮཉٻʯͱ͔ͩͳɻ • > yacc doesn’t support conditions for rules, we can not omit some rules when some conditions are met. • Matz daily 2004/04/26 • https://matz.rubyist.net/20040426.html#p02
45. Nonterminal attributes • Correct, Bison doesn’t have such feature. However the fact does not mean it’s impossible! • Joe Zimmerman “Practical LR Parser Generation”, Sep 2022 • https://arxiv.org/pdf/2209.08383.pdf • “Nonterminal attributes”
46. Nonterminal attributes 1. De fi ne attributes 2. “do” is allowed in top level, however not allowed in while condition 3. “k_do” is allowed when DO_ALLOWED is true
47. Nonterminal attributes https://github.com/yui-knk/lrama/blob/e4a708d2f080f8e9ca8b082ac038fd6658d31077
48. • It works well for “while” Nonterminal attributes https://github.com/yui-knk/lrama/blob/e4a708d2f080f8e9ca8b082ac038fd6658d31077/sample/ nonterminal_attributes_3_2_0.output
49. Con fl icts • E.g. Con fl ict on endless method de fi nition • Lexer hack introduced ambiguities
50. GAME OVER CONTINUE?
 YES
 NO
51. GAME OVER CONTINUE?
 YES
 NO
52. Rethink “do” • There are 4 “do”
53. Rethink “do” • They has precedences • I don’t recommend writing such codes
54. Rethink “do” • (, [, { reset the “context” • Need to care about “context”
55. Already have hints (1) • Precedence is solved yet by “Operator Precedence” • https://www.gnu.org/software/bison/manual/html_node/ Precedence.html
56. Already have hints (2) • Nonterminal attributes carries “context”
57. Nonterminal attributes for con fl ict resolution 1. De fi ne attributes 2. “do” in f_larglist has less precedence than “do” in lambda_body -> “do” is reduced 3. “do” in () is shifted 4. “do” in top level is shifted
58. Nonterminal attributes for con fl ict resolution https://github.com/yui-knk/lrama/tree/nonterminal_attributes No con fl ict !!
59. What happens behind the scenes • Generate two states for one state
60. Summary • “parse.y” dif fi culty comes from tightly coupling between parser and lexer • Nonterminal attributes solves a part of problems • Nonterminal attributes for precedence solves “do” overload • We have not leveraged the potential of LR parser • Defeated the second boss !!
61. Universal Parser We can solve any problem by introducing an extra level of indirection.
62. Why Universal Parser is needed? • Everyone wants to use CRuby parser • mruby, PicoRuby: Other Ruby implementation by C • JRuby, Truf fl eRuby, ruruby: Other Ruby implementation by non-C • sorbet, typeprof: Tools • Implementing 100 % compatible Ruby parser is a bit dif fi cult • Managing parser for each version is dif fi cult
63. Why it isn’t Universal Parser? Ruby lexer & parser
64. Why it isn’t Universal Parser? • CRuby parser depends on other CRuby functionaries !!! lexer & parser GC RString RArray RHash … rb_mRubyVMFrozenCore struct rb_iseq_struct * Ruby
65. The road to Universal Parser 1. Passing required functions as function pointer 2. Linking functions into a parser shared library 1. parse.o: Generated from “parse.y” 2. node2.o: Separate AST/Node codes from “node.c” 3. st2.o: Copy “st.c” and remove unnecessary codes • https://github.com/yui-knk/ruby/tree/universal-parser
66. Done!!! • https://github.com/yui-knk/ruby/tree/universal-parser • https://github.com/yui-knk/my-ruby-parser •
67. However… • 209 functions
68. Sort out the interface • Memory management • malloc, realloc, free … • They should be in the interface • imemo • tmpbuf_auto_free_pointer, tmpbuf_set_ptr • CRuby internal, let’s remove the dependency
69. Sort out the interface • Literal Object • Do not create object, but keep it as “string” instead.
70. Sort out the interface • Parser manipulates object • Parser needs to know structure of objects • Need to pass functions
71. Sort out the interface • Add “negative” fl ag • Add NODE_NEG
72. Sort out the interface • AST transformation • Move it to “compile.c”
73. Summary • Universal Parser is required for tools and other Ruby implementations • 209 functions is a starting line • A lot of sub tasks to make the interface user-friendly • Defeated the third boss !!!
