1. High availability and Scaling MongoDB
2. Agenda •  Replica Sets Lifecycle •  Developing with Replica Sets •  Operational Considerations •  How Replication works
3. Why Replication? •  How many have faced node failures? •  How many have been woken up from sleep to do a fail-over(s)? •  How many have experienced issues due to network latency? •  Different uses for data –  Normal processing –  Simple analytics
4. ReplicaSet Lifecycle
5. Node 1 Node 2 Node 3 Replica Set – Creation
6. Node 1 Secondary Node 2 Secondary Node 3 Primary Replication Heartbeat Replication Replica Set – Initialize
7. Node 1 Secondary Node 2 Secondary Node 3 Heartbeat Primary Election Replica Set – Failure
8. Node 1 Secondary Node 2 Primary Node 3 Replication Heartbeat Replica Set – Failover
9. Node 1 Secondary Node 2 Primary Replication Heartbeat Node 3 Recovery Replication Replica Set – Recovery
10. Node 1 Secondary Node 2 Primary Replication Heartbeat Node 3 Secondary Replication Replica Set – Recovered
11. ReplicaSet Roles & Configuration
12. Node 1 Secondary Node 2 Arbiter Node 3 Primary Heartbeat Replication Replica Set Roles
13. > conf = { _id : "mySet", members : [ {_id : 0, host : "A", priority : 3}, {_id : 1, host : "B", priority : 2}, {_id : 2, host : "C"}, {_id : 3, host : "D", hidden : true}, {_id : 4, host : "E", hidden : true, slaveDelay : 3600} ] } > rs.initiate(conf) Configuration Options
14. > conf = { _id : "mySet", members : [ {_id : 0, host : "A", priority : 3}, {_id : 1, host : "B", priority : 2}, {_id : 2, host : "C"}, {_id : 3, host : "D", hidden : true}, {_id : 4, host : "E", hidden : true, slaveDelay : 3600} ] } > rs.initiate(conf) Configuration Options Primary DC
15. > conf = { _id : "mySet", members : [ {_id : 0, host : "A", priority : 3}, {_id : 1, host : "B", priority : 2}, {_id : 2, host : "C"}, {_id : 3, host : "D", hidden : true}, {_id : 4, host : "E", hidden : true, slaveDelay : 3600} ] } > rs.initiate(conf) Configuration Options Secondary DC Default Priority = 1
16. > conf = { _id : "mySet", members : [ {_id : 0, host : "A", priority : 3}, {_id : 1, host : "B", priority : 2}, {_id : 2, host : "C"}, {_id : 3, host : "D", hidden : true}, {_id : 4, host : "E", hidden : true, slaveDelay : 3600} ] } > rs.initiate(conf) Configuration Options Analytics node
17. Backup node > conf = { _id : "mySet", members : [ {_id : 0, host : "A", priority : 3}, {_id : 1, host : "B", priority : 2}, {_id : 2, host : "C"}, {_id : 3, host : "D", hidden : true}, {_id : 4, host : "E", hidden : true, slaveDelay : 3600} ] } > rs.initiate(conf) Configuration Options
18. Developing with Replica Sets
19. Secondary Secondary Primary Client Application Driver Write Read Strong Consistency
20. Secondary Secondary Primary Client Application Driver Write Read Read Delayed Consistency
21. Write Concern •  Network acknowledgement •  Wait for error •  Wait for journal sync •  Wait for replication
22. write Driver Primary apply in memory Unacknowledged
23. Driver Primary apply in memory getLastError MongoDB Acknowledged (wait for error)
24. Driver Primary write to journal apply in memory getLastError write j:true Wait for Journal Sync
25. Driver Primary Secondary getLastError write w:2 replicate apply in memory Wait for Replication
26. Tagging •  New in 2.0.0 •  Control where data is written to, and read from •  Each member can have one or more tags –  tags: {dc: "ny"} –  tags: {dc: "ny", subnet: "192.168", rack: "row3rk7"} •  Replica set defines rules for write concerns •  Rules can change without changing app code
