Reverse caching proxies: Varnish or Nginx? - Techorama 2014

Reverse caching proxies Varnish or nginx? By thijs feryn

Hi, I’m Thijs

I’m @ThijsFeryn on Twitter

I’m an at Evangelist

I’m a at board member

Thanks guys!

What’s a reverse proxy?

Why? ✓ Hide origin server ✓ SSL termination ✓ Load
balancing ✓ Caching ✓ Compression

✓ Hide origin server ✓ SSL termination ✓ Load balancing
✓ Caching ✓ Compression Why?

Protecting your backend server

Kevin & Whitney

Cache-control Cache-‐Control “max-‐age=3600, s-‐ maxage=1000, public, must-‐revalidate”

Expires Expires "Wed, 1 Jan 2014 20:00:00 GMT"

ETag If-‐None-‐Match: "3e86-‐410-‐3596Obc" ETag: "3e86-‐410-‐3596Obc" Problems with browser cache

What’s not cacheable ✓HTTP POST, PUT, DELETE ✓ Cookie &
Set-Cookie headers ✓ Authorization ✓ TTL == 0

Meet the contenders Varnish Nginx

Varnish ✓Poul-Henning Kamp ✓Verdens Gang AS ✓Redpill Linpro ✓Varnish software
✓Reverse proxy only ✓2005: ideas @ Verdens Gang ✓2006 : development & v1 ✓2008: v2 ✓2011: v3 ✓2014: v4 (April 29th)

Nginx ✓Igor Sysoev ✓2002: development ✓2004: first release ✓15% of
the internet ✓CK10 problem ✓Event driven, async ✓$3M Series A funding ✓$10M Series B funding ✓Webserver & reverse proxy

Install

curl http://repo.varnish-‐cache.org/debian/GPG-‐key.txt | sudo apt-‐ key add -‐ echo
"deb http://repo.varnish-‐cache.org/ubuntu/ trusty varnish-‐3.0" | sudo tee -‐a /etc/apt/sources.list sudo apt-‐get update sudo apt-‐get install varnish curl http://repo.varnish-‐cache.org/debian/GPG-‐key.txt | sudo apt-‐ key add -‐ echo "deb http://repo.varnish-‐cache.org/debian/ wheezy varnish-‐3.0" | sudo tee -‐a /etc/apt/sources.list sudo apt-‐get update sudo apt-‐get install varnish

deb http://nginx.org/packages/ubuntu/ trusty nginx deb-‐src http://nginx.org/packages/ubuntu/ trusty nginx deb
http://nginx.org/packages/debian/ wheezy nginx deb-‐src http://nginx.org/packages/debian/ wheezy nginx Go to h&p://wiki.nginx.org/Pgp for PGP signature Go to h&p://wiki.nginx.org/Install for more info

Configure

DAEMON_OPTS="-‐a :80 \ -‐T localhost:6082 \ -‐f /etc/varnish/default.vcl
\ -‐S /etc/varnish/secret \ -‐s malloc,256m" In “/etc/default/varnish”

backend default { .host
= "127.0.0.1"; .port = "8080"; } In “/etc/varnish/default.vcl”

server { listen
80; server_name host-‐name.dev; access_log /var/log/nginx/access.log; error_log /var/log/nginx/error.log; ! location / { proxy_pass http://localhost:8080; proxy_cache proxy-‐cache; proxy_cache_key "$scheme://$host $request_uri"; proxy_cache_valid 200 302 1h; } } In “/etc/nginx/sites-‐enabled”

proxy_cache_path /tmp/ levels=1:2 keys_zone=proxy-‐cache:10m inactive=5m; Add to “/etc/nginx/nginx.conf”

Backend Listen 8080 In “/etc/apache2/ports.conf”

