プロダクションレディ Pods+ / Production-Ready Pods Plus
Container X mas Party with flexy (2018/12/17)
https://flexy.connpass.com/event/110839/
---
Kubernetes は、コンテナを運用するためにさまざまな機能を備えています。しかし、本番環境ではユーザからのトラフィックを受けながらエラーなくデプロイできなければなりませんし、特定のコンテナが CPU やメモリといったリソースを使い切らないように備えなければなりません。このように本番環境での運用には配慮が必要です。このセッションでは、Kubernetes でもっとも重要なオブジェクトである Pods をプロダクションレディ(本番対応)とするために必要なテクニックをお話します。
Kazuki Suda
December 18, 2018
Transcript
36 slides
-
Container X mas Party with flexy 2018/12/18 Kazuki Suda <[email protected]>
@superbrothers ϓϩμΫγϣϯϨσΟ Pods -
@superbrothers ▶ 複数のコンテナと複数のボリューム ▶ デプロイの最⼩単位 ▶ IP-per-Pod Pods Pod Volume
Web server File Puller -
@superbrothers Pod A ボリューム コンテナ コンテナ ノード1 ノード2 IP: 10.60.0.5
Pod B IP: 10.60.1.7 Pod C IP: 10.60.1.8 Podに含まれるコンテナは 必ず同じノード上で実⾏される 各PodはフラットなネットワークのIPアドレスを持ち、ノードをまたいで通信できる -
@superbrothers apiVersion: v1 kind: Pod metadata: name: nginx spec: containers:
- name: nginx image: nginx:1.13.7 ports: - containerPort: 80 ▶ 複数のコンテナと複数のボリューム ▶ デプロイの最⼩単位 ▶ IP-per-Pod Pods -
@superbrothers Pod A Deployment レプリカ数: 3 セレクタ: app=nginx ノード1 Podテンプレート
ノード2 Pod B Pod C app: nginx app: nginx app: nginx app: nginx Podオブジェクトのテンプレートでこの設定を元に Podレプリカが作成される 作成されるPodは、適切なノードに ⾃動的にスケジュールされ実⾏される -
@superbrothers Building Containers ▶ The Twelve-Factor App + 設定を環境変数に格納する +
ログは stdout, stderr に出⼒する, etc ▶ 1プロセス / 1コンテナ ▶ ⼩さいベースイメージを使う ▶ 不要なパッケージをインストールしない + multi-stage builds -
@superbrothers multi-stage builds Use multi-stage builds | Docker Documentation FROM
golang:1.7.3 WORKDIR /go/src/github.com/alexellis/href-counter/ RUN go get -d -v golang.org/x/net/html COPY app.go . RUN CGO_ENABLED=0 GOOS=linux go build -a -installsuffix cgo -o app . FROM alpine:latest RUN apk --no-cache add ca-certificates WORKDIR /root/ COPY --from=0 /go/src/github.com/alexellis/href-counter/app . CMD ["./app"] -
@superbrothers resource requests ▶ コンテナの実⾏に必要最低限必要なリソース ▶ スケジュールされたコンテナのリソース要求の 合計がノードの容量よりも少ないことを保証する apiVersion: v1
kind: Pod metadata: name: kuard spec: containers: - image: gcr.io/kuar-demo/kuard- name: kuard resources: requests: cpu: "500m" memory: “128Mi" ephemeral-storage: “2Gi" ports: - containerPort: 8080 name: http protocol: TCP -
@superbrothers ephemeral-storage ▶ コンテナの⼀時ストレージ + emptyDir volumes, container logs +
container writable layers (runtime partition 利⽤時は⾮カウント) apiVersion: v1 kind: Pod metadata: name: kuard spec: containers: - image: gcr.io/kuar-demo/kuard- name: kuard resources: requests: cpu: "500m" memory: “128Mi" ephemeral-storage: “2Gi" ports: - containerPort: 8080 name: http protocol: TCP v1.13 beta -
@superbrothers Running ノードのリソースを使い切ってしまう コンテナのリソース使⽤量の上限を指定する + resource limits アプリケーションがハングして固まってしまう リクエストを受ける準備が終わる前にリクエストがきてしまう コンテナのヘルスチェックを設定する
+ Liveness probe (⽣きているかどうか) + Readiness probe (応答できるかどうか) -
@superbrothers apiVersion: v1 kind: Pod metadata: name: kuard spec: containers:
- image: gcr.io/kuar-demo/kuard-am name: kuard resources: requests: cpu: "500m" memory: “128Mi" ephemeral-storage: “2Gi" limits: cpu: "1000m" memory: “256Mi" ephemeral-storage: “4Gi" ports: - containerPort: 8080 name: http protocol: TCP ▶ コンテナのリソース使⽤量の上限を指定する + cpu: 上限を超えて使⽤しない + memory: 上限を超えると強制終了 (OOM) + ephemeral-storage: 上限を超えると強制終了 resource limits -
@superbrothers ▶ Pod レベル + 全コンテナの⼀時ストレージの使⽤量が Limit の合計値を超えたら ▶ コンテナレベル
+ container logs と writable layer が Limit を超えたら ephemeral-storage: 上限を超えると強制終了 v1.13 beta -
@superbrothers Liveness probe ▶ コンテナ内プロセスの死活監視 ▶ 失敗するとコンテナを強制的に再起動する spec: containers: -
image: gcr.io/kuar-demo/kuard-amd64:1 name: kuard ports: - containerPort: 8080 name: http protocol: TCP livenessProbe: httpGet: path: /healthy port: 8080 initialDelaySeconds: 5 timeoutSeconds: 1 periodSeconds: 10 failureThreshold: 3 readinessProbe: httpGet: path: /ready port: 8080 initialDelaySeconds: 30 timeoutSeconds: 1 periodSeconds: 10 failureThreshold: 3 -
