Advantages of HiFi reads for variant discovery and genome assembly

The PacBio Sequel II System is capable of generating highly accurate, long reads (HiFi reads) that can be used for variant detection and assembly. In this presentation, we demonstrate the utility and provide example workflows for variant detection, and discuss advantages of human HiFi assemblies. Finally, we discuss coverage titrations for these applications, and provide links to publicly available HiFi datasets produced on the Sequel II System.

Transcript

1. For Research Use Only. Not for use in diagnostic procedures. © Copyright 2019 by Pacific Biosciences of California, Inc. All rights reserved. Advantages of HiFi reads for variant discovery and genome assembly William Rowell, Senior Scientist, Bioinformatics Applications, PacBio @nothingclever #SMRTLeiden
2. AGENDA -Introduction to HiFi -Variant Calling -De Novo Assembly -Coverage Recommendations -Public HiFi Datasets
3. Introduction to HiFi
4. HIFI LIBRARY PREP PRODUCES UNIFORM INSERT SIZES Wenger, Peluso, et al. (2019). bioRxiv. doi:10.1101/519025
5. PACBIO CIRCULAR CONSENSUS SEQUENCING (CCS) First round Rolling circle Generate consensus HiFi read Subreads (passes) Subread errors
6. PACBIO CIRCULAR CONSENSUS SEQUENCING (CCS) First round Rolling circle Generate consensus HiFi read Subreads (passes) Subread errors Accuracy (Phred) 5 10 15 20 0 30 0 10 20 40 50 Sequel (1M) Passes
7. PACBIO CIRCULAR CONSENSUS SEQUENCING (CCS) First round Rolling circle Generate consensus HiFi read Subreads (passes) Subread errors Accuracy (Phred) 5 10 15 20 0 30 0 10 20 40 50 Sequel (1M) Passes Passes 30 0 10 20 40 50 8 5 15 20 0 10 Sequel II (8M)
8. HIFI READS ARE LONG AND ACCURATE
9. HIFI READS ARE EASILY MAPPED TO REPETITIVE REGIONS HAP 2 HAP 1 11 kb HiFi 2x250 bp
10. DETECT MORE VARIANTS IN MEDICALLY-RELEVANT GENES % problem exons resolved Genes 100% ABCC6, ABCD1, ACAN, ACSM2B, AKR1C2, ALG1, ANKRD11, BCR, CATSPER2, CD177, CEL, CES1, CFH, CFHR1, CFHR3, CFHR4, CGB, CHEK2, CISD2, CLCNKA, CLCNKB, CORO1A, COX10, CRYBB2, CSH1, CYP11B1, CYP11B2, CYP21A2, CYP2A6, CYP2D6, CYP2F1, CYP4A22, DDX11, DHRS4L1, DIS3L2, DND1, DPY19L2, DUOX2, ESRRA, F8, FAM120A, FAM205A, FANCD2, FCGR1A, FCGR2A, FCGR3A, FCGR3B, FLG, FLNC, FOXD4, FOXO3, FUT3, GBA, GFRA2, GON4L, GRM5, GSTM1, GYPA, GYPB, GYPE, HBA1, HBA2, HBG1, HBG2, HP, HS6ST1, IDS, IFT122, IKBKG, IL9R, KIR2DL1, KIR2DL3, KMT2C, KRT17, KRT6A, KRT6B, KRT6C, KRT81, KRT86, LEFTY2, LPA, MST1, MUC5B, MYH6, MYH7, NEB, NLGN4X, NLGN4Y, NOS2, NOTCH2, NXF5, OPN1LW, OR2T5, OR51A2, PCDH11X, PCDHB4, PGAM1, PHC1, PIK3CA, PKD1, PLA2G10, PLEKHM1, PLG, PMS2, PRB1, PRDM9, PROS1, RAB40AL, RALGAPA1, RANBP2, RHCE, RHD, RHPN2, ROCK1, SAA1, SDHA, SDHC, SFTPA1, SFTPA2, SIGLEC14, SLC6A8, SMG1, SPATA31C1, SPTLC1, SRGAP2, SSX7, STAT5B, STK19, STRC, SULT1A1, SUZ12, TBX20, TCEB3C, TLR1, TLR6, TMEM231, TNXB, TRIOBP, TRPA1, TTN, TUBA1A, TUBB2B, UGT1A5, UGT2B15, UGT2B17, UNC93B1, VCY, VWF, WDR72, ZNF419, ZNF592, ZNF674 [75%, 100%) ANAPC1, C4A, C4B, CHRNA7, CR1, DUX4, FCGR2B, HYDIN, OTOA, PDPK1, TMLHE [50%, 75%) ADAMTSL2, CDY2A, DAZ1, GTF2I, NAIP, OCLN, RPS17 [25%, 50%) DAZ2, DAZ3, KIR3DL1, OPN1MW, PPIP5K1 (0%, 25%) NCF1, RBMY1A1 0% BPY2, CCL3L1, CCL4L1, CDY1, CFC1, CFC1B, GTF2IRD2, HSFY1, MRC1, OR4F5, PRY, PRY2, SMN1, SMN2, TSPY1, XKRY 16 2 5 7 11 152 Genes
