Presentation given by Miguel Araujo (@maraujop) at Codemotion Madrid 2013 and PyCon Spain 2013.

This talk introduces Computer Vision in Python for everyone, from an engineer perspective. Putting some of the concepts introduced into place building a red light running detector named HAL.

Miguel Araujo

October 19, 2013
Tweet

More Decks by Miguel Araujo

Other Decks in Programming

Transcript

  1. CAMERAS Compact cameras DSLR cameras (Reflex) Micro cameras USB cameras

    (webcams) IP cameras Depth field / 3D cameras
  2. CHOOSING A CAMERA Volume / Weight Size of the sensor,

    bigger is always better Focal Length Resolution Light conditions Adjustable Price
  3. PHOTOGRAPHY 101 3 PILLARS Shutter speed Aperture ISO (Film speed)

    ALSO White balance etc http://bit.ly/poBjKi
  4. ISO

  5. VISION Compact Cameras Many take from 6-15 seconds using libgphoto2.

    Rarely can stream video in real time. Rarely can adjust camera settings on the go.
  6. VISION DSLRs Good time response. Very well supported, many features.

    Many camera parameters adjustable on the fly.
  7. OPENCV Open Source Known and respected C++ powered Python bindings

    Low level concepts, hard for newbies opencv-processing and others
  8. SIMPLECV Built on top of OpenCV using Python Not a

    replacement High level concepts and data structures It also stands on the shoulders of others giants: numpy, Orange, scipy... Well, yeah, it uses camelCase simplecv-js
  9. BLOB A region of an image in which some properties

    are constant or vary within a prescribed range of values. Blue M&Ms are blobs m_and_ms = Image('m&ms.jpg') blue_dist = m_and_ms.colorDistance(Color.BLUE) blue_dist.show()
  10. POLISHING IT findBlobs(minsize, maxsize, threshval, ...) blue_dist.findBlobs(minsize=200) blobs = blobs.filter(blobs.area()

    > 200) len(blobs) >> 36 average_area = np.average(blobs.area()) >> 37792.77 blue_dist = blue_dist.scale(0.35) blobs = blue_dist.findBlobs(threshval=177, minsize=100) len(blobs) >> 25
  11. RULES Dynamic is better than fixed, but harder to achieve.

    If color is not needed, drop it, at least until needed. The smaller the picture, less information, faster processing. Always use the easiest solution, which will usually be the fastest too. Real life vs laboratory situations. Some things are harder than they look like. When working in artificial vision, don't forget about other input sources (time, sounds, etc).
  12. COLOR SPACES RGB / BGR image.toRGB() HSV (HUE SATURATION VALUE)

    image.toHSV() YCBCR image.toYCbCr() http://bit.ly/1dSSoI2
  13. BINARIZE Creates a binary (black/white) image. It's got many parameters

    you can tweak. Use Otsu's method by default, adjusting the threshold dynamically for better results. blue_dist.binarize(blocksize=501).show()
  14. DETECTORS CORNERS Hessian Affine Harris Affine FAST KEYPOINTS SIFT SURF

    MSER ORB (Tracking) BRISK (Tracking) FREAK (Tracking) MANY MORE Find ROIs
  15. FINDKEYPOINTMATCH Detection: Hessian affine Description: SURF Matching: FLANN Knn Filtering:

    Lowe's ratio test find an Homography Returns a FeatureSet with one KeypointMatch
  16. CLUSTERING def find_clusters(keypoints, separator=None): features = FeatureSet(keypoints) if separator is

    None: separator = np.average(features.area()) features = features.filter( features.area() > separator ) return features.cluster( method="hierarchical", properties="position" )
  17. BIGGEST CLUSTER def find_biggest_cluster(clusters): max_number_of_clusters = 0 for cluster in

    clusters: if len(cluster) > max_number_of_clusters: biggest_cluster = cluster max_number_of_clusters = len(cluster) return biggest_cluster
  18. NORMAL DISTRIBUTION Point = namedtuple('Point', 'x y') def distance_between_points(point_one, point_two):

    return sqrt( pow((point_one.x - point_two.x), 2) + \ pow((point_one.y - point_two.y), 2) ) skp_set = FeatureSet(biggest_cluster) x_avg, y_avg = find_centroid(skp_set) centroid = Point(x_avg, y_avg) uno.drawRectangle( x_avg, y_avg, 20, 20, width=30, color=Color.RED )
  19. NORMAL DISTRIBUTION distances = [] for kp in biggest_cluster: distances.append(distance_between_points(kp,

    centroid)) mu, sigma = cv2.meanStdDev(np.array(distances)) mu = mu[0][0] sigma = sigma[0][0] for kp in skp: if distance_between_points(kp, centroid) < (mu + 2*sigma): uno.drawRectangle( kp.x, kp.y, 20, 20, width=30, color=Color.GREEN )
  20. HAAR Needs to be trained with hundreds/thousands Scale invariant NOT