27. { _id : "mySet", members : [ {_id : 0, host : "A", tags : {"dc": "ny"}}, {_id : 1, host : "B", tags : {"dc": "ny"}}, {_id : 2, host : "C", tags : {"dc": "sf"}}, {_id : 3, host : "D", tags : {"dc": "sf"}}, {_id : 4, host : "E", tags : {"dc": "cloud"}}], settings : { getLastErrorModes : { allDCs : {"dc" : 3}, someDCs : {"dc" : 2}} } } > db.blogs.insert({...}) > db.runCommand({getLastError : 1, w : "someDCs"}) Tagging Example
28. Driver Primary (SF) Secondary (NY) getLastError write W:allDCs Secondary (Cloud) replicate replicate apply in memory Wait for Replication (Tagging)
29. Read Preference Modes •  5 modes (new in 2.2) –  primary (only) - Default –  primaryPreferred –  secondary –  secondaryPreferred –  Nearest When more than one node is possible, closest node is used for reads (all modes but primary)
30. Tagged Read Preference •  Custom read preferences •  Control where you read from by (node) tags –  E.g. { "disk": "ssd", "use": "reporting" } •  Use in conjunction with standard read preferences –  Except primary
31. Operational Considerations
32. Maintenance and Upgrade •  No downtime •  Rolling upgrade/maintenance –  Start with Secondary –  Primary last
33. •  Single datacenter •  Single switch & power •  Points of failure: –  Power –  Network –  Data center –  Two node failure •  Automatic recovery of single node crash Replica Set – 1 Data Center Datacenter 2 Datacenter Member 1 Member 2 Member 3
34. •  Multi data center •  DR node for safety •  Can’t do multi data center durable write safely since only 1 node in distant DC Replica Set – 2 Data Centers Member 3 Datacenter 2 Member 1 Member 2 Datacenter 1
35. •  Three data centers •  Can survive full data center loss •  Can do w= { dc : 2 } to guarantee write in 2 data centers (with tags) Replica Set – 3 Data Centers Datacenter 1 Member 1 Member 2 Datacenter 2 Member 3 Member 4 Datacenter 3 Member 5
36. How does it work?
37. Implementation details •  Heartbeat every 2 seconds –  Times out in 10 seconds •  Local DB (not replicated) –  system.replset –  oplog.rs •  Capped collection •  Idempotent version of operation stored
38. > db.replsettest.insert({_id:1,value:1}) { "ts" : Timestamp(1350539727000, 1), "h" : NumberLong("6375186941486301201"), "op" : "i", "ns" : "test.replsettest", "o" : { "_id" : 1, "value" : 1 } } > db.replsettest.update({_id:1},{$inc:{value:10}}) { "ts" : Timestamp(1350539786000, 1), "h" : NumberLong("5484673652472424968"), "op" : "u", "ns" : "test.replsettest", "o2" : { "_id" : 1 }, "o" : { "$set" : { "value" : 11 } } } Op(erations) Log is idempotent
39. > db.replsettest.update({},{$set:{name : "foo"}, false, true}) { "ts" : Timestamp(1350540395000, 1), "h" : NumberLong("-4727576249368135876"), "op" : "u", "ns" : "test.replsettest", "o2" : { "_id" : 2 }, "o" : { "$set" : { "name" : "foo" } } } { "ts" : Timestamp(1350540395000, 2), "h" : NumberLong("-7292949613259260138"), "op" : "u", "ns" : "test.replsettest", "o2" : { "_id" : 3 }, "o" : { "$set" : { "name" : "foo" } } } { "ts" : Timestamp(1350540395000, 3), "h" : NumberLong("-1888768148831990635"), "op" : "u", "ns" : "test.replsettest", "o2" : { "_id" : 1 }, "o" : { "$set" : { "name" : "foo" } } } Single operation can have many entries
40. Replica sets •  Use replica sets •  Easy to setup –  Try on a single machine •  Check doc page for RS tutorials –  http://docs.mongodb.org/manual/replication/#tutorials