11. IMPROVED MAPPING IN REFERENCE-DIVERGENT REGIONS HAP 2 HAP 1 11 kb HiFi 2x250 bp
12. IMPROVED MAPPING IN SEGMENTAL DUPLICATIONS SMN1 SMN2 11 kb HiFi 2x250 bp
13. Variant Calling
14. 5 Mb 3 Mb 10 Mb 1 bp SNVs ≥50 bp structural variants 1-49 bp indels vs Structural Variants (SVs): • Indels ≥50 bp • Duplications • Copy Number Variants (CNVs) • Translocations • Inversions “Small variants”: • Single Nucleotide Variants (SNVs) • Indels <50 bp GENOME VARIATION COMES IN ALL SIZES
15. 5 Mb 3 Mb 10 Mb 1 bp SNVs ≥50 bp structural variants 1-49 bp indels PacBio SMRT Prior tech vs OTHER TECHNOLOGIES MISS VARIANTS
16. 5 Mb 3 Mb 10 Mb 1 bp SNVs ≥50 bp structural variants 1-49 bp indels PacBio SMRT Prior tech vs long insertions events in repeat regions PACBIO ENABLES STRUCTURAL VARIANT DETECTION
17. 5 Mb 3 Mb 10 Mb 1 bp SNVs ≥50 bp structural variants 1-49 bp indels PacBio SMRT Prior tech vs unmappable regions segmental duplication and tandem repeats PACBIO HIFI READS ENABLE SMALL VARIANT DETECTION IN DIFFICULT-TO-MAP REGIONS
18. WGS HIFI STRUCTURAL VARIANT CALLING OVERVIEW HiFi reads pbmm2 pbsv discover pbsv call variant calls (vcf) SMRT Link Structural Variant Calling SMRT Link Mapping
19. WGS HIFI STRUCTURAL VARIANT CALLING OVERVIEW HiFi reads pbmm2 pbsv discover pbsv call variant calls (vcf) SMRT Link Structural Variant Calling SMRT Link Mapping OR
20. 15-FOLD HIFI READS PROVIDE A COMPREHENSIVE VIEW OF STRUCTURAL VARIANTS ≥20BP SVTYPE HG001 HG002 HG005 BND 752 712 708 CNV 108 107 97 DEL 24,192 24,471 24,353 DUP 11,523 11,472 11,451 INS 20,638 20,820 21,066 INV 51 47 50
21. 15-FOLD HIFI READS PROVIDE A COMPREHENSIVE VIEW OF STRUCTURAL VARIANTS ≥20BP SVTYPE HG001 HG002 HG005 BND 752 712 708 CNV 108 107 97 DEL 24,192 24,471 24,353 DUP 11,523 11,472 11,451 INS 20,638 20,820 21,066 INV 51 47 50 Recall Precision 3 SMRT Cells 8M HG002 (16-fold, 11kb) 96.8% 95.4%
22. HETEROZYGOUS ALU DELETION IN HG001 chrX:116,449,107-116,459,909 HAP 2 HAP 1 11 kb HiFi pbsv HETEROZYGOUS ALU DELETION IN HG001 chrX:116,449,107-116,459,909 HAP 2 HAP 1 11 kb HiFi pbsv
23. HOMOZYGOUS APP INTRONIC INVERSION IN HG001 chr21:27,373,479-27,375,496 11 kb HiFi pbsv
24. SMALL VARIANTS CAN BE DETECTED BY GATK HAPLOTYPECALLER HiFi reads pbmm2 HaplotypeCaller VariantFiltration variant calls (vcf) GATK4 SMRT Link Mapping A framework for variation discovery and genotyping using next-generation DNA sequencing data DePristo M, Banks E, Poplin R, Garimella K, Maguire J, Hartl C, Philippakis A, del Angel G, Rivas MA, Hanna M, McKenna A, Fennell T, Kernytsky A, Sivachenko A, Cibulskis K, Gabriel S, Altshuler D, Daly M, 2011 NATURE GENETICS 43:491-498
25. SMALL VARIANTS CAN BE DETECTED BY GATK HAPLOTYPECALLER HiFi reads pbmm2 HaplotypeCaller VariantFiltration variant calls (vcf) GATK4 SMRT Link Mapping Precision Recall SNVs 99.6% 99.7% Indels 85.0% 82.3% 15-fold HiFi HG002 against GIAB v3.3.2 benchmark A framework for variation discovery and genotyping using next-generation DNA sequencing data DePristo M, Banks E, Poplin R, Garimella K, Maguire J, Hartl C, Philippakis A, del Angel G, Rivas MA, Hanna M, McKenna A, Fennell T, Kernytsky A, Sivachenko A, Cibulskis K, Gabriel S, Altshuler D, Daly M, 2011 NATURE GENETICS 43:491-498