✓mod_php ✓mod_fcgid & php-cgi ✓mod_proxy_fcgi & php-fpm ✓Behind Varnish &
Nginx

✓Native fastcgi proxying for php-fpm ✓Cacheable

server { listen
80; server_name nginx-‐proxy.dev; root /home/data/www; access_log /var/log/nginx/access.log; access_log /var/log/nginx/error.log; location / { index index.php; } location ~ \.php$ { fastcgi_split_path_info ^(.+\.php)(/.+)$; fastcgi_pass 127.0.0.1:9000; fastcgi_index index.php; include fastcgi_params; fastcgi_param SCRIPT_FILENAME $request_filename; fastcgi_cache fastcgi-‐cache; fastcgi_cache_valid 200 302 1h; fastcgi_cache_key "$scheme://$host$request_uri"; } } 38

h&ps://www.varnish-‐cache.org/trac/wiki/ Future_Feature#FCGIbackendsupport

Out of the box

✓POST, DELETE & PUT ✓cookies & auth headers ✓set-cookie headers
✓cache ttl <= 0 (< v4) ✓“no-cache", "no-store", „private” in v4 Varnish wil not cache

✓POST, DELETE & PUT ✓“no-cache", "no-store", "private” ✓set-cookie headers ✓cache
ttl <= 0 ✓X-Accel-Expires: 0 Nginx wil not cache

About cookies

About cookies HTTP cookie request header via browser HTTP set-cookie
response header via webserver

set $bypass 0; if ($http_cookie) { set $bypass
1; } fastcgi_cache_bypass $bypass; fastcgi_no_cache $bypass; Nginx caches cookies by default

Monitoring & Logging

access_log error_log

varnishstat varnishlog varnishtop

varnishstat

4+05:26:25 Hitrate ratio:
10 100 254 Hitrate avg: 0.8486 0.7619 0.7285 ! 1760818 6.99 4.82 client_conn -‐ Client connections accepted 11088687 25.96 30.36 client_req -‐ Client requests received 8042715 11.98 22.02 cache_hit -‐ Cache hits 2609561 11.98 7.15 cache_miss -‐ Cache misses 47104 1.00 0.13 backend_conn -‐ Backend conn. success 610 0.00 0.00 backend_fail -‐ Backend conn. failures 2998265 12.98 8.21 backend_reuse -‐ Backend conn. reuses 12081 0.00 0.03 backend_toolate -‐ Backend conn. was closed 3010356 13.98 8.24 backend_recycle -‐ Backend conn. recycles 13 0.00 0.00 backend_retry -‐ Backend conn. retry 520 0.00 0.00 fetch_head -‐ Fetch head 2857965 11.98 7.83 fetch_length -‐ Fetch with Length 151309 2.00 0.41 fetch_chunked -‐ Fetch chunked 4404 0.00 0.01 fetch_close -‐ Fetch wanted close 676 0.00 0.00 fetch_failed -‐ Fetch failed 31164 0.00 0.09 fetch_304 -‐ Fetch no body (304) 220 . . n_sess_mem -‐ N struct sess_mem 53 . . n_sess -‐ N struct sess 29540 . . n_object -‐ N struct object 29561 . . n_objectcore -‐ N struct objectcore 5058 . . n_objecthead -‐ N struct objecthead 2613 . . n_waitinglist -‐ N struct waitinglist 3 . . n_vbc -‐ N struct vbc 22 . . n_wrk -‐ N worker threads 1789 0.00 0.00 n_wrk_create -‐ N worker threads created

varnishlog

11 SessionOpen c 12.12.12.1 53727 :80
11 ReqStart c 12.12.12.1 53727 1401010767 11 RxRequest c GET 11 RxURL c / 11 RxProtocol c HTTP/1.1 11 RxHeader c Host: 12.12.12.6 11 RxHeader c User-‐Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10.8; rv:17.0) Gecko/20100101 Firefox/17.0 11 RxHeader c Accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/ *;q=0.8 11 RxHeader c Accept-‐Language: nl,en;q=0.7,fr-‐be;q=0.3 11 RxHeader c Accept-‐Encoding: gzip, deflate 11 RxHeader c Connection: keep-‐alive 11 VCL_call c recv lookup 11 VCL_call c hash 11 Hash c / 11 Hash c 12.12.12.6 11 VCL_return c hash 11 VCL_call c miss fetch 11 Backend c 13 default default 11 TTL c 1401010767 RFC 0 -‐1 -‐1 1357920021 0 1357920020 0 0 11 VCL_call c fetch 11 TTL c 1401010767 VCL 120 -‐1 -‐1 1357920021 -‐0 11 VCL_return c hit_for_pass 11 ObjProtocol c HTTP/1.1 11 ObjResponse c OK 11 ObjHeader c Date: Fri, 11 Jan 2013 16:00:20 GMT 11 ObjHeader c Server: Apache 11 ObjHeader c X-‐Powered-‐By: PHP/5.3.2-‐1ubuntu4.18 11 ObjHeader c Cache-‐Control: no-‐cache, no-‐store, max-‐age=0 Client

