Build Your Own Color Pallet

カラーパレットをコードから生成して、InterfaceBuilder上での色指定を統一する話

Transcript

1. B U I L D Y O U R O W N C O L O R PA L L E T S Yu s e i N i s h i y a m a ( C o o k p a d i n c . ) O c t o b e r 2 2 , 2 0 1 4 @ p o t a t o t i p s # 1 0
2. W H O A M I ? • Mobile app engineer • Develop apps for iOS • Regulate “Auto Layout” day after day… :’-( • I’m interested in • Metal (new graphics API of Apple) • Functional programming (with Swift) • Reactive programming (Reactive Cocoa) Twitter: @yuseinishiyama
 GitHub: https://github.com/yuseinishiyama
 Blog: yuseinishiyama.com
 (not so active)
3. O O P S …
 self.view.backgroundColor = [UIColor colorWithRed:250.f/255.f
 green:250.f/255.f
 blue:245.f/255.f alpha:1.f];

 _someLabel.textColor = [UIColor colorWithRed:181.f/255.f green:177.f/255.f blue:169.f/255.f alpha:1.f];
 It’s so hard to maintain.
4. W E N E E D M O R E U N I F I E D WAY @implementation UIColor (CookpadUIColors) ! + (UIColor *)cui_greenColor { return [self cui_greenColorWithAlpha:1.0]; } ! + (UIColor *)cui_greenColorWithAlpha:
 (CGFloat)alpha { return [self colorWithRed:0.545
 green:0.678
 blue:0.0
 alpha:alpha]; }
5. There still remain the problem
6. I R E C O M M E N D Y O U T O …
7. B U I L D Y O U R O W N C O L O R PA L L E T S
8. Y O U C A N F I N D I T AT
 < ~ / L i b r a r y / C o l o r s / * . c l r >
9. I S T H I S F I N I S H E D ? • Once created, you can’t modify it • GUI Only • There is no way to automate
10. NSColorList
11. – M A C D E V E L O P E R L I B R A RY “An NSColorList object is an ordered list of NSColor objects, …The NSColorPanel list mode color picker uses instances of NSColorList to represent any lists of colors that come with the system, as well as any lists created by the user. An application can use NSColorList to manage document-specific color lists.”
12. R E A D A N D W R I T E • Read from a file




 • Install a color list
 NSColorList *colorList =
 [[NSColorList alloc] initWithName:colorListName
 fromFile:self.inputURL.path];


 [colorList writeToFile:nil];


13. NSURL *inputURL =
 [NSURL fileURLWithPath:@“~/Library/Colors/potatotips.clr"];
 NSString *colorListName =
 [[inputURL lastPathComponent] stringByDeletingPathExtension];
 NSColorList *colorList =
 [[NSColorList alloc] initWithName:colorListName
 fromFile:self.inputURL.path]; ! NSColor *hogeColor =
 [NSColor colorWithRed:0.5 green:0.5 blue:0.5 alpha:1];
 ! [colorList insertColor:hogeColor key:@"HogeColor" atIndex:0];
 [colorList writeToFile:nil]; E D I TA B L E
14. < s q u a re / o b j c - c o d e g e n u t i l s > • Generate codes from .crl files • https://github.com/square/objc-codegenutils/tree/ master/colordump • brew install objc-codegenutils
15. Thank you
