ApacheCon Europe Big Data 2016 – Parquet Format in Practice & Detail

Apache Parquet is among the most commonly used column-oriented data formats in the big data processing space. It leverages various techniques to store data in a CPU- and I/O-efficient way. Furthermore, it has the capabilities to push-down analytical queries on the data to the I/O layer to avoid the loading of nonrelevant data chunks. With various Java and a C++ implementation, Parquet is also the perfect choice to exchange data between different technology stacks.

As part of this talk, a general introduction to the format and its techniques will be given. Their benefits and some of the inner workings will be explained to give a better understanding how Parquet achieves its performance. At the end, benchmarks comparing the new C++ & Python implementation with other formats will be shown.

Uwe L. Korn

November 16, 2016
Tweet

More Decks by Uwe L. Korn

Other Decks in Programming

Transcript

  1. What is Parquet? How is it so efficient? Why should

    I actually use it? Parquet in Practice & Detail
  2. About me • Data Scientist at Blue Yonder (@BlueYonderTech) •

    Committer to Apache {Arrow, Parquet} • Work in Python, Cython, C++11 and SQL xhochy [email protected]
  3. Agenda Origin and Use Case Parquet under the bonnet Python

    & C++ The Community and its neighbours
  4. About Parquet 1. Columnar on-disk storage format 2. Started in

    fall 2012 by Cloudera & Twitter 3. July 2013: 1.0 release 4. top-level Apache project 5. Fall 2016: Python & C++ support 6. State of the art format in the Hadoop ecosystem • often used as the default I/O option
  5. Why use Parquet? 1. Columnar format
 —> vectorized operations 2.

    Efficient encodings and compressions
 —> small size without the need for a fat CPU 3. Query push-down
 —> bring computation to the I/O layer 4. Language independent format
 —> libs in Java / Scala / C++ / Python /…
  6. Who uses Parquet? • Query Engines • Hive • Impala

    • Drill • Presto • … • Frameworks • Spark • MapReduce • … • Pandas
  7. • More than a flat table! • Structure borrowed from

    Dremel paper • https://blog.twitter.com/2013/dremel-made-simple-with-parquet Nested data Document DocId Links Name Backward Forward Language Url Code Country Columns: docid links.backward links.forward name.language.code name.language.country name.url
  8. Encodings • Know the data • Exploit the knowledge •

    Cheaper than universal compression • Example dataset: • NYC TLC Trip Record data for January 2016 • 1629 MiB as CSV • columns: bool(1), datetime(2), float(12), int(4) • Source: http://www.nyc.gov/html/tlc/html/about/ trip_record_data.shtml
  9. Encodings — PLAIN • Simply write the binary representation to

    disk • Simple to read & write • Performance limited by I/O throughput • —> 1499 MiB
  10. Encodings — RLE & Bit Packing • bit-packing: only use

    the necessary bit • RunLengthEncoding: 378 times „12“ • hybrid: dynamically choose the best • Used for Definition & Repetition levels
  11. Encodings — Dictionary • PLAIN_DICTIONARY / RLE_DICTIONARY • every value

    is assigned a code • Dictionary: store a map of code —> value • Data: store only codes, use RLE on that • —> 329 MiB (22%)
  12. Compression 1. Shrink data size independent of its content 2.

    More CPU intensive than encoding 3. encoding+compression performs better than compression alone with less CPU cost 4. LZO, Snappy, GZIP, Brotli
 —> If in doubt: use Snappy 5. GZIP: 174 MiB (11%)
 Snappy: 216 MiB (14 %)
  13. Query pushdown 1. Only load used data 1. skip columns

    that are not needed 2. skip (chunks of) rows that not relevant 2. saves I/O load as the data is not transferred 3. saves CPU as the data is not decoded
  14. Competitors (Python) • HDF5 • binary (with schema) • fast,

    just not with strings • not a first-class citizen in the Hadoop ecosystem • msgpack • fast but unstable • CSV • The universal standard. • row-based • schema-less
  15. C++ 1. General purpose read & write of Parquet •

    data structure independent • pluggable interfaces (allocator, I/O, …) 2. Routines to read into specific data structures • Apache Arrow • …
  16. Get involved! 1. Mailinglist: [email protected] 2. Website: https://parquet.apache.org/ 3. Or

    directly start contributing by grabbing an issue on https://issues.apache.org/jira/browse/PARQUET 4. Slack: https://parquet-slack-invite.herokuapp.com/
