  1. H D Moore Director of Security Research BreakingPoint Systems Blue

    Hat 3 Conference Metasploit 3 (Exploit Intelligence and Automation)
  2. 3 Introductions - Who?  BreakingPoint Systems  Director of

    Security Research  We build hardware to break things  The Metasploit Project  Founder, developer, researcher  We build software to break things  Two primary developers, eight part-time
  3. 4 Introductions - What?  Exploit Frameworks  What they

    are  Why they matter  Metasploit Framework  What you can do with it now  What you can do with soon :-)  Metasploit v3.0  New features, new design  Starting to be usable...
  4. 5 Introductions - Why?  Security is fun!  Nearly

    everything depends on security  Improving products by breaking them  Exploiting flaws is challenging  Metasploit  Group of enthusiasts and professionals  Research and implement new techniques  Learn new languages, improve skills  Skills and tools useful for “day jobs”
  5. 6 Frameworks - Introduction  Thousands of reported vulns every

    year  People develop exploits for those vulns  Verify that a vendor patch actually works  Test a similar system for the same issue  Perform regression testing before release  Gain access to vulnerable systems  Exploits are only as good as their author  Writing solid exploits requires time
  6. 7 Frameworks – Exploit diversity  Hundreds of people release

    exploits  Everyone wants to be first  Everyone has their own style  Everyone thinks their style is best :-)  Exploits are all basically the same 1.Create and configure a payload 2.Create a string of data with the payload 3.Send that data to an application 4.Wait for the payload to execute 5.Interact with the payload
  7. 8 Frameworks – Exploit collections  Exploit frameworks add some

    sanity  Every exploit has the same structure  Redundant code moved to libraries  Consistent user interface to all exploits  Commercial  Two commercial exploit frameworks  Government, consulting, Fortune-500  Open source  Metasploit provides the only 'true' framework  Everyone, students, admins, consultants...
  8. 9 Frameworks – Commercial options  Core Impact  The

    first and arguably the most complete  Contains 126 exploits, 11 DoS, 148 misc.  Focused on 'Rapid Penetration Testing'  Immunity CANVAS  Open architecture, user-extensible  Focused on exploiting unpublished flaws :-)  Active “after-market” for CANVAS exploits
  9. 10 Frameworks – Open source  Metasploit Framework  Written

    in Perl, cross-platform support  Focused on research and exploits  Many features, loosely integrated  Quickly becoming the standard :-)  Protocol stacks  SMB, DCERPC, MSSQL  Arkeia, BackupExec, ARCServe  Basic IDS/IPS evasions
  10. 11 Frameworks – Metasploit v2.5  March 2006 status 

    125 remote exploits, 75 payloads  Web site reaches 350,000 IPs a month  Found in 16 books, 880 blogs, 180 articles  20,000 unique online update IPs in 2006  Growing pains...  Load time keeps increasing (200+ modules)  Still difficult to target client-side flaws  Recon modules lack real automation  Feature integration is non-optimal
  11. 12 Frameworks – Metasploit v3.0  Completely rewritten in Ruby

     Object oriented model was a better fit  Code compression right around 40%  2.5 was 40K of Perl, 3.0 is 80K of Ruby  New design, new features, new goals  Focused on flexibility and automation  Closer integration between features  Development guide and API docs!
  12. 13 Metasploit v3.0 - Architecture rex framework-core framework-base interfaces modules

    msfweb msfcli msfconsole msfwx encoders payloads exploits nops auxiliary msfapi security tools web services integration libraries protocol tools custom plugins
  13. 14 Metasploit v3.0 – New features  Multitasking through Ruby

    threads  Share single instance with many users  Great for team-based penetration testing  Multi-user plugin is only ~20 lines of code :-)  Concurrent exploits and sessions  Support for passive exploits and recon  Multiple payload sessions open at once  Suspend and restore payload sessions  Share payload sessions with other users
  14. 15 Metasploit v3.0 – New features  Extensive exploit module

    “Mixins”  Write advanced exploits in only 3 lines :-)  Mixins for SMB, DCERPC, HTTP, FTP...  Huge boost for module consistency  Example FTP server exploit: connect buf = Rex::Text.rand_text_english(2048, payload_badchars) seh = generate_seh_payload(target.ret) buf[229, seh.length] = seh send_cmd( ['USER', buf] , false ) handler disconnect
  15. 16 Metasploit v3.0 – New features  Shiny new interfaces!

     Console uses module hierarchy/regex  Web interface now uses AJAX  GUI version now in development:
  16. 17 Metasploit v3.0 – Opcode Database  Opcode DB has

    been enhanced  Online database of win32 DLL information  Stores the location of usable 'opcodes'  Now supports multiple languages  Useful for developing reliable exploits  Framework integration  New command-line tool for queries  Building an 'opcode pool' system  Automated return address updates  Combine this with fingerprinting...
  17. 18 Metasploit v3.0 – Executable processing  msfpescan  Command-line

    tool for EXE processing  Discovers usable return addresses  Partially used to create the Opcode DB  Now handles Resources and TLBs  msfrpcscan  Extracts MIDL information from PE files  Creates boilerplate for new exploits  Still in development...
  18. 19 Metasploit v3.0 – Exploit upgrades  Rewrite of all

    exploit modules  Massive number of bug fixes  Improved randomness, use of Mixins  Exploit module structure  Single exploit can target many platforms  Simplified the meta-information fields  Mixins can also modify exploit behavior  Target brute forcing  Passive exploits
  19. 20 Metasploit v3.0 – Payload upgrades  Enhancements  Bug

    fixes and size improvements  New “cmd” modules, new “PHP” payloads...  Meterpreter  Consolidation of standard modules  Wicked cool API and remote scripting # Process migration pid = client.sys.process['calc.exe'] client.core.migrate(pid) # Mirror the remote hard drive in one line client.fs.dir.download(“/tmp/”, “C:\\”, true)
  20. 21 Metasploit v3.0 – Auxiliary modules  The problem... 

    Not all exploits fit into the standard structure  Recon modules overlapped with exploits  No standard for information sharing  Auxiliary modules  Catch-all for interesting security tools  Perform reconnaissance and reporting  Integrate with third-party utilities  Export data in a standard format  Can trigger events which launch attacks...
  21. 22 Metasploit v3.0 – Plugins  The Ruby language rocks

     Ability to redefine anything at runtime  Plugins can alter almost anything  Framework plugins  Extend and replace Framework code  Hook events and filter parameters  Simplify feature development  Examples:  Socket tracing and filtering  Multiuser exploit console
  22. 23 Metasploit v3.0 – IDS / IPS Evasion  Evasion

    is finally taken seriously  Evasion options now a separate class  Protocol stacks integrate IDS evasion  Mixins expose these to exploit modules  Strong evasion techniques  Multi-layered evasion defeats most solutions  Client-side attacks impossible to detect  WMF = HTTP + Compress + Chunked + JScript  Deep protocols offer so many options  LSASS = TCP + SMB + DCERPC
  23. 24 Metasploit v3.0 – Status  Finally released 3.0-alpha-r3! 

    User interfaces are still a bit rough  Module caching a huge improvement  Over half of the exploits are ported  Only support Linux / OS X right now...  New licensing, organization updates  Keep source code open, prevent abuse  Non-profit status through sponsor (soon!)  Shiny new graphics from BRUTE!
