Classical Ray Tracing
yumcyawiz
June 03, 2018
Transcript
20 slides
RAY TRACING 古典的レイトレーサーからはじめるレイトレーシング
古典的レイトレーシング(CLASSICAL RAY TRACING) • コンピューターグラフィクス黎明期に流行ったもの
古典的レイトレーシング(CLASSICAL RAY TRACING) • コンピューターグラフィクス黎明期に流行ったもの • 物理的に正しくはないが、陰影計算ができる
None
CG感半端ないけどちゃんと影ついてる
古典的レイトレーシング(CLASSICAL RAY TRACING) • コンピューターグラフィクス黎明期に流行ったもの • 物理的に正しくはないが、陰影計算ができる • はじめてのレイトレに最適
古典的レイトレーシング(CLASSICAL RAY TRACING) • コンピューターグラフィクス黎明期に流行ったもの • 物理的に正しくはないが、陰影計算ができる • はじめてのレイトレに最適 これからみんなに作ってもらいます
CLASSICAL RAY TRACER構造図
VEC3クラス • 3次元ベクトルを表すクラス • 四則演算、内積、外積なども定義されている Ԧ +
RAYクラス • Rayを表す Ԧ Ԧ Ԧ + Ԧ
HITクラス • 衝突情報を格納するクラス • 衝突距離、衝突位置、法線などの情報を持つ Sphere Ray
IMAGEクラス • 画像データを格納し、PPM画像として出力する機能を持つ • 指定した画素に色を書き込む機能を持つ
(, ) 画像の座標系(10*8の場合) (0, 0) (10, 8) 10 8
CAMERAクラス • 画素 , に対応するRayを返す機能を持つ (, ) Ray
ピンホールカメラ ピンホール カメラセンサー
SHAPEクラス • 物体の形を表すクラス • 与えられたRayとの衝突計算を行う Sphere Ray
MATERIALクラス • 物体の材質を表すクラス • Diffuse(マットな面), Mirror(鏡面), Glass(ガラス)の3つを用意する • 受け取ったRayを反射させる機能を持つ Sphere
Ray
PRIMITIVEクラス • ShapeとMaterialをデータとして持つクラス • シーンの中の物体はすべてPrimitiveで記述される
ACCELクラス • 物体集合を管理するクラス • すべての物体と衝突計算を行う機能を持つ
ray = cam->getRay(i, j) accel->intersect(ray, hit) hitの中身によって画素に色を書き 込む Ray Tracingの流れ
