  1. Presented by Liang Gong Skeletal Program Enumeration for Rigorous Compiler

    Testing Qirun Zhang, Chengnian Sun, Zhendong Su Liang Gong, Electric Engineering & Computer Science, University of California, Berkeley.
  2. Motivation Liang Gong, Electric Engineering & Computer Science, University of

    California, Berkeley. • Test generation for compilers • Existing works: • Program generation (Csmith) • Generate test from scratch • Program mutation (EMI) • Randomly remove statements Random  Opportunistic Favor large/complex programs 2
  3. Program Enumeration Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. • Observation • Bug-triggering programs are small • ~30 LOC (Sun et al. ISSTA’16) • Program mutation • mutations of statements • Change variable names • Search space is bounded  enumeration • Confirmed Bugs: • GCC/Clang (217),CompCert (29), Scala (42) 3
  4. Change Identifiers Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. mutate identifiers can trigger optimizations 4 Original Test Mutated Test • Constant propagation • Dead code elimination
  5. Motivating Example Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. 5 Mutated program triggers a bug related to alias in GCC.
  6. Motivating Example Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. 6 Mutated program triggers a bug related to constant folding. GCC crash
  7. Program Enumeration Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. Goal: Enumerate all identifier mutations • Step-1: Convert an existing test into skeleton 7 Test Skeleton
  8. Program Enumeration Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. Goal: Enumerate all identifier mutations • Step-1: Convert an existing test into skeleton 8 Syntax rule of program Correspond rule of transformation
  9. Program Enumeration Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. Goal: Enumerate all identifier mutations • Step-2: fill in the holes in a skeleton 9 Generated Test Skeleton Generated Test
  10. Program Enumeration Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. Goal: Enumerate all identifier mutations • Step-2: fill in the holes in a skeleton 10 Generated Test Skeleton Generated Test <b, a, b, b, b, a> <a, b, b, b, a, b> 2 1 3 4 5 6
  11. Program Enumeration Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. Goal: Enumerate all identifier mutations • Step-2: fill in the holes in a skeleton 11 Generated Test Skeleton Generated Test 2 1 3 4 5 6 <b, a, b, b, b, a> <a, b, a, a, a, b> α-equivalent
  12. Program Enumeration Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. Goal: Enumerate all identifier mutations • Step-2: fill in the holes in a skeleton • Formulate as a set partition problem (well-known) 12 Generated Test Skeleton Generated Test 2 1 3 4 5 6 <b, a, b, b, b, a> <a, b, a, a, a, b> { {1,3,4,5}, {2, 6} } { {1,3,4,5}, {2, 6} } 64 (naive)  31 (set partition) 
  13. Stirling Partition Number Liang Gong, Electric Engineering & Computer Science,

    University of California, Berkeley. 13 The number of ways to partition n elements into k subsets
  14. Stirling Partition Number Liang Gong, Electric Engineering & Computer Science,

    University of California, Berkeley. 14 The number of ways to partition n elements into k subsets
  15. Stirling Partition Number Liang Gong, Electric Engineering & Computer Science,

    University of California, Berkeley. 16 Partition n+1 elements into k subsets
  16. Stirling Partition Number Liang Gong, Electric Engineering & Computer Science,

    University of California, Berkeley. 17 Partition n+1 elements into k subsets • The selected element is partitioned to a set s, where | s | = 1
  17. Stirling Partition Number Liang Gong, Electric Engineering & Computer Science,

    University of California, Berkeley. 18 Partition n+1 elements into k subsets • The selected element is partitioned to a set s, where | s | = 1 • The selected element is partitioned to a set s, where | s | > 1
  18. Stirling Partition Number Liang Gong, Electric Engineering & Computer Science,

    University of California, Berkeley. 19 • Now we can get all partitions recursively: function par(n, k) { ... // handle base cases return union( add(n, par(n-1, k)), par(n-1, k-1)); }
  19. Time Complexity Liang Gong, Electric Engineering & Computer Science, University

    of California, Berkeley. 20 • A skeleton with n holes and k variables. Olver et al. NIST Handbook of Mathematical Functions.
  20. Set Partition (with Scopes) Liang Gong, Electric Engineering & Computer

    Science, University of California, Berkeley. Each hole in a skeleton can be filled with a different set of variables. 21 Global scope hole local scope
  21. Set Partition (with Scopes) Liang Gong, Electric Engineering & Computer

    Science, University of California, Berkeley. Naïve approach: 22
  22. Set Partition (with Scopes) Naïve approach does not completely enumerate

    X Locally: <a,c> = <c,a> Globally: <a,a,a,c,b> ≠ <a,a,c,a,b> { {3}, {4} } { {1,2,3}, {4}, {5} } ≠ { {1,2,4}, {3}, {5} } 27
  23. Set Partition (with Scopes) Liang Gong, Electric Engineering & Computer

    Science, University of California, Berkeley. promote local holes to be global holes 28
  24. Set Partition (with Scopes) Liang Gong, Electric Engineering & Computer

    Science, University of California, Berkeley. 29 , { 3 }, { 4 }, { 3, 4 } promote local holes to be global holes
  25. Set Partition (with Scopes) Liang Gong, Electric Engineering & Computer

    Science, University of California, Berkeley. 30 , { 3 }, { 4 }, { 3, 4 } X promote local holes to be global holes
  26. Set Partition (with Scopes) Liang Gong, Electric Engineering & Computer

    Science, University of California, Berkeley. 31 , { 3 }, { 4 }, { 3, 4 } X X { 3 } promote local holes to be global holes
  27. Set Partition (with Scopes) Liang Gong, Electric Engineering & Computer

    Science, University of California, Berkeley. 32 , { 3 }, { 4 }, { 3, 4 } X X { 3 } X { 4 } { 3, 4 } promote local holes to be global holes
  28. Evaluation: size reduction • 94 orders of reduction • Still

    too large in practice Liang Gong, Electric Engineering & Computer Science, University of California, Berkeley. 33
  29. Evaluation: size reduction • 94 orders of reduction • Still

    too large in practice • Throw away tests with > 10K variants Liang Gong, Electric Engineering & Computer Science, University of California, Berkeley. 34
  30. Evaluation: size reduction • 94 orders of reduction • Still

    too large in practice • Throw away tests with > 10K variants Liang Gong, Electric Engineering & Computer Science, University of California, Berkeley. 35
  31. Evaluation: size reduction • 94 orders of reduction • Still

    too large in practice • Throw away tests with > 10K variants • Retained 90% of the original tests Liang Gong, Electric Engineering & Computer Science, University of California, Berkeley. 36
  32. Evaluation: size reduction • Throw away tests with > 10K

    variants • Retained 90% of the original tests Characteristics of tests after filtering Liang Gong, Electric Engineering & Computer Science, University of California, Berkeley. 37
  33. Evaluation: coverage GCC: ~30% Clang: ~20% GCC Clang (PM-X: EMI

    deletes X statements) Liang Gong, Electric Engineering & Computer Science, University of California, Berkeley. 38
