DESIGN TEMPLATES TO IMPROVE THE QUALITY AND PRODUCTIVITY OF POWERPOINT

Download ".PPTX" version of this document: http://ppt.design4u.jp/template/#en

Shinichi Miyagi

January 02, 2015
Tweet

More Decks by Shinichi Miyagi

Other Decks in Business

Transcript

  1. Introduction • This document contains design templates intended to improve

    the quality and productivity of presentations. • This templates ware created with PowerPoint 2010. 1 #E00000
  2. About the author • Occupation: A marketer who likes design.

    • Operates a “PowerPoint Design” informational site that clearly explains presentation materials from a design perspective. harutosuzuki 2 #E00000
  3. Design Templates TO IMPROVE THE QUALITY AND PRODUCTIVITY OF POWERPOINT

    1. Page Settings 2. Color 3. Margins (Header/Footer) 4. Grid and Guides 5. Guide Position 6. Text (Body) 7. Headings 8. Bullet Lists 9. Tables 10.Supplementary Explanation /Notes 11.Cover Page 12.Table of Contents 3 #E00000
  4. 1. Page Settings Set the slide size to “A4 Paper

    (210 x 297 mm)”. Set the width to “27.51cm” and the height to “19.05cm”. A4 Paper (210 x 297 mm) 0 4 #E00000
  5. 2. Color Decide the colors used on the slides as

    “theme colors” and unify the rules for colors in the entire document. Theme Colors Base Main Accent Achromatic Color Sub-Color Main Sub-Color Achromatic 255 0 255 77 226 234 255 113 80 77 241 234 255 188 80 77 250 234 * Please note that the "theme colors" referenced in this slide refer to the general design term, and not to the PowerPoint setting. * Light sub-colors may not display well when projected using a projector. 5 #E00000
  6. 11.50mm 11.50mm 7.80mm 8.00mm 3. Margins (Header/Footer) Leave space around

    the outside border of the slide. Treat the upper and lower margins as “header” and “footer”. Header and Footer, Left and Right Margins Position Distance from center Included information Header 7.80 mm Slide Title Footer 8.00 mm Corporate Identity (CI), slide number Left and right 11.50 mm In principle, write nothing 6 #E00000
  7. 4. Grid and Guides CHECK CHECK 0.1cm CHECK Use the

    “Grid and Guides” to align elements on the slide and determine margin positioning. 7 #E00000
  8. Set the guide so you can see the border of

    the header and footer, the center of the slide, and guidelines dividing the slide in thirds. 0mm 4.30mm 11.50mm 8.00mm 5. Guide Position 7.80mm 4.30mm 11.50mm 0mm 4.30mm 4.30mm 8 #E00000
  9. Dividing the image in thirds is also a technique used

    when composing photographs (for deciding the placement of the subject). 9 #E00000
  10. 6. Text (Body) Set the font size to “24pt”. Use

    the achromatic color from the theme colors for the text color. Set the line spacing to “1.2-1.4lines”, spacing before paragraphs to “0pt”, and spacing after paragraphs to “6-12pt”. Set the text alignment to “Left” in principle. A Christmas Carol Once upon a time—of all the good days in the year, on Christmas Eve—old Scrooge sat busy in his counting-house. It was cold, bleak, biting weather: Body Heading and Body 10 #E00000
  11. Supplement | Line Spacing Settings the court was of the

    narrowest, the houses opposite were mere phantoms. To see the dingy cloud come drooping down, obscuring everything, one might have thought that Nature lived hard by, and was brewing- The line spacing for text is in the presentation tools “paragraph” function. Example of setting the line spacing to “1.4lines”. Example of setting the “Line Spacing” 11 #E00000
  12. Supplement | Paragraph Settings have thought that Nature lived hard

    by, and was brewing on a large scale. The door of Scrooge’s counting- house was open that he might keep his eye upon his clerk, who Paragraphs use the “Spacing After Paragraph” function to make room after the paragraphs. Avoid blank line breaks as much as possible. Example of setting spacing after paragraph to “12pt”. Example of setting the “Spacing After Paragraph” 12 #E00000
  13. Supplement | The “Paragraph” Dialog Box Click the arrow mark

    on the right part of the “Paragraph” section of the “Home” tab. 13 #E00000
  14. 7. Headings Set the font size to “36pt”. Use the

    main color from the theme colors for the text color. Set the line spacing to “1.2-1.4lines”, spacing after paragraphs to “12-18pt”, and spacing before paragraphs to “24pt” or more. Set the text alignment to “Left”. Heading and Body A Christmas Carol Once upon a time—of all the good days in the year, on Christmas Eve—old Scrooge sat busy in his counting-house. It was cold, bleak, biting weather: Headings 14 #E00000
  15. • List Parent Element. ⁃ List Child Element. The space

    after paragraph is set to “6pt”. ⁃ List Child Element #2. • List Parent Element. Line spacing before paragraph is set to “12pt”. 8. Bullet Lists Use the “Bullets and Numbering” feature for bullet lists. Set the line spacing to “1.0-1.4 lines”, spacing before paragraph to “0pt”, and spacing after paragraph to “6-12pt”. Bullet Lists Line Spacing 1.0-1.4pt Spacing after paragraph for child elements 6-12pt Spacing before paragraph for parent elements 12pt or higher 15 #E00000
  16. Supplement | The “Bullets and Numbering” Dialog Box Select “Bullets

    and Numbering” from the “Home” tab. 16 #E00000
  17. For bullet lists, do you adjust the indents by hand!?

    It's much easier to use the PowerPoint function!! 17 #E00000
  18. 9. Tables Use the “Table” function in PowerPoint for tables.

    Consider legibility when adjusting table borders, background colors, and character placement. Tables No. Name Qty Unit Price Total 1 Product A 1 $100 $100 2 Product B 3 $300 $900 3 Product C 5 $500 $2,500 Total $3,500 Border Thickness 1/2pt Border Color Achromatic Color Center item numbers Left-align names Right-align numbers 18 #E00000
  19. 10. Supplementary Explanation / Notes It is also possible to

    write supplementary explanation and notes in the footer as exceptions. Use the accent color as necessary in the notes. * Here is a supplementary explanation. * It is also fine to change the color of notes. Supplementary Explanation / Notes 19 #E00000
  20. 11. Cover Page DESIGN TEMPLATES TO IMPROVE THE QUALITY AND

    PRODUCTIVITY OF POWERPOINT Set the background color to plain white. List the title and CI (Corporate identity, logo, contributor) in the center. 20 #E00000
  21. 12. Table of Contents 1. Page Settings 2. Color 3.

    Margins (Header/Footer) 4. Grid and Guides 5. Guide Position 6. Text (Body) 7. Headings 8. Bullet Lists 9. Tables 10.Supplementary Explanation /Notes 11.Cover Page 12.Table of Contents Design Templates TO IMPROVE THE QUALITY AND PRODUCTIVITY OF POWERPOINT Fill 1/5th of the background with the main color to indicate that it is different from the normal slides. 21 #E00000
  22. • Download “.PPTX” version of this document: ≫ http://ppt.design4u.jp/template/#en •

    I also have many other design techniques to help make presentation materials clear: ≫ http://ppt.design4u.jp/ *Using the content of this file for commercial mass redistribution (recording to CD or DVD, posting on web sites, etc.) may be subject to terms of use. If you are considering redistribution, please contact [email protected]. 23 #E00000