11 VCL_return c hit_for_pass
11 ObjProtocol c HTTP/1.1 11 ObjResponse c OK 11 ObjHeader c Date: Fri, 11 Jan 2013 16:00:20 GMT 11 ObjHeader c Server: Apache 11 ObjHeader c X-‐Powered-‐By: PHP/5.3.2-‐1ubuntu4.18 11 ObjHeader c Cache-‐Control: no-‐cache, no-‐store, max-‐age=0 11 ObjHeader c Vary: Accept-‐Encoding 11 ObjHeader c Content-‐Encoding: gzip 11 ObjHeader c Content-‐Length: 119 11 ObjHeader c Content-‐Type: text/html 11 Gzip c u F -‐ 119 336 80 80 887 11 VCL_call c deliver deliver 11 TxProtocol c HTTP/1.1 11 TxStatus c 200 11 TxResponse c OK 11 TxHeader c Server: Apache 11 TxHeader c X-‐Powered-‐By: PHP/5.3.2-‐1ubuntu4.18 11 TxHeader c Cache-‐Control: no-‐cache, no-‐store, max-‐age=0 11 TxHeader c Vary: Accept-‐Encoding 11 TxHeader c Content-‐Encoding: gzip 11 TxHeader c Content-‐Type: text/html 11 TxHeader c Content-‐Length: 119 11 TxHeader c Accept-‐Ranges: bytes 11 TxHeader c Date: Fri, 11 Jan 2013 16:00:20 GMT 11 TxHeader c X-‐Varnish: 1401010767 11 TxHeader c Age: 0 11 TxHeader c Via: 1.1 varnish 11 TxHeader c Connection: keep-‐alive 11 Length c 119 11 ReqEnd c 1401010767 1357920020.712090731 1357920020.727306366 0.000087738 Client

13 BackendClose -‐ default 13
BackendOpen b default 127.0.0.1 51597 127.0.0.1 8080 13 TxRequest b GET 13 TxURL b / 13 TxProtocol b HTTP/1.1 13 TxHeader b Host: 12.12.12.6 13 TxHeader b User-‐Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10.8; rv:17.0) Gecko/20100101 Firefox/17.0 13 TxHeader b Accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/ *;q=0.8 13 TxHeader b Accept-‐Language: nl,en;q=0.7,fr-‐be;q=0.3 13 TxHeader b X-‐Forwarded-‐For: 12.12.12.1 13 TxHeader b X-‐Varnish: 1401010767 13 TxHeader b Accept-‐Encoding: gzip 13 RxProtocol b HTTP/1.1 13 RxStatus b 200 13 RxResponse b OK 13 RxHeader b Date: Fri, 11 Jan 2013 16:00:20 GMT 13 RxHeader b Server: Apache 13 RxHeader b X-‐Powered-‐By: PHP/5.3.2-‐1ubuntu4.18 13 RxHeader b Cache-‐Control: no-‐cache, no-‐store, max-‐age=0 13 RxHeader b Vary: Accept-‐Encoding 13 RxHeader b Content-‐Encoding: gzip 13 RxHeader b Content-‐Length: 119 13 RxHeader b Content-‐Type: text/html 13 Fetch_Body b 4(length) cls 0 mklen 1 13 Length b 119 13 BackendReuse b default Backend

