Droidcon London '21 - A Hitchhiker's Guide to Compose Compiler: Composers, Compiler Plugins, and Snapshots

If you are an Android Developer, chances are you are pretty excited about Jetpack Compose! But how does it work? In this talk, we will take you along the journey of a Composable function, from being written, going through the unknown lands of the Kotlin and Compose compilers to being executed and displaying UI!

From Composables all the way down into the compiler plugins, we expose the metaprogramming responsible for all the "magic". Whether your interest is Jetpack Compose, compilers, or code transformations, this talk takes an otherwise complicated topic and makes it digestible for everybody by diving into specific features offered by Compose.

By examining Compose's snapshot system, you'll follow the compiler phases down to intercepting code transformations with IR. By recognizing the patterns that make it hard for Compose to generate efficient code, and this can help us to recognize patterns to use for performance.

mvndy_hd

October 29, 2021
Tweet

More Decks by mvndy_hd

Other Decks in Technology

Transcript

  1. "Jetpack Compose is Android's modern toolkit for building native UI."

    #hg2compose - developer.android.com @mvndy_hd @jossiwolf
  2. #hg2compose Text(text = name) Layout Layout name by remember {

    mutableStateOf("") } @mvndy_hd @jossiwolf
  3. A Composable is a restartable function that emits nodes into

    a tree. #hg2compose @mvndy_hd @jossiwolf Glossary
  4. @Composable fun HitchhikerApp() { var name by remember { mutableStateOf("Bob")

    } HelloWorld(greeting = name) name = "Chet" } @Composable fun HelloWorld(greeting: String) { Text("Hello, $greeting!") } #hg2compose @mvndy_hd @jossiwolf
  5. #hg2compose Text(text = name) Layout Layout name by remember {

    mutableStateOf("") } @mvndy_hd @jossiwolf
  6. #hg2compose Text(text = name) Layout Layout name by remember {

    mutableStateOf("Bob") } @mvndy_hd @jossiwolf
  7. #hg2compose Text(text = name) Layout Layout name by remember {

    mutableStateOf("Bob") } @mvndy_hd @jossiwolf
  8. #hg2compose Text(text = name) Layout Layout name by remember {

    mutableStateOf("Bob") } Bob @mvndy_hd @jossiwolf
  9. • State (Snapshots) • Memory (Slot Tables) • State Management

    (Recomposition) #hg2compose @mvndy_hd @jossiwolf
  10. "A Snapshot is a lot like a save point in

    a video game: it represents the state of your entire program at a single point in history." #hg2compose https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn - "Introduction to the Compose Snapshot System" by Zach Klippenstein Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
  11. #hg2compose interface MutableState<T> : State<T> { override var value: T

    operator fun component1(): T operator fun component2(): (T) .> Unit } package androidx.compose.runtime @mvndy_hd @jossiwolf
  12. #hg2compose https://dev.to/zachklipp/introduction-to-the-compose-snapshot-system-19cn fun main() { val dog = Dog() dog.name.value

    = "Spot" val snapshot = Snapshot.takeSnapshot() dog.name.value = "Fido" println(dog.name.value) ./ Fido snapshot.enter { println(dog.name.value) ./ Spot } println(dog.name.value) ./ Fido } Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf
  13. #hg2compose dog.name.value = "Fido" 1 2 Dog(name = "Spot") Dog(name

    = "Fido") Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf Snapshot.takeMutableSnapshot()
  14. #hg2compose dog.name.value = "Fido" 1 2 Dog(name = "Spot") Dog(name

    = "Fido") snapshot.enter { ... } Snapshots 📸 (and dogs🐕) @mvndy_hd @jossiwolf Snapshot.takeMutableSnapshot()
  15. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) 1 2 dog.name.value

    = "Fido" Dog(name = "Fido") snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot") Snapshot.takeMutableSnapshot()
  16. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) 1 2 dog.name.value

    = "Fido" Dog(name = "Fido") snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot") Snapshot.takeMutableSnapshot()
  17. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) 1 2 dog.name.value

    = "Fido" Dog(name = "Fido") snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot") Dog(name = "Taco") ✔ Snapshot.takeMutableSnapshot()
  18. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) snapshot.apply() dog.name.value =

    "Fido" 1 2 snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot") Dog(name = "Taco") Dog(name = "Fido") Dog(name = "Taco") Snapshot.takeMutableSnapshot()
  19. #hg2compose @mvndy @jossiwolf Snapshots 📸 (and dogs🐕) snapshot.apply() dog.name.value =

