Fun with VxWorks

HD Moore
August 02, 2010

Fun with VxWorks

This talk was given at Defcon Sky Talks in 2010. More information is available in the blog post at https://community.rapid7.com/community/metasploit/blog/2010/08/02/shiny-old-vxworks-vulnerabilities

HD Moore

August 02, 2010
Tweet

More Decks by HD Moore

Other Decks in Research

Transcript

  1. introduction VxWorks • An embedded, real-time operating system • Most

    widely deployed embedded OS in ~2005 Claimed 300 million devices in 2006 Produced by Wind River Systems, now owned by Intel http://www.eetimes.com/discussion/other/4025539/Embedded-systems-survey-Operating-systems-up-for-grabs
  2. internals VxWorks internals • Support for dozens of hardware platforms

    • PowerPC, ARM, MIPS, x86, i960, SPARC • All “applications” run as kernel threads • Little memory protection between apps • Everything runs with the highest privileges • …but not necessarily the highest priority.
  3. vxworks systems VxWorks is everywhere • VoIP phones, telecom equipment,

    switches • Satellite, WiFi, microwave, sensors • RAID controllers and fibre channel switches • Video conferencing equipment • Industrial control monitors • Military routing equipment • Automobile controls • Spacecraft
  4. vulnerabilities VxWorks security • Only 12 CVEs mention VxWorks •

    Only 2 refer to flaws in the actual OS • Bug free or just too boring to hack?
  5. vulnerabilities A common thread… • The VxWorks debug service on

    port 17185 • Lightly mentioned in 2002, 2004, 2005 • CVE-2005-3715 & CVE-2005-3804 • No information on the protocol • Works on all architectures “Allows attackers to access the phone OS, obtain sensitive information, and cause a denial of service”
  6. vxworks debug service Protocol information • Basic API mentioned in

    dev docs • Signed up for a Tornado eval kit • Wouldn’t connect to VxWorks 5 targets • Gave up and searched Google…
  7. vxworks debug service Metasploit modules • Created a WDBRPC protocol

    library • Created an easy-to-call Mixin • Wrote modules  wdbrpc_version  wdbrpc_bootline  wdbrpc_memory_dump  wdbrpc_reboot
  8. vxworks debug service Identifying affected devices • At least 5

    different vendors had flubbed this • Probably much more where that came from • Email the vendors and ask? • Ask Wind River Systems?
  9. vxworks debug service This is 2010 • Just survey the

    entire Internet • Use wdbrpc_bootline as a scanner • Use tcpdump to capture replies • Use a VPS with a friendly provider • Scan, scan, scan! • Parse the results
  10. vxworks debug service Preliminary results • Scanned 3,185,049,600 IP addresses

    • Found over 250,000 vulnerable • Rescanned those with SNMP • Organized the results • SNMP on 25%
  11. vxworks debug service Checking score • Someone must have noticed

    this scan • Lets look through the DShield data…
  12. too late, we lost Winning the internet • Someone spent

    a year scanning for these • This was 4 years ago, nobody noticed
  13. shiny fun things Exploiting the debug service • We can

    read, write, exec memory • We can reboot the device • What code should we execute? • How do we get a shell?
  14. exploiting functionality Save-game hacking • Take a memory snapshot of

    the device • Make a configuration change • Take another memory snapshot • Diff the results • Patch bytes
  15. advisories Advisories out August 2nd • List of affected products

    and vendors • Detection code in NeXpose & Metasploit • No specific exploits until September 2nd
  16. exploiting functionality Changing the device mode • Modify the boot

    flags in memory • Soft reset the device • Login remotely
  17. exploiting functionality Huawei IAD2 boot flags: 0x02 - load local

    system symbols 0x04 - don't autoboot 0x08 - quick autoboot (no countdown) 0x20 - disable login security 0x40 - use bootp to get boot parameters 0x80 - use tftp to get boot image 0x100 - use proxy arp
  18. authentication Getting a shell (quickly) • Dug into the login

    process for Telnet & FTP • The password is hashed, hashes compared • Tons of static backdoor accounts* • Password is stored hashed… * Check for calls to loginUserAdd()
  19. authentication Math is hard (apparently) • The algorithm is indexed

    in Google • Used an additive byte sum as the “secret” • Only 210,000 possible output hashes • Only ~8,000 are easy to type • Most passwords within ~4000 • Range is 8-40 characters, \x00 -> \xFF
  20. authentication Hash output examples • “password” > 3974 / RcQbRbzRyc

    • “passwore” > 3966 / RRc9dydebz • “howdybob” > 3847 / ReySzQQSRR • “AAAAAAAA” > 2304 / Rrdeebbe • “!@$%^WTF” > 2564 / b9SdezeRcb
  21. authentication Precomputed passwords • Calculated a “workalike” for all outputs

    • Sorted by probability of it working • Plug this into Metasploit bruteforce
  22. authentication Brute force is easy • No account lockouts by

    default • Telnet disconnects after 3 attempts • FTP never disconnects • FTP allows 4 connections • Crack most passwords in ~30 minutes
  23. authentication Combine debug + weak hashes • Remote memory dump

    a target device • Scan the memory dump for hashes • Find the username as well • Login!
  24. vxworks Summary • These bugs are just the tip of

    the iceberg • Metasploit code will drive research • Expect to see these for a long, long time Timeline • Public advisories on August 2nd • Rapid7 NeXpose checks on August 2nd • Metasploit scanners on August 2nd • Exploit modules pushed in early September • Master password list also in September
  25. vxworks References • VU#362332 - http://www.kb.cert.org/vuls/id/362332 • VU#840249 - http://www.kb.cert.org/vuls/id/840249

    • http://www.metasploit.com/redmine/projects/framework/wiki/VxWorks • http://www.rapid7.com/vulndb/lookup/vxworks-wdbrpc-exposed
