Cash App & Gradle: A Journey in Android Developer Productivity

A case study on how Cash App and Gradle have been working together to optimize Cash App builds, find bottlenecks, and improve developer productivity. John Rodriguez from Square and Rooz Mohazzabi from Gradle will share wins and findings from their journey on...

* How Cash App does builds
* Biggest wins and findings debugging Cash App local and CI builds
* Best performance practices for builds at scale
* Optimizing for your expensive build tasks, i.e., assemble, lint, etc
* Tracking down bottlenecks in 3rd-party plugins
* Speeding up local builds with the remote build cache during pandemic

Video: https://www.droidcon.com/2021/11/17/cash-app-gradle-a-journey-in-android-developer-productivity/

Transcript

1. A Journey in Android Developer Productivity Cash App & Gradle
2. How Cash App Does Builds
7. The Tools We Used
9. ./gradlew app:assembleDebug
10. ./gradlew app:assembleDebug --scan
17. Biggest wins and findings
18. What we discovered - Discovered negative savings from the remote cache

 - After optimizations and applying the cache fix plugin, most instances of negative savings were eliminated, even in East Coast regions.

 - Wire plugin cacheability issues

 - The configuration for enabling the remote cache was not working properly

 - Unnecessary VPN issues causing long build times
19. After identifying and fixing cache misses avoidance savings from the remote cache started to increase
20. AssembleDebug Build Time Down by ~50%
21. Remote Cache Saving CI Builds an average ~8 min per build CI Compute Resource Savings from remote cache: 55 Days & 16 hours per week
22. Optimizing for your expensive build tasks
27. apply plugin: 'com.android.library ' apply plugin: 'org.jetbrains.kotlin.android ' apply plugin: 'org.jetbrains.kotlin.kapt ' apply plugin: 'org.jetbrains.kotlin.plugin.parcelize ' apply plugin: 'app.cash.paparazzi ' apply plugin: 'app.cash.treehouse'
28. Section Title apply plugin: 'java-library'
29. apply plugin: 'com.android.library '
30. JavaCompile task
31. JavaCompile task class files
32. JavaCompile task class files source files
33. JavaCompile task class files source files target sdk
34. JavaCompile task class files source files target sdk max heap size
35. task task outputs task inputs
36. task task outputs task inputs UP-TO-DATE (aka incremental build)
37. JavaCompile task class files source files target sdk max heap size
38. JavaCompile task A.class A.java JDK 11 4 GB
39. JavaCompile task A.class A.java JDK 11 4 GB EXECUTED
40. JavaCompile task A.class, B.class A.java, B.java JDK 11 4 GB
41. JavaCompile task A.class, B.class A.java, B.java JDK 11 4 GB EXECUTED
42. JavaCompile task A.class, B.class A.java, B.java JDK 11 4 GB UP-TO-DATE x 2
43. JavaCompile task A.class A.java JDK 11 4 GB
44. JavaCompile task A.class A.java JDK 11 4 GB CACHED echo “org.gradle.caching=true” >> gradle.properties
45. Speeding Up Local Builds with the Remote Build Cache
50. Average AssembleDebug savings from the remote cache were low: 20 sec wall clock time
51. private void addOsXMetadata() { buildScan.background { def json = new JsonSlurper( ) def ip = exec('curl', '-s', 'https://ipinfo.io/ip' ) def ge o if (ip) { geo = json.parseText ( exec('curl', '-s', “https://json.geoiplookup.io/$ip” ) ) } if (ip && geo) { value 'OS: Location', "${geo.city}, ${geo.region}, ${geo.country} " value 'OS: Coordinates', "${geo.latitude}, ${geo.longitude} " } else { value 'OS: Location', 'Unknown ' } } }
53. NYC Developers Saving 1 min 12 sec of build execution time per build from the remote build cache
 Wall Clock Time: 38 sec of eng time savings
54. SF Developers Saving 3 min 41 sec of build execution time per build from the remote build cache Wall Clock Time: 3 min 10 sec eng time savings
55. SF vs NYC difference in remote cache avoidance savings: 2 min 12 sec East Coast Local AssembleDebug builds: ~709 per week Remote Cache Node in the East Coast would result in... 709 * 2 min 12 sec = 1559.8 min of saved eng time per week * 48 work weeks per year = 1247.84 hours of saved eng time per year
56. $ grep "include '" settings.gradle | wc -l 590
57. $ 590 grep "include '" settings.gradle | wc -l
58. $ grep "include '" settings.gradle | wc -l 590
62. Tracking down bottlenecks in 3rd-party plugins
77. Time to run task Time loading from cache Avoidance Savings!
80. Best practices for build performance
84. @Overrid e <T extends Task> T create ( String name, Class<T> type, Action<? super T> configuratio n ) throws InvalidUserDataException;
85. @Overrid e <T extends Task> T create ( String name, Class<T> type, Action<? super T> configuratio n ) throws InvalidUserDataException;
86. @Overrid e <T extends Task> T create ( String name, Class<T> type, Action<? super T> configuratio n ) throws InvalidUserDataException; @Overrid e TaskProvider<Task> register ( String name, Action<? super Task> configurationActio n ) throws InvalidUserDataException ;
87. @Overrid e <T extends Task> T create ( String name, Class<T> type, Action<? super T> configuratio n ) throws InvalidUserDataException; @Overrid e TaskProvider<Task> register ( String name, Action<? super Task> configurationActio n ) throws InvalidUserDataException ;
90. Upgrade!
94. $ grep "include '" settings.gradle | wc -l 590
97. buildCache { remote(HttpBuildCache) { if (!isCi) { def pingCache = 'ping -c1 -W1 -q gradle-enterprise.aws.square.com'.execute( ) def isCacheUnreachable = !pingCache.waitFor(2, TimeUnit.SECONDS) | | pingCache.exitValue() == 6 8 if (isCacheUnreachable) { throw new GradleException(... ) } url = 'https://gradle-build-cache.aws.square.com/cache/ ' }
98. boolean isVpnCheckEnabled = hasProperty('com.squareup.cash.vpn.check.enabled') ? getProperty('com.squareup.cash.vpn.check.enabled').toBoolean() : true buildCache { remote(HttpBuildCache) { if (!isCi) { def pingCache = 'ping -c1 -W1 -q gradle-enterprise.aws.square.com'.execute( ) def isCacheUnreachable = !pingCache.waitFor(2, TimeUnit.SECONDS) | | pingCache.exitValue() == 6 8 if (isCacheUnreachable && isVpnCheckEnabled) { throw new GradleException(... ) } url = 'https://gradle-build-cache.aws.square.com/cache/ ' }
99. void addGradleBuildMetadata() { def filteredProperties = project.propertie s .findAll { def key = it.ke y key.startsWith('android.') | | key.startsWith('org.gradle.') | | key.startsWith('com.squareup.') | | key.startsWith('app.cash.') | | key.startsWith('kotlin.') | | key.startsWith('kapt.' ) } filteredProperties.sort()*.ke y .forEach { key - > println("$key = ${filteredProperties[key]}" ) buildScan.value("Property: $key", "${filteredProperties[key]}" ) } }
104. http://bit.ly/34ZN5UQ
105. https://github.com/JetBrains/kotlin/blob/master/libraries/tools/kotlin-gradle-plugin/src/main/kotlin/org/ jetbrains/kotlin/gradle/tasks/Tasks.kt#L223
106. Recap of Build Performance Essentials Build Scans = your best friend Daemon Parallel Max Workers Configuration On Demand
111. A Journey in Android Developer Productivity Cash App & Gradle @jrodbx @DJRooz
