RBS meets LLMs - Type inference using LLM

RBS meets LLMs - Type inference using LLM

RubyKaigi 2023での発表資料です。以下、公式サイトに掲載した概要となります。

---

Recently, Large Language Models (LLMs), such as ChatGPT, have been rapidly evolving. LLMs are characterized by their ability to interpret word meanings and contexts, and by their very wide range of applications.

By the way, common static analyzers and execution systems treat class and variable names as mere labels, but they are important clues when humans read code. By using LLMs, we can interpret those intentions and use them for type inference.

Also, static analysis is not good at dynamic definitions such as define_method, which cannot be distinguished from a simple method call in Ruby syntax. LLMs may be able to successfully generate type definitions in these cases.

In this session, we will introduce our efforts to use ChatGPT for RBS generation and discuss the possibility of incorporating LLMs into development tools.

kokuyouwind

May 11, 2023
Tweet

More Decks by kokuyouwind

Other Decks in Programming

Transcript

  1. RBS meets LLMs
    Leaner Technologies, Inc.
    黒曜
    (@kokuyouwind)
    ~ Type inference using LLM ~

    View Slide

  2. Talk: Japanese
    Slides: English (+ Japanese)

    View Slide

  3. $ whoami
    黒曜 / @kokuyouwind
    Work at: Leaner Technologies, Inc.
    Ruby Sponsor
    Day 1: Sponsor Talk (Done)
    Day 2: Leaner Drinkup

    View Slide

  4. The idea is covered by Matz's Keynote,
    but this is the first time you've heard of it!
    Matz
    のKeynote
    で出た話と発想が被っていますが、
    初めて聞いたことにしてください!

    View Slide

  5. Large Language Model (LLM)
    Machine learning models trained on large amounts of text data.
    ChatGPT Bard Bing Chat
    ⼤量のテキストデータを使ってトレーニングされた機械学習モデル
    ⼤規模⾔語モデル

    View Slide

  6. Example: ChatGPT

    View Slide

  7. Can we do something fun with this?
    🤔
    なにか⾯⽩いことに使えないかな?

    View Slide

  8. Type Inference
    user = User.new
    # `user` is an User type variable
    name = user.name
    # `name` is a String type variable(?)
    1
    2
    3
    4
    5
    Humans sometimes infer type from word meanings.
    ⼈間は単語の意味から型を推測することがある

    View Slide

  9. With ChatGPT,
    can we infer the type
    from the meaning of a word?
    ChatGPT
    を使えば、単語の意味から
    型を推測できるのでは?

    View Slide

  10. Let's see some cases!
    Tool Settings
    model: ChatGPT(gpt-3.5-turbo)
    Temperature: 0
    GUI: BetterChatGPT

    View Slide

  11. Case 1: User Builder
    user = UserBuilder.new.name('kokuyouwind').build
    # We infer types as follows:
    # * UserBuilder#name returns an UserBuilder
    # * UserBuilder#build returns an User
    1
    2
    3
    4
    5

    View Slide

  12. Case 1: User Builder

    View Slide

  13. Case 1: User Builder

    View Slide

  14. (There is extra output, but)
    Perfect!!!
    👏

    View Slide

  15. Case 2: Company Repository
    company = CompanyRepository.new.find(1).name
    # We infer types as follows:
    # * CompanyRepository#find returns a Company
    # * Company#name returns a String
    # Note.
    # This expression has the same syntactic form with:
    # user = UserBuilder.new.name('kokuyouwind').build
    1
    2
    3
    4
    5
    6
    7
    8
    9

    View Slide

  16. Case 2: Company Repository

    View Slide

  17. (There is extra output, but)
    Perfect, again!!!
    👏

    View Slide

  18. Problems
    RBS sometimes broken (
    たまにRBS
    の構⽂がおかしい)
    Extra Outputs (
    不要な出⼒がある)
    Only RBS output needed (RBS
    だけ出⼒させたい)
    Single RBS (RBS
    がひとまとめになっている)
    Separate User's RBS to user.rbs, and so on
    (User
    のRBS
    はuser.rbs
    に、などクラスごとに分割したい)

    View Slide

  19. Improve: FewShot
    Demonstrate type inference for UserBuilder,
    then ask about the CompanyRepository case.
    UserBuilder
    の模範解答を⼊⼒してから、CompanyRepository
    について推論させる
    Demo Input
    Main Question
    Output
    模範解答
    メインの問い合わせ
    出⼒

    View Slide

  20. Improve: FewShot
    Demo Input Main Question
    模範解答を⼊⼒ メインの問い合わせ

    View Slide

  21. View Slide

  22. Really Perfect!!!
    👏

    View Slide

  23. Please talk to me at parties, etc.
    ぜひドリンクアップなどで話しかけてください!
    I've tried to infer types for metaprogramming,
    refine existing RBS, etc.,
    but I don't have time to talks. So,
    メタプログラミングコードに対する型の推測や既存RBS
    の詳細化なども試しましたが
    今回は話す時間が⾜りないので、

    View Slide

  24. Future Works
    CommandLine Tool (
    コマンドラインツール化)
    Fine tuning for type inference (
    型推測⽤のファインチューニング)
    Agent-style autonomous drive (
    エージェントスタイルの⾃律駆動)
    Refer to the necessary files (
    必要なファイルの参照)
    Correction with type check results (
    型チェックを元にした修正)
    Run with LLMs locally (
    ローカルで動くLLM
    を使った動作)
    Alpaca.cpp, ChatRWKV, or else

    View Slide
