Zesty journey to adopt Apache Iceberg

Our journey to adopt Apache Iceberg on AWS

Transcript

1. Zesty journey to adopt Apache Iceberg Eran Levy @levyeran
2. Eran Levy Data & Platform Group Lead @Zesty https://levyeran.medium.com/ @levyeran Introduction @levyeran
3. How can you utilize Iceberg on AWS with no Spark expertise in your team and going serverless all-in? WIFM @levyeran
4. Build Fast. Stay Cost Efficient.
5. 300% Customer Growth YoY $120M Raised Since 2020 406% Employee Growth YoY
6. The Goal - Database Explorer @levyeran
7. Medallion Architecture @levyeran
8. Why did we choose Apache Iceberg? @levyeran - Open data table format widely adopted and integrates well with AWS ecosystem (Glue catalog, Athena, etc). - Table evolution - Mainly schema and partitioning layout (particularly hidden partitioning). - Integrating well with many processing engines - supports our long term strategy in leveraging the right technologies to their needs.
9. While there are many cool things in Iceberg, There are some challenges… The main challenge is: Maintenance @levyeran
10. Architecture @levyeran
11. Table Configuration @levyeran - Iceberg v2 table, created with AWS Glue catalog and Athena engine version 3 (preferably a dedicated WorkGroup). - Parquet with ZSTD compression - this is the data format we adopted across our data lake. - Snapshot age - 2 days (default is 5 days). Athena allows predefined key-value TBLPROPERTIES only. Glue catalog - Metadata tracking
12. @levyeran Table Maintenance Main maintenance operations for optimizing Iceberg table in Athena: 1. VACUUM 2. OPTIMIZE
13. Table Maintenance @levyeran We are updating our Iceberg table frequently (every minute, 5GBs, insert/update, 50 columns, 500M records)… So we wanted to VACUUM but were hitting the Athena query limits:
14. Table Maintenance @levyeran Increasing the limits didn’t help much because we were hitting another : ICEBERG_VACUUM_MORE_RUNS_NEEDED: Removed 1000 files in this round of vacuum, but there are more files remaining. Please run another VACUUM command to process the remaining files You can try overcome it by running AWS Step Functions in a loop like this suggested solution Missing several runs and you will face another challenge as increasing Athena query limits won’t help you much this time…
15. Table Maintenance @levyeran Same for OPTIMIZE but were hitting the partitions limitation:
16. Glue Spark ETL Jobs @levyeran In order to solve it for the long run, we decided to utilize the Iceberg Spark procedures in order to perform our maintenance jobs: - Glue 3.0 and later supports Iceberg integration out of the box - Ad-hoc & built-in scheduler - Integrated with CI/CD pipeline using AWS SDKs Nice AWS blog and an AWS Glue Developer Guide are available
17. Glue Spark Maintenance Jobs @levyeran Basically the most important steps to perform are: - Register the Iceberg connector for AWS Glue (Not required for Glue 4.0) - Create ETL Job or a Jupyter Notebook - Provide the necessary configuration to the Spark job/notebook such as: –datalake-formats and –conf NOTE: these actions automatically inject the Iceberg Spark SQL extension
18. @levyeran Full example is available here: https://github.com/eran-levy/iceberg-journey-session-examples Glue Spark Maintenance Jobs
19. Glue Spark Maintenance Jobs @levyeran Main maintenance procedures: • Expire_snapshots • Rewrite_data_files • Remove_orphan_files • Rewrite_manifests
20. QuickSight for Apache Iceberg metadata analysis @levyeran Not Optimized Optimized!
21. Snapshots after optimization @levyeran
22. Snapshots after expiration procedure @levyeran
23. QuickSight for Apache Iceberg data files analysis @levyeran
24. Summary • Apache Iceberg is well adopted in the industry and specifically in the AWS ecosystem. • It's not persist & forget -> take Iceberg maintenance into consideration while choosing your architecture. • Keep monitoring -> your partitioning strategy might change, file size, query latencies, etc. as there are many moving parts that can impact your performance.
25. Next Steps • Choosing our data lakehouse platform • Maintenance is an issue as we scale to additional use cases with larger data volume - we might need a managed service to assist us here