@superbrothers Liveness probe ▶ exec: コマンドの実⾏ + Exit コードが0で healthy
判定 ▶ httpGet: HTTP GET リクエスト + ステータスコードが200以上400未満で healthy 判定 ▶ tcpSocket: TCP Socket + コネクションが確⽴すれば healthy 判定 -
@superbrothers Readiness Probe ▶ コンテナ内プロセスがリクエストに 応答できるか ▶ 失敗するとServices を通じて トラフィックを受信しない
(Unready) spec: containers: - image: gcr.io/kuar-demo/kuard-amd64:1 name: kuard ports: - containerPort: 8080 name: http protocol: TCP livenessProbe: httpGet: path: /healthy port: 8080 initialDelaySeconds: 5 timeoutSeconds: 1 periodSeconds: 10 failureThreshold: 3 readinessProbe: httpGet: path: /ready port: 8080 initialDelaySeconds: 30 timeoutSeconds: 1 periodSeconds: 10 failureThreshold: 3 -
@superbrothers Services ▶ 仮想IPとポート ▶ ラベルセレクタによる Pod のグルーピング ▶ サービスタイプ:
+ ClusterIP + NodePort + LoadBalancer + Pod app web Pod app web ReplicaSet Service VIP: 10.0.0.249 Selector: app=web -
@superbrothers apiVersion: v1 kind: Service metadata: name: kuard spec: type:
ClusterIP selector: app: kuard ports: - protocol: TCP port: 8080 targetPort: 8080 Services ▶ 仮想IPとポート ▶ ラベルセレクタによる Pod のグルーピング ▶ サービスタイプ: + ClusterIP + NodePort + LoadBalancer + -
@superbrothers http.HandleFunc("/ready", func(w http.ResponseWriter, r *http.Request) { message := ""
if !isDataLoaded() { message += “Initial data is not loaded\n” } if len(message) > 0 { // Send 503 http.Error(w, message, http.StatusServiceUnavailable) } else { w.Write([]byte("OK")) } }) http.ListenAndServe(":8080", nil) -
@superbrothers Terminating 終了中にリクエストがきてエラーを返してしまう コンテナを Graceful shutdown させる + terminationGracePeriodSeconds +
shareProcessNamespace + preStop フック / SIGTERM のハンドリング -
@superbrothers apiVersion: apps/v1 kind: Deployment metadata: name: kuard spec: selector:
matchLabels: app: kuard template: metadata: labels: app: kuard spec: terminationGracePeriodSeconds: 60 shareProcessNamespace: true containers: - image: gcr.io/kuar-demo/kuard-amd64:1 name: kuard ports: - containerPort: 8080 name: http protocol: TCP terminationGracePeriodSeconds ▶ Pod を Graceful に終了させるため必要な秒数 ▶ 設定した秒数が経過するとコンテナに SIGKILL が送信される -
@superbrothers apiVersion: apps/v1 kind: Deployment metadata: name: kuard spec: selector:
matchLabels: app: kuard template: metadata: labels: app: kuard spec: terminationGracePeriodSeconds: 60 shareProcessNamespace: true containers: - image: gcr.io/kuar-demo/kuard-amd64:1 name: kuard ports: - containerPort: 8080 name: http protocol: TCP livenessProbe: shareProcessNamespace ▶ Pod 内のコンテナで PID Namespace を共有する ▶ コンテナの PID 1 問題の解決 + PID1 は、カーネルから特別扱いされてるって本当ですか? v1.13 beta -
@superbrothers $ kubectl attach -it nginx -c shell If you
don't see a command prompt, try pressing enter. / # ps aux PID USER TIME COMMAND 1 root 0:00 /pause 5 root 0:00 nginx: master process nginx -g daemon off; 9 101 0:00 nginx: worker process 10 root 0:00 sh 15 root 0:00 ps aux -
@superbrothers apiVersion: apps/v1 kind: Deployment metadata: labels: app: nginx name:
nginx spec: selector: matchLabels: app: nginx template: metadata: labels: app: nginx spec: containers: - image: nginx:1.13.7 name: nginx lifecycle: preStop: exec: command: [“/bin/sh“, ”-c“, “sleep 2; nginx -s quit; sleep 3”] ▶ Pod の終了フェイズの最初に実⾏される (Optional) + ブロックしなければならない(同期)ことに注意 ▶ preStop フック実⾏後に SIGTERM が送信される preStop フック -
@superbrothers 新規コネクション 接続済コネクション preStop 処理 SIGTERM 処理 Pod の終了開始 (Optional)
preStop フック Services のターゲットから外れる kube-proxy が iptables ルールを更新し、新規接続がなくなる これ以降新規接続はなくなる preStop フックか SIGTERM で Graceful にクローズする必要がある GracePeriodSeconds 後 終了していない場合(デフォルト30秒) SIGKILL SIGTERM Kubernetes: 詳解 Pods の終了 - Qiita -
@superbrothers まとめ ▶ Building Containers + ベストプラクティスに従う ▶ Scheduling +
必要最低限必要なリソースを設定する (resource requests) ▶ Running + ヘルスチェックを設定する (Liveness / Readiness probe) + リソース使⽤量に上限を設定する (resource limits) ▶ Terminating + Graceful shutdown させる (preStop フック / shareProcessNamespace/ SIGTERM ハンドリング)
