A novel Bcl-2 Inhibitor CB6 Attenuates Intestinal Fibrosis in a Myofibroblast cell model and the Mouse S. Typhimurium Model

Presentation at Digestive Disease Week 2021 on a novel, gut-selective small molecule Bcl2 inhibitor designed to reduce or reverse intestinal fibrosis. Compound design, selection, pharmacokinetics, in vitro activity, and in vivo testing in a mouse model are described. This is a promising first step in developing anti-fibrotic drugs for Crohn's disease, though these results are currently limited to mouse models, which has low predictive value for eventual success in human therapy.

Peter Higgins

May 22, 2021
Tweet

More Decks by Peter Higgins

Other Decks in Research

Transcript

  1. A novel Bcl-2 Inhibitor CB6 Attenuates Intestinal Fibrosis in a

    Myofibroblast cell model and the Mouse S. Typhimurium Model Yongjia Feng, Laura A Johnson, Meng Zhang, Steven Collins, Shaomeng Wang, Peter D.R. Higgins MICHIGAN IBD • ANTI-FIBROTIC DRUG DEVELOPMENT
  2. Is Intestinal Fibrosis Reversible? Crohn’s strictures are no more likely

    to occur at the site of strictureplasty than anywhere else. The biology of the myofibroblast can be changed. Can we develop a ”strictureplasty in a pill”? MICHIGAN IBD • ANTI-FIBROTIC DRUG DEVELOPMENT
  3. Background • A program of fibrotic gene expression at the

    time of diagnosis was the strongest predictor of future stricture & surgery in Crohn’s disease (RISK study in children, Kugathasan, et al., Lancet, 2017) • Intestinal myofibroblasts are activated by tissue stiffness, are resistant to apoptosis (FasL), and generate more EC matrix (positive feedback – progression of fibrosis) • Inhibitors of Bcl-2 (a mitochondrial anti-apoptotic protein) make activated myofibroblasts more sensitive to apoptosis. • Hypothesis: A gut-selective Bcl-2 inhibitor could act as an intestinal anti-fibrotic in vitro and in rodent models of Crohn’s disease. MICHIGAN IBD • ANTI-FIBROTIC DRUG DEVELOPMENT
  4. Bcl-2 Inhibitor Candidate Pathway • In development for cancer therapy

    • To sensitize cancer cells to death signals • Bcl inhibitors: Anti-fibrotic efficacy seen for • Apoptosis sensitization of myofibroblasts • Fibrogenic gene expression program • Systemic off-target effects (thrombocytopenia, etc.) are acceptable in cancer (can we do better?) SMAC release Mito Outer Membrane Pores Form from Oligomers Of Bax and Bak (proapoptotic) Bax polymerized into a toroid pore as seen with Atomic Force Microscopy FEBS Lett doi.org/10.1111/febs.14186 B a k B a x MICHIGAN IBD • ANTI-FIBROTIC DRUG DEVELOPMENT Bim
  5. Previous Bcl-2 inhibitor Data in our lab • 5 different

    Bcl-2 inhibitors all inhibit the stiffness-induced fibrosis phenotype in intestinal myofibroblasts • These include ABT-199, ABT-263, and ABT-737 • ↓ fibrogenic gene and protein expression • These also inhibit fibrogenesis in TGF-b models in cells and in human intestinal organoids • Bcl-2 inhibitor compounds can overcome the intestinal myofibroblast resistance to cell death • Not gut-selective, anti-fibrotic efficacy is only moderate. MICHIGAN IBD • ANTI-FIBROTIC DRUG DEVELOPMENT
  6. Iterative Drug Candidate Development Lead candidate molecule Identify target Synthesize

    structural variants Screen for efficacy in vitro Test solubility, Caco2 permeability Evaluate stability, metabolism (rapid) Toxicity testing and pK in rodents Rodent model efficacy testing Learn Structure-Activity Relationships (SAR) Best Compounds for Testing in Humans Developing BH3-mimetic compounds to be more potent and gut-selective MICHIGAN IBD • ANTI-FIBROTIC DRUG DEVELOPMENT
  7. Compound # exp Co1A1 gene Fn1 gene ACTA2 gene MYLK

    gene Cleaved-PARP protein CB-1 2 X 10 uM X X weak CB-2 2 X X 10 µM trending CB-3 1 X X X X CB-4 2 X X X X .3,1 uM,++ CB-5 3 X X X 10 uM .1,.3,1 uM CB-6 3 X 10 µM 10 µM 1,3,10 uM Meta: trend @ 10 µM .1,.3,1 uM +++ CB-10 3 X X X 10 uM 1 uM,+ CB-11 3 X X 10 µM 10 µM CB-12 2 X X X 10 µM CB-13 1 X X X CB-14 1 +/- X X CB-15 2 X X trending 10 µM 0.1,0.3,1uM, ++ Compound screening results in vitro, testing gene expression of fibrogenic genes & cleaved PARP
  8. - + + + + + + + + TGFβ

