API securing principles as a software developer at Cloud Era

In this session, we will see some real practices of developing APIs using microservice architecture, which go beyond HTTP verbs and Status Code. We will show some principles inherent in the API First methodology until the deployment of the API in production, including security details, that is, how to protect your API using Service Mesh infrastructure and/or API gateway, focusing on the day-to-day life of a software developer.

Transcript

1. API securing as a so ware developer at Cloud Era Cláudio Oliveira & Luram Archanjo
2. Who am I? Luram Archanjo Software Engineer MBA in Java projects Java and Microservice enthusiastic 2
3. Who am I? Cláudio E. de Oliveira APIs Tech Lead at LuizaLabs Golang, Java, microservices & k8s 3
4. Agenda API First Principles of security as a developer Responsibilities - Traffic North & South - Traffic East & West Demo 4
5. 5 Why talk about it?
6. 6 API First An API-first approach means that for any given development project, your APIs are treated as “first-class citizens.” That everything about a project revolves around the idea that the end product will be consumed by mobile devices, and that APIs will be consumed by client applications. Source: https://swagger.io/resources/articles/adopting-an-api-first-approach/
7. 7 API First - Step Back Backend
8. 8 API First #1 Development teams can work in parallel #2 Reduces the cost of developing apps #3 Increases the speed to market #4 Ensures good developer experiences Source: https://swagger.io/resources/articles/adopting-an-api-first-approach/
9. 9 Principles of security as a developer
10. 10 Authentication Authentication is the act of validating that users are whom they claim to be. This is the first step in any security process. Example: Employees in a company are required to authenticate through the network before accessing their company email
11. 11 Authorization Authorization in a system security is the process of giving the user permission to access a specific resource or function. In secure environments, authorization must always follow authentication. Example: After an employee successfully authenticates, the system determines what information the employees are allowed to access
12. 12 Ownership of data Ownership of data is a part of data security and is related to the proper handling of data. It is the process of check the ownership of the data! Example: After an employee successfully authenticates, the employee can only manipulate data that is yours.
13. 13 Authentication Authorization Confirms users who are they say there are Gives users permission to access a resource Ownership Confirms users data and permissions to handle it
14. 14 Cloud Native Security Principles
15. 15 Basics knowledge for API Security • HTTPS • ssl/tls • Metrics • OpenID Connect
16. 16 Perimeter Security
17. 17 Perimeter Security • Defense-in-depth multiple layers of security • Should be easy to integrate with in place systems like VPN, Firewall etc... • Multiple Policy Enforcement Points increase security
18. 18 Infrastructure Security • Language agnostic • Infrastructure is secure (platforms) • Increase governance level • “Hot deployment”
20. Traffic Types 20
21. 21 North-South traffic
22. 22 North-South Traffic • Clients is unknown in general • Best place to put Bot detection and treat abusive traffic • API Products expose business through APIs
23. 23 East-West traffic
24. 24 Zero Trusted Network • The cloud environment is heterogeneous • Different types of workloads • Integrate with Defense-in-depth concept • All elements in network is untrusted • All systems should get kind of grant before call others systems
25. 25 A of them are open-source
26. 26 Big Picture
27. 27 Demo time
29. 29 Securing East-West
30. 30 mTLS
31. 31 Extracted from https://github.com/smallstep/autocert/blob/master/examples/hello-mtls/README.md
34. 34 Demo time
36. Authn 36
37. 37 Every sidecar can check jwt token and validate token integrity
38. 38 RequestAuthentication is for Identity and AuthorizationPolicy is the rule
39. 39 Ok...service mesh is enough to improve secure???
41. 41 Turns to!!!
43. 43 “Micro” Gateway can help us! Hiding implementation details and acting as Bounded Context https://www.solo.io/blog/challenges-of-adopting-service-mesh-in-enterprise-organizations/
45. 45 Demo time
47. 47 Securing North-South
48. 48 Securing North-South #1 Micro gateway vs Enterprise Gateway #2 OpenID Connect for external clients (end-users) #3 Handle abusive traffic rate limiting #4 API Products
50. 50 Demo time
53. Thanks! Any questions? You can find us at 53 claudioed claudioed luramarchanjo luram_archanjo
54. 54 API First - Step Forward Frontend Team Backend Team Mock Backend Frontend
55. 55 Authentication Authorization Confirms users who are they say there are Gives users permission to access a resource ??? ???
56. 56 What is PeP?? The Policy Enforcement Point (PEP) is the piece of network or security equipment that controls user access and ensures the authorization decision made by the Policy Decision Point (PDP).
57. 57 https://www.manning.com/books/microservices-security-in-action
58. 58 Infrastructure Security
59. 59 How mTLS works in Istio / Envoy 1. Service account token is assigned to Istio Proxy 2. Pilot agent send Token and CSR to Istiod 3. Istiod validate k8s token 4. The istiod signs the certificate and provides it to pilot agent 5. The pilot agent calls Envoy SDS to configure it https://www.manning.com/books/istio-in-action