26. SMALL VARIANTS CAN BE DETECTED BY GATK HAPLOTYPECALLER -High SNP Recall and Precision -Lower Indel Recall and Precision -HaplotypeCaller optimized for error mode of short reads: -[mismatch error] >> [indel error] HiFi reads pbmm2 HaplotypeCaller VariantFiltration variant calls (vcf) GATK4 SMRT Link Mapping Precision Recall SNVs 99.6% 99.7% Indels 85.0% 82.3% 15-fold HiFi HG002 against GIAB v3.3.2 benchmark A framework for variation discovery and genotyping using next-generation DNA sequencing data DePristo M, Banks E, Poplin R, Garimella K, Maguire J, Hartl C, Philippakis A, del Angel G, Rivas MA, Hanna M, McKenna A, Fennell T, Kernytsky A, Sivachenko A, Cibulskis K, Gabriel S, Altshuler D, Daly M, 2011 NATURE GENETICS 43:491-498
27. DEEPVARIANT CAN BE TRAINED TO LEARN NEW ERROR MODELS https://rdcu.be/7Dhl - Poplin, R. et al. A universal SNP and small-indel variant caller using deep neural networks. Nature Biotechnology 36, 983–987 (2018) New sequence data type (HiFi) Known Genotypes (GIAB)
28. DEEPVARIANT CAN BE TRAINED TO LEARN NEW ERROR MODELS https://rdcu.be/7Dhl - Poplin, R. et al. A universal SNP and small-indel variant caller using deep neural networks. Nature Biotechnology 36, 983–987 (2018) New sequence data type (HiFi) Known Genotypes (GIAB) Starting CNN
29. DEEPVARIANT CAN BE TRAINED TO LEARN NEW ERROR MODELS https://rdcu.be/7Dhl - Poplin, R. et al. A universal SNP and small-indel variant caller using deep neural networks. Nature Biotechnology 36, 983–987 (2018) New sequence data type (HiFi) Known Genotypes (GIAB) Starting CNN Model Training
30. DEEPVARIANT CAN BE TRAINED TO LEARN NEW ERROR MODELS https://rdcu.be/7Dhl - Poplin, R. et al. A universal SNP and small-indel variant caller using deep neural networks. Nature Biotechnology 36, 983–987 (2018) New sequence data type (HiFi) Known Genotypes (GIAB) Starting CNN Model Training
31. DEEPVARIANT CAN BE TRAINED TO LEARN NEW ERROR MODELS https://rdcu.be/7Dhl - Poplin, R. et al. A universal SNP and small-indel variant caller using deep neural networks. Nature Biotechnology 36, 983–987 (2018) New sequence data type (HiFi) Known Genotypes (GIAB) Starting CNN Model Training New data type specific model
32. HiFi reads pbmm2 (MAPQ60) make_examples call_variants postprocess_variants variant calls (vcf) DeepVariant SMRT Link Mapping DEEPVARIANT IMPROVES SMALL VARIANT DETECTION New data type specific model
33. HiFi reads pbmm2 (MAPQ60) make_examples call_variants postprocess_variants variant calls (vcf) -DeepVariant learns error model of HiFi reads from training data. -Improved precision and recall for both SNVs and Indels DeepVariant SMRT Link Mapping DEEPVARIANT IMPROVES SMALL VARIANT DETECTION 15-fold HiFi against GIAB v3.3.2 benchmarks Sample SNV Recall SNV Precision Indel Recall Indel Precision HG001 99.1% 99.5% 94.1% 95.0% HG002 99.2% 99.5% 95.4% 96.6% HG005 99.4% 99.7% 97.0% 97.5% New data type specific model