    SMA spiro CB6 CB15 GAPDH 0.1 0.3 1 0.1 0.3 1 um CB6 (and CB15) reversed TGFβ-driven aSMA increase in vitro 0.019 0.0011 0.12 0.0013 0 1 2 3 4 ratio to control SMA Group 1 2 3 4 5 6 7 8 9 Group 1 2 3 4 5 6 7 8 9 spirono CB6 CB15 a-smooth muscle actin Western blot, Normalized to GAPDH MICHIGAN IBD • ANTI-FIBROTIC DRUG DEVELOPMENT
  9. MYLK - + + + + + + + +

    spiro CB6 CB15 0.1 0.3 1 0.1 0.3 1 GAPDH TGFβ COL1A1 0.23 0.05 0.32 0.011 0.0 0.5 1.0 1.5 2.0 ratio to control MYLK Myosin Light-chain Kinase (MYLK) and Collagen 1 Western blot, Normalized to GAPDH CB6 > CB15 reversed TGFβ-driven MYLK increase in vitro spirono CB6 CB15 Lane 1 2 3 4 5 6 7 8 9 Group 1 2 3 4 5 6 7 8 9
  10. Figure 1. Metabolic stability in human liver microsomes with NADPH

    Figure 2. Metabolic stability in mouse liver microsomes with NADPH Microsomal Stability CB6 was selected as candidate 5 24 5 24 0 2000 4000 6000 8000 Illeum-Dis compound concentration (ng/ml) Time point (hours) PK results 5 24 5 24 0 2000 4000 6000 Cecum compound concentration (ng/ml) 5 24 5 24 0 20 40 60 80 Liver compound concentration (ng/ml) 5 24 5 24 0 5 10 15 20 25 Plasma compound concentration (ng/ml) Time point (hours) Time point (hours) Time point (hours) CB6 CB15 CB6 CB15 CB6 CB15 CB6 CB15 Terminal Ileum
  11. Water DMSO Water CB6 1.0µM FASL DMSO FASL CB6 0.1µM

    FASL CB6 0.3µM FASL CB6 1.0µM Incubated for 5 hours Serum Starve overnight CCD18co cell (1X105/ML) Harvest cells Cell lysis for western blot Chamber slides for IF Cell lysis for Co-IP FASL:100nM Normal Human colon myofibroblast Can CB6 Overcome Apoptosis Resistance? MICHIGAN IBD • ANTI-FIBROTIC DRUG DEVELOPMENT
  12. FASL CB6(um) - - + + + + 0 1.0

    0 0.1 0.3 1.0 BAX GAPDH 3.6e−05 0.44 8.2e−06 0.001 0.00029 0.00019 0 2000 4000 6000 BAX % to Control % to Control CB6 Not only Inhibits Bcl-2, it Decreases Bcl-2 protein expression, & Increases the expression of the pro-apoptotic protein, Bax CB6 CB6
  13. Cleaved Cas3 Bcl-2 Merged FASL CB6 (um) _ + +

    + + 0 1.0 0 0.1 0.3 1.0 _ DAPI Cleaved-PARP Caspase3-total Cleaved Caspase3 GAPDH CB6 (uM) FASL - + 0 1.0 0 0.1 0.3 1.0 CB6 increased cleaved PARP and cleaved Caspase3 expression & led to apoptosis
  14. Testing for Bax & Bak Oligomeric Complexes • Pro-apoptotic –

    oligomerize into mitochondrial pores • IP for Bax, western blot for BH3 partners • Bax oligomers were increased by both FasL and CB6 • Bak and Bak-Bax oligomers slight increase by FasL, large increase by CB6 • Bax-Bim complexes increased by FasL, not by CB6 • CB6 does increase oligomerization of Bax and Bak • Likely increases activation of CytoC and SMAC
  15. Water DMSO Water CB6 1.0µM TGFβ DMSO TGFβ CB6 0.1µM