    Rotation invariant Fast and robust Not only for faces How face detection works
  21. TRACKING Detection != tracking Uses information from previous frames Initially

    tracks what we want SOME ALTERNATIVES Optic Flow: Lucas-Kanade Descriptors: SURF Probability/Statistics and histograms: Camshift
  22. CAMSHIFT Effective for tracking simple and constant objects with homogeneous

    colors, like faces. Gary Bradski in 1998 Original implementation has problems with similar color objects around or crossing trajectories and lightning changes.
  23. SIMPLE EXAMPLE from SimpleCV import * video = VirtualCamera("jack.mp4", 'video')

    video_stream = VideoStream( "jack_tracking.mp4", framefill=False, codec="mp4v" ) track_set = [] current = video.getImage() while (disp.isNotDone()): frame = video.getImage() track_set = frame.track( 'camshift', track_set, current, [100, 100, 50, 50] ) track_set.drawBB() current = frame frame.save(video_stream)
  24. MORE COMPLEX Initialization video_stream = VideoStream( "jack_tracking.avi", framefill=False, codec="mp4v" )

    video = VirtualCamera("jack.mp4", 'video') disp = Display() detected = False current = video.getImage().scale(0.6) tracked_objects = [] last_diff = None
  25. while (disp.isNotDone()): frame = video.getImage().scale(0.6) # Scene changes diff =

    cv2.absdiff(frame.getNumpyCv2(), current.getNumpyCv2()) if last_diff and diff.sum() > last_diff * 6: detected = False last_diff = diff.sum() # Detects faces and restarts tracking faces = frame.findHaarFeatures('face2.xml') if faces and not detected: tracked_objects = [] final_faces = [] for face in faces: if face.area() > 65: tracked_objects.append([]) final_faces.append(face) detected = True
  26. # Restart if tracking grows too much if detected: for

    i, track_set in enumerate(tracked_objects): track_set = frame.track( 'camshift', track_set, current, final_faces[i].boundingBox() ) # Restart detection and tracking if track_set[-1].area > final_faces[i].area() * 3 \ or not detected: detected = False break # Update tracked object and draw it tracked_objects[i] = track_set track_set.drawBB() current = frame frame.save(video_stream)
  27. MOG

  28. BACKGROUND SUBSTRACTION Separate people and objects that move (foreground) from

    the fixed environment (background) MOG - Adaptative Mixture Gaussian Model
  29. BACKGROUND SUBSTRACTION mog = MOGSegmentation( history=200, nMixtures=5, backgroundRatio=0.3, noiseSigma=16, learningRate=0.3

    ) video = VirtualCamera('semaforo.mp4', 'video') video_stream = VideoStream("mog.mp4", framefill=False, codec="mp4v") while (disp.isNotDone()): frame = video.getImage().scale(0.5) mog.addImage(frame) # segmentedImage = mog.getSegmentedImage() blobs = mog.getSegmentedBlobs() if blobs: blobs.draw(width=-1) frame.save(video_stream)
  30. RED LIGHT RUNNERS 1- Detect if traffic light is red,

    otherwise it's green. Using hysteresis. 2- Project a line for runners. 3- Do MOG and pruning for finding cars. 4- When traffic light is RED, if a car blob intersects the line, then it's a runner. 5- Recognize car to count it only once.
  31. red_light_bb = [432, 212, 13, 13] cross_line = Line( frame.scale(0.5),

    ((329, 230), (10, 360)) ) RED = False number_of_opposite = 0 HISTERESIS_FRAMES = 5
  32. def is_traffic_light_red(frame): red_light = frame.crop(*red_light_bb) # BLACK (30, 28, 35)

    # RED (21, 17, 51) if red_light.meanColor()[2] > 42: return True return False
  33. def hysteresis(red_detected=False, green_detected=False): global RED, number_of_opposite if RED and green_detected:

    number_of_opposite += 1 if number_of_opposite == HISTERESIS_FRAMES: RED = False number_of_opposite = 0 elif not RED and red_detected: number_of_opposite += 1 if number_of_opposite == HISTERESIS_FRAMES: RED = True number_of_opposite = 0 else: number_of_opposite = 0
  34. while (disp.isNotDone()): frame = video.getImage() small_frame = frame.scale(0.5) mog.addImage(small_frame) if

    is_traffic_light_red(frame): hysteresis(red_detected=True) if RED: blobs = mog.getSegmentedBlobs() if blobs: big_blobs = blobs.filter(blobs.area() > 1000) for car in big_blobs: if cross_line.intersects(car.getFullMask()): # RED LIGHT RUNNER small_frame.drawRectangle( *car.boundingBox(), color=Color.RED, width=3 ) else: hysteresis(green_detected=True) small_frame.save(disp)
  35. RASPBERRY Autonomous system, ethernet connected, uploads runner videos online. No

    night time support yet. Slower, not real time, discards green parts. Raspberry SimpleCV Raspicam