34. Results from Adding Long and Linked Reads NIST hosts the Genome in a Bottle Consortium, which develops metrology infrastructure for characterization of human whole genome variant detection. Consortium products include: • Characterization of seven broadly-consented human genomes including 2 son-mother-father trios released as Reference Materials (RMs) • Reference data associated with RMs are benchmark variants and genomic regions covering, for example, 87.84% of assembled bases in chromosomes 1-22 in GRCh37 for the sample HG002 • Short read variant callers perform poorly in genomic locations with high homology such as segmental duplications and low-complexity repeat- rich regions • Now utilizing PacBio long read data and 10X Genomics linked reads to expand the GIAB benchmark regions and reduce errors in current regions • Initial results suggest linked and long reads might be able to add 139,480 benchmark SNPs and 16,081 insertions/deletions, mostly in regions difficult to map with short reads Overview Integration data for HG002 with GRCh37 Expanding the Genome in a Bottle benchmark callsets with high-confidence small variant calls from long and linked read sequencing technologies Justin Wagner1, Nathan D. Olson1, Lesley M. Chapman1, Marc Salit1,2,3, Justin M. Zook1, and the Genome in a Bottle Consortium 1: Material Measurement Laboratory, National Institute of Standards and Technology, 100 Bureau Dr., Gaithersburg, MD 20899; 2: Joint Initiative for Metrology in Biology, Stanford, CA 94305, USA; 3: Department of Bioengineering, Stanford University, Stanford, CA 94305 Ongoing and Future work Integration Pipeline Process Benchmark includes more bases, variants, and segmental duplications in v4⍺ Comparison of Illumina GATK4 VCF against benchmark sets • SNP FN rate increases by a factor of 10, almost entirely due to new benchmark variants in difficult to map regions (lowmap) and segmental duplications (segdups) Performance in medically-relevant genes • Top 5 genes with variants increased from v3.3.2 to v4⍺ benchmark: TSPEAR (37), TNXB (22), CYP21A2 (9), KANSL1 (9), SDHA (8) • PMS2 from ACMG59 has 2 more variants covered in v4⍺ benchmark Genome in a Bottle Consortium Platform Characteristics Alignment; Variant Calling PacBio ~15Kbp reads; ~28x coverage minimap2; GATK4 PacBio ~15Kbp reads; ~28x coverage minimap2; DeepVariant 10X Linked reads; ~84x coverage LongRanger Pipeline Variants PASS Filtered outliers Low/high coverage or low MQ (or low GQ for gVCF) Difficult regions/SVs Callable regions PASS variants #2 Benchmark regions 0/1 1/1 TR 1/1 Benchmark calls 0/1 1/1 Callable regions #2 Variant Calling Method X (1) (2) (3) 1/1 0/1 Callable regions #1 1/1 0/1 1/1 PASS variants #1 Input Methods 1/1 (1) Concordant (2) Discordant unresolved (3) Discordant arbitrated (4) Concordant not callable Find sensitive variant calls and callable regions for each dataset, excluding difficult regions/SVs that are problematic for each type of data and variant caller Find “consensus” calls with support from 2+ technologies (and no other technologies disagree) using callable regions Use “consensus” calls to train simple one-class model for each dataset and find “outliers” that are less trustworthy for each dataset Find benchmark calls by using callable regions and “outliers” to