Varnishlog examples varnishlog -‐c -‐m"VCL_call:hit" | grep RxURL varnishlog -‐c
-‐m"VCL_call:miss" | grep RxURL varnishlog -‐a -‐w /tmp/varnish.log varnishlog -‐r /tmp/varnish.log varnishlog -‐i RxHeader -‐I Cookie

varnishtop

list length 20 ! 107.57 RxHeader
User-‐Agent: Mozilla/5.0 (Windows NT 6.1; W 101.96 RxHeader User-‐Agent: Mozilla/5.0 (Windows NT 6.1; W 82.49 RxHeader User-‐Agent: Mozilla/4.0 (compatible; MSIE 69.90 RxHeader User-‐Agent: Mozilla/5.0 (compatible; MSIE 64.04 RxHeader User-‐Agent: Mozilla/5.0 (Windows NT 6.1; W 43.74 RxHeader User-‐Agent: Mozilla/4.0 (compatible; MSIE 22.01 RxHeader User-‐Agent: Mozilla/5.0 (iPod; U; CPU iPho 21.43 RxHeader User-‐Agent: Mozilla/4.0 (compatible; MSIE 19.86 RxHeader User-‐Agent: Mozilla/5.0 (X11; Linux x86_64 15.47 RxHeader User-‐Agent: Mozilla/5.0 (Windows NT 6.1; W 12.96 RxHeader User-‐Agent: Mozilla/5.0 (Windows NT 6.1; W 4.87 RxHeader User-‐Agent: Mozilla/4.0 (compatible; MSIE 2.97 RxHeader User-‐Agent: Mozilla/5.0 (compatible; MSIE 2.75 RxHeader User-‐Agent: Mozilla/5.0 (Windows NT 6.1; W 2.56 RxHeader User-‐Agent: Mozilla/5.0 (Windows NT 6.1; r 0.97 RxHeader User-‐Agent: Mozilla/5.0 (Windows; U; Windo 0.86 RxHeader User-‐Agent: Mozilla/5.0 (iPhone; CPU iPhon 0.83 RxHeader User-‐Agent: Mozilla/5.0 (Windows; U; Windo 0.53 RxHeader User-‐Agent: Mozilla/5.0 (compatible; Googl 0.44 RxHeader User-‐Agent: Mozilla/4.0 (compatible;) !

Varnishtop examples varnishtop -‐i RxHeader -‐I \^User-‐Agent varnishtop -‐i RxRequest
varnishtop -‐i RxHeader -‐I \^Host varnishtop -‐i RxHeader -‐I Cookie

The flow

vcl_recv vcl_hash vcl_pipe vcl_hit vcl_miss vcl_pass vcl_fetch vcl_deliver

11 SessionOpen c 12.12.12.1 53727 :80
11 ReqStart c 12.12.12.1 53727 1401010767 11 RxRequest c GET 11 RxURL c / 11 RxProtocol c HTTP/1.1 11 RxHeader c Host: 12.12.12.6 11 RxHeader c User-‐Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10.8; rv:17.0) Gecko/20100101 Firefox/17.0 11 RxHeader c Accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/ *;q=0.8 11 RxHeader c Accept-‐Language: nl,en;q=0.7,fr-‐be;q=0.3 11 RxHeader c Accept-‐Encoding: gzip, deflate 11 RxHeader c Connection: keep-‐alive 11 VCL_call c recv lookup 11 VCL_call c hash 11 Hash c / 11 Hash c 12.12.12.6 11 VCL_return c hash 11 VCL_call c miss fetch 11 Backend c 13 default default 11 TTL c 1401010767 RFC 0 -‐1 -‐1 1357920021 0 1357920020 0 0 11 VCL_call c fetch 11 TTL c 1401010767 VCL 120 -‐1 -‐1 1357920021 -‐0 11 VCL_return c hit_for_pass 11 ObjProtocol c HTTP/1.1 11 ObjResponse c OK 11 ObjHeader c Date: Fri, 11 Jan 2013 16:00:20 GMT 11 ObjHeader c Server: Apache 11 ObjHeader c X-‐Powered-‐By: PHP/5.3.2-‐1ubuntu4.18 11 ObjHeader c Cache-‐Control: no-‐cache, no-‐store, max-‐age=0 Got it?

