Caching is Hard: Varnish @ Disqus

Caching is Hard: Varnish @ Disqus

VUG7, May 31st 2013

Matt Robenolt

May 31, 2013
Tweet

More Decks by Matt Robenolt

Other Decks in Programming

Transcript

  1. So, what is Disqus? <div id="disqus_thread"></div> <script type="text/javascript"> /* *

    * CONFIGURATION VARIABLES: EDIT BEFORE PASTING INTO YOUR WEBPAGE * * */ var disqus_shortname = 'mattrobenolt'; // required: replace example with your forum shortname /* * * DON'T EDIT BELOW THIS LINE * * */ (function() { var dsq = document.createElement('script'); dsq.type = 'text/ javascript'; dsq.async = true; dsq.src = '//' + disqus_shortname + '.disqus.com/embed.js'; (document.getElementsByTagName('head')[0] || document.getElementsByTagName('body')[0]).appendChild(dsq); })(); </script> <noscript>Please enable JavaScript to view the <a href="http://disqus.com/? ref_noscript">comments powered by Disqus.</a></noscript> <a href="http://disqus.com" class="dsq-brlink">comments powered by <span class="logo-disqus">Disqus</span></a>
  2. First, some numbers. ๏ ~1 billion unique visitors per month

    ๏ ~5MM new threads per day ๏ Total requests ๏ ~35,000/s ๏ Varnish ๏ ~25,000/s ๏ Django backends ๏ ~12,000/s. ๏ ~66% cache hit ratio ๏ Could be much much better
  3. Clients do terrible things. ๏ Cookies ๏ Cache busting tokens

    ๏ /embed.js?_=1234567 ๏ Querystrings ๏ People will use your shit in ways that you never planned.
  4. How does the embed load? ๏ JavaScript bootloader ๏ Load

    <iframe> as anonymous user ๏ 3 minimum critical HTTP requests ๏ 1 optional API request to fetch user specific data and layer it on top
  5. *.disqus.com/embed.js sub vcl_recv { if (req.url ~ "^/embed\.js") { error

    750; } } } sub vcl_error { if (obj.status == 750) { set obj.http.Location = "http://go.disqus.com/ embed.js"; set obj.response = "Found"; set obj.status = 302; return(deliver); } }
  6. *.disqus.com/embed.js ๏ This request alone is ~10,000/s on average ๏

    Previously hit our slow backends ๏ Maintain ability to toggle behavior with DNS
  7. go.disqus.com/embed.js sub vcl_recv { if (req.http.Cookie) { set req.http.X-Order =

    regsub(req.http.Cookie, "^.*?disqus\.order=([^;] +).*?$", "\1"); if (req.http.X-Order == req.http.Cookie) { set req.http.X-Order = "default"; } } else { set req.http.X-Order = "default"; } set req.url = "/current/build/next/embed." req.http.X-Order ".js"; unset req.http.Cookie; }
  8. go.disqus.com/embed.js sub vcl_fetch { if (req.url ~ "/embed\.\w+\.js$") { set

    beresp.http.Vary = "Accept-Encoding, X- Order"; set beresp.http.Cache-Control = "public, max-age=10"; set beresp.ttl = 10s; set beresp.grace = 24h; } }
  9. go.disqus.com/embed.js ๏ Origin fetches from our static media server once

    every 10 seconds to refresh ๏ This logic used to be handled by our app on the first request ๏ Avoids varying by Cookie at the cache level ๏ Still vary on Cookie at the client, but meh ๏ Will serve stale for 24h if we fuck up
  10. disqus.com/embed/comments/ sub vcl_fetch { set beresp.grace = 4h; set beresp.ttl

    = std.duration(regsub(beresp.http.Surrogate-Control, "max-age=(\d+)", "\1s"), 60s); unset beresp.http.Surrogate-Control; unset beresp.http.Vary; set beresp.http.Vary = "Accept-Encoding"; set beresp.http.Cache-Control = "no-cache, public, must-revalidate"; unset beresp.http.Set-Cookie; }
  11. disqus.com/embed/comments/ ๏ Control the cache duration from the app with

