chips for isoelectric focusing and zone electrophoresis in the free-flow mode

... talk given at MSB 2003, New Orleans.

andreas manz

February 02, 2003
Tweet

More Decks by andreas manz

Other Decks in Science

Transcript

  1. chips for isoelectric focusing and zone electrophoresis in the free-

    flow mode Yi Xu, Chao-Xuan Zhang, Andreas Manz Imperial College, Dept. Chemistry, London UK
  2. 10 fold miniaturization 100 x faster separation 1000 x smaller

    volume 10 x lower reagent consumption identical quality of separation
  3. fluorescence [arb. units] time [s] 0 40 80 120 160

    1 2 3 4 5 6 cycle # 7 8 t 7 s synchr. fluorescence [arb. units] time [s] 0 40 80 120 160 1 2 3 4 5 6 cycle # 7 8 t 7 s synchr. fluorescence [arb. units] time [s] 0 40 80 120 160 1 2 3 4 5 6 cycle # 7 8 t 7 s synchr. electrophoresis by Franz von Heeren
  4. latest design • volume 240 nL plus micro wells •

    36 x 20um inlet channels • 72 x 20um outlet channels • each side 108 x 4um channels • separation bed 12.2 x 4.1 mm – 15,552 posts – 30 x 30 um
  5. 111 ms 41 ms 53 ms 64 ms 76 ms

    88 ms 99 ms integrating over rectangular area
  6. 0 200 400 600 800 0 100 200 300 400

    500 electric field [V/cm] migration distance [um] migration distance = f (E)
  7. isoelectric focusing (IEF) • establish pH gradient • establish electric

    field • charge of protein depends on pH • mobility is nil at isoelectric point • focusing
  8. IEF proof of principle 12 mm 0 mm 4 mm

    4 mm = 500 ms angiotensin I, 1.75 kV, 10 uL/min
  9. IEF – IGF-1 • sample introduced at 4.1 mm width

    • distance post-post on structure 40 um • apparent streamline 10 um • preconcentration factor is around 100x to 400x
  10. IEF chip specific problem • side channels contribute >80% of

    voltage drop • part of the pH gradient will therefore be lost • buffer reservoirs have to be at extreme pH • some proteins will not stay in the separation area
  11. fluorescence [arb. units] time [s] 0 40 80 120 160

    1 2 3 4 5 6 cycle # 7 8 t 7 s synchr. fluorescence [arb. units] time [s] 0 40 80 120 160 1 2 3 4 5 6 cycle # 7 8 t 7 s synchr. fluorescence [arb. units] time [s] 0 40 80 120 160 1 2 3 4 5 6 cycle # 7 8 t 7 s synchr. comparison FFE CE
  12. conclusions • IEF is possible and very fast in small

    FFE system • preconcentration of over 100x is possible • problems with pH gradient and side channels • fraction collection has to be done • detector has to be attached