Cache key

Cache key sub vcl_hash { hash_data(req.url); if (req.http.host)
{ hash_data(req.http.host); } else { hash_data(server.ip); } return (hash); }

Cache key fastcgi_cache_key "$scheme://$host$request_uri"; ! proxy_cache_key "$scheme://$host$request_uri";

Hashing cookies

Hashing cookies sub vcl_hash { if(req.http.Cookie ~ "country"){
hash_data(regsuball(req.http.Cookie, "^.+;? ?country=([a-‐zA-‐Z0-‐9]+) ( |;| ;).*$","\1")); } }

Hashing cookies set $key "$scheme://$host$request_uri"; if ($http_cookie ~* "country=([^;]+)(?:;|
$)"){ set $key "$scheme://$host$request_uri $1"; } proxy_cache_key $key; fastcgi_cache_key $key;

Cache purging

sub vcl_recv {
if (req.request == "PURGE") { return (lookup); } } sub vcl_hit { if (req.request == "PURGE") { purge; error 200 "Purged"; } } sub vcl_miss { if (req.request == "PURGE") { error 404 "Not in cache"; } } Purge config

sub vcl_recv {
if (req.request == "PURGE") { ban("req.http.host == " + req.http.host + " && req.url ~ " + req.url); error 200 "Banned"; } } sub vcl_recv { if (req.request == "PURGE") { ban("req.http.host == " + req.http.host + " && req.url == " + req.url); error 200 "Banned"; } } Ban config Ban URL Ban URL pattern

Smart bans Because cache objects store response data, not request
data

sub vcl_recv {
if (req.request == "PURGE") { ban("obj.http.x-‐host == " + req.http.host + " && obj.http.x-‐url == " + req.url); error 200 "Banned"; } } sub vcl_fetch { set beresp.http.x-‐url = req.url; set beresp.http.x-‐host = req.http.host; } ! sub vcl_deliver { unset resp.http.x-‐url; unset resp.http.x-‐host; } „Smart” bans

Purge/ban execution curl -‐X PURGE http://varnish.dev/your-‐page $ varnishadm varnish>
varnish> ban req.url == "/" 200 Or via telnet

Purge grep -‐lr 'http://host.dev/test.php' /tmp/cache/* | xargs rm

h&ps://github.com/FRiCKLE/ngx_cache_purge location / {
index index.php; error_page 477 = @purge; if ($request_method = PURGE) { return 477; } } location @purge { access_log /var/log/nginx/caching.purge.log; fastcgi_cache_purge fastcgi-‐cache "$scheme://$host $request_uri"; } Purge config

h&ps://github.com/FRiCKLE/ngx_cache_purge location / {
index index.php; error_page 477 = @purge; if ($request_method = PURGE) { return 477; } } location @purge { access_log /var/log/nginx/caching.purge.log; proxy_cache_purge proxy-‐cache "$scheme://$host $request_uri"; } Purge config

Purge execution curl -‐X PURGE http://varnish.dev/your-‐page

Loadbalancing

probe healthcheck {! .url = "/status.php";! .interval = 60s;! .timeout
= 0.3 s;! .window = 8;! .threshold = 3;! .initial = 3;! .expected_response = 200;! }! ! backend www {! .host = "www.example.com";! .port = "http";! .probe = healthcheck;! } Health probes

server {! ...! location / {! proxy_pass http://backend;! health_check match=welcome;!
}! }! ! match welcome {! status 200;! header Content-Type = text/html;! body ~ "Welcome to nginx!";! } Health probes

✓Round-robin ✓Random ✓Client ✓Hash ✓Fallback ✓DNS Directors

backend one { .host = “localhost”;
.port = “80”; } ! backend two { .host = “127.0.0.1”; .port = “81”; } ! director localhosts random { { .backend = one; .weight=4;} { .backend = two; .weight=6;} { .backend = {   .host = “localhost”;   .port = “82”; } } } ! sub vcl_recv { set req.backend = localhosts; } Random