    "Fido" 1 2 snapshot.enter { dog.name.value = "Taco" } Dog(name = "Spot") Dog(name = "Taco") Dog(name = "Fido") Dog(name = "Taco") Snapshot.takeMutableSnapshot()
  20. #hg2compose @mvndy @jossiwolf fun main() { val dog = Dog()

    dog.name.value = "Spot" val snapshot = Snapshot.takeMutableSnapshot( readObserver = { value .> println(value) ./ MutableState(value=Spot)@... }, writeObserver = { value .> ... } ) dog.name.value = "Fido" snapshot.enter { dog.name.value = "Taco" } } Snapshots 📸 (and dogs🐕)
  21. • State (Snapshots) • Memory (Slot Tables) • State Management

    (Recomposition) #hg2compose @mvndy_hd @jossiwolf
  22. The Slot Table is used to store the current state

    of the Composition. #hg2compose @mvndy_hd @jossiwolf Glossary
  23. A Composer connects Composables to Runtime, keeps track of groups

    that are used to build the Slot Table and positions it. #hg2compose Glossary @mvndy_hd @jossiwolf
  24. #hg2compose @mvndy_hd @jossiwolf interface Applier<N> { val current: N fun

    onBeginChanges() {} fun onEndChanges() {} fun down(node: N) fun up() fun insertTopDown(index: Int, instance: N) fun insertBottomUp(index: Int, instance: N) fun remove(index: Int, count: Int) fun move(from: Int, to: Int, count: Int) fun clear() }
  25. #hg2compose var name by remember { mutableStateOf("Bob") } @Composable fun

    Greeting(greeting: String) { Text("Hello, $greeting!") } Greeting(name) name = "Jossi" ./ Hello, Bob! ./ Hello, Jossi! Slot Table by Example @mvndy_hd @jossiwolf
  26. #hg2compose EMPTY EMPTY Group(4) State(“Bob”) var name by remember {

    mutableStateOf("Bob") } Slot Table by Example EMPTY EMPTY EMPTY EMPTY EMPTY @mvndy_hd @jossiwolf
  27. #hg2compose Group(4) State(“Bob”) Group(5) var name by remember { mutableStateOf("Bob")

    } Slot Table by Example EMPTY EMPTY EMPTY EMPTY EMPTY EMPTY @Composable fun Greeting(greeting: String) { } Greeting(name) @mvndy_hd @jossiwolf
  28. #hg2compose EMPTY EMPTY Group(4) State(“Bob”) Group(5) Group(6) Group(7) Group(8) “Hello,

    Bob!” var name by remember { mutableStateOf("Bob") } Slot Table by Example @Composable fun Greeting(greeting: String) { Text("Hello, $greeting!”) } Greeting(name) @mvndy_hd @jossiwolf
  29. #hg2compose EMPTY EMPTY Group(4) State(“Bob”) Group(5) Group(6) Group(7) Group(8) “Hello,

    Jossi!” var name by remember { mutableStateOf("Bob") } @Composable fun Greeting(greeting: String) { Text("Hello, $greeting!”) } Greeting(name) name = "Jossi" Slot Table by Example @mvndy_hd @jossiwolf
  30. #hg2compose Text(text = name) Layout Layout name by remember {

    mutableStateOf("Bob") } Bob @mvndy_hd @jossiwolf
  31. Recomposition is the process of re-executing a Composable function to

    procude an updated slot table #hg2compose @mvndy_hd @jossiwolf Glossary
  32. #hg2compose suspend fun runApp() { val composer = Recomposer() GlobalSnapshotManager.ensureStarted()

    launch(DefaultChoreographerFrameClock) { composer.runRecomposeAndApplyChanges() } Composition(NodeApplier(RootNode()), composer).apply { setContent { Content() } } } @mvndy_hd @jossiwolf
  33. #hg2compose suspend fun runApp() { val composer = Recomposer() GlobalSnapshotManager.ensureStarted()

    launch(DefaultChoreographerFrameClock) { composer.runRecomposeAndApplyChanges() } Composition(NodeApplier(RootNode()), composer).apply { setContent { Content() } } } medium.com/@takahirom/inside-jetpack-compose-2e971675e55e @mvndy_hd @jossiwolf
  34. #hg2compose suspend fun runApp() { val composer = Recomposer() GlobalSnapshotManager.ensureStarted()