arbitrate between datasets when they disagree Find benchmark regions by taking union of callable regions and subtracting uncertain variants Variants in Medical Exome (genes from OMIM, HGMD, ClinVar, UniProt) Benchmark Regions v3.3.2 8,209 Benchmark Regions v4⍺ 8,627 Difficult Region Description Method Excluded From All candidate structural variant regions from the Son-Mother-Father Trio All methods All tandem repeats < 51bp in length All methods except GATK from Illumina PCR- free and Complete Genomics All tandem repeats > 51bp and < 200bp in length All methods except GATK from Illumina PCR- free All tandem repeats > 200bp in length All methods Perfect or imperfect homopolymers > 10bp All methods except GATK from Illumina PCR- free Segmental duplications from Eichler et al. All methods except 10X Genomics linked reads and PacBio CCS Segmental duplications > 10Kbp from self-chain mapping All methods except 10X Genomics linked reads and PacBio CCS Regions homologous to contigs in hs37d5 decoy All methods except 10X Genomics linked reads and PacBio CCS Subset v3.3.2 Recall v4⍺ Recall v3.3.2 Precision v4⍺ Precision All SNPs 0.9995 0.9947 0.9981 0.9933 Lowmap 100 bp 0.9799 0.8464 0.9623 0.8717 Lowmap 250 bp no mismatch 0.9474 0.5522 0.8911 0.7180 Segdups 0.9982 0.9321 0.9910 0.9085 v3.3.2 v4⍺ Increase in v4⍺ Number of bases covered 2,358,060,765 2,442,494,334 84,433,569 Percent of GRCh37 covered 87.84% 90.98% 3.14% SNPs 3,046,933 3,186,536 139,603 Indels 465,670 482,172 16,502 Number of bases covered in Segmental Duplications 269,887 269,589,673 269,319,786 • Machine learning - Multi-view classification, outlier detection, active learning • Refine use of genome stratifications • Adding variant calls from raw PacBio and Oxford Nanopore • Improve benchmark for larger indels, homopolymers, and tandem repeats • Explore graph-based methods to characterize MHC region • Improve normalization of complex variants In addition to the Genome in a Bottle v3.3.2 input data that consisted of Illumina, Complete Genomics, Ion, 10X, and Solid technologies v4⍺ includes PacBio CCS and new 10X linked read data. v4⍺ v3.3.2 Illumina PacBio CCS 10X ONT v4⍺ v3.3.2 v4⍺ v3.3.2 Illumina PacBio CCS 10X ONT v4⍺ v3.3.2 v3.3.2 Error Excluded in v4⍺ Variant Added in v4⍺ New members welcome! Sign up for newsletters at www.genomeinabottle.org Recruiting members to test v4⍺ benchmark please email: justin.zook@nist.gov DEEPVARIANT CONFIDENTLY CALLS SMALL VARIANTS IN HIFI READS OUTSIDE OF THE GIAB HIGH CONFIDENCE REGION -Expands the HG002 small variant high confidence region by >84 Mb (~4%) -Expands high confidence coverage of segmental duplications by 100-fold -Adds an additional ~156,000 variants to the benchmark set -Increases variants in “medically relevant exome” by 5% https://www.slideshare.net/GenomeInABottle/giab-agbt-smallvar2019
35. LONG RANGE INFORMATION CAN BE USED TO PHASE SMALL VARIANTS Marcel Martin, Murray Patterson, Shilpa Garg, Sarah O. Fischer, Nadia Pisanti, Gunnar W. Klau, Alexander Schoenhuth, Tobias Marschall. WhatsHap: fast and accurate read-based phasing. bioRxiv 085050, doi: 10.1101/085050 -WhatsHap phases small variants using long-range information.