41. Sharding
42. Agenda •  Why shard •  MongoDB's approach •  Architecture •  Configuration •  Mechanics •  Solutions
43. Why shard?
44. Working Set Exceeds Physical Memory
45. Read/Write Throughput Exceeds I/O
46. MongoDB's approach to sharding
47. Partition data based on ranges •  User defines shard key •  Shard key defines range of data •  Key space is like points on a line •  Range is a segment of that line -∞ +∞ Key Space
48. Distribute data in chunks across nodes •  Initially 1 chunk •  Default max chunk size: 64mb •  MongoDB automatically splits & migrates chunks when max reached Node 1 Secondary Config Server Shard 1 Mongos Mongos Mongos Shard 2 Mongod
49. MongoDB manages data •  Queries routed to specific shards •  MongoDB balances cluster •  MongoDB migrates data to new nodes Shard Shard Shard Mongos 1 2 3 4
50. MongoDB Auto-Sharding •  Minimal effort required –  Same interface as single mongod •  Two steps –  Enable Sharding for a database –  Shard collection within database
51. Architecture
52. Data stored in shard •  Shard is a node of the cluster •  Shard can be a single mongod or a replica set Shard Primary Secondary Secondary Shard or Mongod
53. Config server stores meta data •  Config Server –  Stores cluster chunk ranges and locations –  Can have only 1 or 3 (production must have 3) –  Two phase commit (not a replica set) or Node 1 Secondary Config Server Node 1 Secondary Config Server Node 1 Secondary Config Server Node 1 Secondary Config Server
54. MongoS manages the data •  Mongos –  Acts as a router / balancer –  No local data (persists to config database) –  Can have 1 or many App Server Mongos Mongos App Server App Server App Server Mongos or
55. Node 1 Secondary Config Server Node 1 Secondary Config Server Node 1 Secondary Config Server Shard Shard Shard Mongos App Server Mongos App Server Mongos App Server Sharding infrastructure
56. Configuration
57. Example cluster setup •  Don’t use this setup in production! -  Only one Config server (No Fault Tolerance) -  Shard not in a replica set (Low Availability) -  Only one Mongos and shard (No Performance Improvement) -  Useful for development or demonstrating configuration mechanics Node 1 Secondary Config Server Mongos Mongod Mongod
58. Node 1 Secondary Config Server Start the config server •  "mongod --configsvr" •  Starts a config server on the default port (27019)
59. Node 1 Secondary Config Server Mongos Start the mongos router •  "mongos --configdb <hostname>:27019" •  For 3 config servers: "mongos --configdb <host1>:<port1>,<host2>:<port2>,<host3>:<port3>" •  This is always how to start a new mongos, even if the cluster is already running
60. Start the shard database •  "mongod --shardsvr" •  Starts a mongod with the default shard port (27018) •  Shard is not yet connected to the rest of the cluster •  Shard may have already been running in production Node 1 Secondary Config Server Mongos Mongod Shard
61. Add the shard •  On mongos: "sh.addShard(‘<host>:27018’)" •  Adding a replica set: "sh.addShard(‘<rsname>/<seedlist>’) •  In 2.2 and later can use sh.addShard(‘<host>:<port>’) Node 1 Secondary Config Server Mongos Mongod Shard
62. Verify that the shard was added •  db.runCommand({ listshards:1 }) •  { "shards" : [ { "_id": "shard0000", "host": "<hostname>:27018" } ], "ok" : 1 } Node 1 Secondary Config Server Mongos Mongod Shard
63. Enabling Sharding •  Enable sharding on a database –  sh.enableSharding("<dbname>") •  Shard a collection with the given key –  sh.shardCollection("<dbname>.people",{"country":1}) •  Use a compound shard key to prevent duplicates –  sh.shardCollection("<dbname>.cars",{"year":1, "uniqueid":1})
64. Tag Aware Sharding •  Tag aware sharding allows you to control the distribution of your data •  Tag a range of shard keys –  sh.addTagRange(<collection>,<min>,<max>,<tag>) •  Tag a shard –  sh.addShardTag(<shard>,<tag>)