74. Conclusion The future is not laid out on a track. It is something that we can decide, and to the extent that we do not violate any known laws of the universe, we can probably make it work the way that we want to. Alan Curtis Kay
75. Conclusion • LR parser can solve 3 major problems, Usability/Maintainability/ Universal Parser • We can ride on DFA’s theory when we use LR parser • We have not leveraged the potential of LR parser • Lrama LALR parser generator is an infrastructure for Ruby parser
76. Dragon Book shows… • Usability • Maintainability • Universal Parser
77. Dragon Book shows… • Usability • Maintainability • Universal Parser • LALR Parser Generation
78. History of parser generator • 2006: GCC migrates it’s parser from Bison to hand- written recursive-descent parsers (C++ was 2004) • 2015: Go migrates it’s parser from Bison to hand-written recursive- descent parsers
79. History of parser generator • 2006: GCC migrates it’s parser from Bison to hand- written recursive-descent parsers (C++ was 2004) • 2015: Go migrates it’s parser from Bison to hand-written recursive- descent parsers • 2020: “Don't Panic! Better, Fewer, Syntax Errors for LR Parsers” • 2022: “Practical LR Parser Generation”
80. History of parser generator • 2006: GCC migrates it’s parser from Bison to hand- written recursive-descent parsers (C++ was 2004) • 2015: Go migrates it’s parser from Bison to hand-written recursive- descent parsers • 2020: “Don't Panic! Better, Fewer, Syntax Errors for LR Parsers” • 2022: “Practical LR Parser Generation” • 2023: “The future vision of Ruby Parser” in RubyKaigi 2023
81. New era of LR parser
82. The future vision of Parser • LR parser is the basic building blocks • Expanding grammar DSL to leverage LR parser • Moving lexer’s logic into parser grammar rules • Multiple parser algorithms for multiple purposes • Users can focus on writing grammar
83. Next Steps • Migrate CRuby parser generator from GNU Bison to Lrama • Install Lrama into CRuby • Usability (Error-tolerant parser) • Integrate Lrama error-tolerant functions with CRuby • Maintainability • Use Nonterminal attributes precedence • Universal Parser • Sort out the interface then merge the PR
84. Need your help ! • For an expert of LR parser • Any feedbacks are welcome • For developers who will use Universal Parser and AST • Share me use cases • For developers who has interest in implementing Universal Parser • Let me know
85. Acknowledgements • @mame, @ko1 and other committers • @nurse, I can not defeat all of 3 bosses without you supports
86. References • Jeffrey Kegler. “Parsing: a timeline”, Sep 2014. http://jeffreykegler.github.io/Ocean-of- Awareness-blog/individual/2014/09/chron.html • Lukas Diekmann and Laurence Tratt. “Don’t Panic! Better, Fewer, Syntax Errors for LR Parsers”, July 2020. https://arxiv.org/pdf/1804.07133.pdf • Joe Zimmerman “Practical LR Parser Generation”, Sep 2022 https://arxiv.org/pdf/ 2209.08383.pdf • େງ ३ “LRߏจղੳͷݪཧ”, Feb 2014. https://www.jstage.jst.go.jp/article/jssst/31/1/31_1_30/ _pdf/-char/ja • Matz “[OSS]yaccͷऑ఺(ͦͷ2)” Matz daily 2004/04/26. https://matz.rubyist.net/ 20040426.html#p02 • Eugene Wallingford “ALAN KAY'S TALKS AT OOPSLA” Knowing and Doing 2004/11/06. http:// www.cs.uni.edu/~wallingf/blog/archives/monthly/2004-11.html#e2004-11-06T21_03_42.htm
87. References • yui-knk “Ruby Parser։ൃ೔ࢽ (1)” ͔Ͷ͜ʹ͖ͬ 2022/12/11. https://yui- knk.hatenablog.com/entry/2022/12/11/154502 • yui-knk “Ruby Parser։ൃ೔ࢽ (2)” ͔Ͷ͜ʹ͖ͬ 2023/01/08. https://yui- knk.hatenablog.com/entry/2023/01/08/190105 • yui-knk “Ruby Parser։ൃ೔ࢽ (3)” ͔Ͷ͜ʹ͖ͬ 2023/01/11. https://yui- knk.hatenablog.com/entry/2023/01/11/220223 • yui-knk “Ruby Parser։ൃ೔ࢽ (4)” ͔Ͷ͜ʹ͖ͬ 2023/01/14. https://yui- knk.hatenablog.com/entry/2023/01/14/144131
88. References • yui-knk “Ruby Parser։ൃ೔ࢽ (5) - Lrama LALR (1) parser generatorΛ࣮૷ͨ͠” ͔ Ͷ͜ʹ͖ͬ 2023/03/13. https://yui-knk.hatenablog.com/entry/2023/03/13/101951 • yui-knk “Ruby Parser։ൃ೔ࢽ (6) - parse.yͷMaintainabilityͷ࿩” ͔Ͷ͜ʹ͖ͬ 2023/04/04. https://yui-knk.hatenablog.com/entry/2023/04/04/190413 • yui-knk “Ruby Parser։ൃ೔ࢽ (7) - doʹ͍ͭͯߟ͑Δ” ͔Ͷ͜ʹ͖ͬ 2023/04/09. https://yui-knk.hatenablog.com/entry/2023/04/09/123723 • yui-knk “Ruby Parser։ൃ೔ࢽ (8) - Universal Parser΁ͷಓ” ͔Ͷ͜ʹ͖ͬ 2023/05/01. https://yui-knk.hatenablog.com/entry/2023/05/01/174828
89. Thank you !!!