36. LONG RANGE INFORMATION CAN BE USED TO PHASE SMALL VARIANTS Marcel Martin, Murray Patterson, Shilpa Garg, Sarah O. Fischer, Nadia Pisanti, Gunnar W. Klau, Alexander Schoenhuth, Tobias Marschall. WhatsHap: fast and accurate read-based phasing. bioRxiv 085050, doi: 10.1101/085050 -WhatsHap phases small variants using long-range information. -PacBio HiFi reads can be used both to generate small variant calls and to provide long-range phasing information.
37. LONG RANGE INFORMATION CAN BE USED TO PHASE SMALL VARIANTS Marcel Martin, Murray Patterson, Shilpa Garg, Sarah O. Fischer, Nadia Pisanti, Gunnar W. Klau, Alexander Schoenhuth, Tobias Marschall. WhatsHap: fast and accurate read-based phasing. bioRxiv 085050, doi: 10.1101/085050 -WhatsHap phases small variants using long-range information. -PacBio HiFi reads can be used both to generate small variant calls and to provide long-range phasing information. -Phase block size is driven by: -insert length -heterozygosity
38. LONG RANGE INFORMATION CAN BE USED TO PHASE SMALL VARIANTS Marcel Martin, Murray Patterson, Shilpa Garg, Sarah O. Fischer, Nadia Pisanti, Gunnar W. Klau, Alexander Schoenhuth, Tobias Marschall. WhatsHap: fast and accurate read-based phasing. bioRxiv 085050, doi: 10.1101/085050 autosomal phase blocks mean median N50 sum 3 SMRT Cells 8M HG002 (16-fold, 11kb) 76 kb 20 kb 94 kb 1.8 Gb -WhatsHap phases small variants using long-range information. -PacBio HiFi reads can be used both to generate small variant calls and to provide long-range phasing information. -Phase block size is driven by: -insert length -heterozygosity
39. HIGHLY CONCORDANT IN GIAB HIGH CONFIDENCE REGION HAP 2 HAP 1 11 kb HiFi GIAB High Confidence GIAB variants DeepVariant small variants WhatsHap phase blocks
40. DETECT VARIANTS OUTSIDE OF HIGH CONFIDENCE REGION HAP 2 HAP 1 11 kb HiFi GIAB High Confidence GIAB variants DeepVariant small variants WhatsHap phase blocks
41. DETECT VARIANTS AND PHASE ACROSS DIFFICULT REGIONS HAP 2 HAP 1 11 kb HiFi GIAB High Confidence GIAB variants DeepVariant small variants WhatsHap phase blocks
42. De Novo Assembly
43. 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 20 25 30 35 40 45 50 100 kb chunks [cumulative] GIAB High Confidence Region Concordance (Phred) HG002 PacBio CCS Canu (mat) HG002 PacBio CCS Canu (pat) HG002 PacBio CCS wtdbg2 HG001 PacBio CLR FALCON HG001 ONT Canu HG001 ONT Canu + Illumina HG002 PacBio CLR PBcR ONT PB CLR PB CCS ONT + Illumina CCS ASSEMBLIES ARE HIGHLY CONCORDANT
44. TRIO INFORMATION CAN BE USED TO UNZIP ASSEMBLIES Sergey Koren, Arang Rhie, Brian P. Walenz, Alexander T. Dilthey, Derek M. Bickhart, Sarah B. Kingan, Stefan Hiendleder, John L. Williams, Timothy P. L. Smith, Adam M.Phillippy. Complete assembly of parental haplotypes with trio binning. bioRxiv 271486; doi: https://doi.org/10.1101/271486
45. TRIO INFORMATION CAN BE USED TO UNZIP ASSEMBLIES Sergey Koren, Arang Rhie, Brian P. Walenz, Alexander T. Dilthey, Derek M. Bickhart, Sarah B. Kingan, Stefan Hiendleder, John L. Williams, Timothy P. L. Smith, Adam M.Phillippy. Complete assembly of parental haplotypes with trio binning. bioRxiv 271486; doi: https://doi.org/10.1101/271486
46. HIFI ASSEMBLIES CAN BE PHASED WITHOUT PARENTAL DATA Phasing accuracy: 56.20% HG003 (paternal) HG004 (maternal) HG002 chr6 collapsed assembly