65. Mechanics
66. Partitioning •  Remember it's based on ranges -∞ +∞ Key Space
67. minKey maxKey minKey maxKey minKey maxKey {x: -20} {x: 13} {x: 25} {x: 100,000} 64MB Chunk is a section of the entire range
68. Chunk splitting •  A chunk is split once it exceeds the maximum size •  There is no split point if all documents have the same shard key •  Chunk split is a logical operation (no data is moved) •  If split creates too large of a discrepancy of chunk count across cluster a balancing round starts minKey maxKey minKey 13 14 maxKey
69. Balancing •  Balancer is running on mongos •  Once the difference in chunks between the most dense shard and the least dense shard is above the migration threshold, a balancing round starts Node 1 Secondary Config Server Shard 1 Mongos Mongos Mongos Shard 2 Mongod
70. Acquiring the Balancer Lock •  The balancer on mongos takes out a "balancer lock" •  To see the status of these locks: -  use config -  db.locks.find({ _id: "balancer" }) Node 1 Secondary Config Server Mongos Shard 1 Mongos Mongos Shard 2 Mongod
71. Moving the chunk •  The mongos sends a "moveChunk" command to source shard •  The source shard then notifies destination shard •  The destination claims the chunk shard-key range •  Destination shard starts pulling documents from source shard Node 1 Secondary Config Server Mongos Shard 1 Shard 2 Mongod
72. Committing Migration •  When complete, destination shard updates config server -  Provides new locations of the chunks Node 1 Secondary Config Server Mongos Shard 1 Shard 2 Mongod
73. Cleanup •  Source shard deletes moved data -  Must wait for open cursors to either close or time out -  NoTimeout cursors may prevent the release of the lock •  Mongos releases the balancer lock after old chunks are deleted Node 1 Secondary Config Server Shard 1 Shard 2 Mongod Mongos Mongos Mongos
74. Routing Requests
75. Cluster Request Routing •  Targeted Queries •  Scatter Gather Queries •  Scatter Gather Queries with Sort
76. Shard Shard Shard Mongos Cluster Request Routing: Targeted Query
77. Shard Shard Shard Mongos 1 Routable request received
78. Shard Shard Shard Mongos 1 2 Request routed to appropriate shard
79. Shard Shard Shard Mongos 1 2 3 Shard returns results
80. Shard Shard Shard Mongos 1 2 3 4 Mongos returns results to client
81. Shard Shard Shard Mongos Cluster Request Routing: Non-Targeted Query
82. Shard Shard Shard Mongos 1 Non-Targeted Request Received
83. Shard Shard Shard Mongos 1 2 2 2 Request sent to all shards
84. Shard Shard Shard Mongos 1 2 2 2 3 3 3 Shards return results to mongos
85. Shard Shard Shard Mongos 1 2 2 2 3 3 3 4 Mongos returns results to client
86. Shard Shard Shard Mongos Cluster Request Routing: Non-Targeted Query with Sort
87. Shard Shard Shard Mongos 1 Non-Targeted request with sort received
88. Shard Shard Shard Mongos 1 2 2 2 Request sent to all shards
89. Shard Shard Shard Mongos 1 2 2 2 3 3 3 Query and sort performed locally
90. Shard Shard Shard Mongos 1 2 2 2 4 4 4 3 3 3 Shards return results to mongos
91. Shard Shard Shard Mongos 1 2 2 2 4 4 4 3 3 3 5 Mongos merges sorted results
92. Shard Shard Shard Mongos 1 2 2 2 4 4 4 3 3 3 6 5 Mongos returns results to client
93. Shard Key
94. Shard Key •  Choose a field common used in queries •  Shard key is immutable •  Shard key values are immutable •  Shard key requires index on fields contained in key •  Uniqueness of `_id` field is only guaranteed within individual shard •  Shard key limited to 512 bytes in size
95. Shard Key Considerations •  Cardinality •  Write distribution •  Query isolation •  Data Distribution
96. Sharding enables scale
97. Working Set Exceeds Physical Memory
98. Click tracking Read/Write throughput exceeds I/O
99. Thank You •  #ConferenceHashTag •  Speaker Name •  Job Title, 10gen