    TGFβ CB6 0.3µM TGFβ CB6 1.0µM Incubated for 48 hours Starving overnight CCD18co cell (5X104/ML) Collection cell Cell lysis for western blot Chamber slides for IF Cell lysis for Co-IP TGFβ: 0.05nM Normal Human colon myofibroblast Is CB6 Antifibrotic in vitro?
  16. 0.039 0.053 0.36 0.47 0.04 0.0053 0 100 200 300

    MYLK TGFβ CB6(uM) - - + + + + 0 1 0 0.1 0.3 1 α-SMA MYLK GAPDH TGFβ CB6(uM) - - + + + + 0 1 0 0.1 0.3 1 % to Control 0.00029 0.0016 0.017 0.042 0.011 1.9e−05 0 100 200 300 SMA - - + + + + 0 1 0 0.1 0.3 1 α-SMA/BCL2/DAPI TGFβ(-) TGFβ(+) CB6 0uM CB6 1.0uM CB6 0uM CB6 0.1uM CB6 0.3uM CB6 1.0uM CB6 0uM CB6 1.0uM TGFβ(-) TGFβ(+) CB6 0uM CB6 0.1uM CB6 0.3uM CB6 1.0uM MYLK/DAPI TGFβ CB6 decreases aSMA expression and MYLK expression
  17. C-PARP C-Caspase3 SMAC Cytochrome C Caspase3 CB6 TGFß - -

    + + + + 0 1.0 0 0.1 0.3 1.0 CB6 also increased pro-apoptotic proteins in the TGFb cell model Simillar changes with Increased oligomers of Bak and Bax were seen in the TGFb model
  18. Cytochrome C SMAC Active Caspase3 Apoptosis Mitochondrion CB6 Bim Bax

    Bak Bax/Bak Oligomers Form MOM Pores Bcl2 CB6 Model of CB6 Activity Either CB6 or Bim could activate Bax and Bak to oligomerize
  19. Mouse S. Typhimurium Model Treatment (day 4-20) S. typhimurium (day

    0 to day 4) Streptomycin wipeout Infect Sac (day 21) Negative Control (5 mice) CB6 100 mg/kg/d S S S CB6 100 mg/kg/d S CB-6 Therapeutic (10 mice) Fibrotic Control (10 mice) Drug Control (5 mice) Timeline and treatment arms Levo
  20. 0 5 10 15 20 60 80 100 days after

    infection Probability of Survival salmonella+vehicle salmonella+CB6 p=0.3150 H B SS_Vehicle H B SS+C B 6 salm onella+vehicle salm onella+C B 6 50 100 150 200 cecum weight (mg) 0.2948 0.0005 >0.9999 0.0173 H B SS_Vehicle H B SS+C B 6 salm onella+vehicle salm onella+C B 6 100 200 300 400 500 colon weight (mg) 0.6363 <0.0001 0.0632 0.0014 Survival Cecal Weight Colon Weight CB6 reduced cecal and colon weight
  21. BAX BIM-XL BIM-L BIM-S BCL-XL BCL-2 GAPDH S typhimurium CB6

    - + - + - - + + A. CB6 decreases Bcl-2, and increases Bax and Bim-S in cecal tissue from S. typhimurium mice, Western blots CB6 Styph
  22. CB6 increases Bax-Bak Oligomers In Mouse Cecum tissue – Bax

    IP/ Bak Western blots Input sample Anti-Bak Western Anti-Bax IP sample Anti-Bak Western S. Typhimurium CB6 - + - + - - + + - + - + + - - + + + IP antibody BAX IgG 160KD Bax- Bak Oligomers Heavy chain 20KD Bak monomer Similar increases in Bax oligomers (Mitochondrial pores), No stable binding of Bim
  23. SMAC Cleaved- PARP Total – Caspase3 Cleaved – Caspase3 α-SMA

    60KD 43KD GAPDH S. Typhimurium CB6 - + + - + + - - Western Blots of pro-apoptotic proteins and aSMA In Mouse Cecum tissue CB6 Styph
  24. CB6 S. Typhimurium _ + + _ _ _ +

    + Circular Muscle Layer CB6 decr aSMA & incr Apoptosis, largely in circular muscle
  25. S. Typhimurium CB6 + + + + - + -

    + Fibrosis Score (0-4) Masked Pathologist Scoring CB6 reduced cecal and colon fibrosis
  26. Conclusion A novel, partially gut-selective Bcl-2 /Bcl-XL inhibitor, CB6, can

    attenuate intestinal fibrosis in myofibroblast cell models and the mouse S. typhimurium fibrosis model through Bax/Bak oligomerization and apoptosis in the circular muscle layer. MICHIGAN IBD • ANTI-FIBROTIC DRUG DEVELOPMENT