    Surrogate-Control ๏ We don’t want to cache at the client, but we do at the edge ๏ Explicitly coerced a request to anonymous ๏ Prevented our app from sending back something stupid ๏ Works in the event of app failure for up to 4h
  12. disqus.com/embed/comments/ ๏ Can more reliably load the embed and at

    least show an error message ๏ If it’s a hot thread, it’s very likely that it is cached ๏ Can cache threads longer in the event of high loads
  13. disqus.com/…/threadDetails sub vcl_recv { // Remove cache busting token set

    req.url = regsuball(req.url, "([\?|&])_\d+=1", "\1"); }
  14. disqus.com/…/threadDetails sub vcl_recv { set req.http.Extension = regsub(req.url, "^.*? threadDetails(\.[^?]+)?.*?$",

    "\1"); // Extract the `thread` if (req.url ~ "thread=") { set req.http.Thread-Id = regsub(req.url, "^.*? thread=(\d+)?.*?$", "\1"); } else { set req.http.Thread-Id = ""; } }
  15. disqus.com/…/threadDetails sub vcl_recv { // Reconstruct a uniform URL set

    req.url = "/api/3.0/embed/threadDetails" + req.http.Extension + "?thread=" + req.http.Thread-Id + "&api_key=" + req.http.API-Key; // Clean up these "Headers" unset req.http.Extension; unset req.http.Thread-Id; unset req.http.API-Key; // Remove trailing &'s and ?'s set req.url = regsuball(req.url, "[\?|&]+$", ""); }
  16. 3000 req/s saved. ๏ Stopped busting our own cache with

    a cache busting token ๏ Large majority of tra c is from anon ๏ Normalized all anon tra c into a common cache key ๏ Profit
  17. High-er Availability ๏ We pushed our first 3 HTTP requests

    out of our data center and into Fastly ๏ This reduces our latency by a ridiculous amount ๏ Our network is nowhere near as reliable or consistent ๏ Working towards 5 9s
  18. What did all of this accomplish? ๏ After a thread

    has been cached once, our embed can be loaded entirely to working state without hitting our app servers ๏ On an uncached thread, we can reliably show an error message instead of nothing at all ๏ Our backends process overall, ~6000 req/s less
  19. My take aways. ๏ Varnish is pretty rad ๏ It’s

    a lot of work to e ectively use Varnish ๏ Optimize for anon, then layer on user information ๏ Understand both sides of Varnish ๏ Don’t cache too much ๏ Be really really careful with user-specific caching!
  20. WTB If-Modified-Since! ๏ experimental-ims branch ๏ “200 Ok Not Modified”

    ๏ A ton of long tail data ๏ Very simple and e cient to serve a 304 Not Modified ๏ https://www.varnish-cache.org/trac/wiki/ BackendConditionalRequests
  21. Bad times were had. ๏ We tested the experimental-ims branch

    in production ๏ Very very short TTLs, with a really long keep ๏ Paired up with SSD file storage ๏ Varnish kept OOM’ing and crashing ๏ Had to keep restarting Varnish every 4-6 hours ๏ Really looking forward to trying this in Varnish 4.0
  22. How we DDoS’d Fastly. ๏ *.disqus.com/count.js loader script ๏ *.disqus.com/count.js?q=1&…

    actually loads the payload ๏ Really bad idea. Really old legacy. ๏ Tried to optimize hit ratio, and ignored all querystrings ๏ Infinite redirect loop, in all browsers
  23. How we DDoS’d Fastly. diff --git a/shortname.disqus.com.vcl b/ shortname.disqus.com.vcl index

    74b59e8..9a17bad 100644 --- a/shortname.disqus.com.vcl +++ b/shortname.disqus.com.vcl @@ -9,7 +9,10 @@ sub vcl_recv { } } - if (req.url ~ "^/count\.js") { + // This absolutely *has* to be an exact match + // Anything else will cause really really bad thigns to happen + // like an infinite loop bringing down all the things + if (req.url == "/count.js") { if (req.http.Fastly-SSL) { error 751 "https"; } else {
