1. Getting Started with Vector Cloud native meetup tokyo #9 This document includes the work that is distributed in the Apache License 2.0
2. profile: name: Wataru Matsui org: [ Z Lab, 3bi.tech ] twitter: @watawuwu
3. • What’s Vector? • Usage • VS ... • Roadmap • Conclusions Agenda
4. What’s Vector？ https://vector.dev
5. Logs, Metrics & Events Router Is like Fluentd?
6. Developed by Timber.io https://timber.io
7. Feature • Log, Metrics, or Events • Agent Or Service • Fast • Correct • Clear Guarantee • Vendor Neutral • Easy To Deploy • Hot Reload
8. • Fluentd • Fluent Bit • Filebeat • Logstash Similar tool
9. 　Summary ©timber.io
10. ©timber.io
11. Topologies: Distributed ©timber.io
12. Topologies: Centralized ©timber.io
13. Topologies: Stream-Based ©timber.io
14. How to use Vector
15. Source types • file • statsd • syslog • tcp • vector • stdin(debug)
16. [sources.my_file_source_id]

 # REQUIRED - General
 type = "file" # must be: "file"
 include = ["/var/log/nginx/*.log"]
 exclude = [""]
 Source config
17. [sources.my_tcp_source_id]

 # REQUIRED - General
 type = "tcp" # must be: "tcp"
 address = ["0.0.0.0:9000"]
 Source config
18. Sink types • aws ◦ cloudwatch_logs ◦ kinesis_streams ◦ s3 • elasticsearch • http • kafka • prometheus • splunk_hec • tcp • vector • console • blackhole(/dev/null)
19. [sinks.my_tcp_sink_id]

 # REQUIRED - General
 type = "tcp" # must be: "tcp"
 input = ["my_tcp_source_id"]
 address = ["92.12.333.224:5000"]

 # OPTIONAL - Requests
 encoding = "json" # default, enum: "json", "text"

 Sinks config
20. [sinks.my_s3_sink_id]

 # REQUIRED - General
 type = "s3" # must be: "s3"
 input = ["my_file_source_id"]
 bucket = "my-bucket"
 region = "ap-northeast-1"
 encoding = "ndjson" # enum: "ndjson", "text"

 # OPTIONAL - Requests
 key_prefix = "date=%F/" # default Sinks config
21. [sinks.my_prometheus_sink_id]

 # REQUIRED - General
 type = "prometheus" # must be: "prometheus"
 input = ["my_log2metrics_source_id"]
 address = "0.0.0.0:9598" Sinks config
22. Transform types • Fileld ◦ add_fields ◦ remove_filed ◦ filed_filter • Paser ◦ grok_parser ◦ json_parser ◦ regex_parser ◦ tokenizer • log_to_metric • sampler • lua • vector • console • blackhole(/dev/null)
23. [transforms.my_regex_trans_id]

 # REQUIRED - General
 type = "regex_parser" # must be: "regex_parser"
 inputs = ["my_file_source_id"]
 regex = "^(?P<host>[\\w\\.]+) - (?P<user>[\\w]+) (?P<bytes_in>[\\d]+) \\[(?P<timestamp>.*)\\] \"(? P<method>[\\w]+) (?P<path>.*)\" (?P<status>[\\d]+) (?P<bytes_out>[\\d]+)$"

 # OPTIONAL - Types
 [transforms.my_regex_trans_id.types]
 status = "int"
 method = "string"
 bytes_in = "int"
 bytes_out = "int" Transform config
24. [transforms.my_prometheus_trans_id]

 # REQUIRED - General
 type = "log_to_metric" # must be: "log_to_metric"
 inputs = ["my_file_source_id"]

 # OPTIONAL - Types
 [[transforms.my_regex_trans_id.metrics]]
 type = "counter" # enum: "counter", "gauge"
 field = "duration"
 increment_by_value = false
 name = "duration_total"
 labels = {host = "${HOSTNAME}", region = "us-east-1"}

 Transform config
25. [sources.logs]
 type = 'file'
 include = ['/var/log/*.log']

 [transforms.tokenizer]
 inputs = ['logs']
 type = 'tokenizer'
 field_names = ["timestamp", "level", "message"]

 [transforms.sampler]
 inputs = ['tokenizer']
 type = 'sampler'
 hash_field = 'request_id'
 rate = 10
 [sinks.search]
 inputs = ['sampler']
 type = 'elasticsearch'
 host = '123.123.123.123:5000'

 [sinks.backup]
 inputs = ['tokenizer']
 type = 's3'
 region = 'ap-northeast-1'
 bucket = 'log-backup'
 key_prefix = 'date=%F'
 Vector config
26. VS
27.
 Vector
 FluentBit
 FluentD
 File to TCP
 76.7MiB/s
 35MiB/s
 26.1MiB/s
 Regex Parsing
 13.2MiB/s
 20.5MiB/s
 2.6MiB/s
 TCP to HTTP
 26.7MiB/s
 19.6MiB/s
 <1MiB/s
 Performance report by Timber.io
28.
 Vector
 FluentBit
 FluentD
 Memory
 188.1MiB
 370MiB
 890MiB
 CPU
 1.51 1m avg
 0.56 1m avg
 0.57 1m avg
 Performance report by Timber.io
29. Don't trust the reports. Measure, Measure, Measure!
30. Measure using GKE • Kubernetes: v1.13.7 • Node x4 ◦ 4 CPU ◦ 3.6 GB Memory ◦ 100 GB Storage(Standard) • Manifests ◦ https://github.com/watawuwu/vector-test
31. Memory Usage Mem usage is low Why fluent-bit uses memory? Vector
 26 MiB/s
 Fluent Bit
 1.091 GiB/s
 Fluentd
 92 MiB/s

32. CPU Usage CPU usage is high Vector
 1.84 core
 Fluent Bit
 0.26 core
 Fluentd
 1.25 core

33. IO Throughput Vector Fluentd Fluentd Bit Throughput is low Error in the test method？ Vector
 9.39 MiB/s
 Fluent Bit
 8.26 MiB/s
 Fluentd
 13.64 MiB/s

34. Roadmap
35. Roadmap • v0.4 Schemas(current) • v0.5 Stream Consumers • v0.6 Columnar Writing • v0.7 CLI • v0.8 Wire Level Tailing • v1.0 Stable => 2019/12 Release!!
36. Conclusions
37. ADAPT
 TRIAL
 ASSESS
 HOLD
 watawuwu’s TECH RADAR
38. Thanks! Kubernetes, Cloud Native zlab.co.jp