    launch(DefaultChoreographerFrameClock) { composer.runRecomposeAndApplyChanges() } Composition(NodeApplier(RootNode()), composer).apply { setContent { Content() } } } medium.com/@takahirom/inside-jetpack-compose-2e971675e55e @mvndy_hd @jossiwolf
  35. #hg2compose private inline fun <T> composing( composition: ControlledComposition, modifiedValues: IdentityArraySet<Any>?,

    block: () .> T ): T { val snapshot = Snapshot.takeMutableSnapshot( readObserverOf(composition), writeObserverOf(composition, modifiedValues) ) try { return snapshot.enter(block) } finally { applyAndCheck(snapshot) } } Recomposer @mvndy_hd @jossiwolf
  36. #hg2compose private inline fun <T> composing( composition: ControlledComposition, modifiedValues: IdentityArraySet<Any>?,

    block: () .> T ): T { val snapshot = Snapshot.takeMutableSnapshot( readObserverOf(composition), writeObserverOf(composition, modifiedValues) ) try { return snapshot.enter(block) } finally { applyAndCheck(snapshot) } } Recomposer @mvndy_hd @jossiwolf
  37. #hg2compose private inline fun <T> composing( composition: ControlledComposition, modifiedValues: IdentityArraySet<Any>?,

    block: () .> T ): T { val snapshot = Snapshot.takeMutableSnapshot( readObserverOf(composition), writeObserverOf(composition, modifiedValues) ) try { return snapshot.enter(block) } finally { applyAndCheck(snapshot) } } Recomposer @mvndy_hd @jossiwolf
  38. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer

    = %composer.startRestartGroup(.>) val %dirty = %changed if (%changed and 0b1110 ..= 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 ..= 0 .| !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ..updateScope { %composer: Composer?, %force: Int .> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
  39. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer

    = %composer.startRestartGroup(.>) val %dirty = %changed if (%changed and 0b1110 ..= 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 ..= 0 .| !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ..updateScope { %composer: Composer?, %force: Int .> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
  40. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer

    = %composer.startRestartGroup(.>) val %dirty = %changed if (%changed and 0b1110 ..= 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 ..= 0 .| !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ..updateScope { %composer: Composer?, %force: Int .> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
  41. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer

    = %composer.startRestartGroup(.>) val %dirty = %changed if (%changed and 0b1110 ..= 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 ..= 0 .| !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ..updateScope { %composer: Composer?, %force: Int .> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
  42. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer

    = %composer.startRestartGroup(.>) val %dirty = %changed if (%changed and 0b1110 ..= 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 ..= 0 .| !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ..updateScope { %composer: Composer?, %force: Int .> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
  43. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer

    = %composer.startRestartGroup(.>) val %dirty = %changed if (%changed and 0b1110 ..= 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 ..= 0 .| !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ..updateScope { %composer: Composer?, %force: Int .> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
  44. @Composable fun HelloWorld(greeting: String, %composer: Composer?, %changed: Int) { %composer

    = %composer.startRestartGroup(.>) val %dirty = %changed if (%changed and 0b1110 ..= 0) { %dirty = %dirty or if (%composer.changed(greeting)) 0b0100 else 0b0010 } if (%dirty and 0b1011 xor 0b0010 ..= 0 .| !%composer.skipping) { Text("Hello, $greeting!") } else { %composer.skipToGroupEnd() } %composer.endRestartGroup() ..updateScope { %composer: Composer?, %force: Int .> HelloWorld(greeting, %composer, %changed or 0b0001) } } #hg2compose @mvndy_hd @jossiwolf
  45. @Composable fun HelloWorld(names: List<String>) { names.forEach { name .> key(name)

    { Text(name) } } } Moveable Groups @mvndy_hd @jossiwolf
  46. @Composable fun HelloWorld(name: String) { if (name .= "Amanda") {

    Text("Hello!") else if (name .= "Jossi") { Text("Hallo!") } else { Text("Uhm.. hi?") } } Replaceable Groups @mvndy_hd @jossiwolf
  47. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens

    - Generates tokens to create an AST - PSI lays over AST Resolution Codegen Resolution performed on AST tree - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Frontend Backend - Takes optimized IR and performs more analysis, transformations + optimisations specific to target CPU architecture - Multithreading Machine-Dependent Optimisations IR Transform Compiler Analysis Middle End “Lower” - Performs optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control-flow graph < > Bytecode Target Program FUN BLOCK_BODY CALL VAR IR Unoptimized IR Codegen IR to Bytecode Optimized IR FUN BLOCK_BODY CALL VAR IR Backend The Kotlin compiler @mvndy_hd @jossiwolf
  48. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens

    - Generates tokens to create an AST - PSI lays over AST Resolution Codegen Resolution performed on AST tree - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Frontend Backend - Takes optimized IR and performs more analysis, transformations + optimisations specific to target CPU architecture - Multithreading Machine-Dependent Optimisations IR Transformations Compiler Analysis Middle End “Lower” - Performs optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control-flow graph < > Bytecode Target Program FUN BLOCK_BODY CALL VAR IR Unoptimized IR Codegen IR to Bytecode R t bytecod Optimized IR FUN BLOCK_BODY CALL VAR IR Backend Compose compiler plugin Backend - Takes optimized IR and performs more analysis, transformations + optimisations specific to target CPU architecture - Multithreading Machine-Dependent Optimisations IR Transform Compiler Analysis Middle End “Lower” - Performs optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control-flow graph < > Bytecode Target Program FUN BLOCK_BODY CALL VAR IR Unoptimized IR Codegen IR to Bytecode Optimized IR FUN BLOCK_BODY CALL VAR IR Backend @mvndy_hd @jossiwolf
  49. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens

    - Generates tokens to create an AST - PSI lays over AST Resolution Codegen Semantic Analysis performed on AST - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Kotlin Compiler Frontend @mvndy_hd @jossiwolf
  50. Element.FUN Element.BLOCK Element.CALL_EXPRESSION Token.L_BRACE Token.R_BRACE Element.REFERENCE_EXPRESSION Element.VALUE_ARGUMENT_LIST Token.IDENTIFIER Token.LPAR Token.RPAR

    Element.STRING_TEMPLATE Element.LITERAL_STRING_TEMPLATE_ENTRY Token.OPEN_QUOTE Element.REGULAR_STRING_PART Token.OPEN_QUOTE #hg2compose @mvndy_hd @jossiwolf Text("Hello, World!") AST
  51. #hg2compose .kt Lexer (Scanner) Syntax Analysis Parsing Phase Generates tokens

    - Generates tokens to create an AST - PSI lays over AST Resolution Codegen Semantic Analysis performed on AST - PSI gets enhanced with descriptors - Symbol table generated; associated node w/ descriptor via BindingTrace Kotlin Compiler Frontend @mvndy_hd @jossiwolf
  52. #hg2compose IR Transform Compiler Analysis Middle End “Lower” - Performs

    optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control-flow graph Backend - Takes optimized IR and performs more analysis, transformations + optimisations specific to target CPU architecture - Multithreading Optimized IR < > Bytecode Target Program @mvndy_hd @jossiwolf FUNC VAL_PARAM VAL_PARAM VA:_PARAM FUNC VAL_PARAM VAL_PARAM VA:_PARAM Unoptimized IR
  53. #hg2compose @mvndy_hd @jossiwolf - Performs optimisations on IR - Removes

    dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control-flow graph CPU-related IR Transformations IR Transform Compiler Analysis Middle End “Lower” Backend - Takes optimized IR and performs more analysis, transformations + optimisations specific to target CPU architecture - Multithreading < > Bytecode Target Program - Performs optimisations on IR - Removes dead code - Refactors the code - Improves performance - Analyzes IR for data needed to create - Call graph - Control-flow graph CPU-related IR Transformations FUNC VAL_PARAM VAL_PARAM VA:_PARAM Unoptimized IR
  54. 🏃Efficient Codegen Tips󰝋 #hg2compose The point of Compose transformations is

    to reduce as many groups + group executions as possible - but you can help too! @mvndy_hd @jossiwolf
  55. #hg2compose Use key to make recomposition of lists cheaper! This

    helps Compose generate moveable groups, avoiding recomposition i.e. when the position of a list item changes. @mvndy_hd @jossiwolf
  56. #hg2compose Make sure to read state values at the lowest

    node of the tree possible You only want to recompose where you actually need the state :) @mvndy_hd @jossiwolf
  57. • Jorge Castillo, author of "Compose Internals" • Leland Richardson

    for his work and sitting down with us to interview him • Zach Klippenstein's 5-part series on Compose state explained #hg2compose Thank you!!! @mvndy_hd @jossiwolf
