Standardizing Applications for the Cloud at a Global Scale

Learn about how to use OAM and its K8s runtime Crossplane to define, deliver and build standard application platform at global scale!

Lei (Harry) Zhang

August 12, 2020
Tweet

More Decks by Lei (Harry) Zhang

Other Decks in Technology

Transcript

  1. What’s Happened? API & Primitives code, app, CI/CD pipeline Deployment

    Pod Controller HPA Node Sidecar NetworkPolicy CR/CRD Levels of Abstraction scaling • auto scale +100 instances when latency > 10% rollout • promote the canary instance with step of 10% when it passes baseline analysis HorizontalPodAutoscaler CustomMetricsServer Prometheus Service Monitor Istio Virtual Service Deployment Ingress Service User Interfaces YAML GUI CLI IaC YAML YAML YAML users’ expectation what we provide
  2. Early 2019: Silos Created ... I run stateful workloads! I

    run stateless apps! I run stateless serverless containers! Users Kubernetes Cert Manager Ingress Let’s Encrypt Flagger Virtual Service Manual Scaling App CRD HPA Knative Service Cert Canary AutoScaler AutoScaling Route Job Deployment •Fragmentation: ~11 PaaS/Serverless •Silos: no interoperability, reusability, or portability •Close: many in-house wheels due to in-house app crd Platform Builders
  3. Rethink Can we build application platforms based on k8s, which

    are user friendly, highly extensible, in a standard approach? Build abstractions! Leverage k8s extensibility! How ??? Knative, OpenFaaS, or DIY your own abstraction! Container, ksvc, VM, auto scaling, manual scaling, canary blue- green, just name it!
  4. Open Application Model (OAM) Components Traits Scaling Rollout Route Cert

    Traffic AppConfig OAM Kubernetes Runtime Definitions Docker Compose Dashboard CL I IaC CLI Deployment Function Application level primitives Capability mgmt. DX/UI layer Kubernetes Application centric primitives for Kubernetes: 1. Components - what workload to run? 2. Traits - how to operate the workload? 3. AppConfig - bind trait with component 4. Definitions - discover CRD as workload/trait
  5. Components Components workload apiVersion: core.oam.dev/v1alpha2 kind: Component metadata: name: frontend

    annotations: description: Container workload spec: workload: apiVersion: apps/v1 kind: Deployment spec: template: spec: containers: - name: web image: 'php:latest' env: - name: OAM_TEXTURE value: texture.jpg ports: - containerPort: 8001 name: http protocol: TCP $ kubectl get deployment NAME REVISION AGE frontend-c8bb659c5 1 2d15h frontend-a8eb65xfe 2 10m $ kubectl get components NAME WORKLOAD TYPE frontend deployment.apps.k8s.io Component is versionized template for your workload workload-v1 workload-v2 Persona: App Developer
  6. Workloads Developers are free to define workloads at any abstraction

    level, including cloud resources. apiVersion: core.oam.dev/v1alpha2 kind: Component metadata: name: frontend annotations: description: Container workload spec: workload: apiVersion: apps/v1 kind: Deployment spec: replicas: 3 selector: matchLabels: app: nginx template: metadata: labels: app: nginx spec: containers: - name: nginx image: nginx:1.14.2 ports: - containerPort: 80 apiVersion: core.oam.dev/v1alpha2 kind: Component metadata: name: frontend annotations: description: Container workload spec: workload: apiVersion: apps.alibaba-inc/v1 kind: Containerized spec: image: nginx:1.14.2 deploy: replicas: 3 Abstraction level: low Abstraction level: high
  7. Traits and AppConfig Component Traits Scaling Rollout Route Cert Traffic

    AppConfig workload apiVersion: core.oam.dev/v1alpha2 kind: ApplicationConfiguration metadata: name: helloworld spec: components: # 1st component - componentName: frontend traits: - trait: apiVersion: autoscaling/v2beta2 kind: HorizontalPodAutoscaler spec: minReplicas: 1 maxReplicas: 10 - trait: apiVersion: networking.alibaba-inc.com/v1 kind: APIGateway spec: hostname: app.alibaba.com path: / service_port: 8001 # 2nd component - componentName: redis · Traits · Declarative abstractions for operational capabilities · AppConfig(Application Configuration) · Bind given trait to component Persona: App Operator
  8. Definitions apiVersion: core.oam.dev/v1alpha2 kind: TraitDefinition metadata: name: virtualservices.networking.istio.io annotations: alias:

    traffic spec: appliesTo: - *.apps.k8s.io conflictsWith: - traffic-split.alimesh.io definition: virtualservices.networking.istio.io OAM K8s Plugin Definitions $ kubectl get traits NAME DEFINITION APPLIES TO CONFLICTS WITH traffic virtualservices.networking.istio.io *.apps.k8s.io traffic-split.alimesh.io route route.core.oam.dev *.apps.k8s.io cert cert.core.oam.dev *.apps.k8s.io Register and discover k8s capabilities (API resources) as workloads or traits # e.g.:Register Istio VirtualService as Traffic trait Persona: Platform Builder/Infra Operator
  9. In 2020: Build Standard Platforms Common Traits Function Deployment K8s

    Operator Virtual Machine Gateway Route Traffic Alert Monitor Service Binding Rollout Ingress interoperability Application Application Application Platform foo Platform bar Serverless baz Common Workload Types Manual Scaler K8s Operators Kubernetes + OAM K8s Plugin HPA Deployment scale-to-0 Knative service Unified Model Layer Platform Capability Pool Open Application Model (OAM) is: 1. a building block to create standard app platforms a. with developer centric primitives and your own level of abstraction 2. a standard and runtime agnostic app definition a. enable global scale app distribution
  10. Globally Distributed Apps • A lot of real life applications

    don’t live in just 1 place • App components and infrastructure can be spread across: • Cloud providers • Regions and zones • Clusters • Justifications • Availability • Resiliency • Cost • Unique services
  11. Global Application Challenges • Know who and what you’re building

    for - act with intention • Understand the infrastructure needs of your app • Tool explosion • how many dashboards, GUIs, consoles do you want to live in? • how many skills sets do you need to learn or hire for? • Monitoring, management, policy, operations...
  12. Control Plane • A set of components that make management

    and orchestration decisions for the entire solution • Centralizes decision making into an authoritative place • Single entry point API • Kubernetes has a control plane • schedules pods/resources across nodes • Global control plane is similar - but bigger scope • Provision infrastructure needed by app • Deploy application components to clouds, regions, etc.
  13. • CNCF sandbox project • Open source control plane for

    applications and their infrastructure • Based on Kubernetes control plane • Provision infrastructure declaratively using the K8s API • Publish your own declarative infrastructure API without code • self-service, on-demand, policy, config, best practices • Run and deploy applications alongside infrastructure • The OAM implementation for Kubernetes
  14. • Standardized apps need infrastructure - databases, caches, buckets, networking,

    etc. • Control plane API - centralized place for provisioning & consuming infrastructure • Define the right API for your organization • Abstractions to • hide complexity & environment knowledge • codify policy & best practices • enable self-service by apps Consuming Infrastructure
  15. • OAM • https://oam.dev/ • https://github.com/oam-dev/spec • Gitter - https://gitter.im/oam-dev/

    • Twitter - https://twitter.com/oam_dev • Community meetings • Crossplane • https://crossplane.io/ • Try it out with the quick start docs! • https://github.com/crossplane/crossplane • Slack - https://slack.crossplane.io/ • Twitter - https://twitter.com/crossplane_io • Community meetings and live streams Get Involved!