47. HIFI ASSEMBLIES CAN BE PHASED WITHOUT PARENTAL DATA Phasing accuracy: 56.20% Phasing accuracy: 99.75% HG003 (paternal) HG004 (maternal) HG003 (paternal) HG004 (maternal) HG002 chr6 collapsed assembly HG002 chr6 phased assembly
48. WORKING ON TWO APPROACHES TO HIFI ASSEMBLY PHASING Phasing accuracy: 99.75% wtdbg2, minimap2, DeepVariant, WhatsHap, Racon accuracy = 0.999820918560694 polished haplotigs chr6 0 2000 4000 6000 0 2500 5000 7500 10000 dat[, 3] dat[, 4] Total 1e+05 2e+05 3e+05 4e+05 5e+05 Assembly merged_h_polished.cleanheader Falcon CCS unzip Phasing accuracy: 99.98% HG003 (paternal) HG004 (maternal) HG003 (paternal) HG004 (maternal)
49. Coverage Recommendations
50. VARIANT DETECTION COVERAGE TITRATION FOR HG002 ON SEQUEL II SYSTEM 40 50 60 70 80 90 100 0 5 10 15 20 25 30 Percentage (%) Fold coverage SNVs with DeepVariant Precision Recall 40 50 60 70 80 90 100 0 5 10 15 20 25 30 Percentage (%) Fold coverage Indels with DeepVariant Precision Recall
51. VARIANT DETECTION COVERAGE TITRATION FOR HG002 ON SEQUEL II SYSTEM 40 50 60 70 80 90 100 0 5 10 15 20 25 30 35 Percentage (%) Fold coverage Structural Variants Precision Recall
52. VARIANT DETECTION COVERAGE TITRATION FOR HG002 ON SEQUEL II SYSTEM 40 50 60 70 80 90 100 0 5 10 15 20 25 30 Percentage (%) Fold coverage SNVs with DeepVariant Precision Recall 40 50 60 70 80 90 100 0 5 10 15 20 25 30 Percentage (%) Fold coverage Indels with DeepVariant Precision Recall 40 50 60 70 80 90 100 0 5 10 15 20 25 30 35 Percentage (%) Fold coverage Structural Variants Precision Recall 15-fold HiFi Coverage (2-3 SMRT Cells 8M) provides a good trade-off between costs and results
53. DE NOVO HUMAN ASSEMBLY COVERAGE TITRATION FOR HIFI READS
54. Public HiFi datasets for Sequel II System
55. WE HAVE MANY GIAB DATASETS AVAILABLE FOR TESTING -HG002/NA24385, 11 kb fraction, 15-fold coverage (3 SMRT Cells): - reads, alignments, analysis: https://downloads.pacbcloud.com/public/dataset/HG002_SV_and_SNV_CCS/ -HG002/NA24385 Ashkenazi son, 11 kb fraction, ~30-fold coverage (6 SMRT Cells) - reads: https://www.ncbi.nlm.nih.gov/Traces/study/?acc=PRJNA527278 - alignments: ftp://ftp.ncbi.nlm.nih.gov//giab/ftp/data/AshkenazimTrio/HG002_NA24385_son/PacBio_SequelII_CCS_11kb -HG001/NA12878 CEU female, ~30-fold coverage (6 SMRT Cells) - reads: https://www.ncbi.nlm.nih.gov/Traces/study/?acc=PRJNA540705 - alignments: ftp://ftp.ncbi.nlm.nih.gov//giab/ftp/data/NA12878/PacBio_SequelII_CCS_11kb -HG005/NA24631 Han Chinese son, ~30-fold coverage (6 SMRT Cells) - reads: https://www.ncbi.nlm.nih.gov/Traces/study/?acc=PRJNA540706 - alignments: ftp://ftp.ncbi.nlm.nih.gov//giab/ftp/data/ChineseTrio/HG005_NA24631_son/PacBio_SequelII_CCS_11kb
56. SUMMARY Baylor – Medhat Mahmoud, Fritz Sedlazeck Dana-Farber – Heng Li Chinese Academy of Agricultural Sciences – Jue Ruan DNAnexus – Chen-Shan Chin, Arkarachai Fungtammasan Google – Andrew Carroll, Pi-Chuan Chang, Mark DePristo, Alexey Kolesnikov Johns Hopkins – Michael Alonge, Michael Schatz Max Planck Dresden – Gene Myers NIH/NHGRI – Sergey Koren, Adam Phillippy NIST – Nathan Olson, Justin Zook PacBio – Greg Concepcion, Richard Hall, Paul Peluso, Yufeng Qian, David Rank, William Rowell, Armin Töpfer, Aaron Wenger, Mike Hunkapiller Saarland University – Jana Ebler, Tobias Marschall -With a single data type, PacBio HiFi reads, you can accurately call small variants and structural variants over >90% of the human genome. -CCS assemblies are highly concordant and can be highly phased without parental data.