Fallback director localhosts fallback { {
.backend = one;} { .backend = two;} } sub vcl_recv { set req.backend = localhosts; } Picks first healthy backend Order matters

director localhosts client { { .backend
= one; .weight=1; } { .backend = two; .weight=1; } } sub vcl_recv { set req.backend = localhosts; //Load balance by client IP, this is the default set client.identity = client.ip; } IP hash Uses client.identity

upstream backend {! server backend1.example.com weight=5;! server backend2.example.com:8080;! server unix:/tmp/backend3;!
}! ! server {! location / {! proxy_pass http://backend;! }! } Random

upstream backend {! server backend1.example.com;! server backend2.example.com backup;! }! !
server {! location / {! proxy_pass http://backend;! }! } Fallback

upstream backend {! ip_hash;! server backend1.example.com weight=2;! server backend2.example.com;! server
backend3.example.com down;! server backend4.example.com;! }! ! server {! location / {! proxy_pass http://backend;! }! } IP hash

HIT/MISS marker

sub vcl_deliver { if (obj.hits > 0) {
set resp.http.X-‐Cache = "HIT"; } else { set resp.http.X-‐Cache = "MISS"; } } HIT/MISS marker

✓MISS ✓EXPIRED ➡expired, request was passed to backend ✓UPDATING ➡expired,
stale response was used due to proxy/ fastcgi_cache_use_stale updating ✓STALE ➡expired, stale response was used due to proxy/ fastcgi_cache_use_stale ✓HIT HIT/MISS marker add_header X-‐Cache $upstream_cache_status;

Set Time To Live

Cache-‐Control “max-‐age=10, s-‐maxage=5, public, must-‐revalidate”

Cache-‐Control “max-‐age=10, s-‐maxage=5, public, must-‐revalidate” 5 seconds TTL

Cache-‐Control “max-‐age=10, s-‐maxage=5, public, must-‐revalidate” 10 seconds TTL

sub vcl_fetch { if(req.url ~ "^/bla")
{ set beresp.ttl = 10s; } else { set beresp.ttl = 3600s; } } Force TTL

location / { proxy_pass http://localhost:8080; proxy_cache proxy-‐cache;
proxy_cache_key "$scheme://$host$request_uri"; proxy_cache_valid 200 302 1h; } location ~ /bla { proxy_pass http://localhost:8080; proxy_cache proxy-‐cache; proxy_cache_key "$scheme://$host$request_uri"; proxy_cache_valid 200 302 10s; } Force TTL

Edge Side Includes

header.php menu.php main.php footer.php TTL 5s No caching TTL 10s
TTL 2s

sub vcl_recv { set req.http.Surrogate-‐Capability=”key=ESI/ 1.0"; }
sub vcl_fetch { if(beresp.http.Surrogate-‐Control~"ESI/1.0") { unset beresp.http.Surrogate-‐Control; set beresp.do_esi=true; } }

h&ps://github.com/taf2/nginx-‐esi Not oﬃcial Haven’t tested it yet Edge Side
Includes

Edge Side Includes Server Side Includes

<html>! <body>! <table>! <tr>! <td colspan="2" >! ! </td>! </tr>! <tr>! <td>  </td>! <td>  </td>! </tr> ! <tr>! <td colspan="2" > !  ! ! </td>! </tr> ! </table>! </body>! </html> Highest TTL is used

server { … ssi on; …
}

SSL support

Varnish doesn’t support SSL

Nginx supports SSL

server { listen 443; ssl on;
ssl_certificate /path/to/ssl.crt; ssl_certificate_key /path/to/ssl.key; server_name hostname.dev; access_log /var/log/nginx/access.log; error_log /var/log/nginx/error.log; ! location / { proxy_pass http://localhost:80; proxy_set_header X-‐Real-‐IP $remote_addr; proxy_cache proxy-‐cache; proxy_cache_key "$scheme://$host$request_uri"; proxy_cache_valid 200 302 1h; } } SSL

What about Varnish v4? https://www.varnish-cache.org/content/varnish-cache-400

✓Streaming objects ✓Background fetch ✓New varnishlog with improved filtering ✓VCL
syntax change (BC breaks) Varnish v4

Who won the battle? Varnish Nginx

And on that bombshell ...

Thanks again guys!