57. SUMMARY Baylor – Medhat Mahmoud, Fritz Sedlazeck Dana-Farber – Heng Li Chinese Academy of Agricultural Sciences – Jue Ruan DNAnexus – Chen-Shan Chin, Arkarachai Fungtammasan Google – Andrew Carroll, Pi-Chuan Chang, Mark DePristo, Alexey Kolesnikov Johns Hopkins – Michael Alonge, Michael Schatz Max Planck Dresden – Gene Myers NIH/NHGRI – Sergey Koren, Adam Phillippy NIST – Nathan Olson, Justin Zook PacBio – Greg Concepcion, Richard Hall, Paul Peluso, Yufeng Qian, David Rank, William Rowell, Armin Töpfer, Aaron Wenger, Mike Hunkapiller Saarland University – Jana Ebler, Tobias Marschall -With a single data type, PacBio HiFi reads, you can accurately call small variants and structural variants over >90% of the human genome. -CCS assemblies are highly concordant and can be highly phased without parental data. CCS improvements – Jim Drake, Chris Dunn, David Seifert, Ivan Sovic, Armin Töpfer CCS Assembly Application Team – Greg Concepcion, Jim Drake, Chris Dunn, Richard Hall, Tzvetana Kerelska, Sarah Kingan, Jonas Korlach, Zev Kronenberg, Ivan Sovic, Michell Vierra, Alicia Yang
58. 7 WORD SUMMARY Baylor – Medhat Mahmoud, Fritz Sedlazeck Dana-Farber – Heng Li Chinese Academy of Agricultural Sciences – Jue Ruan DNAnexus – Chen-Shan Chin, Arkarachai Fungtammasan Google – Andrew Carroll, Pi-Chuan Chang, Mark DePristo, Alexey Kolesnikov Johns Hopkins – Michael Alonge, Michael Schatz Max Planck Dresden – Gene Myers NIH/NHGRI – Sergey Koren, Adam Phillippy NIST – Nathan Olson, Justin Zook PacBio – Greg Concepcion, Richard Hall, Paul Peluso, Yufeng Qian, David Rank, William Rowell, Armin Töpfer, Aaron Wenger, Mike Hunkapiller Saarland University – Jana Ebler, Tobias Marschall Calling all variants with long, accurate reads. CCS improvements – Jim Drake, Chris Dunn, David Seifert, Ivan Sovic, Armin Töpfer CCS Assembly Application Team – Greg Concepcion, Jim Drake, Chris Dunn, Richard Hall, Tzvetana Kerelska, Sarah Kingan, Jonas Korlach, Zev Kronenberg, Ivan Sovic, Michell Vierra, Alicia Yang
59. For Research Use Only. Not for use in diagnostic procedures. © Copyright 2019 by Pacific Biosciences of California, Inc. All rights reserved. Pacific Biosciences, the Pacific Biosciences logo, PacBio, SMRT, SMRTbell, Iso-Seq, and Sequel are trademarks of Pacific Biosciences. BluePippin and SageELF are trademarks of Sage Science. NGS-go and NGSengine are trademarks of GenDx. FEMTO Pulse and Fragment Analyzer are trademarks of Advanced Analytical Technologies. All other trademarks are the sole property of their respective owners. www.pacb.com @nothingclever
